ABB COM600 series Manual

COM600 Station Automation Series
COM605 3.1
Operator's Guide

Contents:
1. About this manual .................................................................................. 5
1.1. Copyrights ...................................................................................... 5
1.2. Trademarks .................................................................................... 5
1.3. General .......................................................................................... 5
1.4. Use of symbols .............................................................................. 5
1.5. Document conventions .................................................................. 6
1.6. Terminology .................................................................................... 7
1.7. Abbreviations ................................................................................. 7
1.8. Related documents ........................................................................ 8
1.9. Document history ........................................................................... 8
2. Introduction ............................................................................................. 9
2.1. Product overview ........................................................................... 9
3. HMI operations ...................................................................................... 10
3.1. General about HMI ....................................................................... 10
3.2. Predefined user account .............................................................. 10
3.3. User management ....................................................................... 10
3.3.1. General about managing users ..................................... 10
3.3.2. Adding new users ......................................................... 11
3.3.3. Modifying user properties .............................................. 12
3.3.4. Changing user's password ............................................ 13
3.4. Connecting HMI to the COM600 computer .................................. 14
3.5. Substation and communication structures ................................... 14
3.5.1. Substation structure ...................................................... 14
3.5.2. Communication structure .............................................. 16
3.6. Single Line Diagram ..................................................................... 17
3.6.1. General about Single Line Diagram .............................. 17
3.6.2. Switch Device Control ................................................... 17
3.6.3. Tap Changer ................................................................. 19
3.6.4. Busbar coloring ............................................................. 21
3.7. Alarms .......................................................................................... 22
3.7.1. General about alarms ................................................... 22
3.7.2. Monitoring and handling alarms .................................... 23
3.7.3. Acknowledging alarms .................................................. 23
3.7.4. Filtering alarms ............................................................. 23
3.8. Events .......................................................................................... 24
3.8.1. General about events .................................................... 24
3.8.2. Monitoring and handling events .................................... 24
3.8.3. Filtering events .............................................................. 25
3.9. Disturbance data upload .............................................................. 26
3.9.1. Disturbance recordings ................................................. 26
3.10. Parameter setting ......................................................................... 27
3.10.1. Changing parameters ................................................... 27
3
COM605 3.1
COM600 Station Automation Series1MRS756121
Operator's Guide
Issued: 16.10.2006
Version: D/21.12.2007

3.11. Measurements ............................................................................. 28
3.11.1. Viewing measurements ................................................. 28
Appendix 1 ................................................................................................... 29
Single Line Diagram symbols ................................................................. 29
Index .............................................................................................................. 33
4
1MRS756121
COM600 Station Automation Series
COM605 3.1
Operator's Guide

About this manual1.
Copyrights1.1.
The information in this document is subject to change without notice and should not be
construed as a commitment by ABB Oy. ABB Oy assumes no responsibility for any
errors that may appear in this document.
In no event shallABB Oy be liable for direct, indirect, special, incidental or consequential
damages of any nature or kind arising from the use of this document, nor shallABB Oy
be liable for incidental or consequential damages arising from use of any software or
hardware described in this document.
This document and parts thereof must not be reproduced or copied without written per-
mission from ABB Oy, and the contents thereof must not be imparted to a third party
nor used for any unauthorized purpose.
The software or hardware described in this document is furnished under a license and
may be used, copied, or disclosed only in accordance with the terms of such license.
©Copyright 2006 ABB. All rights reserved.
Trademarks1.2.
ABB is a registered trademark ofABB Group.All other brand or product names men-
tioned in this document may be trademarks or registered trademarks of their respective
holders.
General1.3.
This manual provides thorough information on the Control and Monitoring Unit COM605
and the central concepts related to it. For more information on each topic related to a
specific protocol, refer to the list of related documents in 1.8, Related documents.
Information in this operator's guide is intended for operators who perform every-day
operations.
Use of symbols1.4.
This publication includes warning, caution, and information icons that point out safety
related conditions or other important information. It also includes tip icons to point out
useful information to the reader. The corresponding icons should be interpreted as follows.
5
COM605 3.1
COM600 Station Automation Series
1MRS756121
Operator's Guide

The electrical warning icon indicates the presence of a hazard
which could result in electrical shock.
The warning icon indicates the presence of a hazard which
could result in personal injury.
The caution icon indicates important information or warning
related to the concept discussed in the text. It might indicate
the presence of a hazard which could result in corruption of
software or damage to equipment or property.
The information icon alerts the reader to relevant facts and
conditions.
The tip icon indicates advice on, for example, how to design
your project or how to use a certain function.
Document conventions1.5.
The following conventions are used for the presentation of material:
•The words in names of screen elements (for example, the title in the title bar of a
window, the label for a field of a dialog box) are initially capitalized.
•Capital letters are used for the name of a keyboard key if it is labeled on the keyboard.
For example, press the ENTER key.
•Lowercase letters are used for the name of a keyboard key that is not labeled on the
keyboard. For example, the space bar, comma key, and so on.
•Press CTRL+C indicates that you must hold down the CTRL key while pressing
the C key (to copy a selected object in this case).
•Press ESC E C indicates that you press and release each key in sequence (to copy
a selected object in this case).
•The names of push and toggle buttons are boldfaced. For example, click OK.
•The names of menus and menu items are boldfaced. For example, the File menu.
•The following convention is used for menu operations: MenuName > Menu-
Item > CascadedMenuItem. For example: select File > New > Type.
•The Start menu name always refers to the Start menu on theWindows taskbar.
•System prompts/messages and user responses/input are shown in the Courier font.
For example, if you enter a value out of range, the following message is displayed:
6
1MRS756121
COM600 Station Automation Series
COM605 3.1
Operator's Guide

Entered value is not valid. The value must be 0 to 30.
•You may be told to enter the string MIF349 in a field.The string is shown as follows
in the procedure:
MIF349
•Variables are shown using lowercase letters:
sequence name
Terminology1.6.
The following is a list of terms associated with the Control and Monitoring Unit COM605
that you should be familiar with. The list contains terms that are unique to ABB or have
a usage or definition that is different from standard industry usage.
DescriptionTerm
An abnormal state of a condition.Alarm
An OPC service for providing information about alarms and
events to OPC clients.
Alarms and Events; AE
A physical device that behaves as its own communication node
in the network, e.g. protection relay.
Device
Change of process data or an OPC internal value. Normally, an
event consists of value, quality and timestamp.
Event
A physical IEC 61850 device that behaves as its own commu-
nication node in the IEC 61850 protocol.
Intelligent Electronic Device
Series of standards specifications aiming at open connectivity
in industrial automation and the enterprise systems that support
industry.
OPC
Named data item.Property
Abbreviations1.7.
The following is a list of abbreviations associated with the Control and Monitoring Unit
COM605 that you should be familiar with. See also 1.6, Terminology.
DescriptionAbbreviation
Alarms and EventsAE
Communication Engineering ToolCET
Data ObjectDO
Gateway, component connecting two communication networks togetherGW
7
COM605 3.1
COM600 Station Automation Series
1MRS756121
Operator's Guide

DescriptionAbbreviation
Human Machine InterfaceHMI
International Electrotechnical CommissionIEC
Intelligent Electronic DeviceIED
Local Area NetworkLAN
Single Line DiagramSLD
Related documents1.8.
MRS numberName of the manual
1MRS756125COM600 3.1 User’s Guide
Document history1.9.
HistoryProduct revisionDocument version/date
Document created3.0A/16.10.2006
Document revised3.0B/22.1.2007
Document revised3.0C/8.6.2007
Document revised3.1D/21.12.2007
8
1MRS756121
COM600 Station Automation Series
COM605 3.1
Operator's Guide

Introduction2.
Product overview2.1.
Product functionalities
Control and Monitoring Unit COM605 allows easy access to the protection and control
devices of a substation with HMI functionality. The substation can be accessed either
locally or remotely through a built-in web server.
COM605 uses an embedded operating system and runs in a dedicated industrial computer
without moving parts.
The products are configured using a separate engineering PC that is connected via the
local area network (LAN). For more information, refer to COM600 User's Guide.
HMI functionality
The features of HMI include a Single Line Diagram, Busbar coloring, lists of events and
alarms, disturbance data upload, system supervision, control of breakers and switches,
parameter settings, measurement display, and user management.
9
COM605 3.1
COM600 Station Automation Series
1MRS756121
Operator's Guide

HMI operations3.
General about HMI3.1.
The HMI interface consists of different views, a menu bar and a tool bar.
You can choose between views by clicking the tabs on the left:
•Substation: Shows the substation structure.
•Communication: Shows the communication structure.
•Users: (Only administrator) Shows the user information. The administrator can
manage users in this view.
•Settings: (If not administrator) Shows the user information. The user can change
the password in this view.
The Menu bar contains the following functions:
•General: Shows device information.
•Single Line Diagram: Shows the Single Line Diagram view.
•Events: Shows the events list.
•Alarms: Shows the events list.
•Help: Shows the HMI help.
•Logout: Logs you out of the window.
Predefined user account3.2.
HMI has a predefined user account with administrator rights.
•User name: admin
•Password: adminadmin
When you log in for the first time as an administrator, you have to change the password
before you can proceed using HMI. If you forget the new password, restore the factory
settings with the Management tool in CET.After the factory settings have been restored,
you can only log in with the predefined administrator password mentioned above.
User management3.3.
General about managing users3.3.1.
COM605 has the following user levels:
•Viewer = Only allowed to view
•Operator = Authorized to make operations
•Engineer = Allowed to change IED parameters, but no operation rights
•Administrator = Full access
10
1MRS756121
COM600 Station Automation Series
COM605 3.1
Operator's Guide

The administrator can add users and define access rights with the User Management
tool.
The user levels of the selected user are displayed in the User Information view and they
can be modified by the administrator.
The purpose of the user groups is mainly to provide customized user interfaces for dif-
ferent users.
AdministratorsEngineersOperatorsViewersFunctionality
XXXXSLD
XviewXviewControl Dialogs
XXXXEvent list
XviewXviewAlarm list
X*1*1*1User manage-
ment
XXviewviewPST
XXXviewDisturbance
recording
XXXviewSystem supervi-
sion
*1: Can change own password.
view: view-only.
Adding new users3.3.2.
The administrator can add users in the Add User window.
To add a new user:
1. Click on the Users tab on the left.
2. Select Add User.
3. Type in a new user name. The length of the user name can be 1 - 99 characters and
it can only contain characters a - z and 0 - 9.
4. Type in a password and confirm it. The length of the password can be 9 - 99 charac-
ters and it can only contain characters a - z and 0 - 9.
5. Select a user group from the drop-down menu.
6. Click Apply to save the user information.
11
COM605 3.1
COM600 Station Automation Series
1MRS756121
Operator's Guide

Figure 3.3.2-1 Adding new users
Modifying user properties3.3.3.
Only an administrator can modify user properties.
You can modify user information by using the tool bar on top of the User Information
view.
To remove a user:
1. Click on the Users tab on the left.
2. Select the user you want to remove.
3. Click Remove User and confirm by clicking OK.
To change a user's user group:
1. Click on the Users tab on the left.
2. Select the user whose user group you want to change.
3. Click Change User Group.
4. In the Change User's Group view, select a new group from the drop-down menu.
5. Click Apply.
12
1MRS756121
COM600 Station Automation Series
COM605 3.1
Operator's Guide

Figure 3.3.3-1 Changing user's group
Changing user's password3.3.4.
To change the password (administrator):
1. Click on the Users tab on the left.
2. Select the user whose password you want to change.
3. Click Change password.
4. Type in a new password and confirm it.
5. Click Apply.
Figure 3.3.4-1 Changing user's password (administrator)
To change your own password:
1. Click on the Settings tab on the left.
2. Click Change password.
3. Type in the old password.
4. Type in a new password and confirm it.
5. Click Apply.
13
COM605 3.1
COM600 Station Automation Series
1MRS756121
Operator's Guide

Figure 3.3.4-2 Changing user's password (not administrator)
Connecting HMI to the COM600 computer3.4.
To connect HMI to the COM600 computer:
1. Open Internet Explorer.
2. Type in the IP address of the COM600 computer.
3. Accept the certificate.
4. A login window opens. Type in the password and log in.
Substation and communication structures3.5.
Substation structure3.5.1.
You can open the substation view of HMI by clicking on the Substation tab on the left.
The substation structure displays the substation and voltage level objects, bays and IEDs,
and their functions.
You can see the status of the IEDs in the substation structure. If there is a problem in
communication, there is a red cross next to the IED.
14
1MRS756121
COM600 Station Automation Series
COM605 3.1
Operator's Guide

Figure 3.5.1-1 The substation view to HMI
Alarm and event information
By clicking on the voltage level and bay objects, you can access their specific alarm
lists. To look at a list of events, click on View Events above the Persisting Alarms list.
IED information
By clicking on the IED objects you can view their communication status and information
on diagnostic counters. Below each IED in the substation structure you can click on
Disturbances, Parameters or Measurements to access the corresponding data.
It depends on the IED configuration, whether Disturbances,
Parameters or Measurements are shown in the substation
structure.
15
COM605 3.1
COM600 Station Automation Series
1MRS756121
Operator's Guide

Communication structure3.5.2.
You can open the communication view of HMI by clicking on the Communication tab
on the left. The communication structure is displayed in the window on the left. In the
communication structure you can see the OPC Server, communication channel objects
and the IEDs.
You can see the status of the IEDs in the communication structure. If there is a problem
in communication, there is a red cross next to the IED.
Figure 3.5.2-1 The communication view to HMI
Device and diagnostics information
By clicking on the computer name at the top of the structure, you can see its device
information, such as the hardware and software versions, in the window on the right side
of the tree. By clicking on the OPC Server object name, corresponding device information
is displayed on the right.You can view device diagnostics information of the whole
subnetwork by clicking on the subnetwork object. To see the communication status or
diagnostic counter information of individual devices, click on the IED objects.
16
1MRS756121
COM600 Station Automation Series
COM605 3.1
Operator's Guide

Single Line Diagram3.6.
General about Single Line Diagram3.6.1.
A Single Line Diagram (SLD) is a graphical user interface presenting process objects
(primary devices) of the substation as graphical symbols. HMI updates the SLD and the
substation and communication structures at regular intervals. A sample SLD is shown
in Figure 3.6.1-1
Figure 3.6.1-1 An example of the Single Line Diagram
For an explanation of the Single Line Diagram symbols, see Appendix 1 , Single Line
Diagram symbols.
Switch Device Control3.6.2.
Switches (circuit breakers, disconnectors) can be operated using the Switch Device
Control dialog.
Only operators and administrators are allowed to control the
switches.
17
COM605 3.1
COM600 Station Automation Series
1MRS756121
Operator's Guide

The station and bay local/remote switch must be in a position which allows it to be
controlled with HMI. The target switch device must also support the operation and it
must be configured properly.
To control a switch device (for example circuit breaker), click the object in the single
line diagram. The Switch device control dialog opens.
The Switch state tab displays information on the substation, voltage level and bay under
operation and the object name of the switch device.Also status information for example
on the interlockings and selection state of the object are displayed.
To control a switch:
1. Select the control direction by clicking Open or Close.
2. Click Operate to activate the selection or Cancel to cancel the operation. Note that
some of the buttons may be disabled depending on the state of the switch.
It is possible to perform a forced cancel operation. This is necessary for example if HMI
is accidentally closed after you have activated a selection. Normally the object would
stay in the selected position until timeout, and the object must be released if any operations
have to be performed before timeout. To perform a forced operation, select the Forced
operation tab of the Switch device control dialog and click Cancel.
To add, edit or delete web links, select the Web links tab and click Edit.
To close the Switch device control dialog, click Exit.
18
1MRS756121
COM600 Station Automation Series
COM605 3.1
Operator's Guide

Figure 3.6.2-1 Switch Device Control dialog
Tap Changer3.6.3.
Clicking a power transformer with tap changer opens a control dialog. In the dialog you
can monitor the voltage and the current tap changer position.
19
COM605 3.1
COM600 Station Automation Series
1MRS756121
Operator's Guide

Figure 3.6.3-1 Tap Changer Control dialog
Depending the device and the configuration, you can manually lower or raise the relative
position of the tap changer or assign a specific position by entering a numeric value.
You must have the required user permissions to perform these
changes, and local/remote switch must allow the operation.
The tap changer must also be be in manual operating mode.
The Operation mode tab shows the auto/manual and single/parallel operation modes
of the tap changer.You can change the modes of the tap if you have the required user
permissions. The operation modes must be supported by the IED support and allowd by
the local/remote. If they are not, the options are not available in the dialog.
20
1MRS756121
COM600 Station Automation Series
COM605 3.1
Operator's Guide
