ABB MagMaster User manual

Controls and Display
Upper display gives continual update of flow rate in
selected units.
By pressing the key, the lower display steps through
the following sequence:
>Forward flow total value.
<Reverse flow total value
*Net flow total value
Alm Active alarms – Any alarms are displayed
sequentially if more than one alarm is present.
'AlmClr'isdisplayedwhennoalarmsarepresent.
Vel Flow Velocity
%% of Flow Range.
Pressingthe keyresetstheflowtotaldisplayed on the
upper display, if parameter 'Tot Clr En' is enabled.
Pressing the key accesses the Login Parameter
where it is necessary to enter a security code before any
other parameters can be accessed – see SECURITY
ACCESS.
Snsr Fact 1
Snsr Fact 2
Snsr Fact 3
Snsr Fact 4
Inpt Mtsnsr Trip
Mtsnsr mv Snsr No
Snsr Tag
Snsr Size
Snsr Vel
Inpt Idle Test Mode
Test Flow
Test %
Test Hz
Test mA
Test Vel
Test Alm
Test Txv
Disp Res Login Key 1
Login Key 2
Return to 'Flow Rng' Page
Disp Mode
Alm Trip Hi
Alm Trip Lo
Alm Trip Hyst
Alm Trip Disp
Flow Rng
Flow Unit
Flow Mult
Flow Time
Flow Rspns
Flow %
Flow Probe Ins
Flow Probe Prf
Anlg Fsd
Anlg Zero
Anlg No2
Anlg mA
Anlg Dir Fwd
Anlg Dir Rev
Pls Fact
Pls Cutoff
Pls Max
Pls Hz
Pls Idle
Pls Size
Alm No1 Idle
Alm No1 En
Alm No1 Fault
Alm No1 Fwd
Alm No1 Rev
Alm No1 Cutoff
Alm No1 Mtsnsr
Alm No1 Hi
Alm No1 Lo
Alm No1 Anlg
Alm No1 Pls
Tot Unit
Tot Mult
Tot ClrEn
Alm No2 Idle
Alm No2 En
Alm No2 Fault
Alm No2 Fwd
Alm No2 Rev
Alm No2 Cutoff
Alm No2 Mtsnsr
Alm No2 Hi
Alm No2 Lo
Alm No2 Anlg
Alm No2 Pls
Press moves
Flow Cutoff Key
Security Level 1
Security Level 2
Press
moves
CONTROLS AND DISPLAY MENU LAYOUT …MENU LAYOUT
Two security code levels, 1 and 2, are available, and are
each accessed with a five digit number.
User Code Level 1 default number is 10760.
Engineer Code Level 2 default number is 56360.
Parameters accessible by the two levels are shown
above.
At the flashing cursor on the first digit of the Login code
number, press either or membrane switches to
reach the required digit.
Tosetthis digit and pass to the nextdigit,depress the
switch. Continue until all digits have been set, and
depress the switch to enter the complete code.
If an incorrect value is entered, access to subsequent
programming pages is prevented and the display reverts
to the Operating Page.
Quick Reference Guide
Kent -Taylor
MagMaster
ASEABROWN BOVERI
MagMasterTM
Electromagnetic
Flowmeters
Keypad Version
A – Advancing to Next Page
Parameter 1
Parameter 2
Parameter 3
Parameter 4
Page 1 Parameter 1 Page 2
Advance to
next page
or
B – Moving Between Parameters
Parameter 1
Parameter 2
Parameter 3
Parameter 4
Advance to
next parameter
Parameter 5
Parameter 6
Parameter 2
Membrane
Switches Resets totaliser, if parameter
'Tot Clr En' is enabled
Upper
Display
Lower
Display
MagMasterKent-Taylor
32.8
Ltr/s
>42315
SECURITY ACCESS
IM/MM-QRG Iss 1 5/96
CONTROLS AND DISPLAY
Depressing this switch for 5 seconds and then releasing
itwillexitthemenusystemand returnto normaloperating
mode.
ASEA BROWN BOVERI
ABB Kent-Taylor Oldends Lane, Stonehouse, Gloucestershire, England GL10 3TA
Telephone: [phone], Facsimile: 01453 826358
C – Adjusting and Storing a Parameter Value
New value is
automatically stored
Parameter Value
or unit
Adjust
D – Selecting and Storing a Parameter Choice
Parameter X
Y
Z
Select
New value is
automatically stored
Advance to next digit

Flow Rng
Flow Unit
5.00000
m^3/Hr
PROGRAMMING ANALOG OUTPUT
Display Setting
2
3
4
5
6
7
8
9
Seconds
2
3
4
8
15
30
60
120
Caution.Access is NOT possible without the
correct password. 'Lost' passwords can ONLY be
reset by the Service Engineer.
PARAMETER DESCRIPTION
Alarm No1 Idle Idle state for alarm output.
With no alarm active:
0 = Low (O/P transistor ON)
1 = High (O/P transistor OFF)
Alm No1 En 0 = Alarm output disabled (set to
idle state).
1 = Alarm output enabled.
Alm No1 Fault Alarm occurs for System fault.
Alm No1 Fwd Alarm occurs for forward flow.
Alm No1 Rev Alarm occurs for reverse flow.
Alm No1 Cutoff Alarm occurs for Pulse Output
Cutoff.
Alm No1 Mtsnsr Alarm occurs for empty sensor.
Alm No1 Hi Alarmoccurs forFlow ≥‘AlmTripHi’.
Alm No1 Lo Alarm occurs for Flow ≤‘Alm Trip Lo’.
Alm No1 Anlg Alarm occurs for Analogue Output
over range.
Alm No1 Pls Alarmoccursfor Pulse Output over
range.
PARAMETER DESCRIPTION
Tot Unit Select totaliser measurement units.
Tot Mult Select multiplier units required.
Tot ClrEn Enter '1' to enable totaliser reset
function to be used from front panel.
PARAMETER DESCRIPTION
Inpt Set up external logic input function:
'Zero' sets flowrate output to zero.
'Hld' holds flowmeter output value.
'Clr' resets all totalizers.
'Anlg' selects Anlg No2 Range.
Inpt Idle Enterinactivestate of input contact:
'1' for Hi normal
'0' for Lo normal. SECURITY PASSWORD
Login Key 1 Set Level 1 security password.
Login Key 2 Set Level 2 security password.
#The maximum which can be entered must not exceed
21000. The value entered may be displayed with a small
error in the decimal digits e.g. 1.900 may be displayed as
1.899. This is a display characteristic and the value 1.900
will be used by the MagMaster.
§Select both parameters for bidirectional operation (e.g.
when dual current output is fitted). If both are zero, then IOUT
is always 0%.
‡On performing a Rapid Reset/Escape to return to
'Operation' level, 'Test Mode' is automatically cancelled.
ØIf the sensor is empty or disconnected, the alarms
'MtSnsr' and 'Coil' will be displayed as appropriate.
PARAMETER CHANGES FLOW MEASUREMENT
When a parameter is selected, which holds one or more
variable units e.g. 'Flow Unit' parameter which can be
Liters, Cubic meters, Gallons etc., proceed as follows to
change the units: ('Flow Rng' selected).
'Flow Unit' selected
Press or switch to change the units.
✶
Note. The existing units will flash at the first
depression of the or switch, and further
switch depressions will change the type of units
displayed.
Depressing the switch will now enter the newly
selected units.
This type of action is similar for all variable units.
Where numerical values are to be changed, initial
depression of the or switches cause the first of
five digits to be highlighted by a flashing cursor. Change
the value with the and switches, the particular
digit with the switch, and enter the final selection with
the switch.
The correct security level MUST be selected – see
SECURITY ACCESS.
Select the parameter to read the value, or to change it as
necessary. All ‘live’ data displayed is updated each
second.
Use the key to move between pages.
Use the key to move between parameters.
The and keys change displayed values and units.
The key will accept the chosen value or unit.
PARAMETER DESCRIPTION
Flow Range Enter main full scale (100%) flow
range (Upper Range Value) in
selected flow units. #
Flow Unit Select Units as required.
Ltr (Liters)
m^3 (Cubic Meters)
IGal (Imp Gals)
UGal (U.S. Gals)
ft^3 (Cubic Feet)
Flow Mult Select multiplier as required.
m(0.001)
c(0.01)
x1 (1)
h(100)
k (1000)
M(1000000)
Flow Time Select time units as required.
s(Second)
Min (Minute)
Hr (Hour)
Dy (Day)
Wk (Week)
Flow Resp Nominal Time Constant for output.
Enter Display Setting from table
below for time constant required.
Flow % Present flow as % of range.
Flow Probe Ins Probe Insertion Factor.
Flow Probe Prf Probe Profile Factor
Flow Cutoff Flow velocity in mm/sec. below
which flow set to 0.
PARAMETER DESCRIPTION
Anlg Fsd Enter output current in mA for 100%
flow (0 ≤FSD ≤21)
Anlg Zero Enter output current in mA for 0%
flow (0 ≤ZERO ≤21)
Anlg No2 Full scale flow range for 2nd analog
range, as % of main flow range.
Anlg mA Present output current (mA)
Anlg Dir Fwd Output responds to forward
flow if set to '1'. §
Anlg Dir Rev Output responds to reverse
flow if set to '1'. §
OUTPUT PULSE
PARAMETER DESCRIPTION
Pls Fact Enter required output pulses per
flow volume unit.#
Pls Cutoff Flow rate (%) below which pulse
output and totaliser cease to operate.
Pls Max Maximum output frequency in Hz.
Pls Hz Display of present output frequency in
Hz (live value).
Pls Idle Idle state for Pulse Output with no
output pulse (e.g. at zero flow).
0 = Low (output transistor ON)
1 = High (output transistor OFF)
Pls Size Enter output pulse width in msecs.
(Value will be rounded up to nearest
10ms). Set to ‘0’ for square wave
output.
ALARMS (CONTD.)
PARAMETER DESCRIPTION
Alarm No2 Idle Identical to, but independent of
Alarm No1 above.
Alarm No2 Pls Alarm occurs for Pulse Output
over range.
TEST MODE
PARAMETER DESCRIPTION
Disp Res Enter number of decimal places
required on flow display (0 to 5).
Disp Mode Serial Communication display
mode (Read Only) – attempts to
edit this parameter result in display
of 'Keypad Version No.' with
eventual return to normal
operation.
DISPLAY RESOLUTION
PARAMETER DESCRIPTION
Test Mode Set to '1' to enable.
Test Flow Displays present flowrate.
If in 'Test Mode', any value may be
entered manually. ‡
Test % Flowrate as a percentage
Test Hz Output Frequency
Test mA Output Current
Test Vel Flow Velocity in sensor
Test Alm Shows present active alarms
sequentially. ('Clr' indicates no
alarms are active). Ø
Test Txv Live flow velocity (uncorrected for
sensor calibration).
SENSOR CALIBRATION
PARAMETER DESCRIPTION
Snsr No Serial No. (Up to 13 characters)
Snsr Tag Tag No. (If required).
Snsr Size Sensor calibrated bore (mm).
Snsr Vel Display of present velocity.
Snsr Fact 1
Snsr Fact 2 Sensor calibration data –
Snsr Fact 3 should agree with sensor data label
Snsr Fact 4
PARAMETER DESCRIPTION
Mtsnsr Trip Set empty pipe detector trip
threshold.
Mtsnsr mV Measured value related to fluid
conductivity.
ALARMS EMPTY PIPE DETECTION
PARAMETER DESCRIPTION
Alarm trip Hi High flow alarm trip point as % of
range.
Alarm Trip Lo Low flow alarm trip point as % of
range.
Alm Trip Hyst Enter hysteresis for alarms as % of
range.
Alm Trip Disp Set to ‘1’ if Hi/Lo Alarms are to be
displayed.
INPUT CONTACT
TOTALIZER
