ABB Welcome M2303 User manual

VER:1.0 │ │ 22.04.2015
ABB-Welcome
Pos: 2 /Di nA4 - A nleitungen O nline/Inhalt/KN X/DoorE ntry/83220- AP-xxx/Tit elblatt - 83220-AP- xxx- ABB @ 19\mod _1323249 806476_15.doc x@ 11108 4@ @ 1
M2303
Guard Unit
=== Ende der List ef ürT extmarke Cover == =

ABB-Welcome
|
—2 —
Pos: 4 /Busch-J aeger (Neustru ktur)/Modul-Str uktur/Online-Doku mentation/Inhal tsverzeichnis (--> Für alle D okumente <--)/Inhalts verzeich nis @ 19\mod _1320649 044386_1 5.docx @ 109653 @ @ 1
1Safety............................................................................................................4
2Intended use..................................................................................................4
3Environment ..................................................................................................4
3.1 ABB devices.................................................................................5
4Operation.......................................................................................................6
4.1 Standard operation.......................................................................6
4.1.1 Control elements ..........................................................................6
4.1.2 Welcome screen and status bar .................................................10
4.2 Control actions............................................................................12
4.2.1 Incoming call / During a call........................................................12
4.2.2 Display settings during calls .......................................................14
4.2.3 Intercept mode............................................................................15
4.2.3.1 VIP settings ................................................................................17
4.2.4 Communication...........................................................................21
4.2.5 Surveillance................................................................................25
4.2.6 Switch actuator...........................................................................26
4.2.7 User list.......................................................................................27
4.2.8 History ........................................................................................30
4.2.9 Settings (Basic) ..........................................................................35
4.2.9.1 Ringtone settings........................................................................35
4.2.9.2 Volume settings..........................................................................36
4.2.9.3 Date and time settings................................................................37
4.2.9.4 Other settings.............................................................................39
4.2.9.5 Language settings ......................................................................41
4.2.9.6 Information..................................................................................43
4.2.10 Settings (Advanced) ...................................................................44
4.2.10.1 Switch actuator settings..............................................................45
4.2.10.2 Program button settings..............................................................49
4.2.10.3 User list management.................................................................51
4.2.10.4 Call code settings .......................................................................58
4.2.10.5 Password settings ......................................................................60
4.2.10.6 Reset factory default...................................................................61
4.2.10.7 Reset Password & Clear All Data...............................................62

ABB-Welcome
|
—3 —
4.3 Cleaning .....................................................................................64
4.4 Adjusting the device....................................................................65
5Technical data.............................................................................................66
6Mounting / Installation..................................................................................68
6.1Requirements for the electrician.................................................68
6.2 General installation instructions..................................................69
6.3 Mounting.....................................................................................71
=== Ende der List efür T extmarke TOC ===

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—4 —
Pos: 6 /Busch-J aeger (Neustru ktur)/Modul-Str uktur/Online-Doku mentation/Übers chriften (--> Für alle Doku mente <--)/1. Ebene/S - T/Sicherheit @ 18\ mod_1302 612791790_15.doc x@ 10335 7@ 1 @ 1
1 Safety
Pos: 7 /Busch-Jaeger (Ne ustruktur)/Modul-Str uktur/Online-Doku mentation/Sicherh eit( -->F ürall eD okument e<--)/W arnhinweise/Sicherh eit- 23 0V @ 18\m od_13026068167 50_15.doc x@ 103 308 @ @ 1
Warning
Electric voltage!
Risk of death and fire due to electrical voltage of 100-240 V.
–Work on the 100-240V supply system may only be performed by
authorised electricians!
–Disconnect the mains power supply prior to installation and/or
disassembly!
Pos: 8 /Busch-J aeger (Neustru ktur)/Modul-Str uktur/Online-Doku mentation/Übers chriften (--> Für alle Doku mente <--)/1. Ebene/A - F/Bestimmungsg emäßer Gebrauch @ 18\mo d_130276332131 6_15.docx @ 1034 83 @ 1 @ 1
2 Intended use
Pos: 9 /DinA4 - Anleit ungen O nline/Inhalt/KNX/D oorEntry/83220- AP-xxx/Besti mmungsgema esser Gebrauch - 8 3220-AP-xxx-500 @ 20\mod_1 32456116 8699_15.d ocx @ 112728 @ @ 1
The M2303 is an integral part of the ABB Welcome door communication system and
operates exclusively with components from this system. The device must only be
installed in dry indoor rooms.
Pos: 10 /Busch-J aeger (Neustru ktur)/Modul- Struktur/Online-D okumentation/Üb erschriften (--> Für alle D okumente <--)/1. Ebene/U - Z/Um welt @ 18\mod _1302614 158967_15.docx @ 103383 @ 1 @ 1
3 Environment
Pos: 11 /B usch-J aeger (Ne ustruktur)/Mo dul-Struktur /Online-Do kumentation/U mwelt (--> Für alle D okumente <--)/Hinw eise/Hi nweis - Umwelt - Hinweis Elektrog eräte @ 18\mod_1302 76397343 4_15.docx @ 1035 00@ @ 1
Consider the protection of the environment!
Used electric and electronic devices must not be disposed of with
domestic waste.

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—5 —
–The device contains valuable raw materials which can be recycled.
Therefore, dispose of the device at the appropriate collecting
depot.
Pos: 12 /DinA4 - Anl eitungen Online/Ueb erschriften/2./ABB G eraete @ 19\mod_13 23162843832_ 15.docx @ 110875 @ 2 @ 1
3.1 ABB devices
Pos: 13 /B usch-J aeger (Ne ustruktur)/Mo dul-Struktur /Online-Do kumentation/U mwelt (--> Für alle D okumente <--)/Hinw eise/Hi nweis - Umwelt - ABB Elektrogerä te@ 1 9\mod_13231627 45839_15.docx @ 110867 @ @ 1
All packaging materials and devices from ABB bear the markings and test seals for
proper disposal. Always dispose of the packaging material and electric devices and their
components via the authorized collecting depots and disposal companies.
ABB products meet the legal requirements, in particular the laws governing electronic
and electrical devices and the REACH ordinance.
(EU-Directive 2002/96/EG WEEE and 2002/95/EG RoHS)
(EU-REACH ordinance and law for the implementation of the ordinance (EG)
No.1907/2006)

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—6 —
Pos: 18 /DinA4 - Anl eitungen Online/Ueb erschriften/1./Bedi enung @ 18\mod_ 1302613924165_15. docx @ 103365 @ 1 @ 1
4 Operation
Pos: 19 /DinA4 - Anl eitungen Online/Ueb erschriften/2./Nor maler Betrieb @ 18\m od_13027688209 65_15.docx @ 103540 @ 2 @ 1
4.1 Standard operation
Pos: 20 /DinA4 - Anl eitungen Online/Ueb erschriften/3./Bedi enelemente @ 20\mo d_13232602205 59_15.docx @ 1116 47@ 3 @ 1
4.1.1 Control elements
Pos: 21 /DinA4 - Anl eitungen Online/Inhalt/ KNX/DoorEntry/8 3220-AP-xxx/Bedienelem ente- 832 20-AP- xxx@ 1 8\mod_ 13032128 53605_15.docx @ 103673 @ @ 1

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—7 —
Fig.
1
Over view of the control buttons

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—8 —

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—9 —
No.
Function
1
Handset
When a call is coming, pick up handset to activate the communication
within 30 seconds and hang up handset to end the call.
2
4.3“Touch screen.
3
Unlock button
Press this button to open the door at any time.
If the LED flashes slowly, this means an incoming call.
If the LED flashes rapidly, it means system is busy or the door has been
opened over the set time (The sensor must be connected first).
4
Surveillance button
In standby mode, press this button to survey the default outdoor station.
5
Programmable button 1,2,3
5A *Programmable buttons for additional functions, e.g. control the switch
actuator.
5B Default function of button 1 is release the lock connected with an
outdoor station (COM-NC-NO)
6
System setting button
Enter into the system setting for various functions of the device.
*For their use, please contact your electrical installer.

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—10 —
4.1.2 Welcome screen and status bar
Fig.
2
Start
On the start page, the following functions are available:
No.
Function
1
Intercept
-Press this button to switch to intercept settings.
2
Communication
-Press this button to enter the communication menu
3
Surveillance
In standby mode, press this button to survey the default outdoor station.
4
Switch actuator
-Press this button to enter the switch actuator menu and enable the
START
1
2013/01/01 00:00
2
3
4
9
6
7
8
10
5
11
12
13

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—11 —
existing actuators here.
5
User list
-Touch this button and then check the contact list.
6
History
-Press this button to enter the history menu. All events and alarms from
indoor stations can be found here.
7
System settings (basic)
- Press this button to set some basic functions for the device,
e.g. ringtone, volume and local language.
8
System settings (advance)
- Press this button to set the various advanced functions for the
device, e.g. switch actuator setting and user list management.
9
Date and time
-Press this button to switch to date and time settings.
10
Cleaning locking
-This icon appears when the display is locked to prevent functions being
triggered during cleaning.
11
Alarm history
- This icon appears when new alarm information is available in the alarm
history.
- Touch this icon and then events will be displayed.
12
Call history
- The icon appears when new call information is available in the call
history.
- Touch this icon and then events will be displayed.
13
Intercept
- The icon appears when the guard unit is in the intercept mode.
Pos: 22 /Busch-J aeger (Neustr uktur)/Modul-Stru ktur/Online-Do kumentation/Ste uermodule - Onli ne-Dokument ation(--> F ür alle Do kumente <--)/++++++ ++++++ Seitenumbruch ++++++++ ++++ @ 9\mod_12688 98668093_0.docx @ 52149 @ @ 1

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—12 —
Pos: 26 /DinA4 - Anl eitungen Online/Ueb erschriften/2./Bedi enaktionen @ 20\ mod_132326229428 1_15.docx @ 111911 @ 2 @ 1
4.2 Control actions
Pos: 27 /DinA4 - Anl eitungen Online/Ueb erschriften/3./Sprec h- und Videoverbin dung @ 20\mod_132 3262368700_15.doc x@ 1 11927 @ 3 @ 1
4.2.1 Incoming call / During a call
Pos: 28 /DinA4 - Anl eitungen Online/Inhalt/ KNX/DoorEntry/8 3220-AP-xxx/Sprech- und Videoverbindung - 83220-AP- xxx@ 20\ mod_13232623418 52_15.docx @ 111919 @ @ 1
Fig.
3
Incoming call
When calling, the following functions are available:
No.
Function
1
Time left of the connection.
2
Number of outdoor stations.
3
Surveillance
Press this button to surveil the analog camera of the outdoor
station if there is one.
1
5
6
END
030s
Outdoor
＜
＞
1-1
2
3
4

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—13 —
4
Snapshot
-Press this button to take a snapshot.
5
Display settings
-Press this button to enter the display settings.
6
End the connection.
Pos: 29 /Busch-J aeger (Neustr uktur)/Modul-Stru ktur/Online-Do kumentation/Ste uermodule - Onli ne-Dokument ation(--> F ür alle Do kumente <--)/++++++ ++++++ Seitenumbruch ++++++++ ++++ @ 9\mod_12688 98668093_0.docx @ 52149 @ @ 1

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—14 —
Pos: 30 /DinA4 - Anl eitungen Online/Ueb erschriften/3./Tuer oeff nen @ 20\mod_132 3263277453_15.doc x@ 1 11935 @ 3 @ 1
4.2.2 Display settings during calls
Pos: 31 /DinA4 - Anl eitungen Online/Inhalt/ KNX/DoorEntry/8 3220-AP-xxx/Tuer oeffne n- 83220-AP- xxx@ 2 0\mod_13232679 58479_15.docx @ 112109 @ @ 1
Fig.
4
Display settings during calls
The following functions are available if you press button.
No.
Functions
1
Adjust the saturation of the display through the ”Plus / Minus” buttons.
2
Adjust the brightness of the display through the “Plus / Minus” buttons.
1
END
120s
Outdoor
+
-
3
2

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—15 —
4.2.3 Intercept mode
Pos: 31 /DinA4 - Anl eitungen Online/Inhalt/ KNX/DoorEntry/8 3220-AP-xxx/Tuer oeffne n- 83220-AP- xxx @ 20\mod_ 1323267958479_15. docx @ 112109 @ @ 1
Fig.
5
Intercept mode
In the “Intercept”, the following functions are available:
No.
Function
1
Activate or deactivate the intercept function by ticking the checkbox
2
Activate the intercept function to intercept calls for all users or for VIPs only
by ticking the checkbox
- ”all” means that the guard unit will intercept calls for all users..
- “VIP” means that the guard unit will intercept calls for VIPs only
3
Set VIPs (available only when there are VIPs)
Back
INTERCEPT
×
Intercept
For
ALL
Type
Permanent
Start Time 1
×
08
30
×
18
30
Start Time 2
End Time 1
08
30
18
30
End Time 2
OK
-
+
Set VIP
1
5
2
3
8
4
7
6

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—16 —
- Press this button to set the VIPs.
4
Choose the type of intercept by ticking the checkbox
-“Permanent” mode and “Repeat” mode are available.
5
“Plus / Minus” buttons.
6
Back
-Press this button to return to the start page without saving the settings.
7
OK
-Press this button to save the settings.
8
In the “Repeat”mode, the timer(s) must be activated by ticking the
checkbox.
-When the timer is activated, set the start time and end time via the “Plus /
Minus”buttons.
-Before adjusting to the “Hour”or “Minute”., the active range is
highlighted in blue
-End time > Start time
The function can only be set through master guard unit.

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—17 —
4.2.3.1 VIP settings
Press to set the VIPs,. A total of 64 entries can be added.
Fig.
6
VIP settings
The following functions are available:
No.
Functions
1
Select “User Name”, press “Add“ button, and then you can add
new VIPs by user name (from the contact lists).
2
Select “Physical Address”, press “Add“ button, and then you can add new
VIPs by their physical address.
3
“VIP”
Set VIP
Back
User Name
Add
VIP
6
1
4
5
Physical Address
3
VIP SETTING
2

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—18 —
-Press the “VIP”button to check the VIP list .
4
“Add”
-Press the “Add”button to add new VIPs.
5
“Back”
-Press the “Back” button to return to the “Intercept” page.
6
“Scroll”
-Switch to other settings by ticking the scroll box.
Press to set VIPs.
Fig.
7
VIP list
The “VIP list” menu has the following functions:
No.
Functions
VIP
Back
VIP List
Alexander.G
Delete
View
1
3
4
Bodin.K
2
1/5
Christian.G
Elizabeth.G
Tom

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—19 —
1
VIP list
-Displays all VIPs.
2
“View”
-Press this button to display specific information of the selected VIP.
3
“Delete”
-Press this button twice to delete the selected VIP.
4
“Back”
-Press this button to return to the VIP settings menu.
Select “Physical address” and press the “Add” button to enter “Add”menu.
Fig.
8
Add VIPs by physical address
No.
Functions
1
Enter a physical address with the numeric keypad.
2
“Add”
Back
VIP SETTING
Add
1
2
3

ABB-Welcome
Error! Use the Home tab
to apply 标题 1 to the
text that you want to
appear here.
|
—20 —
-Press this button to add a new VIP. Enter the correct physical address
before pressing this button.
3
“Back”
-Press this button to return to the VIP settings menu.
