3-form SimpleSpec 200.90-Divide User manual

Ready To Go
Installation Manual
For more information, please visit 3-form.com/Elements or call 800.726.0126
FEBRUARY 2021 | MANRTG20090 | REV 001 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.90Dividetm

Contents Overview
(1)
⅜"Corner
Mitered
Varia Panel
⅜" Varia Panel
(2)
Vertical Post, 2
Glazing Channels
--
(2)
Vertical Post, 1
Glazing Channel
--
(2)
(2)
Installation Template
Base Plate Guide
--
(2)
Installation Template
Spacer Guide
--
(1)
Installation Template
Corner Guide
--
Half Wall Aluminum
Top Rail Slot Cover
--
(4)
Half Wall Aluminum
Top Rail
--
(2)
Glazing
Channel Cover
--
(2)
U Channel
--
(2)
½" Glazing
Channel
--
(3)
Low Proile Glazing
Channel, 96"
--
(2)
Low Proile Glazing
Channel, 47"
--
(2)
2
Ready To Go
Installation Manual
For more information, please visit 3-form.com/Elements or call 800.726.0126
FEBRUARY 2021 | MANRTG20090 | REV 001 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.90Dividetm

Base Plate KIT
---K
(4) = + +
Screw
3152308
(8)
Base Plate
3152110
(4)
Base Plate Cover
3152114
(8) +
VHB Tape Strip
3152416
(16)
Contents Overview
(4) =
Base Plate Universal
Anchoring KIT
---K
+
Hex Head Wood
Lag Screw
3152310
(16)
M8x105 Concrete
Lag Screw
3-15-2309
(16)
(6) =
U Channel Attachment KIT
3152107K
+
Set Screw
632 x 3/8"
3152319
(12) +
Set Screw
632 x 1/8"
3152318
(6)
U Channel
TNut
3152107
(6)
(1) =
U Channel Mitered
Corner KIT
3152352K
+
U Mitered
Corner Bracket
3152170
(1)
+ +
Set Screw
632 x 1/8"
3152318
(4)
U Channel Corner
Miter A Length
3152352
(1) (1)
U Channel Corner
Miter B Length
3152353
3
Ready To Go
Installation Manual
For more information, please visit 3-form.com/Elements or call 800.726.0126
FEBRUARY 2021 | MANRTG20090 | REV 001 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.90Dividetm

(2) =
Half Wall Aluminum
End Cap KIT
3152386K
+
Half Wall Aluminum
End Cap
3152305
(2)
M5 TNut
3152391
(4) +
M5  12mm
Screw
3152392
(4)
(2) =
Half Wall Aluminum Top
Rail, End Adapter Plate KIT
3152380K
+
M5 TNut
3152391
(4) +
M5  12mm
Screw
3152392
(4)
Half Wall Aluminum
Top Rail, End
Adapter Plate
3152380
(2) +
Self Tapping
Screw
3152338
(4)
Contents Overview
(2) =
Half Wall Aluminum Top Rail,
Center Adapter Plate KIT
3152381K
+
M5 TNut
3152391
(8) +
M5  12mm
Screw
3152392
(8) +
Self Tapping
Screw
3152338
(8)
Half Wall Aluminum
Top Rail, Center
Adapter Plate
3152381
(2)
(1) =
Half Wall Aluminum
Mitered Corner KIT
3152384K
+
M5 TNut
3152391
(8) +
M5  12mm
Screw
3152392
(8)
Half Wall Aluminum
Mitered Corner
3152384
(2)
4
Ready To Go
Installation Manual
For more information, please visit 3-form.com/Elements or call 800.726.0126
FEBRUARY 2021 | MANRTG20090 | REV 001 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.90Dividetm

Overview - Divide Partition 5'5' Corner
Vertical Post,
2 Glazing Channels
0-15-2181
½" Glazing Channel
3-15-2009
+
Vertical Post,
1 Glazing Channel
0-15-2182
½" Glazing Channel
3-15-2009
+
Glazing
Channel
Cover
0-15-2105
Base Plate
KIT
3-15-2110-K
+Universal
Anchoring
KIT
3-15-2119-K
U Channel
0-15-2104
+
Low Profile
Glazing
Channel
0-15-2125
⅜" Varia Panel
U Channel
Attachment KIT
3-15-2107
Half Wall
Aluminum
End Cap KIT
3-15-2386-K
Half Wall
Aluminum Top Rail,
End Adapter
Plate KIT
3-15-2380-K
+
Half Wall Aluminum
Top Rail
3-15-2377
Low Profile
Glazing Channel
0-15-2125
Half Wall Aluminum
Top Rail Slot Cover
3-15-1732
+ +
Half Wall Aluminum Top Rail,
Center Adapter Plate KIT
3-15-2381-K
U Channel
Mitered
Corner KIT
3-15-2352-K
Half Wall Aluminum
Mitered Corner KIT
3-15-2384-K
⅜" Varia Corner
Mitered Panel
5
Ready To Go
Installation Manual
For more information, please visit 3-form.com/Elements or call 800.726.0126
FEBRUARY 2021 | MANRTG20090 | REV 001 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.90Dividetm

Divide Partition Systems also accommodate a number of accessory options to customize the use for your application.
Contact your 3form Elements Dealer for additional information.
Overview - Accessory Options
Post to Post Inset on Hush Mount
Markerboard and Markerboard Shelf Accessory Shelf
5-13"
Hush Bar Shelves and Shelving Bracket
Post Attachment Hush Mount Attachment
Coat HookHush Mount
TV Mount
12" Small
24–1/16" Medium
36−1/8" Large
6
Ready To Go
Installation Manual
For more information, please visit 3-form.com/Elements or call 800.726.0126
FEBRUARY 2021 | MANRTG20090 | REV 001 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.90Dividetm

Installation
Base plate templates (3152160) and corner templates (3152340) will be provided. The
base plate template has hole locations for drilling. Spacers will also be provided, unique to
this coniguration; cut to size based o post dimensions in the quoting phase.
1Drill Pilot Holes (16)
a
Ø Depth Anchors
Concrete mm min " --
Wood ⁄" min " --
Substrate Drill Bit
--
--
Installation Template
Base Plate Guide
3-15-2160
Installation Template
Spacer Guide
3-15-2347
Installation Template
Corner Guide
3-15-2340
Following the Installation Template, drill pilot holes. Use
appropriate pilot hole diameter and depth for the type of
substrate you are fastening to.
*3form stocks the drill bits required for the concrete
and wood pilot holes. If you wish to purchase a drill bit,
please contact your 3form sales representative.
b
Required Tools
Drill Drill Bits Hammer Drill Rubber Mallet Saw
7
Ready To Go
Installation Manual
For more information, please visit 3-form.com/Elements or call 800.726.0126
FEBRUARY 2021 | MANRTG20090 | REV 001 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.90Dividetm

2Assemble Vertical Posts
Cut Glazing Channel
(3152009) to
3' 11.125" lengths. (6)
a
Installation
Cut Glazing Slot
Cover (0152105) to
11.375" lengths. (6)
b
(×2) Set Screws
3-15-2319
(×2) Screws
3-15-2308
Base Plate
3-15-2110
U Channel T-Nut
3-15-2107
Vertical Post, 1 Glazing Channel
0-15-2182
Glazing
Channel Cover
0-15-2105
½" Glazing
Channel
3-15-2009
Assemble Vertical Posts (0152182). (2)
(×2) Screws
3-15-2308
Base Plate
3-15-2110
(×2) U Channel T-Nuts
3-15-2107
Vertical Post, 2 Glazing Channels
0-15-2181
(×2) Glazing
Channel Covers
0-15-2105
(×2) ½" Glazing
Channels
3-15-2009
Assemble Vertical Post (0152181). (2)
cSecure U Channel
TNuts. (6)
8
Ready To Go
Installation Manual
For more information, please visit 3-form.com/Elements or call 800.726.0126
FEBRUARY 2021 | MANRTG20090 | REV 001 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.90Dividetm

Installation
--
or --
1

--

--
2
Use hammer drill to secure post.
Secure First Vertical Post to Floor
3
4Attach U Channel to First Vertical Post
U Channel
0-15-2104
Low Profile
Glazing Channel
0-15-2125
Cut Glazing Channel (0152125)
to 3'9.25" length.
a cb
Insert Glazing Channel (015-
2125) into U Channel (015-
2104).
Set Screw
3-15-2318
U Channel
Secure U Channel (0152104) to
Vertical Post.
9
Ready To Go
Installation Manual
For more information, please visit 3-form.com/Elements or call 800.726.0126
FEBRUARY 2021 | MANRTG20090 | REV 001 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.90Dividetm

5Install Varia Panel
Installation
6Install Second Vertical Post
--
or --
1

--
--
2
Set Screw
3-15-2318
U Channel
3
10
Ready To Go
Installation Manual
For more information, please visit 3-form.com/Elements or call 800.726.0126
FEBRUARY 2021 | MANRTG20090 | REV 001 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.90Dividetm

Assemble and Attach U Channel Mitered Corner
7
Installation
Miter Corner
U Channels
U Mitered
Corner Bracket
3-15-2170
(×4) Set Screws
3-15-2318
a
Low Profile
Glazing Channel
0-15-2125
U Channel
Miter
c
Assemble U Channel
Mitered Corner Kit
(3-15-2352).
Cut Glazing Channel
(0152125) to 9"
length. (2)
dSecure U Channel
(0152104) to
Vertical Post.
b
Set Screw
3-15-2318
U Channel
Install Varia Corner Panel
8
Repeat Step 6 for next Vertical Post and then Steps 46
for remaining U Channel, Varia Panel and Vertical Post.
9Install Remaining Posts, U Channel
and Panel
11
Ready To Go
Installation Manual
For more information, please visit 3-form.com/Elements or call 800.726.0126
FEBRUARY 2021 | MANRTG20090 | REV 001 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.90Dividetm

10 Install Adapter Plates on Posts
Install Adapter Plates on Vertical Posts
with 2 Glazing Channels. (2)
Adapter Plate
3-15-2381
(×4) Screws
3-15-2338
Adapter Plate
3-15-2380
(×2) Screws
3-15-2338
Install Adapter Plates on Vertical Posts
with 1 Glazing Channel. (2)
a b
Installation
Cut Glazing Channel (0152369)
to the lengths of each Top Rail
(3152377).
a
11 Assemble Aluminum Top Rail Sections
12
Ready To Go
Installation Manual
For more information, please visit 3-form.com/Elements or call 800.726.0126
FEBRUARY 2021 | MANRTG20090 | REV 001 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.90Dividetm

Installation
11 Assemble Aluminum Top Rail Sections cont...
b
(×2) Screw
3-15-2392
(×4) Screw
3-15-2392
Connection at Vertical Post with 1
Glazing Channel (2)
Connection at Vertical Post with 2
Glazing Channels (2)
12 Attach Half Wall Top Rails
aLay out to ensure overhang at ends prior to install.
Attach Top Rails with
screws (3-15-2392).
b
Top Rail Miter B
3-15-2377
Top Rail Miter A
3-15-2377
(×8) T-Nut
3-15-2391
(×8) Screws
3-15-2392
(×2) Adapter Plate
3-15-2384
Glazing Channel
0-15-2369
(×2) T-Nut
3-15-2391
Glazing Channel
0-15-2369
(×2) T-Nut
3-15-2391
Assemble using Mitered Corner KIT (3-15-2384-K) and Miter A and Miter B Top Rails (3-15-2377).
13
Ready To Go
Installation Manual
For more information, please visit 3-form.com/Elements or call 800.726.0126
FEBRUARY 2021 | MANRTG20090 | REV 001 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.90Dividetm

(×2) T-Nut
3-15-2391
End Cap
3-15-2386
(×2) Screw
3-15-2392
a b
Cut Top Rail Slot Covers (3-15-1732)
to 3'3.5" lengths (4),
8.375" lengths (2),
6.125" lengths (2).
13 Attach End Caps (2)
14 Insert Slot Covers (8)
Installation
a b Insert Slot Covers (3-15-1732) into slots on bottom side of Top Rails.
14
Ready To Go
Installation Manual
For more information, please visit 3-form.com/Elements or call 800.726.0126
FEBRUARY 2021 | MANRTG20090 | REV 001 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.90Dividetm
