Abode Ceramic Inset Sink AX4002 User manual

Important Technical Data
Whilst every effort has been made to make these instructions comprehensive they may not be exhaustive, and
we strongly recommend that this product is installed by a skilled professional. This will ensure the best possible
finished installation.
This product is made from fireclay for the greatest possible durability, after the end of the lifecycle of this
product it should be disposed of responsibly.
Earth bonding: under current IEE regulations there is no statutory re uirement to earth bond sinks as most new
wiring installations are protected with an RCD. If you are unsure whether your wiring is protected by an RCD,
contact a ualified electrician.
Maximum temperature +300°C* Note: If this temperature is exceeded, even for short periods, damage to the
finish can result.
Waste disposers should be mounted in such a way that the weight of the unit is supported by the kitchen
cabinet carcass, not just the sink. Faulty or damaged waste disposal units can cause vibration – this will
damage the sink and can loosen connecting pipework or fixings causing water leaks.
All Abode products are designed in accordance with recognised European or global standards. Please ensure
that your Abode product is fitted in accordance with localised legislation.
The installation should be periodically checked for damage to water sealing parts as described in the
instructions to avoid accidental water damage.
Abode is a registered trademark of Abode. All errors and omissions excepted.
A full technical specification and copies of these instructions are available for this product on our website.
www.abodedesigns.co.uk
Manufacturers Product Reference
©Abode
AX4002 v6 – 10/2016
Unit L, Zenith Park, Whaley Road, Barnsley, S75 1HT.
Tel: [phone] Fax: [phone]
www.abodedesigns.co.uk
All errors and omissions excepted.
Please retain these instructions with the sink for future reference
Norcros Group (Holdings) Ltd
Ladyfield House
Station Road,
Wilmslow
Cheshire
SK9 1BU
Production year: See label
Abode DoP
Product code: See label
Preparation of food, washing of
dishes and discharge of
domestic wastewater.
EN 13310
CA - DA
Ceramic Inset Sink
10 Year Warranty
Terms and Conditions
In the unlikely event that you should experience any
defect in the materials or workmanship of your new
Abode sink within 10 years of purchase, the
manufacturer will repair or replace all or any part of the
product that is defective, at their discretion. The
manufacturer will not be responsible for any other
conse uential costs such as labour, removal or
reinstallation of the sink or any other connected or
related products.
This is provided that the product has been used for
normal domestic purposes in the UK & Eire, and that the
care, installation and maintenance instructions have
been observed. The warranty extends to the original
purchaser only. You should retain a copy of your dated
invoice as proof of purchase to validate any claims
under this guarantee.
Please note that this product is manufactured using
natural materials so slight shade variations can occur.
Marks, scuffs and scratches caused during installation or
accidental damage are not covered by this guarantee.
Neither are stains, discolouration or corrosion or any
damage or defect caused by incorrect installation or
abuse of the product.
We are continuously improving and developing our
range of products, finishes & colours. Therefore, in the
event of a valid claim, we may not be able to provide an
identical replacement for the defective product
throughout the guarantee period. Where an identical
product is no longer available, we will supply the nearest
e uivalent from our then current product range. In
assessing your claim, we must be given the opportunity to
inspect the product as installed prior to removal. Any
product returned to us must be securely packaged and
ade uately insured. We will not accept responsibility for
any damage caused during transportation.
No installer, dealer, agent or employee of Abode has the
authority to modify the obligations or limitations of this
warranty. This warranty does not affect your statutory
rights.
Care Instructions for your itchen Sink
To maintain the appearance of this product, ensure that it is regularly cleaned using only a clean, soft damp
cloth. A solution of warm water and a mild liquid non-antibacterial detergent may be used where necessary,
and then the product rinsed thoroughly and wiped dry. Any other cleaning action will invalidate your warranty.
No household or industrial chemicals should come into contact with this product to prevent damage.
To prevent staining or discolouration of the product always rinse the sink with water after use, if you live in a
hard water area we suggest you also wipe the sink dry.
Do not cut, slice or chop directly onto the sink you may mark the surface finish, avoid the use of plastic washing
up bowls as engrained grit on the bowl underside may mark the surface finish. Avoid impacting the product
with sharp or heavy objects, such as knives, pans or cooking pots and also avoid contact with abrasives. No
hot objects should be placed directly onto the sink surface.
For further care and maintenance advice on removing stubborn marks and more examples of objects or
actions likely to artificially shorten the life of this product, please visit our website.
Please retain these instructions with the sink for future reference

Parts and Contents
ey Description Qty
A Sink
(may differ
from model shown) 1
B Care instructions
and cut out sizes
See included
specification sheet
C Overflow, wastes
and pipework
See included
specification sheet
Installation Instructions
Preparation
1. Take great care when handling this sink. Whilst every effort has been taken to remove sharp edges, the
material by nature may be sharp and we recommend wearing gloves accordingly. Do not lift the
product by the waste hole(s) or tap hole(s). Always use two people to handle this product.
2. Check the package for completeness and any transport damage before installation commences.
Installed faulty product will not be honoured in the warranty.
3. Check that the supporting carcass and worktop is level left to right and front to back to ensure correct
drainage of water.
4. Check that the surrounding furniture is the correct size and shape to accept this product and that no
plumbing or wiring may foul the installation.
5. If replacing an existing sink, remove this product and clean the surrounding area, ensure the new sink
will suit the existing cut out size and position.
Installation
1. Before creating the cut out in the worktop, carefully plan the positioning of the sink. Ensure that the position of the
bowl(s), tap and overflows will not interfere with surrounding units or appliances. To ensure perfect positioning of
this product the cut out details are published on the included specification sheet and on www.abode.eu.
2. IMPORTANT: Due to the larger dimensional tolerances on ceramic products we strongly recommend making the
cut out in a scrap piece of material then checking it against the actual sink to be fitted. The cut out size should be
adjusted to suit the sink tolerances and retested against the intended product before committing to cutting the
final work surface.
3. Carefully mark out the cut out using the cut out drawing provided. Create the sink cut out in the worktop using a
router or jigsaw following the manufacturer’s instructions, taking care not to chip, crack or scratch the worktop.
When preparing the cut out cover any open pipework to avoid any debris contaminating the water supply feeds.
4. Seal the cut edges of the worktop with a waterproof sealant to prevent any possible water damage to the
worktop.
5. If the sink is a reversible design choose the orientation of the bowl(s) and drainer and follow steps 6-10. If the sink is
handed skip to step 11.
b
a
c
After installation
1. Clean the sink ready for use using the attached care advice.
2. Check the sink is flat to the worktop, straight and level; pour a small amount of water onto the drainer to check for
drainage.
3. Close the plug(s) in all bowls fill the sink with water below the overflow, check the water does not leak through or
around the waste(s).
4. Close the plug(s) in all bowls fill the sink with water above the overflow, check the water exits though the overflow
and does not leak from the overflow system.
5. Open the plug(s) and let water drain from the bowls, check the connecting pipework does not leak.
6. If the sink is not to be used for a period after installation, cover the sink and tap to protect them from accidental
damage during further surrounding installation work.
7. We recommend that any water seals on this sink should be checked for water tightness periodically.
6. Choose the tap hole position(s) based on the bowl
and drainer orientation. Our recommendation (for
reduced risk of accidental damage) is to use a 35mm
diamond tipped hole saw to create the taphole,
ensure to drill the product carefully, do not use
‘hammer’ setting on the drill. Alternately carefully
follow the knock out method as described below.
7. You will re uire a centre punch and hammer to knock
out the re uired ‘part-depth’ 35mm tap hole(s).
WARNING: Always wear goggles and gloves when
removing tap holes. With a pencil, mark the show
face directly above the centre of the part-depth tap
hole(s) (Fig1).
Fig 1.
8. Whilst supporting the tap deck, drive the centre
punch through the centre of the part drilled tap hole
with one sharp blow. (Fig 2 & 3).
Note: We do not recommend creating tap holes
additional to the part depth tap holes provided. Damage
to the sink from attempting to create further tap holes will
not be cover under warranty.
Fig 2. Fig 3.
9. Using the hammer and centre punch, carefully knock
away the remaining ceramic to create the 35mm tap
hole(s). (Fig4)
10. Carefully file away any sharp edges around the tap
hole(s) using a half round file. (Fig 5)
Fig 4. Fig 5.
11. Install the tap, waste kit(s) and overflow to the sink according to the manufacturer’s instructions.
12. Apply a generous continuous bead of silicone into the
channel around the underside perimeter of the sink (Fig6).
13. Pass the sink through the worktop cut out from above, align
the sink straight to the cut out hole and worktop front edge.
Fig 6.
14. Attach the sink connecting pipework to the waste kit(s) according to the manufacturer’s instructions.
15. You may choose to neatly seal around the sink outer perimeter using silicone, whilst the underside channel
silicone bead should provide a watertight seal we recommend this step out of prudence.
