ActionTec GT704-WG User manual

* Depends on the services offered by the Internet Service Provider.
© 2008 Actiontec Electronics, Inc.
Actiontec, Actiontec Installation Buddy, Connection1-2-3, Solutions for the Digital Life, Actiontec
Digital Gear and the Actiontec logo are trademarks or registered trademarks of Actiontec
Electronics, Inc. All other names are properties of their respective owners.
Product photo may differ from actual product, however functionality remains as stated above.
Specifications are subject to change without notice.
Main: [phone]
Sales Info: [phone]
Fax: [phone]
Tech Support: [phone]
Tech Support Fax: [phone]
Internet: www.actiontec.com
Minimum System Requirements
•PC or Macintosh with Ethernet or 802.11b/802.11g wireless
connection or PC with available USB port
•Microsoft Windows 98SE, Me, 2000, XP, Vista; Mac OS 9 or high-
er; Linux/BSD, Unix (USB: Windows 98SE, Me, 2000 XP)
•TCP/IP network protocol installed
•Internet Explorer 5.0+ or Netscape 5.0+
Package Contents
•Actiontec Wireless DSL Gateway
•Installation CD-ROM
•Quick Start Guide
•Ethernet Cable
•USB Cable
•User Manual on CD-ROM
•Power Cord
•DSL Cable
Note: Customers may request customized self-install kit configuration
Corporate Office
760N. Mary Avenue, Sunnyvale, CA 94085
Technical Specifications (cont'd)
Power
Requirements
Setup and
Management
Regulatory
Compliance
Limited
Warranty
Operating voltage: +12V DC +-5% @ 600mA max
Plug-N-Play Install
Web-based Management
FCC Class C, Part 15 & Part 68
UL
CE
One Year
DS759/0405
Solutions for the Digital Life™
www.actiontec.com
54 Mbps Wireless DSL Gateway
With its new Wireless DSL Gateway, Actiontec
moves way ahead of the competition. A
completely integrated networking solution in
one box (DSL modem, wireless networking, full routing
capability), the Wireless Gateway solves all of your
customer’s connection and networking needs in one tidy
little package.
Even Easier to Use
In an effort to make the Wireless DSL Gateway as
uncomplicated as possible to deploy and use, the graph-
ical user interface was redesigned from the ground up.
Now it’s a snap to check the status of the network or the
broadband connection’s IP address. Nearly all other
configuration options are one or two clicks away, and the
home page can be customized with specific Internet links
or other online services.
Security Comes First
The Gateway also functions as an Internet firewall,
providing the home network with robust protection
from outside threats, like hackers or other individuals
looking to snoop in personal files. Three different levels
of protection allow your customer to customize the level
of security. Wireless transmissions are also protected,
since the Gateway utilizes 64-, 128-, or 256-bit encryption
or WPA for ironclad protection.
Model # GT704WG
54 Mbps Wireless
DSL Gateway
Solutions for the Digital Life™
www.actiontec.com

Solutions for the Digital Life™
www.actiontec.com
Technical Specifications (cont’d)
IP
ARP
ICMP
UDP
TCP
IP Router
RIP
DHCP Server
DHCP Client
NAT, PAT
(IP Masquerading)
NAT ALGs
(Application
Level Gateway)
(NAT Pass Through)
RFC 791 “Internet Protocol”
RFC 950 “Internet Standard Subnetting Procedure”
RFC 1122 “Requirements for Internet Hosts –
Communication Layers”
RFC 1191 “Path MTU discovery”
RFC 1213 “Management Information Base for Network
Management of TCP/IP-based Internet: MIB-II”
RFC 894 “Standard for the Transmission of IP
Datagrams Over Ethernet Networks”
RFC 826 “Ethernet Address Resolution Protocol: Or
Converting Network Protocol Addresses to 48-bit
Ethernet Address for Transmission on Ethernet
Hardware”
RFC 792 “Internet Control Message Protocol”
RFC 768 “User Datagram Protocol”
RFC 793 “Transmission Control Protocol”
Support Static Route
Support Unnumbered Mode
RFC 1058 “Routing Information Protocol”
RFC 1723 “RIP Version 2 - Carrying Additional
Information”
RFC 2453 “RIP Version 2”
RFC 1812 “Requirements for IP Version 4 Routers”
RFC 1191 “Path MTU Discovery”
RFC 2131 “Dynamic Host Configuration Protocol”
RFC 2132 “DHCP Options and BOOTP Vendor
Extensions”
RFC 2131 “Dynamic Host Configuration Protocol”
RFC 2132 “DHCP Options and BOOTP Vendor
Extensions”
The DHCP client supports the following minimal
subset of options described in RFC 2132:
• Requested IP Address (requested by default; is
mandatory)
• Parameter Request list (subnet-mask only)
• IP Address Lease time (dhcp-lease-time)
• Client-identifier (dhcp-client-identifier)
• Default route (routers)
• DNS proxy servers
RFC 2663 “IP Network Address Translator (NAT)
Terminology and Considerations”
RFC 3022 “Traditional IP Network Address
Translator (Traditional NAT)”
FTP (over NATP)
Netmeeting
IPSec
PPTP
NAT advanced
features
Firewall
Universal
Plug-N-Play
(UPnP)
PPPoA
PPPoE
RFC 1483/2684
TELNET
FTP
Server/Client
Web Server
and Web Based
Configuration
Operating Range
Environmental
Operating Range
Port Forwarding
DMZ
Service Blocking
Web site blocking
Web Activity Log
Stateful Firewall: multiple security levels
Basic IDS: Stateful Packet Inspection for prevention
of Denial of Service (DoS) attacks
Internet Gateway Device (IGD) Standardized Device
Control Protocol V 1.0
RFC 2364 “PPP Over AAL5”
RFC 2516 “Method for Transmitting PPP Over
Ethernet (PPPoE)”
Supports bridged 802.3 Ethernet frames over an
ATM network
• LLC encapsulation, in which an LLC/SNAP
header is prepended to the (Ethernet) frame
• VC multiplexing, in which a null two byte header
is prepended to the frame
Default is LLC encapsulation; VC multiplexing can be
configured using console command or WEB configuration
• RFC 1483 “Multiprotocol Encapsulation Over
ATM Adaptation Layer 5”
• RFC 1213 “Management Information Base for Network
Management of TCP/IP-based Internet: MIB-II”
• RFC 2684 “Multiprotocol Encapsulation Over
ATM Adaptation Layer 5”
RFC 854 “Telnet Protocol Specification”
RFC 855 “Telnet Option Specifications”
RFC 857 “Telnet Echo Option”
RFC 858 “Telnet Suppress Go Ahead Option”
RFC 1350 “The TFTP Protocol (Revision 2)”
FTP server is in boot loader only
RFC 1945“Hypertext Transfer Protocol – HTTP/1.0”
RFC 2068 “Hypertext Transfer Protocol –
HTTP/1.1” (partial support)
RFC 2617 “HTTP Authentication: Basic and Digest
Access Authentication”
Indoors: Up to 13m (40 ft) @ 54 Mbps
Up to 17m (55 ft) @ 18 Mbps
Up to 37m (120 ft) @ 11 Mbps
Up to 91m (300 ft) @ 1 Mbps
Outdoors: Up to 55m (180 ft) @ 54 Mbps
Up to 122m (400 ft) @ 18 Mbps
Up to 171m (560 ft) @ 11 Mbps
Up to 533m (1,750 ft) @ 1 Mbps
Operating Temperature: 0-40 degrees Celsius
Humidity: 8-95% non-condensing
54 Mbps Wireless DSL Gateway
Features
•Integrated Wired andWireless Networking using 802.11g,
USB and 4 Port 10/100 Mbps Ethernet Switch
•802.11b backward compatible, communicating with
802.11b wireless products at speeds up to 11 Mbps
•
802.11g enabled to support speeds up to 54 Mbps wirelessly
•Full-rate ADSL2+ modem – supports data rates of up
to 24 Mbps downstream and up to 1 Mbps upstream*
•Exceeds performance of the DSL Forum specification
•Guaranteed loop reach of up to 18,000 feet using ADSL
and 18,600 feet using ADSL2
•TRO69 compliance available via upgrade
•Tested and compatible with all major DSLAMs
•Advanced security: WPA, WPA-PSK, WEP, Firewall,
Stateful Packet Inspection, NAT, website blocking, web
service blocking, Internet traffic logging, Denial of service
blocking, Internet traffic logging, Denial of Service
(DOS) protection
•Other features include:
Ports at Rear of Unit
Technical Specifications
Auto detection of ADSL
signal on inner or outer
pairs (manufacturing
option)
Bit Swapping
DHCP Server Option
Compliant with DSL
Forum TR048 Rate and
Reach Requirements
DMZ Hosting
DNS Proxy Server
Dynamic Rate Adaptation
Independent upstream
and downstream data
rate provisioning
LAN IP Address Selection
Mac Address Cloning
Multiple PVC supported
NAT Services Blocking
Port Forwarding
Real-time diagnostics
Remote Management
S=1⁄2 Support
Services Blocking
Static Routing
Unnumbered Mode
Support
VPN Pass Through
WAN IP & LAN IP
Address Selection
Website Blocking
54 Mbps Wireless DSL Gateway
Features
ADSL
ATM
OAM
Wireless
Ethernet
Bridge
Descriptions
ITU G.992.1 (G.dmt), G.992.2 (G.Lite), G.994.1
(G.hs), G.992.3/4 (ADSL2), G.992.5 (ADSL2+)
ANSI T1.413 Issue2
ATM User-Network Interface, Version 3.1, Section 3.
The ATM Forum
• The full VPI range (0 – 4095) and VCI range
(1 – 65535) are supported
• Adaptation Layers AAL5, AAL2 and AAL0 are
supported
• The traffic shaping function supports traffic
classes CBR, VBR (real time and non-real time)
and UBR (with PCR limiting)
ITU-T Recommendation I.610 B-ISDN “Operation
and Maintenance Principles and Operations
• F5 segment and end-to-end loopback cells
IEEE 802.11g
IEEE 802.11b
IEEE 802.1x
WPA
WEP 64/128/256 bit encryption
SSID Broadcast enable/disable
ISO/IEC 8802-3; ANSI/IEEE standard 802.3 part 3
• IEEE 802.3x – Full Duplex capable
• IEEE 802.3u – Auto negotiation
RFC 1213 "Management Information Base for Network
Management of TCP/IP-based Internet: MIB-II"
D-I-X "The Ethernet - A Local Area Network: Data
Link Layer and Physical Layer Specifications"
Transparent MAC level bridge for Ethernet-like devices
in conformance with the IEEE 802.1d specification
ISO/IEC 10038:1993 (E), Std 802.1D
RFC 1213 "Management Information Base for Network
Management of TCP/IP-based Internet: MIB-II"
RFC 1493 “Definitions of Managed Objects for Bridges”
Phone
Port
USB
Port
Ethernet
Ports
Power Port
Power
Switch
Reset Button
Model GT704WG
