360 Vision Predator Ultra Instruction sheet

Predator ULTRA Installation Manual V2.1.25.3 Page 1
© 360 Vision Technology Ltd.
Predator ULTRA
Installation/Conguration Manual

Predator ULTRA Installation Manual V2.1.25.3 Page 2
© 360 Vision Technology Ltd.
Table of Contents
1 Safety and Precautions .............................................................................................................................. 3
2 Housing Dimensional Drawing ................................................................................................................... 4
3 Bracket Dimensional Drawing .................................................................................................................... 8
4 Connections ............................................................................................................................................. 10
5 Predator Washer/Nozzle Bracket ............................................................................................................. 16
6 Connections to Predators with HMA......................................................................................................... 17
7 Locating the Predator ULTRA on your Network ....................................................................................... 21
8 Connecting to the Predator ULTRA.......................................................................................................... 21
8.1 Live View.......................................................................................................................................... 23
8.1.1 Live Video ................................................................................................................................ 23
8.1.2 Status....................................................................................................................................... 24
8.1.3 Recording Browser................................................................................................................... 26
8.2 Settings ............................................................................................................................................ 27
8.2.1 Video ........................................................................................................................................ 27
8.2.2 Video Advanced ....................................................................................................................... 28
8.2.3 Advanced Features .................................................................................................................. 30
8.2.4 Camera .................................................................................................................................... 32
8.2.5 PTZ Zones ............................................................................................................................... 35
8.2.6 Date/Time................................................................................................................................. 36
8.2.7 Network.................................................................................................................................... 37
8.2.8 Interfaces ................................................................................................................................. 38
8.2.9 Recording................................................................................................................................. 40
8.2.10 Audio ...................................................................................................................................... 41
8.3 Add/Edit Users ................................................................................................................................. 42
8.4 Maintenance..................................................................................................................................... 43
8.5 Browser ............................................................................................................................................ 45
9 Network Settings Recovery...................................................................................................................... 45
10 Locating the Thermal IP on your Network .............................................................................................. 47
11 Connecting to the Thermal IP................................................................................................................. 47
11.1 Live View ........................................................................................................................................ 49
11.1.1 Live Video............................................................................................................................... 49
11.1.2 Status ..................................................................................................................................... 50
11.2 Settings .......................................................................................................................................... 51
11.2.1 Video ...................................................................................................................................... 51
11.2.2 Video Advanced ..................................................................................................................... 52
11.2.3 Advanced Features ................................................................................................................ 54
11.2.4 Camera................................................................................................................................... 56
11.2.5 Date/Time............................................................................................................................... 57
11.2.6 Network .................................................................................................................................. 58
11.2.7 Interfaces................................................................................................................................ 59
11.3 Add/Edit Users................................................................................................................................ 60
11.4 Maintenance................................................................................................................................... 61
11.5 Browser .......................................................................................................................................... 63
12 Network Settings Recovery.................................................................................................................... 64
13 Special Presets ...................................................................................................................................... 65

Predator ULTRA Installation Manual V2.1.25.3 Page 3
© 360 Vision Technology Ltd.
14 Important - Care of Painted Surfaces..................................................................................................... 66
15 Storage and Handling............................................................................................................................. 66
16 Warranty................................................................................................................................................. 66
17 PSU Enclosure....................................................................................................................................... 67
18 1080p Stream Resolutions & RTSP Links.............................................................................................. 67
19 White Balance and Fast Shutter options................................................................................................ 68
1 Safety and Precautions
1. Please read these notes before attempting to operate the 360 Vision Predator ULTRA, and keep for future
reference.
2. DO NOT disassemble or remove covers. This will break the water seals and invalidate the warranty.
3. All servicing and repairs must be handled by 360 Vision Technology.
4. Avoid pointing the camera directly towards a bright light source (sunlight), or expose the camera to intensive
light situations as this may damage the camera pick-up device.
5. Installation should be carried out by suitably qualied personnel, in accordance with local codes of practice
and regulations.
6. 360 Vision Technology Limited accept no liability for any damage caused by incorrect or improper installation.
7. To prevent risk of injury caused by the Predator ULTRA or mounting options becoming detached, t a suitable
safety chain or lanyard.
8. Connection of data signals and power should only be made using a pre-made Predator Composite cables.
9. Use only 360 Vision Predator ULTRA power supplies. These have suitable terminals for all the wires in the
Predator composite cable.
10. Please handle the Predator ULTRA with care, as improper handling may cause damage within this unit.

Predator ULTRA Installation Manual V2.1.25.3 Page 4
© 360 Vision Technology Ltd.
Predator No LED’s
Weight 7.5kg
Weight 8kg
Predator Single LED array - Covers SIR110, SIR160 or SIR140WL versions.
MUST NOT BE REPRODUCED OR SHOWN TO
DO NOT SCALE
ALL DIMENSIONS IN MM
REMOVE ALL SHARP EDGES
SHEET:
D
C
B
A
D
C
B
A
4
3
2
1
4
3
2
1
A3
DESCRIPTION SCALE:
PERMISSION OF THE AUTHOR.
ANY THIRD PARTY WITHOUT THE DIRECT WRITTEN
C COPYRIGHT PROTECTED AND
THIS DRAWING AND ALL COPIES ARE
PART NUMBER:
0.300 1 OF 2
TOLERANCES:-
X = 0.5
X.X = 0.1
X.XX = 0.05
A3
3rd ANGLE PROJECTION
360 Vision Technology Ltd.
Unit 7, Seymour Court,
Manor Park, Runcorn, Cheshire,
WA7 1SY. United Kingdom.
www.360visiontechnology.com
11
422
270
TILT
SWEEP
125
MOUNTING BASE
9 (x4) ON
101.6 (4 INCH) PCD
380
253 420 PAN SWEEP
NAME:
M5701-A
PREDATOR ASSEMBLY
SINGLE LAMP - ALUMINIUM
ISS DATE REFERENCE
A 060616 FIRST ISSUE
060616
DATE :
K.CRAIK
RELEASED:
APPROVED:
ENGINEER:
-- MATERIAL: FINISH:
SINGLE IR LIGHTS
SCALE 0.3
MOUNTING
BASE
SCALE 0.3
2 Housing Dimensional Drawing

Predator ULTRA Installation Manual V2.1.25.3 Page 5
© 360 Vision Technology Ltd.
Predator Dual LED array - Covers SIR250SW, 250SWL or IR275 versions.
Weight 8.5kg
MUST NOT BE REPRODUCED OR SHOWN TO
DO NOT SCALE
ALL DIMENSIONS IN MM
REMOVE ALL SHARP EDGES
SHEET:
D
C
B
A
D
C
B
A
4
3
2
1
4
3
2
1
A3
DESCRIPTION SCALE:
PERMISSION OF THE AUTHOR.
ANY THIRD PARTY WITHOUT THE DIRECT WRITTEN
C COPYRIGHT PROTECTED AND
THIS DRAWING AND ALL COPIES ARE
PART NUMBER:
0.300 1 OF 2
TOLERANCES:-
X = 0.5
X.X = 0.1
X.XX = 0.05
A3
3rd ANGLE PROJECTION
360 Vision Technology Ltd.
Unit 7, Seymour Court,
Manor Park, Runcorn, Cheshire,
WA7 1SY. United Kingdom.
www.360visiontechnology.com
11
422
270
TILT
SWEEP
125
MOUNTING BASE
9 (x4) ON
101.6 (4 INCH) PCD
380
253 420 PAN SWEEP
NAME:
M5702-A
PREDATOR ASSEMBLY
DUAL LAMP - ALUMINIUM
ISS DATE REFERENCE
A 160616 FIRST ISSUE
160616
DATE :
K.CRAIK
RELEASED:
APPROVED:
ENGINEER:
-- MATERIAL: FINISH:
DUAL IR LIGHTS
SCALE 0.3
MOUNTING
BASE
SCALE 0.3
Weight 8kg
Predator Single LED array (Straight Arm version) - Covers SIR110, SIR160 or SIR140WL versions.

Predator ULTRA Installation Manual V2.1.25.3 Page 6
© 360 Vision Technology Ltd.
Predator Thermal (upto 35mm lens) with LED array and built in thermal encoder
Weight 10.5kg
MUST NOT BE REPRODUCED OR SHOWN TO
DO NOT SCALE
ALL DIMENSIONS IN MM
REMOVE ALL SHARP EDGES
SHEET:
D
C
B
A
D
C
B
A
4
3
2
1
4
3
2
1
A3
DESCRIPTION SCALE:
PERMISSION OF THE AUTHOR.
ANY THIRD PARTY WITHOUT THE DIRECT WRITTEN
C COPYRIGHT PROTECTED AND
THIS DRAWING AND ALL COPIES ARE
PART NUMBER:
0.300 1 OF 2
TOLERANCES:-
X = 0.5
X.X = 0.1
X.XX = 0.05
A3
3rd ANGLE PROJECTION
360 Vision Technology Ltd.
Unit 7, Seymour Court,
Manor Park, Runcorn, Cheshire,
WA7 1SY. United Kingdom.
www.360visiontechnology.com
435
TILT
SWEEP
125
MOUNTING BASE
10 (x4) ON
101.6 (4 INCH) PCD
253
10
(569)
585
PAN SWEEP
387.5
NAME:
M5722-A
PREDATOR ASSEMBLY -TC35 THERMAL
WITH LAMP - ALUMINIUM
ISS DATE REFERENCE
A 210317 FIRST ISSUE
210317
DATE :
K.CRAIK
RELEASED:
APPROVED:
ENGINEER:
- - MATERIAL: FINISH:
SCALE 0.3
MOUNTING
BASE
SCALE 0.3
Predator Thermal (35 -100mm lens) with LED array
Weight 9.5kg
MUST NOT BE REPRODUCED OR SHOWN TO
DO NOT SCALE
ALL DIMENSIONS IN MM
REMOVE ALL SHARP EDGES
SHEET:
D
C
B
A
D
C
B
A
4
3
2
1
4
3
2
1
A3
DESCRIPTION SCALE:
PERMISSION OF THE AUTHOR.
ANY THIRD PARTY WITHOUT THE DIRECT WRITTEN
C COPYRIGHT PROTECTED AND
THIS DRAWING AND ALL COPIES ARE
PART NUMBER:
0.300 1 OF 2
TOLERANCES:-
X = 0.5
X.X = 0.1
X.XX = 0.05
A3
3rd ANGLE PROJECTION
360 Vision Technology Ltd.
Unit 7, Seymour Court,
Manor Park, Runcorn, Cheshire,
WA7 1SY. United Kingdom.
www.360visiontechnology.com
505
435
TILT
SWEEP
287
125
MOUNTING BASE
9 (x4) ON
101.6 (4 INCH) PCD
253
11
(457)
585
PAN SWEEP
NAME:
M5711-A
PREDATOR ASSEMBLY -TC100 THERMAL
WITH LAMP - ALUMINIUM
ISS DATE REFERENCE
A 211016 FIRST ISSUE
211016
DATE :
K.CRAIK
RELEASED:
APPROVED:
ENGINEER:
-- MATERIAL: FINISH:
SCALE 0.3
MOUNTING
BASE
SCALE 0.3

Predator ULTRA Installation Manual V2.1.25.3 Page 7
© 360 Vision Technology Ltd.
Weight 8.5kg
HMA Predator No Lamps (shown)
All versions of the Predator can be built to order with the integral HMA (Hinged Mount Adapter). The HMA is
tted during manufacture and is NOT available as an option for the installer to add to an existing Predator.
Predator Thermal (Side mounted)
MUST NOT BE REPRODUCED OR SHOWN TO
DO NOT SCALE
ALL DIMENSIONS IN MM
REMOVE ALL SHARP EDGES
SHEET:
D
C
B
A
D
C
B
A
4
3
2
1
4
3
2
1
A3
DESCRIPTION SCALE:
PERMISSION OF THE AUTHOR.
ANY THIRD PARTY WITHOUT THE DIRECT WRITTEN
C COPYRIGHT PROTECTED AND
THIS DRAWING AND ALL COPIES ARE
PART NUMBER:
0.300 1 OF 2
TOLERANCES:-
X = 0.5
X.X = 0.1
X.XX = 0.05
A3
3rd ANGLE PROJECTION
360 Vision Technology Ltd.
Unit 7, Seymour Court,
Manor Park, Runcorn, Cheshire,
WA7 1SY. United Kingdom.
www.360visiontechnology.com
522
125
MOUNTING BASE
10 (x4) ON
101.6 (4 INCH) PCD
253
10
(458)
387
270
TILT SWEEP
418
PAN SWEEP
100
M20x1.5P
M20x1.5P
NAME:
M5920-A
PREDATOR ASSEMBLY -TC35 THERMAL
WITH LAMP - ALUMINIUM
ISS DATE REFERENCE
A 210317 FIRST ISSUE
210317
DATE :
K.CRAIK
RELEASED:
APPROVED:
ENGINEER:
-- MATERIAL: FINISH:
SCALE 0.3
MOUNTING
BASE
SCALE 0.3
Weight 8.5kg

Predator ULTRA Installation Manual V2.1.25.3 Page 8
3 Bracket Dimensional Drawing
Predator Wall Bracket
Predator Long Range LED array - Covers SIR400 or SIR550S versions.
Weight 8.5kg
MUST NOT BE REPRODUCED OR SHOWN TO
DO NOT SCALE
ALL DIMENSIONS IN MM
REMOVE ALL SHARP EDGES
SHEET:
D
C
B
A
D
C
B
A
4
3
2
1
4
3
2
1
A3
DESCRIPTION SCALE:
PERMISSION OF THE AUTHOR.
ANY THIRD PARTY WITHOUT THE DIRECT WRITTEN
C COPYRIGHT PROTECTED AND
THIS DRAWING AND ALL COPIES ARE
PART NUMBER:
0.111 1 OF 2
TOLERANCES:-
X = 0.5
X.X = 0.1
X.XX = 0.05
A3
3rd ANGLE PROJECTION
360 Vision Technology Ltd.
Unit 7, Seymour Court,
Manor Park, Runcorn, Cheshire,
WA7 1SY. United Kingdom.
www.360visiontechnology.com
325
TILT
SWEEP
473
458 PAN SWEEP249
463
125
MOUNTING BASE
9.0 (x4) ON
101.6 (4 INCH) PCD
11
NAME:
M5500-A
PREDATOR ASSEMBLY
SIRIUS INTEGRAL LIGHTING
ISS DATE REFERENCE
A 180416 FIRST ISSUE
040416
DATE :
K.CRAIK
RELEASED:
APPROVED:
ENGINEER:
-- MATERIAL: FINISH:
SCALE 0.3
SCALE 0.3
MOUNTING
BASE
Predator PMA Bracket
Weight 1kg
MUST NOT BE REPRODUCED OR SHOWN TO
DO NOT SCALE
ALL DIMENSIONS IN MM
REMOVE ALL SHARP EDGES
SHEET:
D
C
B
A
D
C
B
A
4
3
2
1
4
3
2
1
A3
DESCRIPTION SCALE:
PERMISSION OF THE AUTHOR.
ANY THIRD PARTY WITHOUT THE DIRECT WRITTEN
C COPYRIGHT PROTECTED AND
THIS DRAWING AND ALL COPIES ARE
PART NUMBER:
0.125 9 OF 9
TOLERANCES:-
X = 0.5
X.X = 0.1
X.XX = 0.05
A3
3rd ANGLE PROJECTION
360 Vision Technology Ltd.
Unit 7, Seymour Court,
Manor Park, Runcorn, Cheshire,
WA7 1SY. United Kingdom.
www.360visiontechnology.com
125
OUTSIDE
DIAMETER
9 (x4) ON
101.6 (4 INCH) PCD
USE M8 BOLT FOR
FIXING TO POLE
60
M8 (x4) ON 101.6
(4 INCH) PCD.
FIX PREDATOR USING:
M8x30 HEX-HEAD BOLTS (x4)
- STAINLESS STEEL.
M8 SPRING LOCK WASHER (x4)
- STAINLESS STEEL.
73
M20x1.5P
M20x1.5P
73
M20x1.5P
8.0 (x4) ON 101.6
(4 INCH) PCD.
FIX PREDATOR USING:
M8x30 HEX-HEAD BOLTS (x4)
- STAINLESS STEEL.
M8 SPRING LOCK WASHER (x4)
- STAINLESS STEEL.
53.0
125
OUTSIDE
DIAMETER
M20x1.5P
10 (x4) ON
101.6 (4 INCH) PCD
USE M8 BOLT FOR
FIXING TO POLE
NAME:
M5350-A
PREDATOR ASSEMBLY
STAINLESS STEEL
ISS DATE REFERENCE
A 290216 FIRST ISSUE
290216
DATE :
K.CRAIK
RELEASED:
APPROVED:
ENGINEER:
-- MATERIAL: FINISH:
MOUNT PREDATOR
TO THIS FACE.
MOUNT POLE
TO THIS FACE.
MOUNT PREDATOR
TO THIS FACE.
MOUNT POLE
TO THIS FACE.
MATERIAL:
STAINLESS STEEL
MASS = 3.6 Kg PMA = STAINLESS STEEL
SCALE 0.5
SCALE 0.5
PMA = ALUMINIUM
MATERIAL:
ALUMINIUM
MASS = 0.93Kg
SCALE 0.5 SCALE 0.5
MUST NOT BE REPRODUCED OR SHOWN TO
DO NOT SCALE
ALL DIMENSIONS IN MM
REMOVE ALL SHARP EDGES
SHEET:
D
C
B
A
D
C
B
A
4
3
2
1
4
3
2
1
A3
DESCRIPTION SCALE:
PERMISSION OF THE AUTHOR.
ANY THIRD PARTY WITHOUT THE DIRECT WRITTEN
C COPYRIGHT PROTECTED AND
THIS DRAWING AND ALL COPIES ARE
PART NUMBER:
0.333 4 OF 4
TOLERANCES:-
X = 0.5
X.X = 0.1
X.XX = 0.05
A3
3rd ANGLE PROJECTION
360 Vision Technology Ltd.
Unit 7, Seymour Court,
Manor Park, Runcorn, Cheshire,
WA7 1SY. United Kingdom.
www.360visiontechnology.com
9.5 (x4)
ON 101.6 (4") PCD
10
238
M8 (x8) x 15 DEEP
ON 101.6 (4") PCD
125
MOUNTING BASE
125
CAMERA BASE
45°
65
128
(65)
(40)
165
M5x10 DEEP
(LANYARD)
33
12
NAME:
M5635-B
WALL BRACKET DETAIL
VANDAL - ALUMINUM
ISS DATE REFERENCE
A -
FIRST ISSUE
B 240717
SHEET 4 ADDED
240717
DATE :
K.CRAIK
RELEASED:
APPROVED:
ENGINEER:
- - MATERIAL: FINISH:
SCALE 0.4
PRODUCT DATA SHEET
Weight 1kg

Predator ULTRA Installation Manual V2.1.25.3 Page 9
© 360 Vision Technology Ltd.
Weight 2.5kg
Predator PMB Bracket
Weight 2.2kg
Predator Corner Bracket

Predator ULTRA Installation Manual V2.1.25.3 Page 10
© 360 Vision Technology Ltd.
4 Connections
Predator Composite Cable
This pre-made Predator Composite Cable is available in 3m, 10m, 25m and 40m lengths. It contains video
coax, power and data cables. One end is tted with the IP68 12-way connector for direct connection to the
Predator, the other is supplied with all cables stripped and tinned ready to be connected to the two-part
connectors which are supplied with the Predator ULTRA power supply.
Connecting the composite cable to the Predator ULTRA
Route the cable through the brackets and cable glands before connecting it to the Predator ULTRA. Ensure
that the pins and sockets are lined up correctly, insert the connector and tighten the locking ring to make the
connector water tight.
It is important that the water should not be allowed to pool around the connector, as this will increase the risk of
contamination and corrosion which may cause poor connections.
The connector on the base of the Predator ULTRA is rated IP68, when it is correctly connected and the locking
ring is tight.
Predator ULTRA 12-way connector pin-out.
Cables for Ethernet Connection to Predator ULTRA Power Supply
Use CAT5, CAT5e or CAT6 cable for Ethernet Connections to Predator ULTRA power supply (PRED-PSU-SM).
Maximum Distance from Network Switch/Router to PRED-PSU-SM
Using
PRED-3m
Using
PRED-10m
Using
PRED-25m
Using
PRED-40m
100m 100m 50m 3m
When using PRED-25M or PRED-40M the distance can be increased to 100m if a Network Switch is tted local
to the Predator ULTRA Power Supply.
Socket 12-pin socket (solder side view)
fitted by 360 Vision to the composite cable
Coax Screen (B)
Grey (C)
White (D)
Blue (E)
Violet (F)
Pink (G)
Green (H)
Orange (J)
Red (K)
Black (M)
Brown (L)
Coax Core (A)
A
B
L C
D
E
F
G
MH
K
J

Predator ULTRA Installation Manual V2.1.25.3 Page 11
© 360 Vision Technology Ltd.
MAINS FUSE
PRED-PSU-SM
MAINS FUSE 3 = 2AF
OUTPUT FUSE
PRED-PSU-SM
FUSE 1 = 6.3AT
FUSE 2 = 1AT
FUSE 4 = N/A
MAINS input
100 - 240Vac
Io Vo
Adj Adj
Model Number: PRED-PSU-SM Serial Number: yymmndd-xxxx Input Voltage:100-240VAC 50/60Hz Input current: 2.1A Output Voltage: 30V DC Output Current: 6.2A
Use pre-made cable PRED-3M,
PRED-10m, PRED-25m or
PRED-40m to connect to
Predator.
NOTE -All wires in composite
cable must
be connected.
PRED-PSU-SM
255 x 180 x 100mm
Enclosure Dimensions
HD IP Version Wiring
Camera Network/
Ethernet connection
30Vdc(+)PINK
30Vdc(-)GREEN
30Vdc(+)GREY
30Vdc(-)WHITE
30Vdc(+)BROWN
30Vdc(-)BLACK
Tx-
Rx-
Rx+
Tx+
RED
ORANGE
VIOLET
BLUE
Coax Core
Coax Screen
360
USE
Thermal Camera
(if tted)

Predator ULTRA Installation Manual V2.1.25.3 Page 12
© 360 Vision Technology Ltd.
MAINS FUSE
PRED-XALARM-PSU-SM-HD
MAINS FUSE 3 = 2AF
OUTPUT FUSE
PRED-XALARM-PSU-SM-HD
FUSE 1 = 6.3AT
FUSE 2 = 1AT
FUSE 4 = N/A
MAINS input
100 - 240Vac
Io Vo
Adj Adj
Model Number: PRED-XALARM-PSU-SM-HD Serial Number: yymmndd-xxxx Input Voltage:100-240VAC 50/60Hz Input current 2.1A Output Voltage: 30V DC Output Current: 6.2A
ALARM INPUTS
CON1
(e.g. Connect A1 to COM
to activate Alarm 1)
ALARM RELAY OUTPUT
CON3 (Volts Free)
0.5A 125Vac max.
1A 24Vdc max
PRED-XALARM-PSU-SM-HD
Coax Core
Coax Screen
Use pre-made cable PRED-3M,
connect to Predator.
NOTE - All wires in
composite cable must
be connected.
255 x 180 x 100mm
Enclosure Dimensions
30Vdc(+)PINK
30Vdc(-)GREEN
30Vdc(+)GREY
30Vdc(-)WHITE
30Vdc(+)BROWN
30Vdc(-)BLACK
Tx-
Rx-
Rx+
Tx+
RED
ORANGE
VIOLET
BLUE
Camera Network/
Ethernet connection

Predator ULTRA Installation Manual V2.1.25.3 Page 13
© 360 Vision Technology Ltd.
The PRED-XALARM-PSU-SM-HD has eight normally open/normally closed (Dilswitch S1, switch 8 on) alarm
inputs on connector CON1 on the alarm PCB. When using normally closed contacts, all un-used alarm inputs
must be connected to alarm in common CON1. Connect switches or volts free relay outputs from PIRs or other
equipment to CON1 connector so that the terminal labelled COM is connected to the appropriate alarm input
(A1 to A8) when the alarm contact is activated. There is also an alarm relay which can be used to activate
alarms on other equipment (DVRs etc..). The alarm relay contacts (Common – ‘C’, Normally Open – ‘NO’ and
Normally Closed – ‘NC’) use connector CON3 on the alarm PCB.
When an alarm is activated, the ALARM PCB will activate the alarm relay output and will send commands to set
the Predator ULTRA to activate ‘alarm mode’. The Predator ULTRA will save the current status (pan, tilt, lens,
tour and mimic) then it will seek the preset which corresponds with the active alarm number.
The alarm will remain active while the alarm input is active. After the alarm input becomes inactive, a 10 second
alarm timer will start. The timer extends the alarm activity until the alarm timer expires. If the alarm input
becomes active again before the timer has expired, the timer resets and will restart again when the alarm input
becomes inactive and a further preset seek command is sent to the Predator ULTRA.
If an alarm is active and a further alarm become active, the latest alarm will interrupt the previous alarm. (i.e.
the latest alarm has highest priority) The Predator ULTRA will seek the preset that corresponds with the new
alarm. When the contacts become inactive, the Predator ULTRA will seek the preset that corresponds with the
previous highest priority alarm that is still active. When all alarms inputs are inactive the alarm timer starts.
After the timer expires, the Alarm PCB sends a command to the Predator ULTRA to end the ‘alarm mode’ and
the Predator ULTRA will return to the status position and action that had been saved when rst alarm became
active.
When an alarm is active and the Predator ULTRA has automatically selected the appropriate preset, it is
possible to send further commands (i.e. manual control) to the Predator ULTRA which will override the preset
which had previously been automatically selected. Each time an automatic preset seek occurs as described in
the previous paragraph; the manual control will be interrupted.
Alarm Number Preset Number
1 1
2 2
3 3
4 4
Alarm Number Preset Number
5 5
6 6
7 7
8 8

Predator ULTRA Installation Manual V2.1.25.3 Page 14
© 360 Vision Technology Ltd.
MAINS FUSE
PRED-PSU-SM-CODEC
MAINS FUSE 3 = 2AF
OUTPUT FUSE
PRED-PSU-SM-CODEC
FUSE 1 = 6.3AT
FUSE 2 = 1AT
FUSE 4 = N/A
MAINS input
100 - 240Vac
Io Vo
Adj Adj
Model Number: PRED-PSU-SM-CODEC Serial Number: yymmndd-xxxx Input Voltage:100-240VAC 50/60Hz Input current 2.1A Output Voltage: 30V DC Output Current: 6.2A
PRED-PSU-SM-CODEC
255 x 180 x 100mm
Enclosure Dimensions
30Vdc (+)
0Vdc (-)
THERMAL ETHERNET
CONNECTION
NOT USED ON
HMA VERSION CAMERA

Predator ULTRA Installation Manual V2.1.25.3 Page 15
© 360 Vision Technology Ltd.
MAINS FUSE
PRED-PSU-SM-WA-HD
MAINS FUSE 3 = 2AF
OUTPUT FUSE
PRED-PSU-SM-WA-HD
FUSE 1 = 6.3AT
FUSE 2 = 1AT FUSE 4 = 1AT
MAINS input
100 - 240Vac
Io Vo
Adj Adj
Model Number: PRED-PSU-SM-WA-HD Serial Number: yymmndd-xxxx Input Voltage:100-240VAC 50/60Hz Input current 2.1A Output Voltage: 30V DC Output Current: 6.2A
PRED-PSU-SM-WA-HD
Coax Screen
Coax Core
Use pre-made cable PRED-3M,
PRED-10m, PRED-25m or
PRED-40m to connect to
Predator.
NOTE - All wires in
composite cable must
be connected.
255 x 180 x 100mm
Enclosure Dimensions
360
USE
30Vdc(+)PINK
30Vdc(-)GREEN
30Vdc(+)GREY
30Vdc(-)WHITE
30Vdc(+)BROWN
30Vdc(-)BLACK
Tx-
Rx-
Rx+
Tx+
RED
ORANGE
VIOLET
BLUE
Camera Network/
Ethernet connection

Predator ULTRA Installation Manual V2.1.25.3 Page 16
© 360 Vision Technology Ltd.
MAINS input
100 - 240Vac
L
N
E
MAINS FUSE
MAINS FUSE = 1.6AF PRED-POE-PSU
Data In
Data &
Power Out
RJ45 CONNECTION
TO CAMERA
RJ45 CONNECTION
TO NETWORK
255 x 180 x 100mm
Enclosure Dimensions
5 Predator Washer/Nozzle Bracket
Nozzle bracket.
The predator washer bracket kit includes the bracket, nozzle M8 plain metal washer, M8 lock washer and four
cable ties.
Nozzle Adjustment
The nozzle is set to produce a vertical water jet. The direction of the jet can be adjusted by rotating the nozzle
body in the bracket, or by using the screw-driver slot.
Fixing Bracket to Predator
Choose one of the four M8 predator xing bolt positions to be used to mount the nozzle bracket so that it does
not obscure an important view. E.g. directly above the horizontal bar of a wall bracket would be suitable.
Fit an M8 at metal washer between the predator base and the nozzle bracket so that the base of the bracket is
not crooked. Fit an M8 lock washer under the head of the bolt to reduce the risk of the bolt becoming loose and
the bracket moving. Ensure that the curved end of the bracket xing plate is directed towards the Predator pan
shaft so that the vertical part of the bracket is the maximum distance from the rotating body.
Tube Connection
Suitable tube (not supplied) for connection to the nozzle is PVC with internal diameter 3mm and outside
diameter 6mm PVC.
The end of the tube is pushed over the ridged tube at the rear of the nozzle. Fit a cable tie around the joint
between the PVC tube and the rear of the nozzle to ensure that the tube can not become detached.
The PVC tube should weave through the two slots in the bracket to provide strain relief. Cable ties can be used
to secure the tube so that it is clear of the Predator’s rotating body. Take care that the cable ties do not cause
excessive restriction of the tube.

Predator ULTRA Installation Manual V2.1.25.3 Page 17
© 360 Vision Technology Ltd.
K.Craik
15-08-2016
Predator washer image
Water Jet direction (vertical)
Adjustable Nozzle
Tie
Tube
Nozzle Bracket located
Fit M8 Plain Washer Between Nozzle
Bracket and Predator Mounting Base.
6 Connections to Predators with HMA
When the HMA (Hinged Mount Adaptor) is tted to the Predator, the ‘Predator Composite Cable’ is not used.
Connections between the power supply and Predator use conventional cables as detailed below.
30Vdc Power connections between Predator PSU and Predator that is tted with HMA
Cable Size No IR SIR110 SIR140WL SIR160 SIR250SWL SIR275 SIR400/
SIR550S
0.75mm² 85m 32m 32m 30m 30m 30m 5m
1.00mm² 113m 43m 43m 40m 40m 40m 10m
1.50mm² 170m 65m 65m 60m 60m 60m 15m
2.50mm² 283m 108m 108m 100m 100m 100m 25m
3.00mm² 340m 130m 130m 120m 120m 120m 30m
4.00mm² 450m 173m 173m 160m 160m 160m 40m
Note: Large Lamp units (SIR400/SIR550S) must be used with the PRED-PSU-SM (30vdc 6A) power supply.
If a thermal camera is tted (50 - 100mm lens) in the Predator use a coax to connect the video signal CON8
from the Predator that is tted with HMA and Predator PSU (PCB-000-0240-xx) CON2. This is used for the
thermal camera video.
If an Alarm PCB is present in the PSU then connect the data signal CON8 from the Predator that is tted with
a HMA to the Predator PSU (PCB-000-0240-xx) CON2. This is used for the serial alarm data to the Predator
ULTRA.
If a Washer PCB is present in the PSU then connect the control signal CON8 from the Predator that is tted with
a HMA to the Predator PSU (PCB-000-0240-xx) CON9. This is used for the washer control from the Predator
ULTRA.
!

Predator ULTRA Installation Manual V2.1.25.3 Page 18
© 360 Vision Technology Ltd.
Camera current draw table.
No Lamps IR80/
SIR110
IR110WL/
SIR140WL
IR130/
SIR160
IR175SW/
SIR250WL
IR200/
SIR275
Power Up 1.2A 1.2A 1.2A 1.2A 1.2A 1.2A
Idle
(No Lamps) 0.83A 0.83A 0.83A 0.83A 0.83A 0.83A
PTZ/Wiper
(No Lamps) 1.45A 1.45A 1.45A 1.45A 1.45A 1.45A
Idle
(IR Lamps) N/A 2.3A 2.3A 3.1A 3.1A 3.1A
PTZ/Wiper
(IR Lamps) N/A 3.1A 3.1A 3.8A 3.8A 3.8A
Idle
(White Lamps) N/A N/A 2A N/A 2A N/A
PTZ/Wiper
(White Lamps) N/A N/A 2.7A N/A 2.7A N/A
Voltage at PSU 30Vdc 30Vdc 30Vdc 30Vdc 30Vdc 30Vdc
Voltage at Camera
(PTZ/IR Fast tour)
28.5Vdc
(No Lamps) 27Vdc 27Vdc 27Vdc 27Vdc 27Vdc
Current/Voltage test at
cable length (1.5mm²) 40m 40m 40m 40m 40m 40m
Ethernet connections between Predator PSU and Predator that is tted with HMA.
The Ethernet connection uses standard CAT5, CAT5e or CAT6 cables tted with RJ45 connectors.
RJ45 CAT5, CAT5e, CAT6 Cable Signal
Pin 1 White with Orange Band Tx+
Pin 2 Orange Tx-
Pin 3 White with Green Band Rx+
Pin 4 Blue
Pin 5 White with Blue Band
Pin 6 Green Rx-
Pin 7 White with Brown Band
Pin 8 Brown
Gain access to connectors in the HMA
• Ensure that the xed part of the HMA is securely bolted to the top of the pole.
• The hinged part of the HMA (Hinged Mount Adapter) is fastened to the xed part using three M8x25
long hex head bolts. Use a spanner (13mm) to remove the three bolts. Each bolt is tted with a
split spring lock washer, a plain metal washer (which prevents the split washer from damaging the
bre washer) and a bre washer (which prevents the paint on the hinged part from being damaged
unnecessarily.
• Open the hinge taking care that the gasket is not damaged and support the weight of the Predator.
Gently open the HMA until the lanyard is able to take the weight. If the lanyard appears to support the
weight of the Predator, there is no need to continue to support the Predator. The connection circuit
board can now be seen.

Predator ULTRA Installation Manual V2.1.25.3 Page 19
© 360 Vision Technology Ltd.
Please make sure there is adequate spare cable (20cm) for when the camera is resting on the lanyard, failure
to do this could damage the connector circuit board.
Thermal Camera (If camera is present)
Use CON 8 if thermal camera is tted to Predator.
Alarm Connection (If feature is present)
Use CON8 to connect alarm signal to Predator PSU
(PCB-000-0240-xx) CON 2 (Video).
Audio Connection (If feature is present)
Use CON8 to connect audio signal from/to the Predator.
Line In
Speaker with Impedance of 8 OHM, 6W
Line Out
Single-Output 0.9V RMS, Line Output can drive a 10k
OHM Load.
Washer Connection (If feature is present)
Use CON6 to connect washer signal to Predator washer
PSU (PCB-000-0240-xx) CON 9
Ethernet Connections
Connect Ethernet cable to HD HMA Predator connection
board using a RJ45 connector (CON4).
Power Connections
Connect 24Vac/30vdc to CON5.
Thermal Camera (If camera is present)
Use BNC 1 if thermal camera is tted to Predator.
POE/Ethernet Connections
Connect Ethernet cable to HD HMA Predator connection
board using a RJ45 connector (CON3).
Alarm Connection (If feature is present)
Use CON4 to connect alarm signal to Predator PSU (PCB-
000-0240-xx) CON 2 (Video).
Washer Connection (If feature is present)
Use CON4 to connect washer signal to Predator washer
PSU (PCB-000-0240-xx) CON 9
Audio Connection (If feature is present)
Use CON5 to connect audio signal from/to the Predator.
Line In
Speaker with Impedance of 8 OHM, 6W
Line Out
Single-Output 0.9V RMS, Line Output can drive a 10k
OHM Load.
Please make sure there is adequate spare cable (20cm) for when the camera is resting on the lanyard, failure
to do this could damage the connector circuit board.
Predator with Thermal (50 - 100mm)
Predator with Thermal (50 - 100mm) - POE

Predator ULTRA Installation Manual V2.1.25.3 Page 20
© 360 Vision Technology Ltd.
Please make sure there is adequate spare cable (20cm) for when the camera is resting on the lanyard, failure
to do this could damage the connector circuit board.
Note
Camera has two separate Ethernet connections and two
separate IP addresses. (Default is 192.168.1.187 and
.188)
Ethernet Connection Predator (192.168.1.187)
Connect Ethernet cable to HMA Predator connection board
using a RJ45 connector (CON4).
Power Connections
Connect 24Vac/30Vdc to CON5.
Ethernet Connection Thermal (192.168.1.188)
Connect Ethernet cable to HMA Predator thermal
connection board using a RJ45 connector (CON8).
Predator with Thermal (upto 35mm)
