Aastra 480I CT User manual

CLASSIC VALUE ENTERPRISE IP
SCREEN
BUSINESS TOOLS FROM AASTRA TELECOM: BUILDING A WORLD OF BUSINESS TELEPHONE SOLUTIONS
The Model 480i CT offers cordless mobility
for enterprise workers. The cordless handset
provides VoIP access anywhere within an
office or warehouse with exceptional features
and performance.
Model 480i CT
IP Phone
Key Features:
•Cordless Mobility —Built-in WDCT technology provides up to 300,000
sq. ft. of coverage without the need for a separate wireless network
•Large Base Unit Display —Eight-line backlit screen with six context
sensitive softkeys provides more information and flexibility in call handling
•Enhanced Call Management —Large storage for personal directory,
callers log, and redial list
•Tight Integration —Support for multiple IP telephony systems including
BroadWorks®, Nortel, Sylantro, and Asterisk SIP
•Multiple Line/Call Appearance Lights —Supports up to 9 simultane-
ous calls. Juggle multiple calls easily with a single press of a button
•Shared Call Appearances —Shared calls allow you to place a call on
hold at one set and pick it up easily at another set
•Remarkable Audio —Quality speakerphone with excellent voice clarity
and delivery
•Protect Your Investments —Firmware upgrades can be downloaded
and installed in the field as standards develop and protocols evolve
•Less Wiring —Built in dual 10/100 switched Ethernet ports let you
share a connection with your computer. Inline power support
eliminates power adapters
480i CT
integrated
upgradeable
flexible

THIRD-PARTY INTEROPERABILITY
BROADSOFT®- BROADWORKS®
SIP (RELEASE 11.1)
NORTEL NETWORKS -
MCS 5100 & 5200* (RELEASE 3.0)
SYLANTRO®– SIP (VERSION 3.1)
ASTERISK™
SPHERE COMMUNICATIONS -
SPHERICALL™MGCP
480i CT
•
•1
•1
•2
480i
•
•
•
•2
•
9133i
•
•
•1
•2
9112i
•
•
•1
•2
Technical specifications
480i CT Base
Physical
» 2 position desk stand
»24.9 cm W x 14.7 cm D x 11.5cm H (9.8''W x 5.8''D x 4.5''H)
» 850 g (30.0 oz.)
Power
» Compatible with IEEE 802.3af inline power device
» Optional Power Over Ethernet (POE) injector available, but not provided, for
networks that do not supply power
Handset / Headset
» Modular headset connector, compatible with amplified business head-
sets
» Hearing aid compatible handset
» Quality speakerphone
Display
»3.5'' x 2.25'', 8 line, backlit display
Feature Keys
» 4 call appearance lines
» 4 navigational keys
» 6 customizable softkeys; programmable up to 18 functions.
» 8 predefined hard keys for most common call handling functions
including Call Transfer, Conference, Intercom, Hold, Redial, Mute
480i CT Cordless Handset
Physical
» 13.7 cm L x 4.6 cm W x 1.9cm H (5.4''L x 1.8''W x 0.8''H)
» 133 g (4.7 oz.)
Power
» AC wall adapter for charging stand
» Nickel Metal Hydride battery – 4 day standby time, 4 hour talktime
Handset / Headset
» One handset included; expandable up to 4 handsets
» 2.4 GHz Frequency Hopped Spread Spectrum (FHSS)
» Warehouse coverage up to 300,0001sq. feet
» Vibration alerter
» Headset compatible
Display
» Large 5 lines backlit display
Feature Keys
» 2 softkeys for tight integration to the 480i CT base features
» 4 predefined hard keys – Mute, Redial, Function, Menu.
»Programmable function key supports up to 14 functions
Networking
» Dual 10/100 Mbps switched Ethernet ports
» Manual or Dynamic Host Configuration Protocol (DHCP) IP address setup
» Time and date synchronization using SNTP
» Built-in HTTP server for web administration and maintenance
» Server provisioned user configuration files
Protocols / Codecs
» IETF SIP (RFC3261)
» G.711 µ-law / A-law
» G.729
Feature Highlights2
» Up to 9 call appearance lines
» Personal directory
» Call forward
» Call transfer
» Call waiting
» Caller and calling line information
»Callers log
»Conference
» Hold
»Redial list
»Live dial pad or pre-dial support
» Broadsoft’s BroadWorks enhanced SIP – supports Shared Call
Appearances, CommPilot Call Manager
» Nortel’s MCS 5100/5200 support – Conferencing, Voicemail, and NAT
Traversal support
» Sylantro SIP – Supports Comcierge, Call Park/Pickup, Conference
Package Contents
» 480i CT base » 480i CT cordless handset
» Desk Stand » Charging stand
» Quick Installation Guide » Belt clip
» Network Cable » AC adapter for charging stand
» AC adapter for base
1Depending on physical enviroment
2Features availability dependent on IP telephony system
V
VI IE EW WA AA AS ST TR RA AT TE EL LE EC CO OM M’ ’S SP PH HO ON NE ES SO ON NT TH HE EI IN NT TE ER RN NE ET TA AT TW WW WW W. .A AA AS ST TR RA A. .C CO OM M
Building success with the business telephone leader
Aastra Telecom Inc. • 155 Snow Blvd., Concord, Ontario, Canada. L4K 4N9 • [email protected] • www.aastra.com
For more information, contact your Aastra Telecom representative,
or call [phone].
COPYRIGHT (C) 2005 AASTRA TELECOM. ALL RIGHTS RESERVED. INFORMATION IN THIS DOC-
UMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. AASTRA TELECOM ASSUMES NO RESPON-
SIBILITY FOR ANY ERRORS THAT MAY APPEAR IN THIS DOCUMENT. PRODUCT CAPABILITIES
DESCRIBED IN THIS DOCUMENT PERTAIN SOLELY TO AASTRA TELECOM’S MARKETING ACTIV-
ITIES IN THE U.S AND CANADA. AVAILABILITY IN OTHER MARKETS MAY VARY.
10/06
1Currently undergoing certification – Q3 2005
2Field tested and deployed
* The Aastra 480i, 9133i and 9112i IP Phones were verified as
compatible with Nortel Networks Multimedia Communications
Server 5100 and 5200 in a controlled laboratory environment.
