LEANtouch (monochrome)
Type: 6136/30M-500
6936/30M
– Number of touch surfaces 6
(possible control pages) on Homepage
– Number of possible functions per 5
control page
– Total of operator functions 30
– Scope of time programs 5 channels, 5 switching times each
– Scope of scenes 32 scenes with max. 10 objects
(loads)
– Number of alarm signals 5
– Presence simulation max. 10 devices
– IR remote control channels 10
– Integrated room thermostat
– Child protection
– Number of logic functions 10
(AND, OR, NAND, NOR, multiplexer,
multiplier, GATE, temperature comparator)
Technical Data
Power supply – Nominal voltage 230 VAC +10%
– Bus voltage (TP only) 24 V DC
– Power consumption 10 W
Operating and display elements – Touch-sensitive display 320 x 240 pixels
16 grey shades (monochrome)
Connections – Power supply Screw plug-in terminals up to 2.5 mm²
– EIB bus connection (TP only) Screw plug-in terminals up to 1.5 mm²
– Multimedia/SD card 1 module slot at the front
Type of protection – IP 20, EN 60 529
Protection class –II
Ambient temperature range – Operation 0 °C to + 45 °C
– Storage and transport - 20°C to + 60 °C
Dimensions – Panel with cover frame 184.6 x 218 mm (H x W)
– Flush-mounted box 163.5 x 199 x 60 (H x W x D)
Weight – 0.742 kg
Certification – EIB-certified
CEnorm – in accordance with the EMC guideline
and the low voltage guideline
Functional overview
The LEANtouch panel is a high-quality
EIB touch-sensitive display. The panel
offers approx. 30 operator functions
with a monochrome display. It is used
as a control, monitoring and
indication unit for the complete EIB
installation which can be operated
across different rooms.
The touch-sensitive display is set in a
black, high-gloss frame and has
backlighting available. The integrated
loudspeaker can e.g. feed back
operations acoustically or signal
alarm and fault messages.
The panel has a pen for operation
and a slot for a multimedia/SD card.
The operation and control is carried
out in a clear menu structure via the
touch surfaces which are labelled in
clear text. The functional assignment
of the touch surfaces can be created
individually and is dependent on the
parameterisation.
All the functions of the panel are listed
in the table below “Functional
overview” (see below).

January 2005 5
ABBi-bus®EIB
ABBPowernetEIB
SMARTtouch (monochrome)
Type: 6136/100M-500
6936/100M
The SMARTtouch panel is a high-
quality EIB touch-sensitive display.
The panel offers approx. 100 operator
functions with a monochrome display.
It is used as a control, monitoring and
indication unit for the complete EIB
installation which can be operated
across different rooms.
The touch-sensitive display (either in
colour or black/white) is set in a black,
high-gloss frame and has
backlighting available. The integrated
loudspeaker can e.g. feed back
operations acoustically or signal
alarm and fault messages.
The panel has a pen for operation
and a slot for a multimedia/SD card.
The operation and control is carried
out in a clear menu structure via the
touch surfaces which are labelled in
clear text. The functional assignment
of the touch surfaces can be created
individually and is dependent on the
parameterisation.
All the functions of the panel are listed
in the table below “Functional
overview” (see below).
– Number of touch surfaces 10
(possible control pages) on Homepage
– Number of possible functions per 10
control page
– Total of operator functions 100
– Scope of time programs 20 channels, 10 switching times each
– Scope of scenes 32 scenes with max. 20 objects
(loads)
– Number of alarm signals 10
– Monitoring function Monitoring of up to 30 signalling
inputs (e.g. window contacts,
movement detectors)
– Presence simulation max. 10 devices
– IR remote control channels 10
– Integrated room thermostat
– Info function
– Timer function
– Child protection
– Number of logic functions 20
(AND, OR, NAND, NOR, multiplexer,
multiplier, GATE, temperature comparator)
Technical Data
Power supply – Nominal voltage 230 VAC +10%
– Bus voltage (TP only) 24 V DC
– Power consumption 10 W
Operating and display elements – Touch-sensitive display 320 x 240 pixels
16 grey shades (monochrome)
Connections – Power supply Screw plug-in terminals up to 2.5 mm²
– EIB bus connection (TP only) Screw plug-in terminals up to 1.5 mm²
– Multimedia/SD card 1 module slot at the front
Type of protection – IP 20, EN 60 529
Protection class –II
Ambient temperature range – Operation 0 °C to + 45 °C
– Storage and transport - 20°C to + 60 °C
Dimensions – Panel with cover frame 184.6 x 218 mm (H x W)
– Flush-mounted box 163.5 x 199 x 60 (H x W x D)
Weight – 0.742 kg
Certification – EIB-certified
CEnorm – in accordance with the EMC guideline
and the low voltage guideline
Functional overview:

6January 2005
ABBi-bus®EIB
ABBPowernetEIB
SMARTtouch (colour)
Type: 6136/100C-500
6936/100C
The SMARTtouch panel is a high-
quality EIB touch-sensitive display.
The panel offers approx. 100 operator
functions with a colour display. It is
used as a control, monitoring and
indication unit for the complete EIB
installation which can be operated
across different rooms.
The touch-sensitive display (either in
colour or black/white) is set in a black,
high-gloss frame and has
backlighting available. The integrated
loudspeaker can e.g. feed back
operations acoustically or signal
alarm and fault messages.
The panel has a pen for operation
and a slot for a multimedia/SD card.
The operation and control is carried
out in a clear menu structure via the
touch surfaces which are labelled in
clear text. The functional assignment
of the touch surfaces can be created
individually and is dependent on the
parameterisation.
All the functions of the panel are listed
in the table below “Functional
overview” (see below).
Technical Data
Power supply – Nominal voltage 230 VAC +10%
– Bus voltage (TP only) 24 V DC
– Power consumption 10 W
Operating and display elements – Touch-sensitive display 320 x 240 pixels
16 grey shades (monochrome)
Connections – Power supply Screw plug-in terminals up to 2.5 mm²
– EIB bus connection (TP only) Screw plug-in terminals up to 1.5 mm²
– Multimedia/SD card 1 module slot at the front
Type of protection – IP 20, EN 60 529
Protection class –II
Ambient temperature range – Operation 0 °C to + 45 °C
– Storage and transport - 20°C to + 60 °C
Dimensions – Panel with cover frame 184.6 x 218 mm (H x W)
– Flush-mounted box 163.5 x 199 x 60 (H x W x D)
Weight – 0.742 kg
Certification – EIB-certified
CEnorm – in accordance with the EMC guideline
and the low voltage guideline
– Number of touch surfaces 10
(possible control pages) on Homepage
– Number of possible functions per 10
control page
– Total of operator functions 100
– Scope of time programs 20 channels, 10 switching times each
– Scope of scenes 32 scenes with max. 20 objects
(loads)
– Number of alarm signals 10
– Monitoring function Monitoring of up to 30 signalling
inputs (e.g. window contacts,
movement detectors)
– Presence simulation max. 10 devices
– IR remote control channels 10
– Integrated room thermostat
– Info function
– Timer function
– Child protection
– Number of logic functions 20
(AND, OR, NAND, NOR, multiplexer,
multiplier, GATE, temperature comparator)
Functional overview:

January 2005 7
ABBi-bus®EIB
ABBPowernetEIB
SMARTtouchB&O
Type: 6136/100CB
6936/100CB
The SMARTtouch panel is a high-
quality EIB touch-sensitive display.
The panel offers approx. 100 operator
functions with a colour display. It is
used as a control, monitoring and
indication unit for the complete EIB
installation which can be operated
across different rooms.
The touch-sensitive display (either in
colour or black/white) is set in a black,
high-gloss frame and has
backlighting available. The integrated
loudspeaker can e.g. feed back
operations acoustically or signal
alarm and fault messages.
The panel has a pen for operation
and a slot for a multimedia/SD card.
The operation and control is carried
out in a clear menu structure via the
touch surfaces which are labelled in
clear text. The functional assignment
of the touch surfaces can be created
individually and is dependent on the
parameterisation.
The SMARTtouch B&O panel is
identical to the “standard”
SMARTtouch panel. In addition, it can
be controlled remotely via a Bang &
Olufsen remote control Beo4 e.g. to
retrieve a lightscene in the panel. The
SMARTtouch B&O panel can further
also be operated via the Busch-
Jaeger IR remote control.
All the functions of the panel are listed
in the table below “Functional
overview” (see below).
Technical Data
Power supply – Nominal voltage 230 VAC +10%
– Bus voltage (TP only) 24 V DC
– Power consumption 10 W
Operating and display elements – Touch-sensitive display 320 x 240 pixels
256 colours
Connections – Power supply Screw plug-in terminals up to 2.5 mm²
– EIB bus connection (TP only) Screw plug-in terminals up to 1.5 mm²
– Multimedia/SD card 1 module slot at the front
Type of protection – IP 20, EN 60 529
Protection class –II
Ambient temperature range – Operation 0 °C to + 45 °C
– Storage and transport - 20°C to + 60 °C
Dimensions – Panel with cover frame 184.6 x 218 mm (H x W)
– Flush-mounted box 163.5 x 199 x 60 (H x W x D)
Weight – 0.742 kg
Certification – EIB-certified
CEnorm – in accordance with the EMC guideline
and the low voltage guideline
– Number of touch surfaces 10
(possible control pages) on Homepage
– Number of possible functions per 10
control page
– Total of operator functions 100
– Scope of time programs 20 channels, 10 switching times each
– Scope of scenes 32 scenes with max. 20 objects
(loads)
– Number of alarm signals 10
– Monitoring function Monitoring of up to 30 signalling
inputs (e.g. window contacts,
movement detectors)
– Presence simulation max. 10 devices
– IR remote control channels 10
– Integrated room thermostat
– Info function
– Timer function
– Child protection
– Number of logic functions 20
(AND, OR, NAND, NOR, multiplexer,
multiplier, GATE, temperature comparator)
Functional overview:

8January 2005
ABBi-bus®EIB
ABBPowernetEIB
Circuit diagram
4
1
2
35
1Touch-sensitive display 320 x 240 3MMC/SD card reader
pixels, colour 4230 V power supply
2Operating pen 524 V EIB bus voltage (TP only)
Application programs Number of Max. number of Max. number of
communication objects group addresses associations
for LEANtouch/SMARTtouch panel Twisted Pair:
Panel TP/1 approx. 500 approx. 4000 approx. 4000
for LEANtouch/SMARTtouch panel Powernet:
Panel PL/1 approx. 500 approx. 4000 approx. 4000
Note Do not lead any live cables behind the
device through the flush-mounted box.
Separation of the TP bus and mains
cable!
LEANtouch (monochrome),
SMARTtouch (monochrome, colour)
Type: 6x36/30M(-500), 6x36/100x(-500), 6x36/100CB
Note If the SMARTtouch panel 6x36/100CB
should be used, there is no separate
entry for it in the ETS or Power-Project
database.
In this case, the SMARTtouch panel
6x36/100C must be used. The
difference between them is that the
SMARTtouch panel 6x36/100CB can
react to signals of the Bang&Olufson
IR remote control Beo4. (See also IR
control)

January 2005 9
ABBi-bus®EIB
ABBPowernetEIB
LEANtouch (monochrome),
SMARTtouch (monochrome, colour)
Type: 6x36/30M(-500), 6x36/100x(-500), 6x36/100CB
Installation of the supplementary
software (RCP tool) To be able to parameterise the LEAN- touch or SMARTtouch panel in ETS 2,
in ETS 3 or in Power-Project (from ver-
sion 4.0 onwards), the supplementary
softwareRCP-Toolmust be installed.
You can find this software on the EIB
productdatabase CD-ROM(art.no.
0405) or on the Internet at www.Busch-
Jaeger.de.
The software can be plugged into
ETS 2, ETS 3 and/or Power-Project.
That means that as soon as you
retrieve the parameters of a panel in
ETS or Power-Project, the panel
software is opened automatically in
which you carry out all further settings.
Before you start the installation of
the panel software, please ensure
that ETS or Power-Project has
already been installed on your
computer.
The following section describes the
individual installation steps.
An installation wizard helps you to in-
stall the panel software. This is started
by double clicking on the file
“Setup.exe” and can run in either
“German”or “English”.
The panel sofware requires at least
Windows98.Yourequire full administra-
tor rights of the operating system in or-
der to install the panel software.
Once you have confirmed the welcome
screen with “Next”, you can enter your
name and the name of your company in
the “User info” dialog. If several users
work on the computer on which you
wish to install the software, you can li-
mit access to the software. This means
that either all the users can start the
software or only you.
Theinstallation path forthe panel soft-
ware is defined in the next dialog. By
default, this is “C:\Program Files\EIB-
Programs\”. It is advisable to keep this
path as e.g. Power-Project has the
samedefault installation path.All EIB
programsand additional EIBsoftware
can thus be easily located on the hard
disk.

10 January 2005
ABBi-bus®EIB
ABBPowernetEIB
LEANtouch (monochrome),
SMARTtouch (monochrome, colour)
Type: 6x36/30M(-500), 6x36/100x(-500), 6x36/100CB
In the “Select functions” dialog, you defi-
ne whether the VD2 or VD3 files should
be copied locally onto the hard disk. You
require these to be able to use the
LEANtouch/SMARTtouch panel in con-
nection with an ETS version. (Also ob-
serve the note at the end of this chap-
ter).
By default, the files are copied into the
following directory:
C:\ProgramFiles\EIB-Programs\RCP-Tool\VDX
Once you have confirmed the “Select
functions” dialog with “Next”, the
installation wizard carries out an
initialisation. This means that all the
required files are compiled together
and stored temporarily. The dialog
“Updating the system” is shown for
visual monitoring purposes.
All the required files are then copied into
theappropriate directories. The installa-
tion is concluded with an automatic
amendmentof the Windowsregistration
entries.
The computer must be restarted depen-
ding on the operating system used.
Note
Once you have installed the panel
software, you must import the product
data (VD2 or VD3 files) in the ETS
database if you wish to parameterise a
panelwith ETS.
To do so, please retrieve the ETS im-
port tool (ETS 2 or ETS 3) and import
the VD2 (ETS 2) or VD3 files (ETS 3)
from the default directory
C:\Program Files\EIB-Programs\RCP-
Tool\VDX.
You must import the VD2 or VD3 files
in full.
Caution:
The import of individual files is not
possible.
Commissioning a panel
The commissioning of a panel is
possible either via a multimedia/SD
card (not included) or with “standard”
bus programming.
Due to the high level of functionality,
full programming via the bus takes a
long time depending on the
configuration and medium (Twisted
Pair or Powernet). The use of the
multimedia/SD card is therefore
recommended for quick and simple
commissioning. It is not advisable to
carry out full bus programming via
Powernet.
Themenu item“Download”of the com-
missioning tool therefore has two furt-
her submenus via which the user can
selectthe requiredcommissioningme-
thod.If heselectsprogramming via mul-
timedia card, the configuration is stored
on a card which is connected to the PC.
With a project that is saved in this
way, the panel itself can be
commissioned by inserting the card.
The slot for the multimedia/SD card is
located behind the chrome flap of the
panel.
Several projects can be stored on one
multimedia card. After inserting the
card in the panel, the user can select
the required project which should be
loaded into the panel.
