AAT MAX-E Q1604 Installation and operating instructions

www.aat-online.de
EN
BLACK EDITION
Translation of the original user manual
2020-08 (1.1)

2
Assembly Team
Phone [phone]
Phone [phone]
Fax [phone]
E-Mail [email protected]
New devices
Phone [phone]
Phone [phone]
Fax [phone]
E-Mail [email protected]
Head offi ce
Phone [phone]
E-Mail [email protected]
Web www.aat-online.de
Spare parts
Repair processing
Technical information
Product seminars
Showroom & exhibition devices
Re-use
Complaints
Rental devices
With our professional service concept
AAT proves once again its high claim of
quality and o󰀨 ers its clients an all-inclu-
sive package.
We are at your service!
AAT service concept
Customer service at its best
Service and repairs
Phone [phone]
Phone [phone]
Fax [phone]
E-Mail [email protected]
AAT Alber Antriebstechnik GmbH
Ehestetter Weg 11 · 72458 Albstadt · Germany
Phone: [phone]
Fax: [phone]
[email protected] · www.aat-online.de

3
max-e has been successfully tested by TÜV Süd Product Service GmbH in Hanover according to
DIN EN 12182, DIN EN 12184 and the relevant parts of ISO 7176-14.
People with visual and reading impairments or intellectual disabilities should print out the
user manual available on the website in enlarged letters or have this manual read to them,
if necessary. You will also  nd all safety-relevant changes that have been made to the user manual
on our homepage. All versions with details of the production period of the product are obtainable at:
www.aat-online.de/bda/max-e_black_edition
Manufacturer’s signature:
Martin Kober
(Managing Director)
WARNING
Failure to observe this user manual, in particular the safety instructions, can lead to defects in the max-e
and endanger the user and persons in the immediate vicinity of the device. There is an increased risk of
injury! In the event of an infringement, claims for warranty and liability are excluded!
The product is state of the art and complies with the associated technical safety requirements.
Nevertheless, a low level of residual risks cannot be ruled out. Please observe the safety instructions
to this end.

4
Table of Contents
1 Symbols and safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2 Explanation of the symbols on the packaging . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3 Explanation of the symbols on the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
4 Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4.1 Device overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4.2 Indication and intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
4.3 Contraindication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
4.4 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.5 Dimensional drawing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.6 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.7 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.1 Quick-release wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.2 Battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.3 Drive unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
5.4 Operating unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.5 Anti-tip supports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
6 Starting up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6.1 Turning on the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6.2 Display indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6.3 Driving with max-e . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
6.4 Overcoming obstacles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
6.5 Deactivating the drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7 Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
8 Transportation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
9 Care and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
9.1 Battery pack and charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
9.2 Replacing the fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
9.3 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
9.4 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
9.5 Long-term storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
9.6 Technical safety testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
9.7 Reuse (change in operator) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
9.8 Corrective action/recall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
10 Warning notices, error messages and troubleshooting . . . . . . . . . . . . . . . . . . . . . 28
10.1 Warning notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
10.2 Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
10.3 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
11 Warranty and liability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

5
1 Symbols and safety instructions
DANGER - Immediately imminent danger
If not avoided, this will result in death or severe bodily injuries!
WARNING - Possible imminent danger
If not avoided, this may result in death or severe bodily injuries!
CAUTION - Possible imminent danger or harmful situation
If not avoided, this may result in minor bodily injuries or damage to property!
iNOTE - Information by the manufacturer
General safety instructions
iNOTE
If you have a visual disability, this user manual can be downloaded at:
www.aat-online.de/bda/max-e_black_edition.
Read the user manual prior to start-up and observe the warning notices and safety instructions.
In the event of reading disabilities, cover training content in more depth verbally.
The user manual must be kept in a safe place after reading through it.
It does not consist exclusively of ame retardant substances. Keep max-e away from sources of
ignition.
max-e can interfere with highly sensitive electromagnetic elds of other electronic devices
(e.g. anti-theft devices).
Stability tests were performed under laboratory conditions. max-e may behave di󰀨erently under real
conditions compared to laboratory tests.
Training may only be carried out by the manufacturer, the AAT eld sta󰀨 or the qualied specialist shop.
CAUTION
External heat sources may cause the surface temperature to rise (e.g. sunlight)!
Do not touch the a󰀨ected surfaces in this case to avoid burns!

6
Symbol Explanation
Handle with care
The packaging including the product must be handled with special care.
Protect from moisture
Protect the packaging including the product from overly high air humidity.
Cover during storage. If necessary, cover thoroughly with tarpaulins.
Caution fragile
Handle the packaging including the product carefully and never allow it to fall.
This way up
The packaging must be stored and transported in such a way that the arrows
point upwards at all times. Any failure to comply with this rule, such as rolling
or tilting the package, must be avoided.
2 Explanation of the symbols on the packaging
WARNING / RISK OF CRUSHING
Never touch rotating/moving parts (e.g. engagement of gear wheel in the toothed ring),
to prevent crushing.
DANGER
max-e must not be operated in the case of severe visual impairment and/or blindness!
Do not exceed the total permissible weight and the maximum person weight, as this may lead to
defects or an overloading of max-e!
Avoid driving in heavy rain, ice, snow and on unsurfaced ground (sand, mud, loose crushed rock) to
prevent slipping!
Do not use on escalators or travellators to avoid injuries caused by a crash or the falling out of the
occupant and the occurrence of damage to property!
The operational capability of max-e can be inuenced by electromagnetic elds
(e.g. by mobile phones, electric generators or high-voltage sources)!
Do not store near medical devices, for example with a life support function,
and diagnostic devices, as these may malfunction!

7
3 Explanation of the symbols on the device
Symbol Explanation
CE mark
The product complies with the relevant provisions of
EC Directives 2006/42/EC, 2007/47/EC und 93/42/EC
SN SN
Serial number of the product e. g. Q1604XXXXXX
www.aat-online.de
Note on the user manual
The user manual must be observed!
24 V -
Electrical voltage / V = Volt
Inspection plate for technical safety testing (see Chapter 9.6)
Provides information on the due date of the next technical safety test

8
4 Product description
4.1 Device overview
Battery pack
Power lead; Battery pack connection
Battery bag
Operating unit holder
Operating unit
Joystick
Power cable / Spiral cable connection
Drive unit
Bracket for the drive unit
Wheels with sprocket
Anti-tip supports
Emergency release button
ON/OFF
Horn
Speed selection fast
Speed selection slow
Display
Spiral cable; control unit connection
Type label incl. serial number (without  gure)
on the back of the drive unit
i
Manufacturer’s informa-
tion:
For a simpli ed assignment
of the individual components,
the numbers listed here are
cited in full for the  rst time in
the following chapters.

9
4.2 Indication and intended use
The max-e is an electrical transport device and is attached to a manual wheelchair. The objective of the
electrical transport device is to make movement with a manual wheelchair easier for a self-propelled
person and to take over the force generation for the movement of the wheelchair. This shall maintain
autonomous movement and increase mobility and exibility for the patient.
The max-e drive can optionally be equipped with a control unit for use by an accompanying person.
This applies to the following indication:
If the wheelchair user does no longer have the motor ability to move the wheelchair by himself/herself by
operating the joystick control, and the strength of the accompanying person is not enough to steer and/
or push and brake a person sitting in the wheelchair.
The max-e can be used indoors as well as outdoors.
4.3 Contraindication
The max-e must not be used if:
• the operator has obtained no training/instruction for the product
• the operator is not physically and mentally able to operate the max-e safely
• more than one person shall be transported simultaneously
• the operator does not have adequate eyesight
• the braking e󰀨ect is lost due to rain, wet conditions, snow or black ice
• the braking e󰀨ect of the max-e does not set in
• escalators or travelators shall be overcome
• medical devices with e.g. a life support function, and diagnostic devices are in the proximity
• it is not used according to the intended use
• objects shall be transported

10
4.4 Technical data
WARNING - Do not exceed the total permissible weight and the maximum weight of the person,
as this may lead to defects or an overloading of max-e!
iNOTE - Observe the technical data.
Technology max-e
Drive dimensions Width: min. 300 - max. 700 mm; height: 290 mm; depth: 153 mm
Own weight
Drive unit: 9.1 kg; battery pack: 10.1 kg; operating unit: 0.5 kg;
power cable: 0.3 kg; battery bag incl. Velcro tapes: 0.2 kg;
Total weight max-e (without wheelchair): 20.2 kg;
charger: 0.3 kg
Total permissible weight 200 kg (person, wheelchair, max-e)(1)
Possible wheel sizes in inches 20, 24
Limit values during construction From seat width 28, max. 0° camber
Widening of wheelchair by attachment max. 3.6 cm
Speed forward I backward 6 km/h I 3 km/h
Range with one charge of the batteries up to 16 km (2)
Rated slope with a weight of the person of
up to 80 kg I from 81 kg to 160 kg max. 20 % (11.3°) (3) I max. 16 % (9°) (3)
Lead gel battery pack 2 x 12 V / 16 Ah
Direct current motor 24 V / 130 W
Noise information The A-weighted sound pressure level is typically below 61 dB (A)
Switching/actuating forces Joystick: 3.5 N; buttons (ON/OFF, horn, speed): 0.74 N
Emergency release button = 0.74 N
Static stability downhill / sideways Observe the wheelchair manufacturer’s information
Turning circle diameter Observe the wheelchair manufacturer’s information
Tire pressure / Hand rim diameter 7 bar / 540 mm
Maximum surmountable obstacle height Observe the wheelchair manufacturer’s information and chapter 6.4
Storing/operating temperature: Device 0° C to +60° C / -20° C to +50° C
Storing/operating temperature: Battery pack 0° C to +40° C / -20° C to +50° C
Charging temperature: Battery pack 0° C to 40° C
Vibration information The weighted RMS value of acceleration, to which the upper body is
subjected, is typically below 2.5 m/s2.
Adhesive label with serial number Drive unit and back of the user manual
(1) Observe the maximum load according to the wheelchair manufacturer's information.
(2) According to ISO 7176-4, the distance range depends, among other factors, on the weight of the transported person, the ground, the terrain prole, the
ambient temperature, etc.
(3) Climbing and braking ability also depend on the surface, terrain prole, ambient temperature etc.

11
4.5 Dimensional drawing
4.6 Scope of delivery
max-e drive unit
Operating unit with operating unit holder
Battery pack
Battery bag incl. Velcro tapes
Pair of wheels with toothed rings (24x1 3/8 or 20x1 3/8“)
Power cable / spiral cable 700 mm
Charger for the rechargeable battery pack
min. 300mm - max. 700mm
min. 290mm - max. 660mm
18
18
181
153
290
Für diese technische Unterlage behalten wir uns alle Rechte nach DIN 34 vor.
Ers. für
>315-1000
>120-315
>30-120
>6-30
Zust.
>0,5-6
Name Änderung Datum
±0,8
±0,5
±0,3
±0,2
±0,1
bearb.
gepr.
Werkstoff
Datum Name
Toleranzen
Zeichnungsnummer
Baugruppe
Benennung
BL.
Oberfläche
Werkstück-
kanten DIN ISO 13715
-0,3
+0,3
Maßstab
Revision
Status
AAT Alber Antriebstechnik GmbH
Rauheit
Reihe 3
22.07.2020
Kramer
Q1604
1:1
1/1
www.aat-online.de
Fax: [phone]
Tel.: [phone]
D-72458 Albstadt
Ehestetter Weg 11
A0
DIN ISO 2768-1-m / DIN ISO 2768-2-m
DIN ISO 1302
1
In Bearbeitung
Black Edition
max-e Kabel kpl.
041423
Artikelnummer
RoHS & REACH Compliant
Normen im Zeichnungsfeld vorrangig

12
4.7 Accessories
Bracket
Spoke protector
Battery pack (additional)
NOTE - Only use AAT Alber Antriebstechnik GmbH accessories.
i
Quick-release wheels with drum brake
Vehicle voltage converter 12 V / 230 V
22 Ah mega battery pack
Bag for mega battery pack
Anti-tip supports
Power cable (longer design - 900 mm)
Lighting set according to the Road Tra󰀩 c Licensing Regulation
Therapy tray installation
Bracket for the attendant control
Dotter operator
40 or 50 mm ball
Soft ball
Tetraplegic fork
Swivel arm
Accessories for the operating unit

13
5 Installation
WARNING - Never short-circuit or connect the poles of the battery pack to avoid
electric shocks!
CAUTION - Plug-in contacts must be dry!
5.2 Battery pack
5.1 Quick-release wheels
DANGER - Quick-release wheels must lock into place, as they may become detached
unexpectedly!
Position the drive wheel and
press in the quick-release
axle release button.
Adapt wheel. Let go of the quick-release
axle release button. Repeat
this process on the other side.
If the wheelchair still has the original wheels on, then remove them and attach the pair of wheels with
toothed rings that is included in the max-e’s delivery contents.
Detach the Velcro on the
battery pack pre-mounted on
the wheelchair.
Place the battery pack in
the battery bag and x with
Velcro.
Insert the power cable pre-
mounted on the wheelchair
into the battery pack’s
charging socket.

14
5.3 Drive unit
CAUTION - Plug-in contacts must be dry!
DANGER - The drive unit must be fully inserted in the bracket, as may otherwise
move unexpectedly and the drive shafts cannot be extended correctly!
Activate the parking brakes to
prevent the wheelchair from
rolling away.
Fully insert the drive unit
into the wheelchair bracket
and make sure it has been
inserted evenly.
iManufacturer information:
The width of the Delrin castor bracket is set especially for your wheelchair. If you have any questions
or need to make any changes, please contact your authorised specialised dealer, the AAT eld team or
the manufacturer.
Insert the other end of the
power cable into the left drive
unit socket.
Incorrect!
»max-e must fully lock into
place!
Manufacturer’s recommen-
dation:
Only release the parking
brakes if chapter 5 has been
carried out in full.
i

15
5.4 Operating unit
CAUTION - Plug-in contacts must be dry!
Attach the operating unit
holder.
Push the operating unit into
the bracket and secure with
the ball knob.
Plug the other end of the
spiral cable into the socket
on the control unit.
5.5 Anti-tip supports
WARNING - Never use without both anti-tip supports to prevent the wheelchair from tipping
backwards!
WARNING - Check the anti-tip supports before initial operation to ensure safety!
If anti-tip supports are not available on your wheelchair as standard, use AAT anti-tip supports in pairs!
The wheelchair bracket determines which anti-tip supports you require. The type of holder you should
attach to your wheelchair depends on the model of your wheelchair.
Option 1: Bracket with locking bolts
Remove bracket locking
bolts.
Push the anti-tip support into
the bracket and secure with
the locking pin.
Observe the “R” + “L”
markings! Repeat process
on the other side.

16
6 Starting up
Option 2: Bracket with locking pin
Press in the locking pin button
and pull it out.
Push the anti-tip support into
the bracket and secure with
the locking pin.
Observe the “R” + “L”
markings! Repeat process
on the other side.
DANGER - Operation only by a single, trained person. This person must be physically and
mentally able to safely operate max-e and may not su󰀨er from cognitive impairments!
DANGER - Never use without both anti-tip supports to prevent the wheelchair from tipping
backwards!
DANGER - Avoid parallel journeys on steep hillsides or rails, to prevent the wheelchair from
overturning!
DANGER - Cross over roads, crossroads and railway crossings with increased caution!
DANGER - Avoid driving on slopes with max-e disabled, as there is no braking e󰀨ect when
doing so!
DANGER - Do not use on escalators or travellators to avoid injuries caused by a
crash or the falling out of the occupant and the occurrence of damage to property!
WARNING - Practise outdoors on a level surface and at low speed!
WARNING - Drive down slopes at the lowest speed to avoid dangerous situations!
WARNING - Do not drive up stairs or steps to prevent the wheelchair from overturning!
WARNING - Avoid driving in heavy rain, ice, snow and on unsurfaced ground
(sand, mud, loose crushed rock) to prevent slipping!
WARNING - During driving breaks, when using local transport (busses, trams, etc.)
and when transferring, switch max-e o󰀨 and apply the parking brakes to prevent the
wheelchair from rolling away!
WARNING - When driving on public roads, observe the road tra󰀩c regulations!

17
CAUTION - Always overcome kerbs/obstacles backwards (see chapter 6.4)!
CAUTION - Maintain su󰀩cient distance to the edge of the kerb to avoid damage!
CAUTION - When using seat supports (cushions, etc.), ensure that the occupant is
securely seated to prevent the occupant from falling out or slipping!
iNOTE - Never drive backwards on walls with the anti-tip supports mounted so as not to
damage the anti-tip supports.
WARNING - Never touch rotating/moving parts (e.g. engagement of gear wheel in the toothed
ring), to prevent crushing.
WARNING - If the drive elements become blocked or when the driving behaviour
has been altered, switch o󰀨 max-e immediately and do not use it!
WARNING - Observe the maximum permissible weight (see chapter 4.4)!
Switching on the max-e.
6.1 Switching on the device
6.2 Display indicators
Start display. Activate.
Pressure builds up and the
drive shafts extend.
Standard display.
»Battery pack capacity
»Speed level
Please, switch the max-e only
after the occupant has taken
his seat.

18
Apply the brakes.
Before the drive shafts are
engaged, secure the wheel-
chair by applying the parking
brake.
Switch o󰀨.
Pressure reduces and the
drive shafts retract.
Overload warning sign.
Error messages.
(see chapter 10.2)

19
6.3 Driving with max-e
After switching on the device,
please check the battery
capacity.
»5 bars = full battery
»3 bars = battery is half-full
»1 bar = battery almost empty > please charge!
(see chapter 9.1)
Select speed.
»Practise at the lowest
speed.
»Cannot be set when
moving - only when device
is stopped.
Move the joystick in the
desired direction of travel.
» Can be moved 360° in one
go!
Horn.
iNOTE - Please refer to the chapter on warning notices, error messages and troubleshooting!
i NOTE - Display lighting switches o󰀨 if the operating unit has not been used for 20 seconds.
DANGER - When going up a slope, reduce the speed in order to prevent the wheelchair from
tilting backwards!
Emergency stop function
When you let go of the joystick the max-e stops automatically on the at surface within 1 meter1).
1) depending on the weight of the transported person, the ground, the terrain prole, etc.
In the event of an emergency situation, there is the possibility to unplug the end of the spiral cable from
the socket on the operating unit (refer to gure 4 in chapter 6.5)

20
Emergency release button
Unplug power lead (if
necessary, apply the parking
brake beforehand).
Press the emergency release
button. Pressure reduces and
the drive shafts retract.
Emergency stop function
If, while moving (joystick deected), the user presses the OFF button, the drive stops immediately
and an acoustic warning signal sounds.
• If the OFF button remains pressed, the “switch-o󰀨 notice” appears after approx. 2 seconds. The
switch-o󰀨 can be conrmed via the PLUS button. The drive is switched o󰀨.
• If the user acknowledges the “switch-o󰀨 notice” via the MINUS button, the drive remains switched
on and standing still.
• To be able to continue moving, the joystick must rst be brought to neutral position.
If the user releases the OFF button again before the 2 seconds have expired, the following will
occur:
• The drive remains standing still.
• To be able to continue moving, the joystick must rst be brought to neutral position
Standby function
• One minute prior to reaching the set switch-o󰀨 time, a "warning notice" appears on the display and
the acoustic "warning signal" sounds
• The backlight is switched on
• By deecting the joystick or by pressing the PLUS or the MINUS or the HORN button, the
warning notice will disappear again
• The timer starts again
• If the joystick is deected or one of the buttons is pressed before the “warning notice” appears,
the timer starts again
Switch-o󰀨
• When reaching the set switch-o󰀨 time, the "switch-o󰀨 notice" appears
• The acoustic "warning signal" sounds
• The backlight is switched on
• Then, the user can conrm the switch-o󰀨 via the PLUS button
• Then, the drive is switched o󰀨
• If the user acknowledges the "switch-o󰀨 notice" via the MINUS button, the drive remains
switched on and the standby timer starts again
Reminder
• If the switch-o󰀨 is not acknowledged:
• the acoustic “warning signal” sounds every minute
• the backlight is switched on
» Wheelchair can be moved
manually!
i
