ABB Welcome IP H8131.P. Series User manual

2TMD041900D0015 │21.10.2019
Product manual
ABB-Welcome IP
H8131.P.-. , H8131.P.-.-02
H8136.P.-. , H8136.P.-.-02
Mini video outdoor station

Table of contents
Product manual 2TMD041900D0015 │
2
Tableo fcontents
1 Notes on the instruction manual....................................................................................................................4
2 Safety.............................................................................................................................................................4
3 Intended use..................................................................................................................................................5
4 Environment...................................................................................................................................................6
4.1 ABB devices.......................................................................................................................................6
5 Product description........................................................................................................................................7
5.1 Control elements................................................................................................................................7
5.2 Terminal description...........................................................................................................................8
5.3 Lock type and connection..................................................................................................................9
6 Technical data .............................................................................................................................................10
7 Mounting/Installation....................................................................................................................................11
7.1 Requirement for the electrician........................................................................................................11
7.2 Preparation.......................................................................................................................................12
7.3 Installation height.............................................................................................................................12
7.4 Wiring ...............................................................................................................................................12
7.5 Surface-mounted installation ...........................................................................................................13
7.6 Flush-mounted installation...............................................................................................................15
7.7 Cavity wall installation......................................................................................................................16
7.8 Replacing the nameplate .................................................................................................................17
7.9 Installation situation..........................................................................................................................18
8 Commissioning............................................................................................................................................19
8.1 Configure the settings on indoor station..........................................................................................19
8.1.1 Outdoor station enters engineering mode......................................................................................19
8.1.2 Indoor station enters engineering settings.....................................................................................20
8.1.3 Device settings...............................................................................................................................21
8.1.4 Lock management..........................................................................................................................23
8.1.5 Door status detection .....................................................................................................................24
8.1.6 Sound .............................................................................................................................................25
8.1.7 Anti-ficker setting............................................................................................................................26
8.1.8 Set the function of pushbutton .......................................................................................................27
8.1.9 Time sync setting............................................................................................................................28
8.1.10 Compatible mode setting................................................................................................................29
8.1.11 Firmware update.............................................................................................................................30
8.1.12 Version information ........................................................................................................................31
8.1.13 Serial number.................................................................................................................................32
8.1.14 Signature ........................................................................................................................................33
8.2 Configure the settings on SmartAP .................................................................................................34
8.2.1 Add mini outdoor station.................................................................................................................34
8.2.2 Configure the settings ....................................................................................................................35
8.3 Card management on mini outdoor station .....................................................................................42
8.4 Card management on SmartAP.......................................................................................................44

Table of contents
Product manual 2TMD041900D0015 │
3
8.4.1 Assigning ID authentications to a user...........................................................................................44
8.4.2 Assigning the locks to a user .........................................................................................................47
8.4.3 Removing ID authentications from a user......................................................................................48
9 FCC..............................................................................................................................................................49
10 Cyber security..............................................................................................................................................50
10.1 Disclaimer.........................................................................................................................................50
10.2 Performance and service.................................................................................................................50
10.3 Deployment guideline ......................................................................................................................51
10.4 Upgrading.........................................................................................................................................51
10.5 Backup/Restore................................................................................................................................51
10.6 Malware prevention solution............................................................................................................51

Notes on the instruction manual
Product manual 2TMD041900D0015 │
4
1 Notes on the instruction manual
Please read through this manual carefully and observe the information it contains. This will
assist you in preventing injuries and damage to property, and ensure both reliable operation and
a long service life for the device.
Please keep this manual in a safe place. If you pass the device on, also pass on this manual
along with it. ABB accepts no liability for any failure to observe the instructions in this manual.
2 Safety
Warning
Electric voltage!
Dangerous currents flow through the body when coming into direct or indirect
contact with live components.
This can result in electric shock, burns or even death.
– Disconnect the mains power supply prior to installation and/or disassembly!
– Permit work on the 100-240 V supply system to be performed only by
specialist staff!

Intended use
Product manual 2TMD041900D0015 │
5
3 Intended use
As part of the ABB-Welcome IP system, this device can only be used with accessories from that
system.

Environment
Product manual 2TMD041900D0015 │
6
4 Environment
Consider the protection of the environment!
Used electric and electronic devices must not be disposed of with household
waste.
– The device contains valuable raw materials that can be recycled. Therefore,
dispose of the device at the appropriate collecting facility.
4.1 ABB devices
All packaging materials and devices from ABB bear the markings and test seals for proper
disposal. Always dispose of the packing materials and electric devices and their components via
an authorized collection facility or disposal company.
ABB products meet the legal requirements, in particular the laws governing electronic and
electrical devices and the REACH ordinance.
(EU-Directive 2012/19/EU WEEE and 2011/65/EU RoHS)
(EU-REACH ordinance and law for the implementation of the ordinance (EG) No.1907/2006)

Product description
Product manual 2TMD041900D0015 │
7
5 Product description
5.1 Control elements
No. Description
1Indicator flashes slowly: ringing
Indicator flashes quickly: busy line
2 Call indicator
3 Unlock indicator
4 Speaker and microphone integration
5 Round pushbutton
4
5
1
2
3

Product description
Product manual 2TMD041900D0015 │
8
5.2 Terminal description
No. Description
1 Connector for the sensor used for door status detection
2Connector for exit button
3Plug-in clamps (LOCK...AGND) for door opener
4Plug-in clamps (COM...NC...NO) for floating output
5 Plug-in clamps (DC+...GND) for standalone power supply
6 LAN (PoE)
7 N/A
DS
NC COM NO GND DC+
LAN
1
2 3
45
6
7
LOCKAGNDEXIT

Product description
Product manual 2TMD041900D0015 │
9
5.3 Lock type and connection
Lock type Pic Operation type Voltage Wiring type
Electrical strike
lock, 12V Power on to open 12 V
⎓
/~ Type A/B
Electrical strike
lock, 24V Power on to open 24 V
⎓
/~ Type B
Electrical rim
lock, 12 V Power on to open 12 V
⎓
Type A/B
Electrical
mortise lock Power off to open 12 V
⎓
Type C
Magnetic lock Power off to open 12/24 V
⎓
Type C
AGND
GND
NO
DC+
NC
DS
LOCK
COM
EXIT
AGND
GND
NO
DC+
NC
DS
LOCK
COM
EXIT
AGND
GND
NO
DC+
NC
DS
LOCK
COM
EXIT
+
+
+
-
--
PS
PS
TypeA
Type B
Type C

Technical data
Product manual 2TMD041900D0015 │
10
6 Technical data
Designation Value
Rating voltage 24 V
⎓
Operating voltage range 20-27 V
⎓
Rating current 27 V
⎓
, 310 mA
24 V
⎓
, 350 mA
Operating temperature -40 °C…+55 °C
Product dimensions 99 mm x 168 mm × 26 mm (H8131.P.-.)
105 mm x 180 mm × 43 mm (H8136.P.-.)
Camera type CMOS
Camera viewing angle 104°
Power supply for door opener 15 V
⎓
, 4A impulse, max. 250 mA holding
Floating output for door opener 30 V
⎓
, 3 A
IP level IP 54
IK level IK 07
Network connection standard IEEE802.3, 10/100 Mbps, auto MDI/MDI-X
