Operating Instructions
Busch-AudioWorld®Installation and electrical
connection
Operating Instructions | 1473-1-8365 — 8 —
Pos:33 /#Neustruktur#/Online-Dokumentation(+KNX)/Überschriften (-->Für alle Dokumente<--)/1. Ebene/M - O/Mon tage und elektrischer Anschluss @ 23\mod_1336 477157864_15.docx @ 209033 @ 2211 @ 1
6 Installation and electrical connection
Pos:34 /#Neustruktur#/Online-Dokumentation(+KNX)/Überschriften (-->Für alle Dokumente<--)/2. Ebene/M - O/Mon tage @ 18\mod_130261596045 8_15.docx @ 103424 @ 11111 @ 1
6.1 Mounting
Pos: 35 /#Neustruktur #/Online-Dokumen tation (+KNX)/Sic herheitshinweise und Hinweise (--> Für alleDokumente<--)/Warnhinweise/Sicherheit- Niederspannu ngs- und 230 V-Leitungen @ 23\ mod_1336558868201_15. docx @ 209164 @ 222 @ 1
Warnin
Electric voltage!
Risk of death due to electrical voltage of 230 V during short-circuit in the low-voltage line.
– Low-voltage and 230 V lines must not be installed together in a flush-mounted socket!
Pos: 36 /#Neustruktur #/Online-Dokumen tation (+KNX)/Sic herheitshinweise und Hinweise (--> Für alleDokumente<--)/Warnhinweise/Sicherheit- Fachkenntnisse @ 23\mod_1336 559183027_15.doc x@ 209 179 @ 111 @ 1
6.2 Requirements for the electrician
Warnin
Electric voltage!
Install the device only if you have the necessary electrical engineering knowledge and experience.
• Incorrect installation endangers your life and that of the user of the electrical system.
• Incorrect installation can cause serious damage to property, e.g. due to fire.
The minimum necessary expert knowledge and requirements for the installation are as follows:
• Apply the "five safety rules" (DIN VDE 0105, EN 50110):
1. Disconnect from power;
2. Secure against being re-connected;
3. Ensure there is no voltage;
4. Connect to earth and short-circuit;
5. Cover or barricade adjacent live parts.
• Use suitable personal protective clothing.
• Use only suitable tools and measuring devices.
• Check the supply network type (TN system, IT system, TT system) to secure the following
power supply conditions (classic connection to ground, protective earthing, necessary
additional measures, etc.).
Pos: 37 /#Neustruktur #/Online-Dokumen tation (+KNX)/Montage/ alle Geräte/Montag e - UP-Dosen - DIN 49073-1 oder geei gnetes Aufputzg ehaeuse - Ohne Docvariable @ 25\ mod_1340354979636_15. docx @ 219890 @ 22 @ 1
The flush-mounted insert must only be installed in flush-mounted wall boxes according to DIN 49073-1, Part 1, or
suitable surface-mounted housings.
