ABB Relion REB500 Quick start guide

Substation Automation Products
Distributed busbar protection REB500
Commissioning Manual

Document ID: 1MRK 505 351-UEN
Issued: March 2016
Revision: -
Product version: 8.2
© Copyright 2016 ABB. All rights reserved

Copyright
This document and parts thereof must not be reproduced or copied without written
permission from ABB, and the contents thereof must not be imparted to a third
party, nor used for any unauthorized purpose.
The software and hardware described in this document is furnished under a license
and may be used or disclosed only in accordance with the terms of such license.
Trademarks
ABB and Relion are registered trademarks of the ABB Group. All other brand or
product names mentioned in this document may be trademarks or registered
trademarks of their respective holders.
Warranty
Please inquire about the terms of warranty from your nearest ABB representative.
ABB AB
Substation Automation Products
SE-721 59 Västerås
Sweden
Telephone: [phone]
Facsimile: [phone]
http://www.abb.com/substationautomation

Disclaimer
The data, examples and diagrams in this manual are included solely for the concept
or product description and are not to be deemed as a statement of guaranteed
properties. All persons responsible for applying the equipment addressed in this
manual must satisfy themselves that each intended application is suitable and
acceptable, including that any applicable safety or other operational requirements
are complied with. In particular, any risks in applications where a system failure
and /or product failure would create a risk for harm to property or persons
(including but not limited to personal injuries or death) shall be the sole
responsibility of the person or entity applying the equipment, and those so
responsible are hereby requested to ensure that all measures are taken to exclude or
mitigate such risks.
This document has been carefully checked by ABB but deviations cannot be
completely ruled out. In case any errors are detected, the reader is kindly requested
to notify the manufacturer. Other than under explicit contractual commitments, in
no event shall ABB be responsible or liable for any loss or damage resulting from
the use of this manual or the application of the equipment.

Conformity
This product complies with the directive of the Council of the European
Communities on the approximation of the laws of the Member States relating to
electromagnetic compatibility (EMC Directive 2004/108/EC) and concerning
electrical equipment for use within specified voltage limits (Low-voltage directive
2006/95/EC). This conformity is the result of tests conducted by ABB in
accordance with the product standards EN 50263 and EN 60255-26 for the EMC
directive, and with the product standards EN 60255-1 and EN 60255-27 for the low
voltage directive. The product is designed in accordance with the international
standards of the IEC 60255 series.

Safety information
Dangerous voltages can occur on the connectors, even though the
auxiliary voltage has been disconnected.
Non-observance can result in death, personal injury or substantial
property damage.
Only a competent electrician is allowed to carry out the electrical
installation.
National and local electrical safety regulations must always be
followed.
The frame of the IED has to be carefully earthed.
This is a class A ITE product. In a domestic environment this
product may cause radio interference in which case the user may be
required to take adequate measures.
Whenever changes are made in the IED, measures should be taken
to avoid inadvertent tripping.
The IED contains components which are sensitive to electrostatic
discharge. Unnecessary touching of electronic components must
therefore be avoided.

Table of contents
Commissioning Manual 1
Distributed busbar protection REB500
Table of contents
Section 1 Introduction.................................................................3
1.1 This manual.................................................................................... 3
1.2 Intended audience .......................................................................... 3
1.3 Product documentation................................................................... 3
1.4 Symbols and conventions ............................................................... 4
1.4.1 Symbols..................................................................................... 4
1.4.2 Document conventions............................................................... 5
Section 2 Commissioning...........................................................6
2.1 Preconditions.................................................................................. 6
2.2 Commissioning procedure............................................................... 7
2.2.1 Overall procedure ...................................................................... 7
2.2.2 Commissioning with a partial system.......................................... 8
2.2.3 Comparison with the layout of the primary system...................... 8
2.2.4 Checking the analog inputs (CTs).............................................. 9
2.2.5 Checking the analog inputs (VTs)............................................... 9
2.2.6 Checking the binary input signals (optocoupler inputs) ............... 9
2.2.7 Checking the binary output signals........................................... 11
2.2.8 Checking protection stability..................................................... 12
Section 3 Maintenance.............................................................15
3.1 Periodic Maintenance.................................................................... 15
3.2 Replacing units............................................................................. 15

1MRK 505 351-UEN Section 1
Introduction
Commissioning Manual 3
Distributed busbar protection REB500
Section 1 Introduction
1.1 This manual
The commissioning manual contains instructions on how to commission the IED.
The manual can also be used by system engineers and maintenance personnel for
assistance during the testing phase. The manual provides procedures for checking
of external circuitry and energizing the IED, parameter setting and configuration as
well as verifying settings by secondary injection. The manual describes the process
of testing an IED in a substation which is not in service. The chapters are organized
in chronological order in which the IED should be commissioned.
1.2 Intended audience
This manual addresses the personnel responsible for commissioning, maintenance
and taking the IED in and out of normal service. The commissioning personnel
must have a basic knowledge of handling electronic equipment. The
commissioning and maintenance personnel must be well experienced in using
protection equipment, test equipment, protection functions and the configured
functional logics in the IED.
1.3 Product documentation
Manual Document number
Product Guide
1MRK 505 352
-
BEN
Application Manual
1MRK 505 349
-
UEN
Technical Manual
1MRK 505 350
-
UEN
Operation Manual
1MRK 500 124
-
UEN
Commissioning Manual
1MRK 505 351
-
UEN
Application Manual
B
ay protection Functions
1MRK 505 353
-
UEN
Cyber Security Guideline
1MRK 511 373
-
UEN
Communication Protocol
Manual
IEC 61850
1MRK 511 370
-
UEN
Communication Protocol Manual
IEC 60870
-
5
-
103
1MRK 511 371
-
UEN

Section 1 1MRK 505 351-UEN
Introduction
4Commissioning Manual
Distributed busbar protection REB500
1.4 Symbols and conventions
1.4.1 Symbols
The electrical warning icon indicates the presence of a hazard which
could result in electrical shock.
The warning icon indicates the presence of a hazard which could
result in personal injury.
The caution icon indicates important information or warning related
to the concept discussed in the text. It might indicate the presence of
a hazard which could result in corruption of software or damage to
equipment or property.
The information icon alerts the reader of important facts and
conditions.
The tip icon indicates advice on, for example, how to design your
project or how to use a certain function.
Although warning hazards are related to personal injury, it is necessary to
understand that under certain operational conditions, operation of damaged
equipment may result in degraded process performance leading to personal injury
or death. Therefore, comply fully with all warning and caution notices.

1MRK 505 351-UEN Section 1
Introduction
Commissioning Manual 5
Distributed busbar protection REB500
1.4.2 Document conventions
A particular convention may not be used in this manual.
•Abbreviations and acronyms in this manual are spelled out in the glossary. The
glossary also contains definitions of important terms.
•Push button navigation in the LHMI menu structure is presented by using the
push button icons, e.g.:
To navigate the options, use and .
•HMI menu paths are presented in bold, e.g.:
Select Main menu/Settings.
•LHMI messages are shown in Courier font, e.g.:
To save the changes in non-volatile memory, select Yes and ….
•Parameter names are shown in italics, e.g.:
The function can be enabled and disabled with the Operation setting.
•The * character after an input or output signal name in the function block
symbol given for a function indicates that the signal must be connected to
another function block in the application configuration to achieve a valid
application configuration.

Section 2 1MRK 505 351-UEN
Commissioning
6Commissioning Manual
Distributed busbar protection REB500
Section 2 Commissioning
2.1 Preconditions
It is assumed that the REB500 protection system is already installed and all input
and output signals that have been configured are also wired and the optical fiber
cables are run and tested.
It must also be assumed that the busbars or sections of them are in operation and
that circuit-breakers and isolators are in the process of being installed or
maintained.
The commissioning engineer requires the operating instructions and the station
diagrams prepared by the respective engineering department.
The protection system may only be commissioned by trained commissioning
personnel.
The greatest care must be taken when testing a busbar protection
system on busbars in operation, as the consequences of unexpected
operation in due process of the commissioning can be extremely
serious.
The REB500 protection system is equipped with an extensive,
continuous self-supervision and diagnosis feature. All functions are
constantly monitored by the system software. The overall system
has been extensively tested by ABB before releasing the product.
It is therefore not necessary to re-test the internal protection
algorithm by secondary injection.
This manual is therefore restricted to verifying the correct
connection to the primary process.

1MRK 505 351-UEN Section 2
Commissioning
Commissioning Manual 7
Distributed busbar protection REB500
2.2 Commissioning procedure
2.2.1 Overall procedure
The following overall procedure has proven as best practice.
Some items listed might not be applicable depending on the
substation architecture.
Checks prior to energizing on the IED
1. Record the equipment data
2. Visually inspect for transport damage
3. Visually inspect the external wiring and cables
4. Check the grounding of cubicles and other units
5. Check the auxiliary DC battery supply
6. Check the settings
7. Check the CT circuits
Polarity, ratio and wiring
8. Check the VT circuits
Checks after energizing the IED
9. Comparison with the layout of the primary system.
10. Secondary injection tests using the test set
11. Check the binary input signals
12. Check auxiliary contacts on the isolators and circuit-breakers and the
“CLOSE” command
13. Check the control signal and alarm circuits
14. Check the tripping circuits
15. Check the stability factor

Section 2 1MRK 505 351-UEN
Commissioning
8Commissioning Manual
Distributed busbar protection REB500
16. Set the system time
17. Record traceability data
18. Final test and inspection
Since the methods to perform the above mentioned procedure should be well
known to the commissioning engineer, a detailed explanation is omitted. The
following paragraphs focus on items specific to the REB500
2.2.2 Commissioning with a partial system
In order to operate, the REB500 protection system requires signals from the
isolators and circuit-breakers indicating their status. If one or several positions are
unknown, the protection system starts incompletely. The system is only fully
operational and standing by when all the position signals are available.
At the beginning of commissioning, these signals are frequently incorrectly wired
or the supply for the auxiliary contacts is unavailable. To enable commissioning of
the protection system to proceed in spite of this, the positions of the isolators and
circuit-breakers have to be simulated. This can be achieved either using jumpers at
the terminals or by simulating optocoupler positions in the test mode.
The checks described in this document assume a system in a stable
stand-by mode, i.e. no alarms with the exception of “Test generator
active” may be active.
2.2.3 Comparison with the layout of the primary system
In order to operate correctly, the REB500 process image needs to reflect the actual
setup of the primary equipment in the substation. It is therefore important to verify
the correct engineering at the beginning and make sure that not yet installed parts
are masked accordingly.
The easiest way to verify this is by checking the layout in HMI500 using the
“Single-line diagram” in the “View” menu.
Check that the locations of the CTs in the single-line diagram
conforms to the actual primary system. This check is essential if an
end fault protection is installed, as it influences the tripping logic
and most tests do not disclose an incorrect location.

1MRK 505 351-UEN Section 2
Commissioning
Commissioning Manual 9
Distributed busbar protection REB500
2.2.4 Checking the analog inputs (CTs)
Using a test set, inject a secondary current into each of the CT inputs.
The CT connections can be checked in one of the following ways:
·Reading the injected currents on the local HMI
(Note: The readings are referred to the primary values.)
·Reading the injected currents via HMI500 by selecting “Analog input
measurements” in the “View” menu
·Reading the injected currents via HMI500 by selecting “Protection zone
measurements” in the “View” menu
·Reading the injected currents via HMI500 by selecting “Single-line
diagram”
·Increasing the currents until a protection function picks up.
2.2.5 Checking the analog inputs (VTs)
Using a test set, inject a secondary voltage into each of the voltage transformer
inputs.
The checks can be executed in different ways:
·Reading the injected currents on the local HMI
·Reading the injected currents via HMI500 by selecting “Analog input
measurements” in the “View” menu.
Primary values of phase-to-neutral voltages are displayed.
2.2.6 Checking the binary input signals (optocoupler inputs)
Check the proper function of every binary optocoupler input by exciting the signal
source.
The binary inputs can be checked in one of the following ways:
·Reading the status on the local HMI

Section 2 1MRK 505 351-UEN
Commissioning
10 Commissioning Manual
Distributed busbar protection REB500
·Reading the statuses via the HMI500 by selecting “Binary input/output
status” in the “View” menu
·Checking the events generated in the event list.
Besides showing the correct operation, the event list also provides a
mean to check the correct functional assignment of the input.
2.2.6.1 Wiring for auxiliary contacts
The standard wiring of the N/C auxiliary contacts on L1, L2 and L3 phases of
isolators and circuit-breakers is in series and the N/O contacts in parallel.
This is reversed in case of the special version “not OPEN = CLOSED”.
Figure 1 Switching sequence of auxiliary contacts
ABB principle: Isolator
closed
open
Current measurement
open closed open
1
0
1
1
1
1
1
1
1
0
0
0
0
0
0
0
closed
open
Current measurement
not OPEN= CLOSED:
(When both isolator position
inputs are inverted)

1MRK 505 351-UEN Section 2
Commissioning
Commissioning Manual 11
Distributed busbar protection REB500
Inverting the logic means that local events are generated while a bay unit is starting
that signal a change of input status that did not take place. Correct operation is
nevertheless unimpaired.
2.2.6.2 Checking the isolator and circuit-breaker auxiliary contacts
Check the timing sequence of the isolator auxiliary contacts by inspecting the
construction of the isolator or assessing it from the respective data sheet.
Verify the operation of the “CLOSED” and “OPEN” contacts
1. According to the circuit diagram and
2. by physically opening and closing the isolator. A check can be done in one
of the following ways
·Menu item “View àSwitchgear objects”
·Menu item “View àBinary input/output status”
·Menu item “View àSingle-line diagram”.
2.2.6.3 Checking the manual “CLOSE” command
The local HMI is the best way of checking the circuit-breaker “CLOSE” command,
because the signal is generated only briefly and the local HMI is refreshed the
quickest. The corresponding menu item is “Measurements/Inputs”.
Alternatively the circuit-breaker “CLOSE” command can be temporarily
configured as an event and its operation observed in the HMI500 event list.
2.2.7 Checking the binary output signals
Test operations of circuit-breakers and isolators require the
permission of the user and all the prescribed safety precautions must
be observed. Avoid unnecessary switching operations.
All binary inputs are tested by setting them appropriately in the test mode. Select
“Test mode” from the “Testing” menu and clock on “Unblock all relays” in the test
mode dialog.
In the test mode, select “Binary input/output status” in the “View” menu to view
the outputs of a binary module. The status of an output can be changed by double-
clicking on the corresponding field, which then changes to yellow.

Section 2 1MRK 505 351-UEN
Commissioning
12 Commissioning Manual
Distributed busbar protection REB500
Check that the correct circuit-breaker tripping coil is tripped by the
correspondingly configured tripping output. Repeat the procedure for the separate
alarm contacts.
2.2.8 Checking protection stability
The stability check verifies that all CTs are connected with the correct polarity and
have the correct ratio. All feeder and bus-tie breaker CTs must be connected,
otherwise the correct operation of the protection cannot be guaranteed.
Wherever possible the stability should be checked before the busbar is energized,
because the risk of a busbar fault is especially high when it is being energized for
the first time (flashovers, grounding isolators still closed etc.).
2.2.8.1 Checking through-fault stability with de-energized busbars
Inject a current from a primary injection test set (25 % of the CT rated current is
recommended) into two feeders (a reference feeder and one other feeder). Any
feeder can be used as reference. Compare each of the other feeders and bus-tie
breaker with the reference feeder.
Figure 2 Through-fault stability by primary injection (two feeders)
If a bus-tie breaker is only equipped with one set of CTs, note that they are used by
two busbar sections.
