ZURN Aquaspec Z82100 Series User manual

AQUASPEC FAUCETS
MODEL - Z82100 SERIES
GOOSENECK SPOUT
TECHNICALINFORMATION
FLOW: 2 GPM [7.6L] PRESSURE COMPENSATINGAERATOR*
MAXIMUM PRESSURE: 125 PSI
MAXIMUM TEMPERATURE: 180OF
*OTHERAERATORSAVAILABLE BYREQUESTF
INSTALLATIONINSTRUCTIONS
1. REMOVEGOOSENECKBASE(#3) FROM CARTON,INSTALLGASKET (#4A) ONTOBASEASSEMBLY.
2. MOUNTBASEASSEMBLY (#3) TO DECK USING MOUNTING NUT (#4C)AND LOCK WASHER (#4B). FOR WALL
MOUNTED (WM) OPTION, MOUNTING HARDWARE IS TO BE PROVIDED BY THE CONTRACTOR.
3. CONNECT SUPPLY PIPINGTO GOOSENECK BASE (#3) USING 1/ 2” RISER NUT (#4D).
4. ASSEMBLE SPOUTTO BASE USING SPLIT WASHERS (#2C) FOR SWING SPOUT MOUNTING OR SPACER WASHER
(#2D) FOR RIGID MOUNTING.
5. TURN SUPPLY WATER ONAND OPERATE FAUCET CHECKING FOR LEAKS.
6. INSTALLAERATORINTO FAUCETANDHANDTIGHTEN INTOFAUCET SPOUT. IT MAY BE NECESSARYTOREMOVEAND
CLEANTHEAERATORATSTARTUP.
IMPORTANTTHEWATER SUPPLY LINESMUST BETHOROUGHLYFLUSHED BEFOREINSTALLATIONTOPREVENT
FOREIGNMATTERANDDEBRISFROMCLOGGINGAND/ORDAMAGINGINTERNALCOMPONENTSANDTHEREBYPREVENTING
THEFAUCETFROMFUNCTIONINGPROPERLY
MAINTENANCE
1. YOUR ZURN FAUCET HASAHIGHLY POLISHED NICKELCHROME PLATED FINISH. CLEAN WITH SOAPAND WATER
ORAMILD CLEANER WHICH IS SAFE FOR CHROME PLATING. DO NOT USEACIDS ORTOILET BOWLCLEANERAS
THEYWILL DAMAGE THE FINISH.
REPAIRPARTS
G63367 MOUNTING COMPONENTS FOR GOOSENECK SPOUT
Trouble Shooting Guide
Problem Cause Solution
NO WATER COMES OUT
OFFAUCETSPOUT.ALL
SUPPLIESARE ON. AERATOR ISCLOGGED.
AERATOR HASDEBRIS
REMOVEAERATOR.
REMOVEDEBRISAND
REINSTALLAERATOR
WATER DEFLECTSAT
ANANGLEFROM THE
FAUCETSPOUT
REMOVEAERATOR.
REMOVEDEBRISAND
REINSTALLAERATOR
PAGE1 OF 2 Form # CF202 Date: 12/27/11
C.N. No. 128454 Rev. C
ZURN INDUSTRIES, LLC.
♦♦
♦♦
♦ COMMERCIAL BRASS OPERATION
♦♦
♦♦
♦ 5900 ELWIN BUCHANAN DRIVE
♦♦
♦♦
♦ SANFORD NC 27330
Phone: [phone]
♦♦
♦♦
♦ Fax: [phone]
♦♦
♦♦
♦ World Wide Web: www.zurn.com
In Canada: ZURN INDUSTRIES LIMITED
♦♦
♦♦
♦ 3544 Nashua Drive
♦♦
♦♦
♦ Mississauga, Ontario L4V1L2
♦♦
♦♦
♦ Phone: [phone] Fax: [phone]

Item Part Number Description Qty.
1 G63504 3/4"-27 FemaleAerator - 2.0 GPM 1
2 G61064 5-3/8” Centerline Gooseneck SpoutAssembly 1
2A 60250002 5-3/8” Centerline Gooseneck ‘B’Spout 1
2B 58155018 O-Rings 2
2C 59666001 Split Swing Washers 2
2D 59436001 Spacer Washer 1
2E 59435001 Spout Nut 1
3 60552004 Base Assembly 1
4 G63367 Mounting Hardware 1
4A 60549001 Gasket 1
4B 61613019 Lockwasher 1
4C 59530002 Mounting Nut 1
4D 59532001 1/2” [13mm] NPSM Riser Nut 1
PAGE 2 OF 2
Z821B0 SHOWN
Form # CF202 Date: 12/27/11
C.N. No. 128454 Rev. C
