ZyXEL Communications P-600 Series Reference guide

Procedure to install a bitstream Zyxel modem.
1. Open the box and remove it’s contents. This includes the following items;
a. 1 * Zyxel P-600 series modem
b. 1 * Power supply
c. 1 * telephone cable (grey)
d. 1 * Network cable (yellow)
e. 3 * DSL line filters
f. 1 * CD
g. 1 * quick start guide
h. 1 * Magnet user manual
2. Plug one end of the grey telephone cable into the Modem DSL port and the other
end into the DSL/HPN port of the DSL line filter.
3. Plug the DSL line filter into the primary telephone socket in your home.
4. Plug the network cable into any of the 4 Ethernet ports on the modem and the
other end of the cable into the network card of your PC.
5. Plug the power cable into the power port on the back of the modem. Plug the
power supply into a power socket, ensuring that if the power socket has a switch,
that it is in the on position.
6. Press the ON/OFF switch to the ON position.
7. Allow the Modem approx 60 seconds to boot. You will know the modem has
booted fully when you see the following lights lit on the modem;
a. Power
b. WLAN
c. DSL
d. Ethernet Port (whichever Light corresponds to the position of the Network
cable)
8. Open Internet explorer on your PC
9. Type http://192.168.1.1 in the address bar of your Internet browser, the following
screen will appear;

10. Enter the modem default password, this is 1234 and click login.
11. You will now be presented with the following screen;
12. Open a new Internet explorer page, you should see the following screen;

13. You are now required to enter the following information;
a. Router Configuration Password – by default is 1234
b. User Name – refer to your welcome letter.
c. Password – Refer to your welcome letter.
14. Enter t is information and click log on to internet.
15. Once you ave successfully entered t e required information you will see t e
following screen;
16. You ave now successfully connected to t e internet.
Note: If you ave difficulties during any part of t is set-up process call 1800-624638
and c oose t e tec nical support option for assistance and a member of staff will be
only to appy to assist you.
Wireless set-up
1. Open an internet explorer page.
2. Type 192.168.1.1 in t e Address bar and it return.
3. You will be asked for t e modem password, w ic by default is 1234, see
figure below; (note t e password field may be automatically populated, ignore
t is and type in 1234)

4. Click Login, you will be prompted to change your password, see figure below;
5. Type in your new password if you wish, however you can click ignore to skip this
step. Note: Make sure that you keep a note of this password for future reference).
6. Click Apply once you have entered the password.
7. You will be now presented with the following screen;

8. In order to set-up wireless security on your modem complete the following steps;
a. Click on network.
b. Click on Wireless LAN
c. You will be presented with the following screen.
d. Ensure that the “Active wireless LAN” tick box is ticked
e. You can set you SSID to what ever you like, in the example it will be set
to magnet. For this example the SSID ID will be change to
Magnet_Example
f. Select static WEP from the Security mode drop down menu. You will be
presented with the following screen;

g. Type in a pass phrase and WEP key, in this example 12345 will be used
for illustration purposes only. Click Apply.
Note:
The different WEP key lengths configure different strength security, 40/64-bit, 1 8-bit, or 56-bit
respectively. Your wireless client must match the security strength set on the router.
-Please type exactly 5, 13, or 9 characters.
or
-Please type exactly 10, 6, or 58 characters using only the numbers 0-9 and the letters 'a-f' or 'A-F'.
h. In this example we are setting 64Kb encryption
i. The wireless security features are now set.
