Abode MARIDO ACT3034-36 User manual

Installation:
1. Screw studded rod (D) into the base of the tap (A).
2. Ensure the upper seal (C) is inserted inside base plinth (B) then place the base plinth (B) onto the bottom of
the tap (A).
3. Screw the hot cold water tail pipes (H I) into the base of the tap (A) as shown.
4. Place the mixertap (A), base plinth (B) and upper seal (C), onto the sink/worktop, passing the tail pipes (H
I) and studded rod (D) through the tap hole.
5. Pass lower gasket (E) and then metal horseshoe (F) over the studded rod (D) and around the flexible tail
pipes (H I)
6. Fasten the fixing nut (G) securely onto the fixing stud (D) to fix the tap (A) into its correct location.
7. Connect the hot and cold tail pipes (H I) to the water mains using ½” BSPx15mm compression fittings.
After Installation:
Once you have visually checked the new fittings and connections, ensure that all taps and drains are closed
except the new product which should be left open. Turn on (reconnect) the water supplies, check carefully for
leaks around the installation and product function. Once you are sure of no leaks, close the new product and
recheck for leaks, turn on the water heating power.
Clean and dry the product of any marks from installation then cover the product with the bag provided to
protect it until use.
Important Technical Data
Minimum operating pressure
:
0.
3
bar
Maximum operating pressure: 5.5 bar*
F
low
characteristic
s
:
Single
flow
Maximum hot water temperature: 60°C*
Recommended hot water temperature: 46°C
*
If these t
emperatures or pressures are exceeded, even for short periods, damage can result
and
will void
your
warranty.
In these instances, reduce the incoming water temperature and or install a pressure reducing valve. Ensure that
your product is fitted in accordance with Local Water Byelaws or regulations by a qualified installer.
These installation guidelines have been prepared for your direction and you must exercise due care at all times.
We do not accept responsibility for problems that may occur through improper installation. Whilst installing
the product take care not to accidentally loosen any screwed assemblies.
Manufacturers Product Reference
:
A
CT30
34
, ACT3035
, ACT3036 ACT3059
04
/20
2
4
FOR SPARES TECHNICAL SUPPORT CALL ([phone]
All errors and omissions excepted.
ACT3034-36 & 59 – Single Lever Swan
5 Year arranty
Terms and Conditions:
In the unlikely event that you should experience
any defect in the materials or workmanship of
your new product within 5 years of purchase, the
purchaser’s sole remedy shall be the replacement
(at the manufacturer’s discretion) of all or any
part of the product that is defective. All working
parts and valves are guaranteed for a period of 5
years from purchase. Decorative surface finishes
and O-rings are guaranteed for 1 year from the
date of purchase provided that our advice
concerning care has been observed and no
scouring agents have been used. This is provided
that the product has been used for normal
domestic purposes only and that the care,
installation, and maintenance instructions have
been observed. The warranty extends to the
original purchaser only.
Marks, scuffs and scratches caused by improper
installation or accidental damage are not covered
by this guarantee. Neither are shade variations or
any damage or defect caused by incorrect
installation or abuse of the fitting.
As we are continuously improving and developing
our range of products, finishes colours, in the
event of a valid claim, we may not be able to
provide an identical replacement for the defective
product throughout the guarantee period. Where
an identical product is no longer available, we will
supply the nearest equivalent from our then
current product range. In assessing your claim, we
must be given the opportunity to discuss your
claim, review your proof of purchase and or
inspect the product as installed prior to removal.
Any agreed product return must be packaged as
received and complete.
No other warranties, express or implied, are
made, including merchantability or fitness for a
particular purpose. Under no circumstances shall
the manufacturer be liable for any loss or damage
arising from the purchase, use or inability to use
this product, or for any special, indirect, incidental
or consequential damages. No liability is accepted
for consequential damage to other household
fixtures, fittings or furnishings arising from this
claim, even if attached to the product. No
installer, dealer, agent or employee has the
authority to modify the obligations or limitations
of this warranty.
Important Care Instructions for your Product:
To maintain the appearance of this product, ensure that it is regularly cleaned only using a clean, soft damp
cloth. A solution of warm water and a mild liquid detergent may be used where necessary, and then the
fitting rinsed thoroughly and wiped dry. Any other cleaning action or use of common domestic cleaning
products will invalidate your warranty.
If the product has a plastic aerator insert at the end of the spout it should be unscrewed and the plastic internal
insert only removed and cleaned or descaled to maintain flow performance. Do not use descaling solution on
any decorative metal housing, rinse the insert thoroughly before reattaching in the reverse order.
Abrasive cleaners, scouring cleaners and acidic cleaners must not be used on this product under any
circumstances. Avoid contact with all solvents (including chlorinated solvents, ketones or acetones as these
may result in surface deterioration or etching). Also avoid contact with any harsh household chemicals such as
oven cleaners, drain cleaners, rust removers, paint strippers and toilet bowl cleaners, bar keepers friend or
Brasso.
Please leave these instructions for your customer.

Parts and Contents:
Key Description Qty
A Mixertap body 1
B Base plinth 1
C Upper seal 1
D Fixing stud 1
E Lower gasket 1
F Fixing bracket 1
G Fixing nut 1
H Hot Flexi tail (Pre-fitted seal) 1
I Cold Flexi tail (Pre-fitted seal) 1
Installation Instructions:
Preparation
Before installing the new product it is essential that you thoroughly flush through the supply pipes in order to remove any
remaining solder, swarf or impurities from your system. Failure to carry out this simple procedure could cause problems or
damage to the workings of the product or reduce performance invalidating the warranty.
We strongly recommend best practice of installing particle filters and isolation valves to both the hot and cold feed pipes in an
accessible position. This will help to prevent premature failure of the valves and ease any future maintenance.
All parts should be removed from their packaging and inspected for any transport damage prior to installation.
Shut off (isolate) your hot and cold water supply locally at the point of installation before continuing with the installation. If the
water cannot be isolated locally the turn off the mains stopcock and power to any heating system, now open the lowest tap or
drain point in the system until both hot and cold supplies are fully drained.
This product requires a 35mm tap hole, if replacing an existing product, remove it and clean the end of the hot and cold feed
pipes using wire wool, the tap hole area should be free from dirt and sealant.
If the handles on the product operate backwards and forwards, allow for this when planning the sink or tap hole position.
Loosely position the product and fittings to check if any alteration to the existing pipework is required, if needed, do this now.
If the product is single flow (see section important technical data “flow characteristics”) then non return (check) valves must be
installed to comply with regulations. Some products are supplied with non-return valves this will be noted in the instructions.
⚠ Correct use of Flexible Hose Connectors
If this product is supplied with flexible hose connections for ease of installation you must observe the conditions below,
failure to observe these standard installation guidelines will invalidate the warranty for your product.
Always screw
the flexi hoses
into the
product only
by hand, until
feeling
mechanical
rest, a spanner
must not be
used on the
product end of
the connecting
hose.
Always use the
pipes provided
and not an
alternative
substitute
The braiding
on the flexible
hose must not
be in contact
with anything
else, for
example
chemicals,
internal or
external room
walls or
dissimilar
metals or
materials or
sharp objects.
Never twist or
stretch the
flexible hose
during
installation.
Do not
overtighten the
hexagonal end
of the hose
connecting to
the supply
feeds when
using a spanner
causing the
hose to twist.
Hoses must
not be double
bent in
multiple
directions
kinked or
looped.
Observe the
minimum
bend radius of
50mm.
Before
assembling the
hose to the
product ensure
the hose
ferrule has
been crimped
(as highlighted)
on both ends of
the hose after
the braided
hose sleeve.
Both ends of
the hose must
have a
minimum
50mm
straight
section before
any bend.
50mmØ
