Introduction

System Overview

This manual was written to help you start using this product

as quickly and smoothly as possbile. Inside, you will find

the answers to solve most problems. In order for this

reference material to be of greatest use, refer to the

“expanded table of contents” to find relevant topics.

This board provides a total PC solution by incorporating the

System , I/O , and PCI IDE. The mainboard support single

Intel P4 processors base PC ATX system, PCI Local Bus,

CNR Bus, and AGP Bus to upgrades your system

performance.

It is ideal for multi-tasking and fully supports MS-DOS,

Windows, Windows NT , Windows ME, Windows 2000,

Novell, OS/2, Windows95/98, Windows 98SE, Windows XP,

UNIX, SCO UNIX etc.

This manual also explains how to install the mainboard for

operation, and how to setup your CMOS configuration with

the BIOS setup program.

1-11-1

1-1

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

1.Motherboard Description

1.1 Features

1.1.1 Hardware

CPU

-400MHz System Interface speed.

-Single Socket 478 for Intel P4TM up to 1.8GHz or higher(Northwood

Processor).

-Support Intel NetburstTM Micro-architecture.

Speed

-Supports 33MHz PCI Bus speed.

-Supports 2X/4X AGP Bus.

-Only support AGP 66 MHz/1.5V for 2X/4X device.

DRAM Memory

-Supports 8/16/32/64....MB DIMM module socket.

-Supports Synchronous DRAM(3.3V)

-Supports a maximum memory size of 3GB with SDRAM.

-Main support for PC-133 Module W/SPD EEPROM, but not ensure

support for PC-100 RAM Module .

Shadow RAM

-A memory controller provide shadow RAM and supports

8-bit ROM BIOS.

Bus Slots

-Provide one CNR slot and AGP slot.

-Five 32-bit PCI bus.

BIOS

-The mainboard BIOS provides “Plug & Play” BIOS whichdetects the

peripheral devices and expansion cards of the board automatically.

-The mainboard provides a Desktop Management Interface (DMI)

function which records your mainboard specifications.

-BIOS support CD-ROM, SCSI, LAN BOOT, Temperature sensor,

LAN, Alarm Bus CLK setup with BIOS.

3.3V3.3V

3.3V

AGPAGP

AGP

1-31-3

1-3

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

Universal Serial Bus

-Supports two back Universal Serial Bus(USB)Ports

and two front Universal serial Bus(USB)Ports.

Hardware Monitor Function

-CPU Fan Speed Monitor.

-CPU Temperature Monitor.

-System Voltage Monitor.

Flash Memory

-Support 2MB flash memory.

-Support ESCD Function.

IDE Bulit-in On Board

-Supports four IDE devices.

-Supports PIO Mode 5, Master Mode, high performance hard disk

drives.

-Support Ultra DMA 33/66/100 Bus Master Mode.

-Supports IDE interface with CD-ROM.

-Supports high capacity hard disk drives.

-Support LBA mode.

PCI-Based AC 97 Digital Audio Processor

-AC 97 2.1 interface.

-16 channels of high-quality sample rate conversion.

-16x8 channel digital mixer.

-Stereo 10 band graphic equalizer.

-Sound Blaster and Sound Blaster Pro emulation.

WOL (Wake On LAN)

Supports system power up from LAN ring up .

Smart Panel

Supports BIOS Port 80H POST Code output to debug LED.

1-41-4

1-4

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

I/O Bulit-in On Board

-Supports one multi-mode Parallel Port.

(1)Standard & Bidirection Parallel Port

(2)Enhanced Parallel Port (EPP)

(3)Extended Capabilities Port

-Supports two serial ports, 16550 UART.

-Supports one Infrared transmission (IR).

-Supports PS/2 mouse and PS/2 Keyboard.

-Supports ATX 4 pin power connector +12V in.

-Supports 360KB, 720KB, 1.2MB, 1.44MB, and 2.88MB floppy disk

drivers.

1.1.2 Software

BIOS

-AWARD legal BIOS.

-Supports APM 1.2.

-Supports USB Function.

-Supports ACPI

Operation System

-Supporting the highest performance for MS-DOS,Windows,

Windows NT, Windows 2000, Windows ME, Novell, OS/2,

Windows 95/98, Windows 98 SE, Windows XP, UNIX,

SCO UNIX etc.

1.1.3 Attachments

-HDD UDMA66/100 Cable.

-FDD Cable.

-Flash Memory Written for BIOS Update.

-USB2 Cable (Option).

-Fully Setup CD Driver built in Utility(Ghost, Anitivirus,

Adobe Acrobat).

-This Manual.

1-51-5

1-5

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

1.2 Motherboard Installation

1.2.1 Motherboard Map

1-61-6

1-6

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

1.2.2 Motherboard Layout

USB1

COM1

COM2

Printer

FAN5

Speak out

Line in

MIC in

GAME1

Intel

PANEL

FAN3

CNR SLOT

AGP SLOT

DIMM2

DIMM1

DIMM3

JP7

SP-J6

PCI1

PCI2

PCI3

PCI4

PCI5

FAN1 FAN2

I/O CHIP

BIOS

FAN4

JP3

JP6

JP4

(Only 2X/4X/1.5V Card)

FAN6

478

SP-J1

1-71-7

1-7

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

USB1

COM1

COM2

Printer

FAN5

Speak out

Line in

MIC in

GAME1

Intel

PA N EL

FAN3

CNR SLOT

AGP SLOT

DIMM2

DIMM1

DIMM3

JP7

SP-J6

PCI1

PCI2

PCI3

PCI4

PCI5

FAN1 FAN2

I/O CHIP

BIOS

FAN4

JP3

JP6

JP4

(Only 2X/4X/1.5V Card)

FAN6

478

SP-J1

1.3 Motherboard Connectors

1.Babk PandkI.O Cnnndbsnrr1.Babk PandkI.O Cnnndbsnrr

1.Babk PandkI.O Cnnndbsnrr1.CCAtchn-InCnnndbsnr1.CCAtchn-InCnnndbsnr

1.CCAtchn-InCnnndbsnr1.CCAtchn-InCnnndbsnr

1.CCAtchn-InCnnndbsnr

3.IR Cnnndbsnr3.IR Cnnndbsnr

3.IR Cnnndbsnr 4.Frnns COM1Cnnndbsnr4.Frnns COM1Cnnndbsnr

4.Frnns COM1Cnnndbsnr4.Frnns COM1Cnnndbsnr

4.Frnns COM1Cnnndbsnr

5.Wakd-On-LAN Cnnndbsnr5.Wakd-On-LAN Cnnndbsnr

5.Wakd-On-LAN Cnnndbsnr 6.Frnns USB1Cnnndbsnr6.Frnns USB1Cnnndbsnr

6.Frnns USB1Cnnndbsnr6.Frnns USB1Cnnndbsnr

6.Frnns USB1Cnnndbsnr

7.Frnns PandkCnnndbsnr7.Frnns PandkCnnndbsnr

7.Frnns PandkCnnndbsnr 8.FanCnnndbsnrr8.FanCnnndbsnrr

8.FanCnnndbsnrr8.FanCnnndbsnrr

8.FanCnnndbsnrr(Fan1.1.3.4.5.6((Fan1.1.3.4.5.6(

(Fan1.1.3.4.5.6((Fan1.1.3.4.5.6(

(Fan1.1.3.4.5.6(

9.ICD Cnnndbsnrr9.ICD Cnnndbsnrr

9.ICD Cnnndbsnrr10.Fknooy Cnnndbsnr10.Fknooy Cnnndbsnr

10.Fknooy Cnnndbsnr10.Fknooy Cnnndbsnr

10.Fknooy Cnnndbsnr

11.ATX Pnwdr Cnnndbsnr(ATX.J8(11.ATX Pnwdr Cnnndbsnr(ATX.J8(

11.ATX Pnwdr Cnnndbsnr(ATX.J8(11.11.

11.11.

11.ACAC

ACAC

AC’9797

9797

97 COCDC Sdkdbshnn(J1(COCDC Sdkdbshnn(J1(

COCDC Sdkdbshnn(J1(COCDC Sdkdbshnn(J1(

COCDC Sdkdbshnn(J1(

13.CPU Cknbk Frdq. Sdsshng(JP4(13.CPU Cknbk Frdq. Sdsshng(JP4(

13.CPU Cknbk Frdq. Sdsshng(JP4(14.AGP Vnksagd Acjtrs(JP8(14.AGP Vnksagd Acjtrs(JP8(

14.AGP Vnksagd Acjtrs(JP8(14.AGP Vnksagd Acjtrs(JP8(

14.AGP Vnksagd Acjtrs(JP8(

15.CMOS FtnbshnnSdkdbshnn(JP7(15.CMOS FtnbshnnSdkdbshnn(JP7(

15.CMOS FtnbshnnSdkdbshnn(JP7(

16.Tdkdohnnd hn Cnnndbsnr(TAC((noshnn(16.Tdkdohnnd hn Cnnndbsnr(TAC((noshnn(

16.Tdkdohnnd hn Cnnndbsnr(TAC((noshnn(

17.Slars PandkFtnbshnn(SP-J1.SP-J6.SP-J5((noshnn(17.Slars PandkFtnbshnn(SP-J1.SP-J6.SP-J5((noshnn(

17.Slars PandkFtnbshnn(SP-J1.SP-J6.SP-J5((noshnn(

1-81-8

1-8

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

1.3.1 Front Panel Connector (PANEL)

PANEL Connector

Speaker Connector (SPEAKER)

An offboard speaker can be installed onto the motherboard as a

manufacturing option. An offboard speaker can be connected to

the motherboard at the front pannel connector. The speaker

(onboard or offboard) provides error beep code information

during the Power Self-Test when the computer cannot use the

video interface. The speaker is not connected to the audio

subsystem and does not receive output from the audio subsystem.

Hard Drive LED Connector (HD_LED)

This connector supplies power to the cabinet IDE activity LED.

Read and write activity by devices connected to the Primary or

Secondary IDE connectors will cause the LED to light up.

SMI Suspend Switch Lead (EXTSMI) (Disabled)

This allows the user to manually place the system into a suspend

mode of Green mode. System activity will be instantly decreased

to save electricity and expand the life of certain components

when the system is not in use. This 2-pin connector (see the

figure) connects to the case-mounted suspend switch. If you do

not have a switch for the connector, you may use the "Turbo

Switch” instead since it does not have a function. SMI is

activated when it detects a short. It may require one or two

pushes depending on the position of the switch. Wake-up can be

controlled by settings in the BIOS but the keyboard will always

allow wake-up (the SMI Suspend Switch Lead cannot wake-up

the system). If you want to use this connector, the "Suspend

Switch" in the Power Management Setup of the BIOS SOFT-

WARE section should be on the default setting of Enable.

SPEAKER

PW_BN

RESET

EXTSMI

HD_LED PW_LED

KBLOCK

1-91-9

1-9

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

ATX Power Switch (PW_BN)

The system power is controlled by a momentary switch

connected to this lead. Pushing the button once will switch

the system ON. The system power LED lights when the

system's power is on .

Power LED Lead (PW_LED)

The system power LED lights when the system power is on.

Keyboard Lock (KBLOCK)

The header is for setting keyboard locked.

Reset Switch Lead (RESET)

The connector can be connected to a momentary SPST type

switch that is normally open. When the switch is closed, the

motherboard resets and runs the POST.

1.3.2 Floppy Disk Connector (FDC)

This connector supports the provided floppy drive ribbon

cable. After connecting the single end to the board, connect

the two plugs on the other end to the floppy drives.

1.3.3 Hard Disk Connectors (IDE1/IDE2)

These connectors support the provided IDE hard disk ribbon

cable. After connecting the single end to the board, connect

the two plugs at the other end to your hard disk.

If you install two hard disks, you must configure the second

drive to Slave mode by setting its jumper settings. BIOS now

supports SCSI device or IDE CD-ROM boot up (see "HDD

Sequence SCSI/IDE First" & "Boot Sequence" in the BIOS

Features Setup of the BIOS SOFTWARE) (Pin 20 is removed

to prevent inserting in the wrong orientation when using

ribbon cables with pin 20 plugged) .

1-101-10

1-10

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

1.3.4 ATX 4-pin/20-pin Power Connector (J8/ATX)

-This connector supports the power button on-board. Using

the ATX power supply, functions such as Modem Ring Wake-

Up and Soft Power Off are supported on this motherboard .

This power connector supports instant power-on

functionality, which means that the system will boot up

instantly when the power connector is inserted on the board.

-ATX 4-pin power connector only support +12V voltage.

Pin Signal Pin Signal

1 3.3V 11 3.3V

2 3.3V 12 -12V

3 GND 13 GND

4 5V 14 PS-ON

5 GND 15 GND

6 5V 16 GND

7 GND 17 GND

8 PW-OK 18 -5V

9 5V_SB 19 5V

10 12V 20 5V

Pin J8 Signal Pin J8 Signal

1 GND 2 GND

3 +12V 4 +12V

NOTE:

If there isn’t ATX 4 pin power connector, you

can move L7 to L8, but you must use 350W or

higher power supply.

1-111-11

1-11

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

1.4 Back Panel Connectors

1.4.1 PS/2 Mouse /Keyboard CONN.

The motherboard provides a standard PS/2 mouse / Keyboard

mini DIN connector for attaching a PS/2 mouse. You can

plug a PS/2 mouse / Keyboard directly into this connector.

1.4.2 USB Connectors: USB1 & USB2

The motherboard provides a OHCI(Open Host Controller

Interface)Universal Serial Bus Roots for attaching USB

devices such as a keyboard, mouse and other USB devices.

You can plug the USB devices directly into this connector.

Pin Signal

1 +5V_SB

2 USBP0-(USBP1-)

3 USBP0+(USBP1+)

4 GND

PS/2 Keyboard

(6-pinFemale)

Serial

Port(9-pin

Male)

COM1COM2SPEAKERMIC

LINE

PS/2 Mouse

USB1

Parallel

(Printer)

Port

(25-pinFemale)

MIDI/(GAME)

Port

(15-pinFemale)

USB1

1.3.5 Infrared Connector (IR)

After the IrDA interface is configured, files can be

transferred from or to portable devices such as laptops,

PDAs, and printers using application software.

1-111-11

1-11

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

USB1

COM1

COM2

Printer

FAN5

Speak out

Line in

MIC in

GAME1

Intel

PA N EL

FAN3

CNR SLOT

AGP SLOT

DIMM2

DIMM1

DIMM3

JP7

SP-J6

PCI1

PCI2

PCI3

PCI4

PCI5

FAN1 FAN2

I/O CHIP

BIOS

FAN4

JP3

JP6

JP4

(Only 2X/4X/1.5V Card)

FAN6

478

SP-J1

Front Two USB Connectors: USB2

USB2

VCC

P2-

P2+

GND

P3+

P3-

VCC

1-131-13

1-13

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

1.5 Serial and Parallel Interface Ports

This system comes equipped with two serial ports and one

parallel port. Both types of interface ports will be explained

in this chapter.

The Serial Interfaces: COM1/COM2

The serial interface port is sometimes refered to as an RS-

232 port or an asynchronous communication port. Mice,

printers, modems and other peripheral devices can be

connected to a serial port. The serial port can also be used

to connect your computer system. If you wish to transfer

the contents of your hard disk to another system it can be

accomplished by using each machine’s serial port.

The serial port on this system has one 9-pin connector.

Some older computer systems and peripherals used to be

equipped with only a 25-pin connector. Should you need to

connect your 9-pin serial port to an older 25-pin serial port,

you can purchase a 9-to-25 pin adapter.

Signal DB9 Pin DB25 Pin

DCD 1 8

RX 2 3

TX 3 2

DTR 4 2 0

GND 5 7

DSR 6 6

RTS 7 4

CTS 8 5

RI 9 22

COM1/COM2

COM2

1-141-14

1-14

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

USB1

COM1

COM2

Printer

FAN5

Speak out

Line in

MIC in

GAME1

Intel

PA N EL

FAN3

CNR SLOT

AGP SLOT

DIMM2

DIMM1

DIMM3

JP7

SP-J6

PCI1

PCI2

PCI3

PCI4

PCI5

FAN1 FAN2

I/O CHIP

BIOS

FAN4

JP3

JP6

JP4

(Only 2X/4X/1.5V Card)

FAN6

478

SP-J1

Parallel Interface Port

Unlike serial ports, parallel interface ports have been

standardized and should not present any difficulty interfacing

peripherals to your system. Sometimes called a Centronics port,

the parallel port is almost exclusively used with printers. The

parallel port on your system has a 25-pin, DB 25 connector(see

the picture below).

COM2

PS/2 Keyboard

(6-pinFemale)

Serial

Port(9-pin

Male)

COM1COM2SPEAKERMIC

LINE

PS/2 Mouse

USB1

Parallel

(Printer)

Port

(25-pinFemale)

MIDI/(GAME)

Port

(15-pinFemale)

1-151-15

1-15

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

USB1

COM1

COM2

Printer

FAN5

Speak out

Line in

MIC in

GAME1

Intel

PA N EL

FAN3

CNR SLOT

AGP SLOT

DIMM2

DIMM1

DIMM3

JP7

SP-J6

PCI1

PCI2

PCI3

PCI4

PCI5

FAN1 FAN2

I/O CHIP

BIOS

FAN4

JP3

JP6

JP4

(Only 2X/4X/1.5V Card)

FAN6

478

SP-J1

1.6 CPU Installation

1.6.1 CPU Installation Procedure: Socket 478

1. Pull the lever sideways away from the socket then raise

the lever to a 90-degree angle.

2. Locate Pin 1 in the socket and look for the white dot or

cut edge in the CPU. Match Pin 1 with the white

dot/cut edge then insert the CPU.

3. Press the lever down to complete the installation.

4. Make sure the spec of the heatsink is good enough.

Socket 478

Notch

1-161-16

1-16

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

USB1

COM1

COM2

Printer

FAN5

Speak out

Line in

MIC in

GAME1

Intel

PA N EL

FAN3

CNR SLOT

AGP SLOT

DIMM2

DIMM1

DIMM3

JP7

SP-J6

PCI1

PCI2

PCI3

PCI4

PCI5

FAN1 FAN2

I/O CHIP

BIOS

FAN4

JP3

JP6

JP4

(Only 2X/4X/1.5V Card)

FAN6

478

SP-J1

1.6.2 CPU Clock Frequency Setting: JP4

Overclocking is operating a CPU/Processor beyond its

specified frequency. JP4 jumper is used for the CPU Front

Side Bus Frequencies from 100MHz to 133MHz.

OFFOFF

OFF

ONON

1-2 3-4 5-6 7-8 9-10 CPU(MHz) PCI(MHz)

ON ON ON ON OFF 100 33.3

OFF ON ON ON OFF Auto Auto

1-171-17

1-17

Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn

Chaosdr 1 Mnshdranarc Cdrbrhoshnn

USB1

COM1

COM2

Printer

FAN5

Speak out

Line in

MIC in

GAME1

Intel

PA N EL

FAN3

CNR SLOT

AGP SLOT

DIMM2

DIMM1

DIMM3

JP7

SP-J6

PCI1

PCI2

PCI3

PCI4

PCI5

FAN1 FAN2

I/O CHIP

BIOS

FAN4

JP3

JP6

JP4

(Only 2X/4X/1.5V Card)

FAN6

478

SP-J1

1.7 Jumper Setting

A jumper has two or more pins that can be covered by a

plastic jumper cap, allowing you to select different system

options.

1.7.1 CPU/System Fan Connector: Fan1

Pin Assignment

1 Ground

2 +12VDC

3 FAN1

FAN 3

Connector

WOL

JP7

FAN 5

Connector

FAN4

Connector

JP8

FAN 6

Connector

FAN 1/2

Connector

Table of contents

Popular Motherboard manuals by other brands

Biostar

Biostar G41U3G Setup manual

ASRock Industrial

ASRock Industrial IMB-R1000 user manual

Asus

Asus P5K-E WiFi-AP user manual

Asus

Asus P5GC user manual

Terasic

Terasic XTS-FMC user manual

Asus

Asus B85-PRO GAMER user guide

Alinx

Alinx AXU4EVB-E user manual

TYAN

TYAN S1830 TSUNAMI AT user manual

JETWAY

JETWAY P4XFCU user manual

Asus

Asus IPIBL-LA Berkeley-GL8E instruction manual

MSI

MSI PRO X670-P WIFI user guide

Gigabyte

Gigabyte GA-H55M-D2H user manual

IDT

IDT 8A 72QFN Series user manual

Asus

Asus SK8V user guide

IBASE Technology

IBASE Technology MT800M-AIC user manual

onsemi

onsemi EVBUM2817/D user manual

TDK

TDK mPOL EV1404-3300-A user guide

ECS

ECS K7S6A user manual

Acorp 4S845A User manual

Popular Motherboard manuals by other brands
