Zuden ZDAS-16CA-8 Operating instructions

Page1of 16
SYSTEM-ZDAS-16CA-8 PROGRAMMING GUIDE
Thanks for choosing ZDAS-16CA-8 Multi-Function Alarm Control Panel. We suggest you
reading carefully this guide, operating this system strictly on the standard procedure.
ZDAS-16CA-8 is suitable for most circumstances and convenient for using, no matter its
appearance, function, or operation. We hope this Guide could answer most of your questions
when using the system.
Chapter 1 Summarize
1.1 Summarize
ZDAS-16CA-8 takes advanced microprocessor as its core technology. So it has the
advantages of high integration, very good stability, flexible function and convenient use.
1.2 Attentions before usage
Get approval from local police office before presetting the police phone number as
the alarm phone number
Ensure the system is in the correct installation, then connectAC power supply with
the panel
Only suitable for DC 12V 7AH sealed lead rechargeable storage battery, be cautious
to connect red positive line with positive terminal （+）, and black negative line with
negative terminal（－）. The incorrect connection will cause damage of main panel.
Rechargeable current ≤1.5A
Avoid metal parts or hand contact to the electronic parts on the circuit when install
the lines.
Must use 2.7K resistor short unused wired zone
Mark wires to avoid miss-connection when using too many wired zones
Cut off all AC power supply, battery and telephone line before maintenance
Short JP1 when reset main panel
The 1.00MM copper-core wire from the keypad to alarm panel is up to 150 meters, 4
keypads can be connected in series
1.3 Features
High speed digital communication, compatible ADEMCO4+2, CID digital
communication protocol；Send alarm signal to alarm center.
Different programmable settings, such as alarm sounds, zone types, recording,
monitoring, remote controlling, telephone number, phone line Check, and etc.
Compatible with wired and wireless function
1 group 6 bits primary passwords, 15 groups subsidiary setting passwords are
available to improve security;

ZDAS-16CA-8 Wireless & Wired Security Alarm System
Page 2of 16
6 groups of phone number and 2 group alarm center phone number could be set.
When the alarm activated, it could repeat dialing the numbers.
7 ARM modes: EXITARM, BOUNDARYARM, single zone ARM, delayARM, remote
ARM, compel ARM and preset time ARM.
5 DISARM modes: single zone DISARM, keypad password DISARM, long distance
DISARM, remote setting DISARM, DISARM when connecting alarm.
5 zone modes: instant zone, delay zone, 24 hours zone, BOUNDARY zone and
BY-PASS zone
Remote control function, external monitor, monitoring from long-distance.
Built-in voice module, 10~20seconds record, voice alarm function
Set the alarm delay time and siren yelp time
Search record of emergency
Remote controller can be used to set alarm, DIS-ALARM, emergency alarm and
other operation.
Operate from keypad, easily and convenient.
Phone line malfunction indication function: system will alarm when phone line is cut
off or short.
The alarm dialling is in priority
Backup DC 12V 7AH sealed lead rechargeable battery support work whenAC
power cut off
“Watch dog” function, to avoid system down.
Remark: Pull out the jumper head in JP1 of the main panel after finishing program
for the main panel, which can prevent other person operate the main panel and
improve security.
1.4 Configuration
Main configuration：
Metal box 1pc (transformer and main board inside)
Keypad (LED display) 1pc
User Manual 1pc
Accessories bag 1pc phone line, 1 bag terminal resistors, 1 pc antenna for
Wireless receiver parts
1.5 Main specification
Power supply：AC220V+10%
Stand by consume current: ≤100mA
Power: <1.5W
Alarm output current: <650mA, 12V
Output voltage: DC12V～15V
Wireless receiver frequency: 315MHZ
Working temperature: -10 ～55°C
Working Humidity: 40 ～70%
Weight: 2.5 kgs
Metal box size 255mm×235mm×70mm
Keypad size: 159mm×138mm×33mm

ZDAS-16CA-8 Wireless & Wired Security Alarm System
Page 3of 16
Chapter 2 Installation and Connection
2.1 Wiring Diagram
2.1.1 Wiring diagram on main board
* Indicator LED will light on when working normally, Z1-Z8 means 1－8 zone
2.1.2 Wiring diagram of expand board (Only for ZDAS-16CA)
* Z9－Z16 means 9－16 zone

ZDAS-16CA-8 Wireless & Wired Security Alarm System
Page 4of 16
2.1.3 8 zones Expand module
Z9－Z16 means 9－16 zone
It must connect 2.7K resistors, connecting is the same with Z1-Z8.
Set expanded 9-16 wired zones ON/OFF.
1. Insert the expand module (Factory setting: inserted)
2. Start setting mode (see 4.3)
3. Format: 79 + status + F4 (Confirm key)
Status: 09-16 zones OFF
1 9-16 zones ON
(Factory setting: 0)
4. Exit (see 4.4)
2.2 Connection of Power supply
2.2.1 AC connection terminal AC1, AC2: AC power is supplied after transformation by transformer.
The transformer is fixed on the metal box of main panel. (Spec: inputAC220Vt two red wires,
output 16.5V two black wires). When connecting directly with exterior wire, or using 3-outlets
connector plug into the transformer input terminal (to avoid interrupt of AC current, please
don’t use 2-outlets plug), the transformer output terminal will connect AC terminal AC1 and
AC2.
2.2.2 DC12V storage battery connection: To keep the system working when AC power supply
interrupted, we use high quality sealed lead-acid for backup use. Right connection: the red
wire of the main board should be connected to the positive of battery; the black wire should
be connected to negative of battery.
2.3 Connection of Wired Detector
2.3.1 Connection of signal wires of wired detector:
There are two connection way to avoid destroy,
cutoff or short connection, see picture:
1, NORMALLY CLOSED: Connecting a 2.7K EOL
resistor in series to the terminal detector of the
loop of each zone; connecting the other end of the
resistor to the signal terminal of wired detector.
One of the signal connector should be soldered to
the resistor. The other end of resistor should be
connected to the other signal terminal of detector
by corresponding signal wire, and then connected
to GND port of main board.
2, NOMORMALLY OPENED: Connecting a 2.7K resistor in parallel connection to the terminal
detector of the loop of each zone.
2.3.2 Connection of power of Wired Detector: connecting the POSITIVE of wired detector to the
AUX port; connecting the negative to the ground wire GND port.
2.3.3 Connecting the unused zones with 2.7K EOL resistor connection, otherwise the
corresponding indicator light will keep lighting, so that theARM cannot be set.
Note: Mark wires to avoid miss-connection when using too many wired zones!
2.4 Connection of Siren/Speaker
Siren/Speaker Port: The POSITIVE of siren/speaker should be connected to BELL end of
alarm panel; the negative should be connected to the ground wire GND.

ZDAS-16CA-8 Wireless & Wired Security Alarm System
Page 5of 16
2.5 Connection of Telephone Line
Phone Communication Port: The exterior line should be connected to LIN1, LIN2. TEL1 and
TEL2 should be connected to the telephone.
2.6 Connection of Sound Monitor
Sound Monitor Port: The signal line should be connected to MIK, the POSITIVE should be
connected to MIK+, and the negative should be connected to ground wire GND.
2.7 Installation of Keypad
2.7.1 Opening of the keypad: use a screwdriver to open the plastic hole of the back cover upside
of the keypad, fix the back cover to the wall.
2.7.2 Connection of the keypad: SEE PICTURE, use a copper core wire to connect the keypad
with connector of alarm panel. The wire from the keypad to alarm panel is up to 150 meters, 4
keypads can be connected in series; to avoid destroy of keypad, the anti temper port could be
connected to the terminal of alarm panel.
2.7.3 Keypad address: no address jumper means NO. 1 keypad; insert address jumper “1” means
NO. 2 keypad; insert address jumper “2” means NO. 3 keypad; insert address jumper “3”
means NO. 4 keypad.
2.7.4 Close the cover when the connection is finished.
2.8 Installation when wireless zones only.
If you want to use the wireless zones only, connect the wired zones with the ground wire
GND by 2.7K resistors in short connection, keep close of the wired zones.
Note: Make sure the all the connections are correct before power up the alarm panel.
Avoiding any opposite connection, short connection of power line, siren line and detector
power line; avoiding short connection of detector power line and signal line!

ZDAS-16CA-8 Wireless & Wired Security Alarm System
Page 6of 16
Chapter 3 System Operation
3.1 System Operation
The main usage of the alarm system is to prevent illegal intruder from your home or office, or
to get help in emergency. When you are leaving your office or home, make sure all the
windows and doors are locked. Set ARM by remote controller or keypad of alarm panel, the
system will be in guard status. If any alarm zone is activated, the following circs will happen:
3.1.1 Siren/speaker will yelp loudly if set siren/speaker alarm.
3.1.2 Alarm panel will send the alarm to control center by dialing the telephone if set to send the
alarm to control center.
3.1.3 If telephone number is set, it will dial the preset numbers in turn. You can take the following
action. (See 3.7)
3.1.4 Zone LED will keep light on in alarm status till someone comes
When you go to office or home, use remote controller, or press user password to disarm,
System alarm status will stop, the indicated LED of the zone activated will keep light on till
eliminate its alarm memory.
3.2 Operation of Remote Controller
Remote Controller ：
- DIS-ALARM：
：：
：DIS-ALARM Status
- Set ARM：
：：
：Leaving-taking ARM
- BOUNDARY (Home) ARM BOUNDARY Zone Alarm Status
- Emergency: Emergency when a Hijack or emergency call
DIS-ALARM：
：：
：Fast press twice “ ” Key of the Remote Controller
Note: BOUNDARY ARM will be in effect only when BOUNDARY Zone was set.
3.3 Keypad Panel and Indicator LED Light
Parts Name:
①---Function Indicator Light ②---ARM Zone Light ③---Emergency Alarm Key ④
---Number Key ⑤---Shortcut Key (F
1
-ARM; F
2
-Home ARM; F
3
-Detector Low Vol. Quirt/Pause;
F
4
-Confirm Key)

ZDAS-16CA-8 Wireless & Wired Security Alarm System
Page 7of 16
Specification:
①. Function Indicator Light (Power Supply, Communication, Signal, Status, ARM, Setting):
Indicate the working status of the System
Function
Indicator Light
Display
Explanation
ON AC Power Supply Normal
Power Supply OFF AC Power Supply Break
ON Dialing and Sending message Status, the line is busy
Communication
OFF The line is not in use
ON Signal from Wireless Detector Received
Signal OFF Normal Status
ON Keypad Work Normal
Status OFF Keypad Failure
ON EXIT/BOUNDARY/Single Zone ARM
ARM OFF No ARM Status
ON Programming Status
Setting OFF Normal Status
②
②②
②ARM Zone Light(1, 2, 3……14, 15, 16): Display the Zone Status
Display Explanation
ON ARM Activated; Training Status: ready to Train wireless detector
Zone
Fast Flash Indicate the Zone disarm after Alarm, but the alarm status hasn’t
been stopped
Slow Flash Wired Zone bad connection, the Circuit is Open or Short
ON 1 Second Zones in Effect on ARM Status
③
③③
③Emergency Key (A, B, C) 24 hours Alarm Status, can be defined as Fire Alarm, Robbery
Alarm, Emergency Call; No indicator, no sound; If telephone preset, it will dial the number
when alarm, the communication light will on
④
④④
④Number Key (1, 2, 3, 4, 5, 6, 7, 8, 9, *, 0, ＃
＃＃
＃): For password and program set use.
⑤
⑤⑤
⑤Shortcut Key (F1, F2, F3, F4) Easy to operation with One Key. F1-EXIT ARM;
F2-BOUNDARY ARM (Only when BOUNDARY Zones Preset); F3-Detector Low Vol. Quirt/Pause;
F4-Confirm Key).
⑥
⑥⑥
⑥Buzzer Sound; In this operation, different buzzer sound indicates different meaning
Sound Explanation
Long Sound Remote Control or Keypad operation received
Long Sound 1
minute Sound Zone Alarm
Short Sound Sound per press the Keypad
Short Sound 3
times Invalid Input or Remote Control Operation
Short Sound
per 3 seconds Delay ARM Started, or Delay Zone Activated, the sound will end till the delay time is over
3.4 ARM
3.4.1 Leaving-Taking ARM; All zones (except Side Road or Screened Zones) start Alarm
Status, if any zone activated, the system will take relevant reaction, dial the alarm center,
preset telephone number or local police.
1, Operation: Press F
1
Key or press “ ” on remote controller to setARM.

ZDAS-16CA-8 Wireless & Wired Security Alarm System
Page 8of 16
2, If ARM succeed, the Buzzer will long sound,ARM Indicate Light on; if the system refuse the
dictate, the Buzzer will short sound 3 times, it means that some zone is activated or set
ARM already. If there is an ARM Delay, the system will exit the delay after inputs ARM
dictate, and short sound every second till delay time is over. It will not send alarm before
some zone is activated.
3.4.2 BOUNDARY ARM, also named Home ARM, when a BOUNDARYARM start
alarm status , non-BOUNDARYARM will not activate alarm(BOUNDARY Zone Set: See 4.9)
1, Operation: Press F
2
Shortcut Key or press “ ”on Remote Controller to set ARM.
Zone Number: 1~16
2, ARM Succeed, the Buzzer will long sound, ARM Indicate Light on; if the system refuse the
dictate, the Buzzer will short sound 3 times, it means no BOUNDARY Zone preset or it is
already Set BOUNDARYARM.
3.4.3 Set Single Zone ARM/ DIS- ARM: the specified zone start alarm status, the other
zones will not activated alarm
1, Set single zone ARM: Zone Number(01～16)＋F
1
Shortcut Key,
2, Set single zone DIS-ARM: Password(6 bits)+Zone Number(01～16)＋F
4
Shortcut Key,
3, ARM Succeed, the Buzzer will long sound,ARM Indicate Light on; if the system refuse the
dictate, the Buzzer will short sound 3 times, it means no BOUNDARY Zone preset or it is
already Set BOUNDARYARM or Single Zone ARM.
Note: BOUNDARY ARM and Single Zone ARM can be set at the same time or turn
to EXIT ARM if ARM not stopped.
3.4.4 Fast alarmed set，
，，
，it can be operated direct without time late
Operating: press *+F1
3.5 Disarm: DIS-ALARM Status
1, Operation: User Password (6 bits)＋F4 (Confirm Key) (Factory User Password:
123456), or press “ ” key on Remote Controller
2, Disarm Succeed: ARM Indicate Light off; if the system refuse the dictate, the Buzzer will
short sound 3 times, or system has already disarm.
3.6 Remote Control
When System is set as Remote Controllable (See 4.18), (Factory Setting: non-remote control),
use a preset phone or mobile phone to remote control the alarm system to ARM, disarm, record
or monitor.
3.6.1 Remote ARM, Disarm: Use a preset phone or mobile to remote control the alarm
system toARM or DIS-ALARM status
1, Ring time when dial the preset phone: (Set in Step 4.19, Factory Setting is 8 times);
2, Input User Password: after a long sound “Di”, input “1” to startARM Status, if succeed, you
will hear a long sound ”Di”, if not succeed, you will hear 3 short sound; input “2” to disarm, if
succeed, you will hear a long sound ”Di”, if not succeed, you will hear 3 short sound.
3.6.2 Remote Monitor: Use a preset phone or mobile to remote monitor the alarm system
1, In remote control status, Input User Password: after a long sound “Di”, press “3”, then you
can hear the instant sound from the zones; press “8” to return
3.6.3 Remote control to siren: In remote control status, press “4” start siren, press “5” exit
siren.
3.7 Set Receive Alarm by Telephone ; when the alarm connected the phone or mobile
phone, user can remote control the system by phone or mobile phone. There are two methods
as following
1, Factory Setting: after connected, press “1” key on telephone or mobile phone to receive
recorded sound, after twice record and indicate sound “Du”, input user password to
Remote Control Sta
tus ; press “2” hang up to Confirm; press “3” start directly Remote
Control S tatus.
2, It can also be programmed as: (See 4.21) after connected, receive alarm sound after 5

ZDAS-16CA-8 Wireless & Wired Security Alarm System
Page 9of 16
seconds, or press “1”, after twice record and indicate sound “Du”, input user password to
Remote Control Sta tus.
Remote Control Status: Start control status by using telephone or mobile phone,
press “1” to start ARM; press “2” to disarm, (stop dial the following phone number after
ARM started): press “3” to start Remote Monitor; press “8” to Return, end monitor; press
“7” change recorded sound, press “8” exit; press “4” start siren, press “5” exit siren and
return to control status.
Note: Remote Control Status is different from the “1”, “2”, “3” of Hang on
operation.
3.8 Record: Record the alarm sound by another preset phone or mobile phone
1, Keypad Input ①Installer password (Factory Setting: 666666)＋F4 (Confirm Key) Start Set
Status; ②71＋1＋F4 Start Remote Control Status; ③72＋2＋F4 Set Ring time as 2 times;
④* # Exit Set Status
2, Record: Use another preset phone or mobile phone dial the number of alarm system, after
connected, input user password (Factory Setting: 123456)＋7 Speak what you want to
record to telephone or mobile phone, the recorded sound will play automatically after 12
seconds; or press “8” exit recording, press “6” play the finished recorded sound, then
hang-up If need new record sound, press “8” exit, then press “7” stat new record sound till
it’s satisfied.
3, Confirm Record: Dial the phone or mobile phone, after connected, press “1” key on the
phone or mobile phone to receive sound, if need revised please repeat above Step 2.
4, After record, keypad input ①installer password (Factory setting: 666666)＋F4 (Confirm
Key) Start Set Status; ②71＋0＋F4 End Remote Control Status; ③72＋8＋F4 Set Ring
time as 8 times; ④* # Exit Set Status
3.9 DIS-ALARM: Stop the flashing status of alarm indicator LED light , stop sending
messages to alarm center
1, Operation: User password (6bits)＋F4 (Confirm Key) (User Password Factory Setting:
123456)
Or press “ ” key on the remote controller to DIS-ALARM
2, If succeed, the buzzer will long sound “Di”, the indicator LED light off.
3.10 BY-PASS Zone Checking:
Press F1, the zone LED will light on no more than 1 second
Chapter 4 System Settings
4.1 Basic Settings from Factory
Name Factory Settings
1.
Installer Password 666666
2.
First Group User Password 123456
3.
Zone Type 0---instant sound alarm zone
4.
Play recorded sound automatically 0---inefficacy
5.
AC power supply cut-off check 0---no check
6.
Keypad line cut-off check 0---no check
7.
Keypad anti-disassembly check 0---no check

ZDAS-16CA-8 Wireless & Wired Security Alarm System
Page 10of 16
8.
Telephone Remote Control 0---inefficacy
9.
Ring Times 0---8 times
10.
ARM Delay 0---no delay
11.
Telephone Line Check No Check
12.
Code CID code
13.
Telephone alarm control Input ”1” set, input ”2” stop, input “3” monitor
14.
Recorder No recorder
15.
Wireless Detector No wireless detector
16.
User Number FFFF
17.
Alarm Telephone Number No number
Note：
：：
：Function 1 to 12 will resume factory settings after “RESET”.
4.2 Reset
1. Operation; 951753082＋F4 (Confirm Key);
2. Status: Reset successfully, the buzzer will sound a long” Di”, all the indicator LED will light
on for 1 second.
Note: JP1 jumper on the main board must be short connected before this operation.
4.3 Set Mode
1. Operation: Installer password (6 bits) + F4 (Confirm Key) (Factory Installer Password is
666666)
2. Status: Set successfully, the buzzer will sound a long”Di”; the Indicator LED will light on.
4.4 Exit Set Mode
1. Operation: * #
2. Status: Exit successfully; the buzzer will sound a long “Di”, the indicator LED will light off.
Or exit automatically after 30 seconds, the buzzer will not sound, indicator LED off.
4.5 Change Installer Password
1. Start Set Mode (see 4.3);
2. Format: 30＋New Installer Password (6 bits) ＋F4 (Confirm Key);
3. Exit set mode (see 4.4) after the buzzer sound a long “Di”; new installer password is in effect.
4.6 Change User Password
Start primary password setting status: Primary password (6 bits) + 08 + F4 (Confirm Key), the
setting indicates LED on, (Primary password: 123456)
1. Set new Primary Password: in primary password setting status, input new primary
password (6 bits) + F4 (Confirm Key); after the buzzer sound a long “Di”, the indicator LED
light off, new primary password is in effect
2. Start Subsidiary Password setting status: in primary password setting status, input
subsidiary password number (2 bits) + F4 (Confirm Key), (subsidiary password number:
01-15, means 15 groups subsidiary password number sequent number), the corresponding
LED light on.
Input subsidiary password (4 bits) + F4 (Confirm Key), after the buzzer sound a long “Di”,
new subsidiary password is in effect.
3. Delete subsidiary password: in Subsidiary Password setting status, press F4 to delete

ZDAS-16CA-8 Wireless & Wired Security Alarm System
Page 11of 16
subsidiary password.
4. Exit setting status (see 4.4), or automatically exit after 30 seconds.
(Factory User Password: Group 1: 123456);
4.7 Wireless Detector Learning Function
1. Start Set Mode (see 4.3);
2. Choose the zone to learn: 20＋zone number (2 bits)＋F4 (Confirm Key), Zone number is from
01~16. Corresponding zone LED will light on.
3. Wireless Coding: Press remote controller or activate the detector to send signal to alarm
panel. The signal LED will light up when the alarm panel received the signal, indicating the
alarm panel the signal and saved to the specified zone.
Note: The indicate LED will not light off when the detector stopped sending signal.
4. Press F4 (Confirm Key), the corresponding zone LED light off, the learning is finished.
5. Repeat Step 2-4 to learn more remote controller or wireless detector.
6. Exit Set Mode (see 4.4);
7. When detectors activated, alarm panel will know distinguish the activated detector from
others automatically.
Note: If a remote controller or detector has learned a zone, when it learns a new zone,
the system will delete its memory firstly.
4.8 Delete Wireless Detectors
1. Start Set Mode (see 4.3 );
2. Delete a remote controller or a wireless detector: 21＋zone number (2 bits) ＋F4 (Confirm
Key);
3. Repeat Step 2 to delete more remote controllers or wireless detectors;
4. Exit Set Mode (see 4.4).
5. If the deleted detectors activated, the indicate LED on main board will not light on.
4.9 Set Zone Type and Output Alarm Sound
1. Start Set Mode (see 4.3 );
2. Operation: Zone number (2 bits) ＋Zone type (1 bit) ＋Siren status (1 bit) ＋F4 (Confirm
Key);
Zone number: 01～16, indicates 1～
～～
～16 zone.
Zone Type: 0Instant Alarm zone; 1 Fire Alarm Zone; 2Emergency Zone; 3Delay Alarm
zone; 4 24 Hours Alarm zone; 5Test Zone (at least 2 times alarm in 30
seconds); 6Gas Alarm Zone; 7 BY-PASS zone, 8Door-alarm Zone (in ARM
status if door is open, in DIS-ALARM status if door is closed); factory setting is
“0”
“1”, “2”, “4”, “6” zone type is 24-hourARM status, not effected byARM or DIS-ARM
operation.
Siren/Speaker status: 0 alarm without sound; 1sound alarm, factory setting is “1”
3. Set compelled ARM: Password + * + F1
4. Exit Set Mode (see 4.4)
4.10 Door Bell function set
1 . Start in setting status (see 4.3)
2. Format: 60 + Zone Number (1 bit) + 0/1 + F4 (confirm key), zone number: 1—8
Status: “1” open, “0” close (Factory setting is “0”);when Zone indicate Door-ALARM Zone,
ring function is normal in DIS-ARM status, defense zone is normal inARM status.

ZDAS-16CA-8 Wireless & Wired Security Alarm System
Page 12of 16
3. Exit Set Mode (see 4.4)
4.11 Set User Code (Alarm Center Code)
Alarm allocates 4 bits network code:
1. Start Set Mode (see 4.3 )
2. Set User Code: 31＋4 bits User code＋F4 (Confirm Key);
Delete User Code: 32＋F4 (Confirm Key);
3. Exit Set Mode (see 4.4 ).
Note: Don’t use this operation if without network.
4.12 Set ARM Delay Time
1. Start Set Mode (see 4.3 )
2. Format: 40＋Time(3 bits)＋F4 (Confirm Key) Time: 000～255 seconds
3. Exit Set Mode (see 4.4 ).
4.13 Set ALARM Time
1. Start Set Mode (see 4.3 )
2. Format: 43＋Time(3 bits)＋F4 (Confirm Key) Time: 000～255 seconds
3. Exit Set Mode (see 4.4 ).
4.14 Set Telephone Number
1. Start Set Mode (see 4.3 )
2. Set Telephone Number
Set telephone number in alarm center: 50＋Telephone Number＋F4 (Confirm Key)
(Don’t use this operation if without network.)
Delete telephone number in alarm center: 50＋F4 (Confirm Key)
Set 1
st
group telephone number: 51＋Telephone＋ F4 (Confirm Key)
Delete 1
st
group telephone number: 51＋F4 (Confirm Key)
Set 2
nd
group telephone number: 52＋Telephone＋ F4 (Confirm Key)
Delete 2
nd
group telephone number: 52＋F4 (Confirm Key)
Set 3
rd
group telephone number: 53＋Telephone＋ F4 (Confirm Key)
Delete 3
rd
group telephone number: 53＋F4 (Confirm Key)
Set 4
th
group telephone number: 54＋Telephone＋ F4 (Confirm Key)
Delete 4
th
group telephone number: 54＋F4 (Confirm Key)
Set 5
th
group telephone number: 55＋Telephone＋ F4 (Confirm Key)
Delete 5
th
group telephone number: 55＋F4 (Confirm Key)
Set 6
th
group telephone number: 56＋Telephone＋ F4 (Confirm Key)
Delete 6
th
group telephone number: 56＋F4 (Confirm Key)
3. Press *# exit Set Mode.
4. Messages sent to alarm center: System restart, Set, Reset, ARM, Disarm,ABC Key
EmergencyAlarm, Alarm from zones, Recovery
5. Messages sent when dialing 1st to 6th group telephone number:ABC EmergencyAlarm,
(Automatically stop dialing after confirmed the telephone response);ARM zone alarm,
(Automatically stop dialing after disarm)
6, Set telephone number as need; when you need to connect internal line to external line, press
F3, then input the other telephone number
Note: 1) Delete old numbers before set new telephone number
2) Dial order:Alarm Center, 1
st
Group Number, 2
nd
Group Number, 3
rd
Group Number, 4
th
Group Number, 5
th
Group Number , 6
th
Group Number, if without response, it will keep
dialing 10 rounds;
3) Alarm center number will not be stopped if the 5 groups number ARM stopped, it will
stop dialing the 6 groups number.
7. 7 lines telephone format: 77+ line number (0---6) + F4 (line number correspond 50-56)

ZDAS-16CA-8 Wireless & Wired Security Alarm System
Page 13of 16
Format: “0” “1” “2” is center (“0” CID, “1” available program 4+2), “5” user’s
telephone
Format after reset: “0” is 0, “1--6” line is 5
4.15 Set Report Output
1. Start Set Mode (see 4.3 )
2. Format: 33＋0/1 (ARM or DIS-ARM)+ 0/1 (program) + 0/1 (low battery) + 0/1 (main panel
start)＋F4 (Factory setting is “1”)
34＋0/1 (AC power cut-off)+ 0/1 (AC power recovery) + 00＋F4 (Factory setting is “1”)
Status: 0 No Output, 1 Output (Factory Setting: “1” Output)
3. Exit Set Mode (see 4.4 ).
4.16 Set ABC Key
1. Start Set Mode (see 4.3 )
2. Format: 67＋0/1＋F4 (Confirm Key) ( 0 means closeABC key, 1 means start ABC key.
Factory setting is 1)
3. Exit Set Mode (see 4.4 ).
4.17 Set Alarm Center Communication Protocol
1. Start Set Mode (see 4.3 )
2. Format: 77＋status (0/1/2) ＋F4 (Confirm Key)
status: 0Contact ID Code 1Programmable 4＋2 Code (See 4.20) 2ADEMOCO 4+2 code
3. Exit Set Mode (see4.4).
4.18 Remote Control On/Off
1. Start Set Mode (see 4.3 )
2. Format: 71＋status＋F4 (Confirm Key)
Status; 0 Remote Control Off, 1 Remote Control On (Factory Setting: 0 Off)
3. Exit Set Mode (see 4.4 ).
4.19 Set Remote Control Ring Time
1. Start Set Mode (see 4.3 )
2. Format; 72＋Time＋F4 (Confirm Key)
Time; 1～9 times (Factory Setting: 8times)
3. Exit Set Mode (see 4.4 ).
4.20 Remote Telephone no password Option
1. Start Set Mode (see 4.3 )
2. Format: 74＋status ＋F4 (Confirm Key)
Status: 0need user password 1no need user password (factory setting is “0”)
3. Exit Set Mode (see4.4).
4.21 Choose Alarm Receiver Control
1. Start Set Mode (see 4.3 )
2. Format; 75＋status＋F4 (Confirm Key)
status; 0 Press “1” to receive Alarm sound
1 Receive Alarm sound after 5 seconds, or press “1”
3. Exit Set Mode (see 4.4 ).
4.22 Set Telephone Line Check On/Off
1. Start Set Mode (see 4.3 )
2. Format; 78＋Status＋F4 (Confirm Key)
status; 0 No Check, 1 Check Alarm when the line was cut (Factory Setting: “0” No
Check)
3. Exit Set Mode (see
4.4 ).

ZDAS-16CA-8 Wireless & Wired Security Alarm System
Page 14of 16
4.23 Set Programmable4+2 Code for different Alarm Center
1. Start Set Mode (see 4.3 )
8+ (01~16) +alarm code (2 bits) + F4 Set Zone number 1~16
8+ 17+set alarm code (2 bits) + F4 SetAlarm Code
8+ 18+set alarm code (2 bits) + F4 Set Dis-alarm Code
8+ 19+set alarm code (2 bits) + F4 Set A key Code
8+ 20+set alarm code (2 bits) + F4 Set B key Code
8+ 21+set alarm code (2 bits) + F4 Set C key Code
8+ 22+set alarm code (2 bits) + F4 Set Self-inspection Code
8+ 23+set alarm code (2 bits) + F4 Set Programmed Code
8+ 24+set alarm code (2 bits) + F4 Set System Startup Code
8+ 25+set alarm code (2 bits) + F4 SetAC power recovery Code
8+ 26+set alarm code (2 bits) + F4 SetAC power break Code
8+ 27+set alarm code (2 bits) + F4 Set Low Battery Code
4.24 Set interval time of Self-inspection Report
1. Start Set Mode (see 4.3 )
2. Press 41+ time (2 bits)+F4 (confirm key)
Time: 00~99 (hours) 00 means cancel report of Self-inspection
4.25 Set Alarm Sound time
1. Start Set Mode (see 4.3 )
2. Press 42+ time (2 bits)+F4 (confirm key)
Time: 00~40 Alarm time= (00~40) x 30 second
Factory setting: 02 means 02 x 30=60seconds
4.26 Set Boundary Arm
1. Start Set Mode (see 4.3 )
2. Format: 19 + Zone number (2 bits) + 0/1(0 close, 1 open) + F4. Zone number: 01—16.
4.27 Single Zone Arm/Disarm
1-16 zones can be set as Single Zone arm/disarm.
Single ZoneArm: Zone number (01-16) +F1;
Single Zone Disarm: user password (6 bits) +zone number (01-16) +F4.
4.28 Set Siren Sound of Alarm and Dis-Alarm
1. Start Set Mode (see 4.3 )
2. Press 61+0/1+F4 (1. alarm-1 sound; dis-alarm-2 sounds, 0. no sound; reset won’t
change setting)
4.29 Preset Time Arm/Disarm Setting
1. Preset time: Set Mode (see 4.3 ) + 4+5+ hour (2 bits) +minute (2 bits) +F4
2, Preset time arm: Set Mode (see 4.3 ) + 4+6+ hour (2 bits) +minute (2 bits) +F4.
2. Preset time disarm: Set Mode (see 4.3 ) + 4+7+ hour (2 bits) +minute (2 bits) +F4.
4.30 Set Time-modify Coefficient
1. Start Set Mode (see 4.3 )
2. Format: 48 + Coefficient (00--99) + F4
Status: reset coefficient is 50 make coefficient up if time is too quick (more than 50)
Make coefficient down if time is too slow (less than 50)
Conversion Table
16 Bit Number Related Key
A *0
B *1
C *2
D *3
E *4
F *5

ZDAS-16CA-8 Wireless & Wired Security Alarm System
Page 15of 16
3. Exit Set Mode (see 4.4 ).
4.31 Set Alarm if AC power down
1. Start Set Mode (see 4.3 )
2. Press 62+0/1+F4 (1. sound, 0. no sound. Factory setting: 0)
3. Exit Set Mode (see 4.4 ).
4.32 Set Open/Close of Anti Jumper alarm function
1. Start Set Mode (see 4.3 )
2. Press 63+0/1+F4 (1. open, 0. close. Factory Setting: 0)
3. Exit Set Mode (see 4.4 ).
4.33 Set Keypad wire break inspection
1. Start Set Mode (see 4.3 )
2. Press 64+0/1+F4 (1. open, 0. close. Factory Setting: 0)
3. Exit Set Mode (see 4.4 ).
4.34 Set Center Precision
1. Start Set Mode (see 4.3 )
2. Press 65+ precision value (1 bit) +F4 (value: 0~9. Factory Setting: 6)
3. Exit Set Mode (see 4.4 ).
4.35 Set Center Signal Time
1. Start Set Mode (see 4.3 )
2. Press 66+ Signal time (1 bit) +F4 (time: 0~9. Factory Setting: 6)
3. Exit Set Mode (see 4.4 ).
4.36 Set Dial Rounds
1. Start Set Mode (see 4.3 )
2. Press 69+ dial rounds (1-9) +F4 (Factory Setting: 9)
3. Exit Set Mode (see 4.4 ).
4.37 Record Search
Operating: press 99+2+F4 into the searching emergence
Record method ：+※ ※ + +※ ※ + +※ ※ + + + +※ ※ ※ ※
（number)（days) （things）（hour）（minute）
Things: 01-16 is zone alarm, 30 is alarm set, 40 is alarm deserved
Under the searching emergence, press F3 to find the next one
