ABB 83220 AP-5 series User manual

VER:1.0 ││05.04.2017
ABB-Welcome
Pos: 2 /Di nA4 - A nl eitun gen Online / Inh alt/K NX /Doo rE ntry /832 20-AP - xxx/ Tit elblat t - 832 20-AP -xxx - AB B @ 1 9\m od_ 132 3249 806 476 _15. doc x @ 11 108 4 @ @ 1
83220 AP-6..-5..
7" video hands-free indoor
station, pushbutton
===E nde der Lis te für Tex tmarke C over == =

ABB
-Welcome
| — 2 —
Pos: 4 /Bus c h-Ja ege r (N eust ruk t ur)/ Modul -St rukt u r/Onli ne-D oku ment ation /I nh altsve rz eich nis ( --> Fü r all e Doku men te <--)/I n haltsve rz eic hnis @ 19\ mod _13 206 490 4438 6_1 5.d ocx @ 109 653 @ @ 1
1Safety.......................................................................................................4
2Intended use.............................................................................................4
3Environment..............................................................................................4
3.1 ABB devices .............................................................................4
4Operation..................................................................................................6
4.1 Standard operations..................................................................6
4.1.1 Control elements.......................................................................6
4.1.2 Welcome screen and status bar.................................................8
4.2 Control actions........................................................................10
4.2.1 Surveillance............................................................................10
4.2.2 Intercom.................................................................................11
4.2.3 Calling guard unit....................................................................12
4.2.4 Switch actuator .......................................................................13
4.2.5 Setting up the voice and video connections..............................14
4.2.6 Opening the door....................................................................15
4.2.7 Muting....................................................................................16
4.2.8 Activatingthe custom function.................................................17
4.2.9 Event and picture memory/history............................................19
4.2.10 Information..............................................................................23
4.2.11 Inserting an SD card................................................................24
4.2.12 Settings..................................................................................25
4.2.12.1 Overview ................................................................................25
4.2.12.2 Intercom .................................................................................28
4.2.12.3 Switch actuator .......................................................................31
4.2.12.4 Program button.......................................................................33
4.2.12.5 Leave home management.......................................................34
4.2.12.6 Voice message.......................................................................36
4.2.12.7 Setting door open password....................................................38
4.2.12.8 Blacklist..................................................................................39
4.2.12.9 Audio settings.........................................................................40
4.2.12.10 Auto-unlock.............................................................................42
4.2.12.11 Display settings.......................................................................44
4.2.12.12 Date and time.........................................................................46
4.2.12.13 Camera list.............................................................................48
4.2.12.14 Language...............................................................................49
4.2.12.15 Setup......................................................................................50
4.2.12.16 Firmware update.....................................................................52
4.3 Cleaning.................................................................................53
4.4 Adjusting the device................................................................54

ABB
-Welcome
| — 3 —
4.4.1 Terminal resistor.....................................................................54
4.4.2 Connection.............................................................................55
5Technical data.........................................................................................56
6Mounting/Installation...............................................................................57
6.1 Requirements for the electrician...............................................57
6.2 General installation instructions...............................................58
6.3 Mounting.................................................................................59
===E nde der Liste f ür Textma rke TOC == =

ABB
-Welcome
| — 4 —
Pos: 6 /Bus c h-Ja ege r (N eust ruk t ur)/ Modul -St rukt u r/Onli ne-D oku ment ation /Ü be rschri ft en (- -> Für all e D okum ent e < --)/ 1. E b ene/S - T/S ic herhei t @ 18\ mod _13 026 127 917 90_ 15.d oc x @ 103 357 @ 1 @ 1
1Safety
Pos: 7 /Bus c h-Ja ege r (N eust ruk t ur)/ Modul -St rukt u r/Onli ne-D oku ment ation /S ic herhei t (-- > Für al le Dok um ente <- -)/Wa rn hinw eise /S icher hei t - 23 0 V @ 18\m od_ 130 260 681 675 0_15 .docx @ 1 033 08 @ @ 1
Warning
Electric voltage!
Dangerous currents flow through the body when coming into direct or
indirect contact with live components.
This can result in electric shock, burns or even death.
■Disconnect the mains power supply prior to installation and/or
disassembly!
■Permit work on the 110-240 V supply system to be performed only by
specialist staff!
Pos: 8 /Bus c h-Ja ege r (N eust ruk t ur)/ Modul -St rukt u r/Onli ne-D oku ment ation /Ü be rschri ft en (- -> Für all e D okum ent e < --)/ 1. E b ene/A - F/B esti m mungs ge mä ßer Geb rau ch @ 18\ mod _13 027 6332 131 6_1 5.do cx @ 1034 83 @ 1 @ 1
2Intended use
Pos: 9 /Di nA4 - A nl eitun gen Onli ne /Inh alt/K NX /Doo rE ntry /832 20-AP - xxx /Best i mmu ngsg em aesse r Ge bra uch - 83 220 -A P-xx x- 500 @ 2 0\mo d_1 324 561 168 699 _15. docx @ 11 272 8 @ @ 1
This device is an integral part of the ABB-Welcome door communication system and
operates exclusively with components from this system. The device must only be
installed in dry indoor rooms.
Pos: 10 /B us ch-J aeg er (Neus t ruk tur )/M odul -Struk t ur/O nline -D oku me ntatio n/Ü be rsch rift e n (--> Fü r all e Doku men te < -- )/1. E bene /U - Z/U mwelt @ 18\ mod _13 026 141 5896 7_1 5.d ocx @ 103 383 @ 1 @ 1
3Environment
Pos: 11 /B us ch-J aeg er (Neus t ruk tur )/M odul -Struk t ur/O nline -D oku me ntatio n/U mw elt ( --> F ür all e Doku me nte <-- )/Hi nweis e/Hi nw eis - U mwelt - Hinw eis E lekt roge räte @ 1 8\mo d_1 302 763 973 434 _15. docx @ 10 350 0 @ @ 1
Consider the protection of the environment!
Used electric and electronic devices must not be disposed of with
household waste.
– The device contains valuable raw materials that can be recycled.
Therefore, dispose of the device at the appropriate recycling
facility.
Pos: 12 /Di nA4 - A nleit u ngen Onli n e/Ueb ersc hri ft en/2 ./A BB Gera ete @ 19 \mo d_1 323 162 843 832_ 15. doc x @ 11 087 5 @ 2 @ 1
3.1 ABB devices
Pos: 13 /B us ch-J aeg er (Neus t ruk tur )/M odul -Struk t ur/O nline -D oku me ntatio n/U mw elt ( --> F ür all e Doku me nte <-- )/Hi nweis e/Hi nw eis - U mwelt - AB B E lekt roger äte @ 19\ mo d_1 3231 627 458 39_ 15.d ocx @ 110 867 @ @ 1

ABB
-Welcome
| — 5 —
All packaging materials and devices from ABB bear the markings and test seals for
proper disposal. Always dispose of the packaging material and electric devices and their
components via an authorized recycling facilities or disposal companies.
ABB products meet the legal requirements, in particular the laws governing electronic
and electrical devices and the REACH ordinance.
(EU-Directive 2002/96/EG WEEE and 2002/95/EG RoHS)
(EU-REACH ordinance and law for the implementation of the ordinance (EG)
No.1907/2006)

ABB
-Welcome
| — 6 —
Pos: 18 /Di nA4 - A nleit u ngen Onlin e/ Ueb ersc hrif t en/1 ./B edie nun g @ 18\m od_ 130 261 392 416 5_15 .doc x @ 1 033 65 @ 1 @ 1
4Operation
Pos: 19 /Di nA4 - A nleit u ngen Onli n e/Ueb ersc hri ft en/2 ./Nor mal e rB et rieb @ 18 \mo d_1 302 768 8209 65_ 15. docx @ 10 3540 @ 2 @ 1
4.1 Standard operations
Pos: 20 /Di nA4 - A nleit u ngen Onli n e/Ueb ersc hri ft en/3 ./B edie nele men te @ 20\ mod _13 232 6022 055 9_1 5.do cx @ 1 116 47 @ 3 @ 1
4.1.1 Control elements
Pos: 21 /Di nA4 - A nleit u ngen Onli n e/In halt/K NX /Do orE nt ry/83 220 -AP -xxx /Be di enel eme nte - 8 322 0-AP -xxx @ 18\ mo d_1 3032 128 536 05_ 15.d ocx @ 103 673 @ @ 1
Fig. 1 Control elements
SD-Card
1
2 3 4 5 6 7

ABB
-Welcome
| — 7 —
No. Functions
17" Touch screen
2Communication button
2A For incoming call, press this button within 30 seconds to activate
communication. Press it again to end call.
2B In standby mode, press this button to set up the voice and video
connections to the default outdoor station.
3Unlock button
3A Press this button to open the door at any time.
3B Auto-unlock: The door is automatically opened after an incoming call.
If the LED lights up, this indicates auto-unlock.
If the LED flashes rapidly, it means the door is open over the set time. (The
sensor must be connected first.)
4Mute button
4A In standby mode, press this button to mute the ringtone for this indoor
station.
4B In standby mode, hold this button to mute the ringtone for all indoor
stations in the apartment.
4C Press this button to reject incoming call.
4D During a conversation, press this button to mute the microphone.
If the LED lights up, this indicates a mute status.
5Program button
5A Release the lock connected with outdoor station (COM-NC-NO)
(default function)
5B *Programmable for additional functions, e.g. call guard unit,
intercom, etc.
6Surveillance button
6A In standby mode, press this button to surveil the default outdoor station.
6B When video is on the screen, press this button to snapshot manually.
7System setting button
Enter the system settings menu for various functions of the device.
*For use of this button, please contact your electrical installer.

ABB
-Welcome
| — 8 —
4.1.2 Welcome screen and status bar
Fig. 2 Welcome screen and status bar
No. Functions
1Current date
- Click here to set the current date.
2Time
- Click here to set the current time.
3System information
- Click on this icon to call up the address (number of the indoor station,
default outdoor station, master or slave station) on this panel and the
current software information.
4History
- New informations (events or picture memory) are available when this icon
flashes. This also indicates a missed call or a new voice message.
- Click on this icon to display the events and picture memory .
5Mute function
- Icons "crossed-out handset" and "crossed-out bell" indicate the mute
status of the microphone or the loudspeaker of the panel.
6Open entrance door
3 9
2465 7 8
10
1
11
12
13
14

ABB
-Welcome
| — 9 —
- The "open door" icon is displayed when you press the door opener or
activate the function "automatic door opener".
7SD card
- The icon shows whether or not you have inserted an SD card.
8Switch actuator
- The icon is shown after you activate the switch actuator.
9Cleaning blockage
- The icon is shown when the display is blocked to prevent functions being
enabled during cleaning.
10 SOS
- Hold this button for 3s to send an SOS signal to a guard unit.
11 Surveillance
- Click on this button to start to survey the default outdoor station.
12 Intercom
- Click on this button to enter the intercom call menu.
13 Guard unit
- Click on this button to call guard unit.
14 Switch actuator
- Click on this button to enter the switch actuator menu.
Pos: 29 /B us ch-J aeg er (Neus t ruk tur )/M odul -Struk t ur/O nline -D oku me ntatio n/S teu er mod ule - Onl in e-Dok ume ntati on ( -- > Für al le Dok ume nte <- -)/ +++++ ++ +++ ++S eiten umb ruch + +++++ ++ +++ +@ 9\m od_ 126 8898 668 093 _0. docx @ 521 49 @ @ 1
Pos: 22 /B us ch-J aeg er (Neus t ruk tur )/M odul -Struk t ur/O nline -D oku me ntatio n/S teu er mod ule - Onl in e-Dok ume ntati on ( -- > Für al le Dok ume nte <- -)/ +++++ ++ +++ ++S eiten umb ruch + +++++ ++ +++ +@ 9\m od_ 126 8898 668 093 _0. docx @ 521 49 @ @ 1

ABB
-Welcome
| — 10 —
Pos: 26 /Di nA4 - A nleit u ngen Onlin e/ Ueb ersc hrif t en/2 ./B edie nakti onen @ 2 0\m od_ 1323 262 294 281 _15. docx @ 11 191 1 @ 2 @ 1
4.2 Control actions
Pos: 27 /Di nA4 - A nleit u ngen Onlin e/ Ueb ersc hrif t en/3 ./S prec h- und Vi deov erbi ndu ng @ 20\ mod _13 232 6236 870 0_1 5.do cx @ 1119 27 @ 3 @ 1
4.2.1 Surveillance
Pos: 28 /Di nA4 - A nleit u ngen Onli n e/In halt/K NX /Do orE nt ry/83 220 -AP -xxx /Sp rech - u nd V ide over bi nd ung - 8 322 0-AP -xxx @ 20\ mo d_1 3232 623 418 52_ 15.d ocx @ 111 919 @ @ 1
Fig. 3 Surveillance
Click on this button to start to survey the default outdoor station. Only the video
connection appears first. Press button to activate the voice connection.
No. Function
1Designation of camera.
2Set volume with the "plus/minus" buttons.
3If several outdoor stations or external cameras are connected.
- Select a camera with the “forward/back” buttons
4Click on the button to set the display.
• Saturation of the display (plus and minus).
• Contrast of the display (plus and minus).
Pos: 29 /B us ch-J aeg er (Neus t ruk tur )/M odul -Struk t ur/O nline -D oku me ntatio n/S teu er mod ule - Onl in e-Dok ume ntati on ( -- > Für al le Dok ume nte <- -)/ +++++ ++ +++ ++S eiten umb ruch + +++++ ++ +++ +@ 9\m od_ 126 8898 668 093 _0. docx @ 521 49 @ @ 1
2
3
4
1
Surveillance

ABB
-Welcome
| — 11 —
Pos: 30 /Di nA4 - A nleit u ngen Onlin e/ Ueb ersc hrif t en/3 ./T uer oeff nen @ 2 0\mo d_1 323 263 277 453 _15. doc x @ 11 193 5 @ 3 @ 1
4.2.2 Intercom
Pos: 31 /Di nA4 - A nleit u ngen Onlin e/ In halt/K NX /Do orE nt ry/83 220 -AP -xxx/ Tuer o eff ne n - 832 20-A P-x xx @ 20\ mod_ 132 326 795 847 9_15 . docx @ 1 121 09 @ @ 1
Fig. 4 Intercom
Click on this button to enter intercom call menu, and then the following functions are available:
(Set the intercom call lists in the “system setting-intercom setting” menu first.)
No. Functions
1The name of an intercom.
2The address of an intercom.
3The type of an intercom (external or internal).
means an external intercom from a different apartment.
means an internal intercom from the same apartment.
4Click on “call” button to make an intercom call.
5Click on “back” button to return to the Start screen.
4
1
Intercom
5
2 3

ABB
-Welcome
| — 12 —
4.2.3 Calling guard unit
Pos: 31 /Di nA4 - A nleit u ngen Onlin e/ In halt/K NX /Do orE nt ry/83 220 -AP -xxx/ Tuer o eff ne n - 832 20-A P-x xx @ 20\ mod_ 132 326 795 847 9_15 . docx @ 1 121 09 @ @ 1
Fig. 5 Calling guard unit
Click on the "guard unit" button to call a guard unit, and then the following functions are
available:
No. Functions
1Designation of a guard unit.
2Set volume with the "plus/minus" buttons.
Call guard unit
2
1

ABB
-Welcome
| — 13 —
4.2.4 Switch actuator
Pos: 31 /Di nA4 - A nleit u ngen Onlin e/ In halt/K NX /Do orE nt ry/83 220 -AP -xxx/ Tuer o eff ne n - 832 20-A P-x xx @ 20\ mod_ 132 326 795 847 9_15 . docx @ 1 121 09 @ @ 1
Fig. 6 Switch actuator
Click on “switch actuator” button to enter the switch actuator menu and then the following
functions are available:
(Set actuator lists in the “system setting-switch actuator” menu first.)
No. Functions
1The name of an actuator.
2The address of an actuator.
3Click on this button to activate the selected actuator.
4Click on this button to go back to the Start screen.
Switch actuator
4
1 2
3

ABB
-Welcome
| — 14 —
4.2.5 Setting up the voice and video connections
Pos: 31 /Di nA4 - A nleit u ngen Onlin e/ In halt/K NX /Do orE nt ry/83 220 -AP -xxx/ Tuer o eff ne n - 832 20-A P-x xx @ 20\ mod_ 132 326 795 847 9_15 . docx @ 1 121 09 @ @ 1
Fig. 7 Setting up the voice and video connections
The following functions are available for setting up the voice and video connections:
(Press the communication button.)
No. Functions
1Designation of the camera.
2Set the volume with the "plus/minus" buttons.
3If several outdoor stations or external cameras are connected, select the
camera with the “forward/back” buttons.
4 Click on the buttons to set the display.
• Saturation of the display (plus and minus).
• Contrast of the display (plus and minus).
Pos: 29 /B us ch-J aeg er (Neus t ruk tur )/M odul -Struk t ur/O nline -D oku me ntatio n/S teu er mod ule - Onl in e-Dok ume ntati on ( -- > Für al le Dok ume nte <- -)/ +++++ ++ +++ ++S eiten umb ruch + +++++ ++ +++ +@ 9\m od_ 126 8898 668 093 _0. docx @ 521 49 @ @ 1
2
3
4
1

ABB
-Welcome
| — 15 —
4.2.6 Opening the door
Pos: 31 /Di nA4 - A nleit u ngen Onlin e/ In halt/K NX /Do orE nt ry/83 220 -AP -xxx/ Tuer o eff ne n - 832 20-A P-x xx @ 20\ mod_ 132 326 795 847 9_15 . docx @ 1 121 09 @ @ 1
Fig. 8 Opening the door
Press the key button to activate the door opener, and then the following functions
become available:
No. Functions
1The "open door" icon is displayed after you press the door opener or
activate the function "automatic door opener."
1

ABB
-Welcome
| — 16 —
4.2.7 Muting
Pos: 31 /Di nA4 - A nleit u ngen Onlin e/ In halt/K NX /Do orE nt ry/83 220 -AP -xxx/ Tuer o eff ne n - 832 20-A P-x xx @ 20\ mod_ 132 326 795 847 9_15 . docx @ 1 121 09 @ @ 1
Fig. 9 Muting
The muting menu (mute timer) has the following functions:
No. Functions
1No call is pending:
If you press the "mute function" while no call is pending, the bell sound of
the panel will be deactivated for a certain period.
- If calls come in during this time, only the video image is displayed.
- Missed calls are displayed in the events and pictures memory .
2A call is pending:
If you press the button "mute function" during a call, the microphone of the
panel will be deactivated until the button is pressed again.
1 2

ABB
-Welcome
| — 17 —
4.2.8 Activating the custom function
Pos: 31 /Di nA4 - A nleit u ngen Onlin e/ In halt/K NX /Do orE nt ry/83 220 -AP -xxx/ Tuer o eff ne n - 832 20-A P-x xx @ 20\ mod_ 132 326 795 847 9_15 . docx @ 1 121 09 @ @ 1
1 2
3

ABB
-Welcome
| — 18 —
Fig. 10 Activating the custom function
The program button can be configured with different functions, e.g. call to guard unit,
intercom call or control switch actuator. Its default function is the release of the second
lock, which is connected with terminals COM-NC-NO of an outdoor station.
If no function is assigned to the program button, there will be no action after pressing
this program button.
Only the existing intercom call list & switch actuator list can be assigned for the program
button.
No. Functions
1If the function “release second lock” is assigned to the program button,
the "open door" icon will be displayed when you press the program button.
2If the function “control switch actuator” is assigned to the program button,
the "actuator" icon will be displayed when you press the program button.
3 If the function “make an intercom call” is assigned to the program button,
the call will be activated directly when you press the program button.
4If function “call guard unit” is assigned to the program button, the call will
be activated when you press the program button.
4

ABB
-Welcome
| — 19 —
4.2.9 Event and picture memory/history
Pos: 31 /Di nA4 - A nleit u ngen Onlin e/ In halt/K NX /Do orE nt ry/83 220 -AP -xxx/ Tuer o eff ne n - 832 20-A P-x xx @ 20\ mod_ 132 326 795 847 9_15 . docx @ 1 121 09 @ @ 1
Fig. 11 Event and picture memory/history
The panel records all events. Press the "history" button and then the last 100 events will
be displayed (prior events are overwritten).
No. Functions
1If you have activated the function "auto snapshots activated" in the system
settings, the flashing icon in the status bar signals a newly taken snapshot.
- The symbol stops flashing when you call up the events and pictures
memory.
2Voice message
- Press the flash button to enter the voice message settings menu.
1 2

ABB
-Welcome
| — 20 —
1 2
2
3
4
