Sensor-Operated Lavatory Faucets with Smart Connected Features
®
NOTICE: READ ENTIRE MANUAL PRIOR TO INSTALLING PRODUCT.
Z6955-XL-S-W2 Z6950-XL-S-W2
Connected Aqua-FIT®
Battery Powered Faucets
Serio SeriesTM -W2
Installation, Operation, Maintenance
and Parts Manual
Patented and Patents Pending
WARNING: Cancer and Reproducve Harm - www.P65Warnings.ca.gov
ADVERTENCIA: Cáncer y daño reproducvo - www.P65Warnings.ca.gov
AVERTISSEMENT: Cancer et eets néfastes sur la reproducon - www.P65Warnings.ca.gov

FV723 Rev. B 7/29/2020
Page 1
Z6950-XL-S-W2Z6955-XL-S-W2
Monitor
Monitor
Spout Assembly
Aerator
and Key
Electronics Box
with Solenoid
Filter
Shank
Mounting Kit
Base Gasket
Widespread
Mounting Kit
Aerator
and Key
Electronics Box
with Solenoid
Filter
Shank
Mounting Kit
Base Gasket
Spout Assembly
Required Tools
Batteries
Batteries
Serio Series™ Package Contents
Adjustable Wrench
(Optional)
Smooth Jawed
Wrench
Phillips Head
Screwdriver
3/32”, M3
Allen Wrenches

FV723 Rev. B 7/29/2020
Page 2
Overview:
Zurn connected faucets transmit data 24/7 to the Zurn plumbSMART™* web portal and mobile app. Proactively
monitor your faucet activations and water usage, receive real-time alerts for preset high and low usage parameters,
and access system data for trends and predictive maintenance anytime and anywhere.
AquaSense® sensor faucets are ideal for high-use applications where durability and hands-free operation are
necessary. ADA compliant, battery powered, polished chrome-plated cast brass sensor faucet with infrared proximity
sensor for retrot and new construction. Unit is furnished with a standard 1.5 GPM aerator, and mounting hardware.
Zurn Lead Free products (-XL) are designed and manufactured to comply with Section 1417 of the Safe Drinking
Water Act (SDWA) which mandates the weighted average lead content of no more than 0.25% of the wetted surface
NOTE: The information in this manual is subject to change at any time without notice. Installations may be performed
at di󰀨erent times of construction by di󰀨erent individuals. For this reason, these instructions should be left on-site
with the facility or maintenance manager.
Specications:
Voltage: 6 VDC Series [4 “AA” (Alkaline or Lithium)] for faucet
4 VDC Series [4 “AA” (Alkaline or Lithium)] for monitor
Sensor Range: Self-calibrated, dependent upon sink depth and nish.
Operating Water Pressure: 10-125 psi
Operational Water Temperature: 33°F to 140°F (1°C to 60°C)
Aerator: 1.5 GPM Vandal-Resistant (Standard)
Important Safety Information:
• Installer is responsible for ensuring the product is installed and conforms to all plumbing codes and ordinances.
• Do not convert or modify this Zurn product yourself. All warranties will be voided.
• Water supply lines must be sized according to building designer in order to provide adequate water supply
for each xture.
• Flush all water lines prior to making connections.
Be sure the water supply is turned on and the sink/lavatory/basin is clear from any objects upon making the sensor to electronics
connection initiating the self-calibration feature. The sink must be clear of any and all objects and water supply is turned on in order
to calibrate appropriately (calibration time approx 30-60sec) (the system will perform both a wet & dry calibration).
Prior to Installation:
Before installing your Zurn®Aqua-FIT®Faucet: the items listed below should already be installed on site.
• Lavatory/sink
• Drain Line
• Hot and cold water supply line or pre-tempered water supply line.
• Installer/Servicer should not use pipe dope or teon/thread sealant anywhere on this product, most notably threads
and connection points.
• Care shall be taken when installing this product to prevent marring of any exposed or decorative surfaces.

FV723 Rev. B 7/29/2020
Page 3
2. Install spout to sink using spout base gasket, plastic mounting
washer, star washer and mounting nut.
Note: Faucet location needs to be within 3 feet radius above
electrical outlet for ACA congurations.
NOTE: Before installation, turn o󰀨 water supplies to existing faucet and remove faucet if replacing an existing device.
Clean the faucet basin and clear away debris. Flush all supply lines before connecting the faucet. Failure to do so
may result in debris clogging the inlets and/or internal control and mixing valve
1. Carefully screw aerator into spout using included tool.
Take care to not pinch blue o-ring
3. Ensure that slot in plastic washer is facing forward.
Sensor cable should not pass through plastic mounting washer.
4. Assemble the electronics module
Do not connect the electronic module to spout
Spout Installation Instructions

FV723 Rev. B 7/29/2020
Page 4
Cable to
monitor
1. Install Monitor on wall surface within 2 feet radius of faucet
with dry wall anchors & screws or doubled sided VHB tape
2. Loosen lid screw with supplied 3mm Allen wrench. Open lid
and install supplied batteries. Close lid and tighten lid screw.
5. Tighten electronics module assembly to shank and connect
water line(s).
3. Connect monitor and electronics module assembly.
Do not connect cable to the spout at this step.
4. Open battery module using supplied 3mm Allen wrench and
install supplied batteries in the electronics module. Then close
and tighten battery module..
Use AA Lithium Batteries or AA Alkaline batteries, but do not mix Lithium
with Alkaline.
Use AA Lithium Batteries or AA Alkaline batteries, but do not mix Lithium
with Alkaline.
Monitor & Electronic Module Installation Instructions

FV723 Rev. B 7/29/2020
Page 5
6. Ensure that sink is clear of tools/debris and is in normal
operating condition, and remove protective lm from sensor lens
has been removed.
7. Turn on water supply(ies).
*** Water supply must be turned on in order for sensor to perform
wet calibration step ***
8. Connect sensor cable from spout to monitor.
Do not engage the sensor after the connection is made. The
sensor will perform automatic calibration, which could ow
water for up to 60 seconds. Once the ow of water has stopped,
the faucet is calibrated and can be used normally.
• Do not use any abrasive or chemical cleaners to clean the faucets.
• If abrasives or chemicals are used it can lead to dulling of luster, attacking of chrome plating or decorative nishes.
• ONLY use mildly warm soapy water, and then wipe the device dry with a clean/soft towel or cloth.
• Upon cleaning other areas of the restroom be sure the sensor lenses are protected from other cleaning chemicals/solvents to prevent
potential damages to the sensor and/or electronics.
Care and Cleaning Instructions

Gateway Instruction
Register in plumbSMART
You can request your Ethernet or LTE gateway by visiting
Zurn.com/plumbsmart-gateway-request
or call Zurn Customer Care at 1-844-987-6737
Step 1. Request Gateway:
Step 2. Cabling, Powering and Connecting Your Device:
1. Connect one end of the RJ45 Ethernet cable (supplied) to the
gateway’s Ethernet port and plug the cable’s other end into the
nearest wall port of the building’s Ethernet network.
2. Connect the power supply to the power jack.
3. Wait for status LED to go from ON to double ash every second,
the LoRa LED to turn ON solid, and the cell LED (if LTE enabled)
to ash once every 3 seconds. Should take around 1-2 minutes
depending on location. Your gateway is now ready to transmit
data from your Zurn connected product.
4. Zurn Gateways have been set to DHCP by default. Please
consult local IT support for possible additional access
requirements for your network.
Step 3. Determining general Location for the Zurn Gateway:
• Select a location central to all devices to be connected to this
gateway. Place the gateway as high as possible, such as near
the top of a wall.
• Avoid obstructions. Thick walls and reective surfaces, such
as metal, weaken the signal between the gateway and other
devices.
• The LoRa antenna is an omni-directional antenna, but for best
results, mount the device so the LoRa antenna is in a vertical
position near the top of a wall. We recommend conducting a site
survey to test the signal strength in di󰀨erent locations before
you mount the device.
Step 4. Mounting the Zurn Gateway:
The device ships with a mounting bracket. You will also need:
• Four #6 screws with anchors
• Screwdriver
• Drill
1. Determine where you want to mount the device.
2. Mark where you want the screws to go.
3. Drill holes for the screws and insert anchors.
4. Place the mounting bracket and secure it with screws.
5. Attach the device to the bracket and rotate to lock into place.
NOTE: Instructions below are duplicated from registration card supplied with monitor
1. Install Zurn Connected Product(s)
2. Install Zurn Gateway per the Gateway Instructions Manual
3. Request plumbSMART Administrator Account at 844-987-6737
4. Zurn creates your Enterprise Account for you! (You will be required to identify your building location, number of oors, and number
of rooms.)
5. Log in to plumbsmart.zurn.com
6. Register each Connected Product in plumbSMART (Watch How-To Videos to Get Started. Located in the support section inside the
portal.)
7. Now, Relax. You’re Connected.

FV723 Rev. B 7/29/2020
Page 7
1 2 3 4 5 6 7 8
ON
OFF
To adjust features from default conguration, you must remove the
battery tray. Once battery tray is removed you will see the switches.
Purge Features:
The purge switches can be congured for 4 modes of operation: Disabled (standard conguration), 12 hour, 24 hours, or 48 hours.
Purge water ow duration is 2 minutes. Note: Purge activation occurs every switch selected time (0,12, 24, or 48 hours) after last
activation.
Flow Time:
There are 6 optional time congurations: 30 seconds (standard), 5s, 10s, 15s, 60s, & “Less Time-out”. The “Less Time-out” option
actually ceases water ow (turns o󰀨) after 20 minutes to limit chance of water damage in the event a sink drain becomes blocked .
Sensing Mode (DEFAULT):
During this mode the valve will shut o󰀨 after hands are removed. If hands are not removed the time out delay will turn o󰀨 the faucet (ex:
standard conguration is 30 seconds)) (See Sensing & Metering Mode ow chart above page)
Metering Mode:
When hands are detected by the sensor, water will run for ‘ X’ seconds (standard conguration is 30 seconds) before turning o󰀨. (See
Sensing & Metering Mode ow chart on following page)
Sensor Sensitivity: (Default setting: Low):
There are 4 sensitivity options, which can be selected to achieve the optimal detection performance related to the sink material, shape,
& nish. The faucet sensor sensitivity is congured during pack-out but the mode can be changed upon installation to optimize the
performance within the sink. Sensor sensitivity and sensor detection Modes A & B may be tried for various lighting conditions, sink
materials and shape.
Switch 7 controls the sensitivity
-On (default) is normal sensitivity for most sinks providing max range.
-O󰀨 set the sensor to a lower sensitivity level for sinks that cause false activation. The detection range maybe less for all hands.
Switch 8 controls sensor mode
-On (default) enables the mode that lters the e󰀨ects of owing in the bottom of problematic sinks. Detection maybe less for some
hands.
-O󰀨 disable the lter mode, so detection is expanded deeper into the sink for max detection range for all hands. Some sinks may
only be able to operate in this mode.
NOTE: After a conguration switch change has been made. Disconnect sensor cable from electronics box, wait 30 seconds, then
reconnect sensor cable and wait 30 additional seconds to allow the sensor to tune-in the sink characteristics. Calibration includes
characterizing the sink with water running into the bowl. This could be 5 to 60 seconds depending on conguration.
All switches shown in
default mode.
Switch Posion: 12345678
Purge (Hours)
Disable:
12:
24:
48:
O
On
O
On
O
O
On
On
Time 30:
(Seconds) 5:
10:
15:
60:
Less Time-out
O
On
O
On
O
On
O
O
On
On
O
O
O
O
O
O
On
On
Mode Select
Sensing Mode:
Metering Mode:
O
On
Sensor Sensivity
Low: O
Normal: On
Mode A: O
Mode B: On
Adjustable modes and features selection

FV723 Rev. B 7/29/2020
Page 8
For further assistance with troubleshooting visit http://www.zurn.com
Problem Possible Cause Corrective Action
Faucet is non-responsive Baery voltage low or no power. Change out baeries or verify power provided by ACA
Sensor and electronic connector
cable has bent or broken pins.
Check to see if pins are missing, bent, or broken. If yes, then the
electronic box needs to be replaced
Sensor lens could have surface
damage, scratches, or deposit
build ups.
Inspect the sensor lens underneath the spout p. May require
cleaning with a damp cloth or sensor replacement
Sensor lens could be obstructed
by environmental factors such
as highly reecve surfaces or
bright lighng condions.
If this is the case, then adjust the dip switch sengs for sensor
sensivity per the diagram on previous page (switches 7 and 8).
Direct sunlight into sink may make the unit inoperable. Do not
allow direct sunlight into sink.
If one mode does not help try one of the following:
-switching 7 to O to set the sensor to the lowest sensivity level
(detecon range may be less for all hand types).
-switching to alternate mode using switch 8; mode A or B depend-
ing on current conguraon
Reset sensor aer dip switch changes.
Faucet does not acvate
aer inial installaon
Sensor may not have had enough
me to calibrate prior to a user
or target trying to iniate acva-
on.
Disconnect the sensor and electronic box cables and wait for 30
seconds. Reconnect the cables, but allow for another 30 seconds
before placing hands or a target within the sensor range. You
should hear a click of the solenoid once calibraon is complete.
Check if protecve lm was
removed from lens.
Water does not stop Electronics box cable connector
has bent pins that are shorted
Check to see if pins are missing, bent, or broken. If yes, then the
electronic box needs to be replaced.
Ghost Acvaon Sensor lens could be obstructed
or environmental factors such as
highly reecve surfaces and/or
bright sunlight condions.
Check/clean sensor lens of any debris or buildup If sunlight or IR
interference is a factor, refer to page 7 “Sensor Sensivity” and
adjust faucet for Mode B operaon. Also, decreasing the sensiv-
ity seng (switch 7) may help.
Reset sensor aer dip switch changes.
Sensor faucet is leaking
underneath the sink or
counter
Mounng hardware is not ght-
ened suciently (faucet shank,
electronic box, supply hoses, etc)
Check and ensure the nuts and joints are ght and secure from
the supply stop all the way to the faucet shank.
Missing the washer located in the
solenoid box nut where it assem-
bles to the faucet shank.
Make sure the water supply stops are shut o. Check to ensure
the washer is installed or damaged. If not, install washer. If a
washer is damaged, replace with new.
Trouble Shooting: Faucet

FV723 Rev. B 7/29/2020
Page 9
Problem Corrective Action
“Device Not Communicang” posted in plumbSMART Step 1
Verify baeries installed in LoRa Monitor electronics and have
sucient charge. Install new baeries, as needed. Alert on
product’s page in plumbSMART should clear within 1 hour or on
next faucet acvaon. (Refresh web page by clicking on reload
icon in the browser to clear the alert.)
Step 2
If problem sll present, verify gateway is within range of LoRa
Monitor and funconing (see Gateway Troubleshoong secon)
Step 3
If problem sll present, verify plumbSMART subscripon status
on product page’s Details tab listed as “Acvated”
NETWORK: Senet
SUBSCRIPTION STATUS: Acvated
LAST HEARD FROM: 07/14/2020, 04:29 PM CDT
If listed as “Deacvated”, contact Zurn Custom Service at 1.855.
ONE.ZURN (1.855.663.9876) for assistance.
“Status – Good” posted in plumbSMART and faucet not
actuang
Step 1
Verify LoRa Monitor’s cables are connected to IR sensor
and Faucet actuator electronics. Restore proper electrical
connecon, as needed.
Step 2
Test acvate the faucet.
If problem persists, see Faucet Troubleshoong secon in this
guide for other steps.
“Status – Good” posted in plumbSMART and faucet actuates but
usage event data not appearing in plumbSMART Charts
Step 1
Verify gateway is powered and LoRa Status LED is ON. If
not, apply power per Zurn Gateway Installaon Guide or see
Gateway Troubleshoong secon in this guide of other steps.
Step 2
If problem sll present, verify plumbSMART subscripon status
on product page’s Details tab listed as “Acvated”
NETWORK: Senet
SUBSCRIPTION STATUS: Acvated
LAST HEARD FROM: 07/14/2020, 04:29 PM CDT
If listed as “Deacvated”, contact Zurn Customer Service at
1.855.ONE.ZURN (1.855.663.9876) for assistance.
Step 3
If problem sll present, the LoRa Monitor electronics may be
faulty. Contact Zurn Customer Service at 1.855.ONE.ZURN
(1.855.663.9876) for assistance with addional troubleshoong
steps and, if needed, unit replacement.
Trouble Shooting: LoRa Monitor
For further assistance with troubleshooting, visit https://plumbsmart.zurn.com/app/training

Problem Corrective Action
“Status – Good” posted in plumbSMART and faucet actuaon
event data not appearing in plumbSMART (< 2 hours) or
“Device Not Communicang” warning or severe alert posted in
plumbSMART for all devices (> 3 hours)
Step 1
Verify gateway Status LED ashes twice every 2 seconds. If LED
is OFF or ON solid, power cycle the gateway and wait for no
more than 5 minutes for unit to inialize and connect.
Step 2
Aer inializaon is nished, LORA LED should turn ON solid
within an addional minute.
Step 3
If LORA LED does not turn ON solid and ethernet cable
connected, contact facility IT administrator to modify port rules
to allow Zurn gateway to access the internet via local router.
If gateway model is ETH/LTE, visually verify SIM card is installed
in designated slot on the side of gateway. If unit has a SIM card,
then disconnect ethernet cable and power cycle the gateway
and wait for unit to inialize and connect. LORA LED should
turn ON solid aer inializaon.
Step 4
If problem sll present, move gateway closer to LoRa monitors
and/or verify gateway mounng, orientaon and connecons
comply with requirements listed in Zurn Gateway Installaon
Guide.
Contact Zurn Customer Service at 1.855.ONE.ZURN
(1.855.663.9876) for assistance with addional troubleshoong
steps.
Trouble Shooting: Gateway
For further assistance with troubleshooting, visit https://plumbsmart.zurn.com/app/training

Problem Corrective Action
Usage data presented in Water Usage Chart does not match
expected usage.
Step 1
Conrm installed aerator model’s gallons/minute specicaon
matches parameter seng in plumbSMART product page
“Parameters” tab. If factory-original aerator is installed, reset
parameter value to factory default and click Update.
Step 2
Test acvate the faucet and conrm single usage event data is
properly presented in Chart
Step 3
If problem sll present, contact building maintenance to verify
sucient water pressure in lines.
Step 4
If problem persists, the LoRa Monitor may be paired to the
incorrect xture model. Verify product image and model
number from plumbSMART product page “Details” tab against
model number cited on product literature and packaging.
If incorrect, contact Zurn Custom Service at 1.855.ONE.ZURN
(1.855.663.9876) for assistance.
“High Daily Faucet Acvate Rate” posted in plumbSMART Step 1
Verify faucet is not falsely triggering. See Faucet
Troubleshoong secon for appropriate diagnosc steps.
Step 2
Test acvate the faucet and conrm single usage event data is
properly presented in Chart.
If problem persists, see Faucet Troubleshoong secon in this
guide for addional steps.
LoRa Monitor not listed in plumbSMART. Step 1
Follow registraon steps in plumbSMART to acvate the
connected product.
Trouble Shooting: plumbSMART
For further assistance with troubleshooting, visit https://plumbsmart.zurn.com/app/training

FV723 Rev. B 7/29/2020
Page 12
Loosening screw will cause sensor assembly to back out of spout
body. It may be necessary to push cable from connector end to aid
in sensor assembly removal. Firmly press into pocket and tighten
screw. Sensor connector may need to be turned horizontally when
rst inserting into the spout.
With spout disengaged, sensor assembly can now be removed by
loosening the center screw with supplied M3 Allen wrench. With
assembly removed, you can now install new assembly and reas-
semble your spout.
To service solenoid use Phillips head screw driver to remove the
screws on both sides of the electronics box.
With screws removed, the electronics box can slide o󰀨 and allow
access to the solenoid for service.
Use supplied 3/32” hex wrench to loosen set screw. Screw will
retract into the base to eliminate loss. Using the same hex wrench,
depress the ball detent to release spout from base.
Lift spout and pull sensor cable through deck and base.
Align spout so that the ball detent is between the 2 holes. Press
down and turn clockwise. Use hex wrench to back set screw out
to secure spout.
To reinstall faucet, rst drop sensor cable of new spout through
the front of the base. Lower spout onto base inserting base nipple
into spout port.
To replace spout body, you must rst turn water o󰀨, then remove spout with sensor cable.
Note location of set screw and spring lock.
SPRING LOCK
SIDE
Before removing the spout, disconnect the sensor cable below the
deck so that the cable head can be pulled up through the deck.
*Take care to press the locking mechanism in prior to disconnect-
ing sensor cable. PULLING APART WITHOUT PRESSING IN
THE LOCK MAY DAMAGE THE SENSOR OR CONTROLLER
CABLES.
SET SCREW
SIDE
Spout Replacement
Sensor Assembly Replacement
Accessing the Solenoid

FV723 Rev. B 7/29/2020
Page 13
P6900-120BC,
Filter in standard faucet installation
Control Box
Attach adapter or Braided Hose (-SSH)
here with -MV and TMV-1 options
-SSH su󰀩x option
P6900-12BC Filter
Need to hold at pointed area by suitable
wrench or by hand while applying torque
to the supply hose nut.
Do not over torque the nut.
P6900-MV-ADAP [Supplied Adapter]
with -MV, and -TMV-1 Options
To Control Box To Control Box
-SSH Option -SSH Option
Supplied
Adapter
Supplied
Adapter
3/8 Copper
Tube (By Others)
3/8 Copper
Tube (By Others)
For use with
-TMV-1 Option
For use with
-MV Option
Thermostatic
Mixing Valve
Mixing Valve
Filter and Mixing Valve Installation

FV723 Rev. B 7/29/2020
Page 14
15
16
89
10 14
1A
1B
2
23A
3B
76
6
4
4
11
12
5
13
Z6950-XL & Z6955-XL Parts List
Description Product No.
Z6955 Spout Assembly with Sensor, Item 1A P6955-XL-S-1
Z6950 Spout Assembly with Sensor, Item 1B P6950-XL-S-1
Spout shank base, Item 2 P6950-XL-B
Z6955 Spout base gasket, Item 3A P6950-XL-44
Z6950 Spout base gasket, Item 3B P6950-XL-42
Electronics Box with Solenoid, Item 4 P6950-XL-B-L
Z6955 Sensor Assembly, Item 5 P6950-XL-EL
Mounng Kit, Item 6 P6950-43
Widespread Mounng Kit, Item 7 P6912-43M
Filter Kit, Item 8 P6900-120BC
Filter Screen, Item 9 P6900-MV-7
Mixing Valve with Filter, Item 10 P6900-XL-MV
Description Product No.
Single Stainless Supply Hose (XL), Item 12 P6900-SSH
Stainless Supply Hose (XL), Item 13 P6900-SH-XL
Composite Mixing Valve Adapter, Item 14 P6900-MV-ADAP
Shank Connecon Gasket, Item 15 P6900-SG
Solenoid Rebuilt Kit (Diaphragm, Plunger
and Plunger spring), Item 16 P6950-SRK
Smart Connected Faucet Retrot Kit,
Item 11 P6900-RK-W2

US 1.855.ONE.ZURN CANADA 1.905.405.8272 ZURN.COM
ZURN INDUSTRIES, LLC 511 W. Freshwater Way, Milwaukee, WI U.S.A. 53204 · Ph. 1-855-ONE-ZURN, Fax [phone]
In Canada: ZURN INDUSTRIES LIMITED 7900 Goreway Drive, Unit 10, Brampton, Ontario L6T 5W6, Ph. 905-405-8272, Fax [phone]
Rev. B Date:
07/29/20 C.N. No. 142919 Prod. | Dwg. No. FV723
