Zte ZXHN H108L User manual

ZXHNH108L
WirelessADSLRouter
MaintenanceManual
Version1.0
ZTE CORPORATION
ZTE Plaza, Keji Road South,
Hi-Tech Industrial Park,
Nanshan District, Shenzhen,
P. R. China
518057
Tel: [phone] 800-9830-9830
Fax: [phone]
URL: http://support.zte.com.cn
E-mail: [email protected]

LEGAL INFORMATION
Copyright © 2010 ZTE CORPORATION.
The contents of this document are protected by copyright laws and international
treaties. Any reproduction or distribution of this document or any portion of this
document, in any form by any means, without the prior written consent of ZTE
CORPORATION is prohibited. Additionally, the contents of this document are
protected by contractual confidentiality obligations.
All company, brand and product names are trade or service marks, or registered
trade or service marks, of ZTE CORPORATION or of their respective owners.
This document is provided “as is”, and all express, implied, or statutory warranties,
representations or conditions are disclaimed, including without limitation any implied
warranty of merchantability, fitness for a particular purpose, title or non-
infringement. ZTE CORPORATION and its licensors shall not be liable for damages
resulting from the use of or reliance on the information contained herein.
ZTE CORPORATION or its licensors may have current or pending intellectual property
rights or applications covering the subject matter of this document. Except as
expressly provided in any written license between ZTE CORPORATION and its
licensee, the user of this document shall not acquire any license to the subject matter
herein.
The contents of this document and all policies of ZTE CORPORATION, including
without limitation policies related to support or training are subject to change without
notice.
Revision History
Date
Revision No.
Serial No.
Description
2012/10/19
R1.0
First Edition
2013/4/7
R2.0
Second Edition

ZTE CORPORATION
Values Your Comments & Suggestions!
Your opinion is of great value and will help us improve the quality of our
product documentation and offer better services to our customers.
Please fill out the following questionnaire and fax to:
(86) 755-26772236;
Or mail to:
Publications R&D Department, ZTE CORPORATION, ZTE Plaza, A Wing, Keji
Road South, Hi-Tech Industrial Park, Shenzhen, P. R. China 518057.
Thank you for your cooperation!

Your Comments & Suggestions
Document
Name
ZXHN H108L Wireless ADSL Router Maintenance Manual
Product
Version
V4.0
Document
Revision Number
R1.0
Equipment Installation Date
Your
evaluation of
this
document
Presentation:
(Introductions, Procedures, Illustrations, Completeness, Level of Detail, Organization,
Appearance)
Good Fair Average Poor Bad N/A
Accessibility:
(Contents, Index, Headings, Numbering, Glossary)
Good Fair Average Poor Bad N/A
Intelligibility:
(Language, Vocabulary, Readability & Clarity, Technical Accuracy, Content)
Good Fair Average Poor Bad N/A
Your
suggestions
for
improvement
of this
document
Please check the suggestions which you feel can improve this
documentation:
Improve the overview/introduction Make it more concise/brief
Improve the Contents Add more step-by-step procedures
Improve the organization Add more troubleshooting information
Include more figures Make it less technical
Add more examples Add more/better quick reference aids
Add more detail Improve the index
Other suggestions
____________________________________________________________________
____________________________________________________________________
____________________________________________________________________
____________________________________________________________________
____________________________________________________________________
# Please feel free to write any comments on an attached sheet.
If you wish to be contacted regarding your comments, please complete the following:
Name
Company
Postcode
Address
Telephone
E-mail

Contents
About this Manual.................................................................. i
Purpose of this Manual .......................................................................i
Typographical Conventions .................................................................i
Mouse Operation Conventions............................................................ii
Safety Signs .....................................................................................ii
How to Get in Touch......................................................................... iii
Customer Support.......................................................................................iii
Documentation Support...............................................................................iii
Safety Instructions ............................................................... v
During Installation and Application......................................................v
For Service...................................................................................... vi
Chapter 1 .............................................................................. 1
Introduction.......................................................................... 1
Overview......................................................................................... 1
Packing List ..................................................................................... 2
Front Panel...................................................................................... 2
Rear Panel....................................................................................... 4
System Requirements ...................................................................... 5
Chapter 2 .............................................................................. 7
Product Installation.............................................................. 7
Hardware Connections...................................................................... 7
Default Settings............................................................................... 8

Computer Configuration ....................................................................9
Checking Computer Configuration................................................................ 9
Configuring TCP/IP ..................................................................................... 9
Chapter 3............................................................................ 11
Configuration Page Login................................................... 11
Chapter 4............................................................................ 14
Interface Setup .................................................................. 14
Internet Configuration.....................................................................15
ATM VC and ATM Qos ................................................................................15
Encapsulation............................................................................................17
LAN Configuration...........................................................................23
Router Local IP..........................................................................................24
DHCP .......................................................................................................25
Wireless Configuration.....................................................................27
Access Point Settings .................................................................................28
Multiple SSIDs Settings..............................................................................29
Wireless MAC Address Filter........................................................................30
Chapter 5............................................................................ 31
Advanced Setup ................................................................. 31
Firewall Configuration......................................................................31
Routing Configuration......................................................................32
NAT Configuration...........................................................................33
QoS Configuration...........................................................................34
VLAN Configuration.........................................................................36
ADSL Configuration.........................................................................39
Chapter 6............................................................................ 40
Access Management........................................................... 40

ACL Management............................................................................40
Filter Management ..........................................................................41
UPnP Management..........................................................................43
DDNS Management.........................................................................44
CWMP Management........................................................................45
Chapter 7 ............................................................................ 49
Maintenance .......................................................................49
Administration Configuration............................................................49
Time Zone Configuration .................................................................50
Firmware Configuration ...................................................................50
SysRestart Configuration .................................................................51
Diagnostics.....................................................................................52
Chapter 8 ............................................................................ 53
Status..................................................................................53
Device Information..........................................................................53
System Log ....................................................................................54
Statistics ........................................................................................55
Chapter 9 ............................................................................ 58
Troubleshooting..................................................................58
Appendix A..........................................................................60
Technical Specifications .....................................................60
Appendix B..........................................................................62
Computer WLAN Configuration ..........................................62
Appendix C.......................................................................... 69
PPPoE Dial-up Configuration ..............................................69

Figures................................................................................ 73
Tables ................................................................................. 75

Confidential and Proprietary Information of ZTE CORPORATION i
AboutthisManual
Purpose of this Manual
This manual provides the basic information of installing, configuring
and maintaining the ZXHN H108L wireless ADSL router. It is a
reference book for the maintenance personnel of ZXHN H108L.
Typographical Conventions
ZTE documents employ the following typographical conventions.
TABLE 1TYPOGR APHICAL CONVENTION S
Typeface
Meaning
Italics
References to other guides and documents; parameter values
“Quotes”
Links on screens
Bold
Menus, menu options, input fields, radio button names, check boxes,
drop-down lists, dialog box names, window names
CAPS
Keys on the keyboard and buttons on screens and company name
Constant
w i d t h
Text that you type, program code, files and directory names, and
function names
[ ]
Optional parameters
{ }
Mandatory parameters
|
Select one of the parameters that are delimited by it
Note: Provides additional information about a certain topic
Checkpoint: Indicates that a particular step needs to be checked
before proceeding further
Tip: Indicates a suggestion or hint to make things easier or more
productive for the reader

ZXHN H108L Wireless ADSL Router Maintenance Manual
ii Confidential and Proprietary Information of ZTE CORPORATION
Mouse Operation Conventions
TABLE 2MOUSE OPERATIO N CONVENTIONS
Typeface
Meaning
Click
Refers to clicking the primary mouse button (usually the left
mouse button) once.
Double-click
Refers to quickly clicking the primary mouse button (usually the
left mouse button) twice.
Right-click
Refers to clicking the secondary mouse button (usually the right
mouse button) once.
Drag
Refers to pressing and holding a mouse button and moving the
mouse.
Safety Signs
TABLE 3SAFETY SIGNS
Safety Signs
Meaning
Danger: Indicates an imminently hazardous situation, which if not
avoided, will result in death or serious injury. This signal word
should be limited to only extreme situations.
Warning: Indicates a potentially hazardous situation, which if not
avoided, could result in death or serious injury.
Caution: Indicates a potentially hazardous situation, which if not
avoided, could result in minor or moderate injury. It may also be
used to alert against unsafe practices.
Erosion: Beware of erosion.
Electric shock: There is a risk of electric shock.
Electrostatic: The device may be sensitive to static electricity.
Microwave: Beware of strong electromagnetic field.

About this Manual
Confidential and Proprietary Information of ZTE CORPORATION iii
Safety Signs
Meaning
Laser: Beware of strong laser beam.
No flammables: No flammables can be stored.
No touching: Do not touch.
No smoking: Smoking is forbidden.
How to Get in Touch
The following sections provide information on how to obtain support
for the documentation and the software.
Customer Support
If you have problems, questions, comments, or suggestions
regarding your product, contact us by e-mail at
[email protected]. You can also call our customer support center
at (86) 755 26771900 and (86) 800-9830-9830.
Documentation Support
ZTE welcomes your comments and suggestions on the quality and
usefulness of this document. For further questions, comments, or
suggestions on the documentation, you can contact us by e-mail at
[email protected]; or you can fax your comments and suggestions to
(86) 755 26772236. You can also explore our website at
http://support.zte.com.cn, which contains various interesting
subjects like documentation, knowledge base, forum and service
request.

ZXHN H108L Wireless ADSL Router Maintenance Manual
iv Confidential and Proprietary Information of ZTE CORPORATION
This page is intentionally blank.

Confidential and Proprietary Information of ZTE CORPORATION v
SafetyInstructions
During Installation and Application
Use the power adapter included in this package. Another power
adaptor may make the device unable to work normally or even
damage the device.
Note the power load of the power socket and power cable. The
overloading power socket or broken power cable may cause an
electric shock or fire. It is recommended to check the cables
periodically and replace the broken one immediately.
Appropriate space for heat dissipation is required to prevent the
product from overheating.
Keep the product away from heat sources. Avoid the product
working in high-temperature or direct sunshine environment.
Keep the product away from moisture or vapor. Do not splash any
fluid on the product.
Do not place the product on any unstable surface.
Power off and unplug this product carefully when it is not in use or
before cleaning. Pay attention to the high temperature on the
transformer’s surface.
Wait for at least 15 seconds between powering off and re-powering
on of the device.
Do not block the heat dissipation opening of the product.
When the product is not used for a long period of time, unplug the
power cord.

ZXHN H108L Wireless ADSL Router Maintenance Manual
vi Confidential and Proprietary Information of ZTE CORPORATION
For Service
Do not attempt to disassemble, repair, or open this product, which
will lose the warranty services. Contact qualified service personnel in
case of problems, especially under the following conditions:
The power socket or cable is damaged.
Liquid is splashed into the product.
The product is exposed to rain or water.
The product does not work normally when the operating
instructions are followed.
The product is dropped or struck, causing the product damaged.

Confidential and Proprietary Information of ZTE CORPORATION 1
C ha p te r 1
Introduction
This chapter gives an overview of the ZXHN H108L router, presents
the packing list, introduces the front and rear panels and system
requirements.
Overview
ZXHN H108L is a home and SOHO oriented wireless broadband
router integrating ADSL, AP and LAN Switch. It provides triple-play
services such as Internet data, voice access, and video access. ZXHN
H108L provides priority access for different services with
sophisticated ATM-based and IP-based QoS to meet different
requirements for high-speed Internet access, IPTV Video on Demand
(VoD), live-broadcast access and voice access. Wireless encryption
and built-in firewall prevent unauthorized users from accessing the
network, ensuring the security of legal users accessing the wired and
wireless networks. ZXHN H108L supports TR-069 protocols for
allowing overall remote network management.
Note: ZTE CORPORATION reserves the right to modify
technical specifications in this manual without any
notification in advance.

ZXHN H108L Wireless ADSL Router Maintenance Manual
2 Confidential and Proprietary Information of ZTE CORPORATION
Packing List
The package box for a ZXHN H108L includes the following
components, as shown in Table 4.
TABLE 4PACKING LIST
Component
Quantity
ZXV10 ZXHN H108L Wireless ADSL Router
1
External splitter
1
Power adapter
1
Telephone line
2
Straight-through Ethernet cable
1
ZXHN H108L Wireless ADSL Router User Manual
1
Note: Components actually delivered depend on the
service provider. If any component is missing or
damaged, immediately contact the service provider.
Please keep the packing box and components well in case
of replacement.
Front Panel
FIGURE 1FRONT PANEL

Chapter 1 - Introduction
Confidential and Proprietary Information of ZTE CORPORATION 3
There are 9 indicators on the front panel of a ZXHN H108L indicating
the running status of the device, as shown in Figure 1. These
indicators are described in Table 5.
TABLE 5DESCRIPTIONS FOR THE INDICATORS
Indicator
Color
Description
Power
Red/Gr
een
Red:Indicates the power is just connected or it fails to
function.
Green Steady on: Indicates switched on.
Off: Indicates the power has not been connected
DSL
Green
Steady on: Indicates a DSL link is established.
Slow flashing: Indicates no signal is detected.
Fast flashing: Indicates the MODEM is activating.
Internet
Green
Steady on: Indicates operating in Route mode and
the ADSL link is established. The IP data packet of
the MODEM can be transmitted and received normally
(For example, the embedded PPPOE link is
established and a dynamic IP address is allocated.).
Flashing: Indicates operating in Route mode and
there is data packet passing the MODEM.
Off: Indicates operating in Bridge mode or ADSL link
is not established.
Red
Red on: Device attempted to become IP
connected and failed (no DHCP response, no
PPPoE response, PPPoE authentication failed,
no IP address from IPCP, etc.)
LAN1
LAN2
LAN3
LAN4
Green
Steady on: Indicates a LAN connection is established.
Flashing: Indicates data is transmitting.
Off: Indicates the LAN connection has not been
established
WLAN
Green
Steady on: Indicates the wireless module is on.
Flashing: Indicates wireless data is transmitting.
Off: Indicates the wireless module is off.

ZXHN H108L Wireless ADSL Router Maintenance Manual
4 Confidential and Proprietary Information of ZTE CORPORATION
Indicator
Color
Description
WPS
Green
Steady on: The wireless terminal device is connected
through WPS successfully. The indicator turns off five
minutes later.
Slowly Flashing: The wireless terminal device is
connecting with H108L through WPS.
Fast Flashing: There is error when the wireless
terminal is connecting to H108L through WPS
Off: There is no wireless terminal device connected to
H108L through WPS or the wireless terminal device
has been connected to H108L through WPS for more
than five minutes.
Rear Panel
FIGURE 2REAR PANEL
There are 10 ports and buttons on the rear panel of a ZXHN H108L,
as shown in Figure 2. These ports and buttons are described in Table
6.
TABLE 6DESCRI PTIONS FOR THE PORTS AND BUTTONS
Identification
Description
DSL
RJ-11 connection interface: The equipment is connected to the
ADSL line or splitter via the telephone line.
LAN1-LAN4
RJ-45 connection interface: Connect it to the PC computer or other
network devices using the network cable.
WPS
WPS switch

Chapter 1 - Introduction
Confidential and Proprietary Information of ZTE CORPORATION 5
Identification
Description
WLAN
To turn on / off the Wi-Fi.
Reset
This button is on the bottom of modem. In the power-on state,
you can restore the system to the default configuration by using a
thin needle to press this slot for three seconds or for three
executive times.
ON/OFF
To turn on / off the power.
POWER
Power interface. Connect it to the power adapter.
System Requirements
System requirements for the ZXHN H108L router are as follows:
The user has already subscribed the ADSL or Ethernet service. The
service provider shall provide at least one legal IP address
(allocated either statically or dynamically).
One or more PCs with 10/100M Ethernet Network Interface Card
(NIC).
For wireless access, an external or built-in 802.11b/g/n wireless
adapter is required.
To configure the system via the web page based interface, you
need a web browser such as Internet Explorer (version6.0 or
above), Netscape (version4.7 or above).

ZXHN H108L Wireless ADSL Router Maintenance Manual
6 Confidential and Proprietary Information of ZTE CORPORATION
This page is intentionally blank.
