Abode Ceramic Belfast Sink AX4015 User manual

Important Technical Data
Whilst every effort has been made to make these instructions comprehensive they may not be exhaustive, we
strongly recommend that this product is installed by a skilled professional. This will ensure the best possible
finished installation.
This product is made from high quality fireclay for the greatest possible durability, after the end of the lifecycle
of this product it should be disposed of responsibly. Please be aware that fireclay is a natural material therefore
variations in size, flatness and finish should be expected
arth bonding: under current I regulations there is no statutory requirement to earth bond sinks as most new
wiring installations are protected with an RCD. If you are unsure if your wiring is protected by an RCD, contact a
qualified electrician.
Maximum temperature +300°C* Note: If this temperature is exceeded, even for short periods, damage to the
finish can result.
Waste disposers should be mounted in such a way that the weight of the unit is supported by the kitchen
cabinet carcass, not just the sink. Faulty or damaged waste disposal units can cause vibration – this will
damage the sink and can loosen connecting pipework or fixings causing water leaks. Because the waste size is
smaller than 90mm an adaptor collar will be required.
All Abode products are designed in accordance with recognised uropean or global standards. Please ensure
that your Abode product is fitted in accordance with localised legislation.
The installation should be periodically checked for damage to water sealing parts as described in the
instructions to avoid accidental water damage.
Abode is a registered trademark of Abode. All errors and omissions excepted.
A full technical specification and copies of these instructions are available for this product on our website
www.abodedesigns.co.uk
Manufacturers Product Reference
©Abode
AX4015 v3 - 10/2016
Unit L, Zenith Park, Whaley Road, Barnsley, S75 1HT.
Tel: [phone] Fax: [phone]
www.abodedesigns.co.uk
All errors and omissions excepted.
Please retain these instructions with the sink for future reference
Norcros Group (Holdings) Ltd
Ladyfield House
Station Road,
Wilmslow
Cheshire
SK9 1BU
Production year: See label
Abode DoP
Product code: See label
Preparation of food, washing of
dishes and discharge of
domestic wastewater.
N 13310
CA - DA
Ceramic Belfast Sink
10 Year Warranty
Terms and Conditions
In the unlikely event that you should experience any
defect in the materials or workmanship of your new
Abode sink within 10 years of purchase, the
manufacturer will repair or replace all or any part of the
product that is defective, at their discretion. The
manufacturer will not be responsible for any other
consequential costs such as labour, removal or
reinstallation of the sink or any other connected or
related products.
This is provided that the product has been used for
normal domestic purposes in the UK & ire, and that the
care, installation and maintenance instructions have
been observed. The warranty extends to the original
purchaser only. You should retain a copy of your dated
invoice as proof of purchase to validate any claims
under this guarantee.
Please note that this product is manufactured using
natural materials so slight shade variations can occur.
Marks, scuffs and scratches caused during installation or
accidental damage are not covered by this guarantee.
Neither are stains, discolouration or corrosion or any
damage or defect caused by incorrect installation or
abuse of the product.
We are continuously improving and developing our
range of products, finishes & colours. Therefore, in the
event of a valid claim, we may not be able to provide an
identical replacement for the defective product
throughout the guarantee period. Where an identical
product is no longer available, we will supply the nearest
equivalent from our then current product range. In
assessing your claim, we must be given the opportunity to
inspect the product as installed prior to removal. Any
product returned to us must be securely packaged and
adequately insured. We will not accept responsibility for
any damage caused during transportation.
No installer, dealer, agent or employee of Abode has the
authority to modify the obligations or limitations of this
warranty. This warranty does not affect your statutory
rights.
Care Instructions for your itchen Sink
To maintain the appearance of this product, ensure that it is regularly cleaned using only a clean, soft damp
cloth. A solution of warm water and a mild liquid non-antibacterial detergent may be used where necessary,
and then the product rinsed thoroughly and wiped dry. Any other cleaning action will invalidate your warranty.
No household or industrial chemicals should come into contact with this product to prevent damage.
To prevent staining or discolouration of the product always rinse the sink with water after use, if you live in a
hard water area we suggest you also wipe the sink dry.
Do not cut, slice or chop directly onto the sink as you may mark the surface finish. Avoid the use of plastic
washing up bowls as engrained grit on the bowl underside may mark the surface finish. Avoid impacting the
product with sharp or heavy objects, such as knives, pans or cooking pots and also avoid contact with
abrasives. No hot objects should be placed directly onto the sink surface. Avoid contact with cycles of very hot
and cold substances.
For further care and maintenance advice on removing stubborn marks and more examples of objects or
actions likely to artificially shorten the life of this product please visit our website.
Please retain these instructions with the sink for future reference

Parts and Contents
ey Description Qty
A Sink 1
B Connecting
pipework 1
C
Care instructions
& fitting
information
1
D Basket strainer
waste(s)
1
Installation Instructions
Preparation
1. Take great care when handling this sink, whilst every effort has been taken to remove sharp edges, the
material by nature may be sharp. We recommend wearing gloves accordingly. Do not lift the product
by the waste hole(s) or tap hole(s). We recommend 2 people should be used to handle this product.
2. Check the package for completeness, possible defects or any transport damage before installation
commences. Installed faulty product will not be honoured by the warranty.
3. Check that the supporting carcass and worktop is level left to right and front to back to ensure correct
drainage of water.
4. Check that the surrounding furniture is the correct size and shape to accept this product and that no
plumbing or wiring may foul the installation.
a. All ceramic products should be supported under the reverse face with a substantial braced
shelf similar to the example below. The shelf should be designed to allow for small adjustments in
height at each corner and so that it could be disassembled from the underside in the event that
the sink is accidentally damaged. Alternately a special Belfast sink carcass can be used.
b. The height of the shelf should be such that when the sink is placed on the shelf the top face rim
of the sink is level with the underside face of the worktop, see example below.
ey Description
A Surrounding cupboards or end panels
B
Hole for waste connections
(min recommended dia. 220mm for the
waste, centred to waste)
C
Supporting shelf
(moisture resistant timber or similar, ensure
framework sits directly under the product)
D Incoming hot and cold supply pipes
Supporting uprights (front & back)
5. If replacing an existing sink, remove this product and clean the surrounding area, ensure the new sink
will suit the existing cut out size and position, otherwise amend the cut out size accordingly.
6. Collect the tools you will need to complete this installation. Typically this might include a sprit level,
pencil, straight edge, set square, jigsaw, chopsaw, and a drill with screwdriver bits amongst others.
b
a
c
b
a
c
d
e
d
Installation
1. Before creating the cut out in the worktop, carefully plan the positioning of the sink. nsure that the
position of the bowl(s), tap and overflows will not interfere with surrounding units or appliances. The cut out
details are published on the included specification sheet and on www.abode.eu to ensure perfect
positioning of this product.
2. Carefully mark out the cut out using the provided technical drawing or template. Create the sink cut out in
the worktop using a router or CNC cutter, follow the manufacturer’s instructions taking care not to chip,
crack or scratch the worktop. If preparing the cut out in situ cover any open pipework to avoid any debris
contaminating the water supply feeds.
IMPORTANT: Due to the larger dimensional tolerances on ceramic products we strongly recommend making
the cut out in a scrap piece of material then checking it against the actual sink to be fitted. The cut out size
should be adjusted to suit the sink tolerances and retested against the intended product before committing to
cutting the final worksurface. The ‘nominal’ suggested cut out size will align the cut out edge with the bowl
edge radius. The offset from the bowl can be adjusted to overhang or be set back according to personal taste
but, this may interfere with installation or the correct usage of sink accessories.
3. Install the tap to the worktop according to the manufacturer’s instructions. nsure the tap is secure as later
access may be obstructed by the sink or plumbing. We recommend using long flexible tap connectors to
help.
4. Install the basket strainer waste kit according to the manufacturer’s instructions.
5. If the sink is a reversible design choose the orientation of the bowl(s) and or drainer. Place the sink on the
supporting shelf, then with a long straight edge over the surrounding cabinets and sink rim level the sink to
the cabinet tops, adjusting the supporting shelf at a the corners as required.
6. Clean the cut out perimeter of the worktop underside and the upper perimeter of the sink with a
degreasing cleaning solvent and allow to dry.
7. Apply a continuous generous bead of good quality silicone
onto the rim around the upper perimeter of the sink (fig1).
Note: if the cut out is adjusted to either overhang or step back
from the sink rim sufficient surface area must be left to allow a
water tight seal, fig. 2 shows the cut out flush to the bowl radius.
Fig 1.
8. Gently lay the worksurface onto the sink, carefully align the
sink rim with the cut out shape with equal spacing on all sides
(fig 2).
Where possible apply a 2
nd
and 3
rd
bead of silicone around
inside and outside of the adjoining sink and worktop. Any excess
silicone can be cleaned away using a proprietary silicone
cleaner. Allow the silicone to dry.
Fig 2.
9. Attach the sink connecting pipework to the waste kit(s) according to the manufacturer’s instructions.
After installation
1. Clean the sink using the attached care advice ready for use.
2. Check the sink is flat to the worktop, straight and level.
3. Close the plug(s) in all bowls, fill the sink with water below the overflow and check the water does not leak through
or around the waste(s).
4. Close the plug(s) in all bowls fill the sink with water above the overflow, check the water exits though the overflow
and does not leak from the overflow system.
5. Open the plug(s) and let water drain from the bowls, check the connecting pipework does not leak.
6. If the sink is not to be used for a period after installation, cover the sink and tap to protect them from accidental
damage during further surrounding installation work.
7. We recommend once fully set, the silicone seal should be checked for water tightness and rechecked periodically.
