How to use Aastra 55i with PBXware
This "How to" is written as general guide on how to use Aastra 55i with PBXware using SIP
Version 2.2 Aastra 55i firmware. It covers the most common tasks that are required to have your
Aastra 55i working efficiently.

Registering Aastra 55i
Requirements
1. Aastra 55i firmware.
- Make sure that device is loaded with SIP Version 2.2, up to 3.3.1.4053 firmware.
2. DHCP server.
- Fully configured and operational DHCP server.
Manual Configuration
UAD Settings
STEP ONE: PBXware IP address.
1. Find out the IP address of the PBXware server.
STEP TWO: Login to PBXware.
1. Open a new browser window and enter the IP address followed by "/admin/index.php" in
order to access the PBXware administration interface login screen.
Example: http://192.168.1.2/admin/index.php
UAD Settings an example with IP address following by "/admin/index.php"
2. Hit "Enter" on your keyboard.
3. Login to PBXware with your e-mail address and password.
UAD Settings
STEP THREE: UAD status.

1. Make sure the UAD is enabled. To check the UAD status, navigate to "Settings:UAD", and
click on the "edit" icon corresponding to "Aastra 55i".
2. Make sure "Status" is set to "active", "Auto provisioning" is set to "No" and "DHCP" is set to
"Yes".

3. Click on the "Save" button to save changes.
Creating Extension
STEP ONE: Add Extension.
1. Navigate to "Extensions". Click on "Add Extension".
Creating Extension
2. The standard options window will be shown below.
Creating
Extension/Extensions Add
3. Select Aastra 55i from "UAD" select box.
4. Select Location: "Local" or "Remote".
Note:
-"Local" is for all extensions registered on LAN.
-"Remote" is for all extensions registered from remote networks, WAN, Internet etc.

Creating
Extension/Extensions Add
5. Click on the "Next" button.
STEP TWO: Extension values.
1. Enter values into the required field text boxes.
REQUIRED FIELDS:
Name:
Enter a name for the extension being created. Example: John Smith.
E-mail:
Enter the e-mail address associated with this extension. This e-mail address will receive all
system notification messages. Example: [email protected].
Creating
Extension/Extensions Add
an example with details filled in
2. Click on the "Save" button.
Creating
Extension/Extensions Edit
an example with details filled in
3. Click on the "Save & E-mail" button. Account details will be sent to the e-mail address
associated with this extension.
OPTIONAL FIELDS:
Extension:

An auto-generated extension number based on the next available sequential number. An
extension value can be changed. Example: 1000.
Username:
Username is auto generated/populated and cannot be changed since it allows the system to use
this value for other important operations.
Secret:
A secret value associated with the UAD is auto-generated in order to allow the UAD to
successfully register with the system. The secret value can be changed.
PIN:
An auto-generated PIN will allow access to voicemail and online self care.
Registering Phone
STEP ONE: Electricity and Ethernet.
- Make sure to properly connect your Aastra 55i to the electricity network using a power
adapter or passive power over ethernet injector.
- Connect ethernet port to a hub, router or switch to access LAN.
Please Note: For information and instruction on how to connect your Aastra 55i to the
electricity network and ethernet, check manufacturer documentation on their web site
www.aastra.com.
After successfully connecting Aastra 55i to the electricity and data networks, it is time to
register it to PBXware.
STEP TWO: Aastra 55i IP address.
Find out the IP address of the Aastra 55i connected to the network.
1. Press the button with the "i" sign.
2. Select "Option list" from the menu.
3. Select "Phone status".
4. Select "IP & MAC addresses" option.
5. The IP address of your PBXware displays in the "IP Address" field.
STEP THREE: Aastra 55i Web Interface.
1. Open a new browser window and enter the IP address in order to access the Aastra 55i
administration interface.
Example: http://192.168.1.101/

Registering Phone
an example with IP address
2. Hit "Enter" on your keyboard.
3. Login to the Aastra 55i Web Interface. You'll be prompted to enter a username and password.
The factory default username is lower case "admin" and password is "22222".
STEP FOUR: Configuring Aastra 55i.
1. Click on "Line 1" link.
Registering Phone
2. Enter following details into the respective fields.
REQUIRED FIELDS:
Phone Number
PBXware extension number. Example: 1000
Authentication Name
Usually the same number as "Phone Number".
Password
The Secret of the extension as received in the e-mail associated with this extension. Example:
3dX3r5
Proxy Server
IP address of PBXware server. Example: 192.168.1.2
Proxy Port
5060
Registrar Server
IP address of PBXware server. Example: 192.168.1.2
Registrar Port
5060

Registering Phone
an example with details filled in
OPTIONAL FIELDS:
Screen Name
Example: John Smith
Other fields
Other "options" or "fields" should be left blank or as is by default, they have no importance for
registering your Aastra 55i to PBXware.
3. Click on the "Save Settings" button.
4. Click on "Reset" link.
Registering Phone
5. Click on the "Restart" button to restart Aastra 55i so that the changes take effect.
- Conclusion: If everything is done as above described you should have successfully registered
your Aastra 55i to PBXware. Dial *123 to verify registration.
- For further information, please contact the manufacturer or check their web site
www.aastra.com.
Auto Provisioning
UAD Settings
STEP ONE: PBXware IP address.
1. Find out the IP address of the PBXware server.

STEP TWO: Login to PBXware.
1. Open a new browser window and enter the IP address followed by "/admin/index.php" in
order to access the PBXware administration interface login screen.
Example: http://192.168.1.2/admin/index.php
UAD Settings
an example with IP address following by "/admin/index.php"
2. Hit "Enter" on your keyboard.
3. Login to PBXware with your e-mail address and password.
UAD Settings
STEP THREE: UAD status.
1. Make sure the UAD is enabled. To check the UAD status, navigate to "Settings:UAD", and
click on the "edit" icon corresponding to "Aastra 55i".
UAD Settings
2. Make sure "Status" is set to "active", "Auto provisioning" is set to "Yes" and "DHCP" is set to
"Yes".

UAD Settings
3. Click on the "Save" button to save changes.
Creating Extension
STEP ONE: Add Extension.
1. Navigate to "Extensions". Click on "Add Extension".
Creating Extension
2. The standard options window will be shown below.
Creating
Extension/Extensions Add
3. Select Aastra 55i from "UAD" select box.
4. Select Location: "Local" or "Remote".
Note:
-"Local" is for all extensions registered on LAN.
-"Remote" is for all extensions registered from remote networks, WAN, Internet etc.
Creating
Extension/Extensions Add
5. Click on the "Next" button.
STEP TWO: Extension values.
1. Enter values into required field text boxes.

REQUIRED FIELDS:
Name:
Enter a name for the extension being created. Example: John Smith.
E-mail:
Enter the e-mail address associated with this extension. This e-mail address will receive all
system notification messages. Example: [email protected]
Auto provisioning:
Set to "Yes".
MAC Address:
Aastra 55i MAC address. Example: 001646f5f797
Creating Extension
an example with details filled in
2. Click on the "Save" button.
Creating Extension
an example with details filled in
3. Click on the "Save & E-mail" button. Account details will be sent to the e-mail address
associated with this extension.
OPTIONAL FIELDS:
Extension:
An auto-generated extension number based on the next available sequential number. An
extension value can be changed. Example: 1000.
Username:
Username is auto generated/populated and cannot be changed since it allows the system to use
this value for other important operations.

Secret:
A secret value associated with the UAD is auto-generated in order to allow the UAD to
successfully register with the system. The secret value can be changed.
PIN: An auto-generated PIN will allow access to voicemail and online self care.
Registering Phone
STEP ONE: Electricity and Ethernet.
- Make sure to properly connect your Aastra 55i to the electricity network using a power
adapter or passive power over ethernet injector.
- Connect the ethernet port to a hub, router or switch as to access LAN.
Please Note: For information and instruction on how to connect your Aastra 55i to the
electricity network and ethernet, check manufacturer documentation on their web site
www.aastra.com.
After successfully connecting your Aastra 55i to the electricity and data networks, it is time to
register it to PBXware.
STEP TWO: Aastra 55i IP address.
Find out the IP address of the Aastra 55i connected to network.
1. Press the button with the "i" sign.
2. Select "Option list" from the menu.
3. Select "Phone status".
4. Select "IP & MAC addresses" option.
5. The IP address of your PBXware displays in the "IP Address" field.
STEP THREE: Aastra 55i Web Interface.
1. Open a new browser window and enter the IP address in order to access the Aastra 55i
administration interface.
Example: http://192.168.1.101/
Registering Phone
an example with IP address
2. Hit "Enter" on your keyboard.
3. Login to the Aastra 55i Web Interface. You'll be prompted to enter a username and password.
The factory default username is lower case "admin" and password is "22222".

STEP FOUR: Configuring TFTP server.
1. Click on "Configuration Server" link.
Registering Phone
an example with details filled in
2. "TFTP Server" must be set with TFTP server value. Example: 192.168.1.2
3. Click on the "Save Settings" button.
4. Click on "Reset" link.
Registering Phone
5. Click on the "Restart" button to restart your Aastra 55i so the changes take effect.
Paging
1. Navigate your Internet browser to the phone's IP address (for example http://192.168.1.1).
2. Select "Preferences" under the "Basic Settings" tab.

Paging
3. Make sure that
Auto-Answer box is checked.
Microphone Mute box is not checked.
Paging
4. Navigate to the bottom of the page and click on the "Save Settings" button.
Paging
5. Reboot the phone to apply the new settings.
NOTE: At the time, the paging option is set for all lines and works once the handset is picked
up. Paging tested with Firmware version 1.3.1.1095.
Glossary
- DHCP = Dynamic Host Configuration Protocol (DHCP) is a communications protocol that
allows network administrators to manage and automate the assignment of Internet.
- HUB = A common connection point for devices in a network.
- IP Address = Internet Protocol address.
- Local = A local area network (LAN) is a computer network covering a local area, like a home,
office, or small group of buildings such as a college.

- LAN = Local Area Network.
- PIN = Personal Identification Number.
- Remote = Network devices that are managed or controlled from a network system other than
the system to which they are directly connected.
- Router = A device that forwards data packets from one local area network (LAN) or wide area
network (WAN) to another.
- Switch = Network device that selects a path or circuit for sending a unit of data to its next
destination.
- UAD = User Agent Device.
- VoiceMail = The electronic transmission of voice messages over the Internet. The messages
are stored on a computer until the recipient accesses and listens to them.
- WAN = Wide Area Network.
- Web Interface = A web interface is the system of controls with which the user controls a
device.
