Velociraptor Voice and Eye Upgrade with MONSTER M4SK
Created by John Park
Last updated on 2020-04-15 12:44:49 PM EDT

Overview
Enhance a simple rubber hand puppet with MONSTER M4SK eyes and voice changer!
By snapping the MONSTER M4SK in half (safely!) and joining the halves back together with the 9-pin JST SH cable,
you can place extra awesome eyes on a rubber hand puppet, such as the dinosaur shown here. And, the PDM
microphone and audio output allow us to run voice changer code for extra puppeteering fun!
Parts Used
Your browser does not support the video tag. Adafruit MONSTER M4SK - DIY Electronic Eyes Mask
$44.95
IN STOCK
Add To Cart
Adafruit PDM Microphone Breakout with JST SH Connector
$4.95
IN STOCK
Add To Cart
STEMMA QT / Qwiic JST SH 4-pin Cable - 100mm Long
$0.95
IN STOCK
Add To Cart
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 3 of 23

Convex Plastic Lens with Edge
$3.95
IN STOCK
Add To Cart
You'll want to get two of the lenses

Lithium Ion Polymer Battery with Short Cable - 3.7V 420mAh
$6.95
IN STOCK
Add To Cart
Stereo 3.5mm Plug/Plug Audio Cable - 6 feet
$2.95
IN STOCK
Add To Cart
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 4 of 23

Monoprice 5-Watt Guitar Amplifier, Portable Recorder
$29.95
IN STOCK
Add To Cart
USB Powered Speakers
$9.95
IN STOCK
Add To Cart
Black Nylon Screw and Stand-off Set – M2.5 Thread
$16.95
IN STOCK
Add To Cart
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 5 of 23

Materials & Tools
In addition to the parts above you'll also need:
Rubber hand puppet, such as this dinosaur (https://adafru.it/FVE)
Diagonal cutters
Safety glasses/goggles
Hobby knife
Awl
Small scredriver
Depending on the puppet you use, you may need different hardware fasteners. I used M2.5 x 16mm socket head
screws and nuts for the raptor
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 6 of 23

Separate the MONSTER M4SK
Quickstart
You should be familiar with the basic setup of the M4 Eyes project based on the most excellent Adafruit MONSTER
M4SK guide Quickstart (https://adafru.it/FDD). Before you proceed with making your own eye pattern texture maps, be
sure you've got the M4Eyes.UF2 (https://adafru.it/FDD) working properly using the default Hazel eyes
graphics (https://adafru.it/FDD).
As terrifying as this may seem, the first thing we're going to do is BREAK the MONSTER M4SK! It's going to be OK,
though -- It was designed to be broken! That's what those little perforations on either side of the bridge are there for.
We promise!
The MONSTER M4SK will not boot up just one half of the board, so be sure to plug them together with the 9-
pin cable! Want a single eye board? Check out the HalloWing M0 or HalloWing M4.

© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 7 of 23

Cut the Bridge
Using diagonal cutters, snip the perforation starting at
one end, then flip the board around and finish the cut.
Then, trim the bridge from the other side as well, using
the same procedure.
Note, you'll lose the capacitive touch nose booper capability in the process. But, other than that, by
reconnecting the two halves of the board with the 9-pin JST-SH cable, everything else will work exactly the
same as before.

Wear eye protection when cutting the PCB, as sharp piece can fly off at high velocity.

© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 8 of 23

Plug it In
Next, use the 9-pin JST-SH cable to reconnect the
boards.
Note, while each end of the cable is identical, the plugs
have polarity and can only be plugged in one way to the
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 9 of 23

board connectors. Don't force them in if they aren't
plugging in easily, just flip them around and try again.
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 10 of 23

Try powering the M4SK and turning it on now and you should see it running just as normal! Here, I've got diagnostic
code running, but you should see the eyes that ship on the M4SK.
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 11 of 23

Battery Power
Using double-stick foam tape, secure the LiPoly battery
to the back of the MONSTER M4SK's right eye board
and plug it in.
Depending on your plans for the M4SK, you can now add lenses and lens holders (https://adafru.it/FL9), put on some
eyeball .UF2 code, maybe customize the eye graphics as shown here (https://adafru.it/FIc).
For the hand puppet, we'll go about it a bit differently, so no need for the lens holders.
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 12 of 23

Voice
Changer
This used to be a separate program…it now works together with the eyes! This requires the following:
MONSTER M4SK board (https://adafru.it/FLO)
PDM microphone (https://adafru.it/FNR) and JST SH cable (https://adafru.it/FNS)
You can test with headphones…but for portable or costume use, you’ll want a battery-operated amplified
speaker and a male/male 3.5mm audio cable (https://adafru.it/yNc). Some Bluetooth boom box speakers include
an aux input jack, or I’ve used this belt-worn speaker from Monoprice (https://adafru.it/FNT) with some success
(see notes below).
Usage
The PDM microphone connects using a tiny 4-pin cable to the “PDM MIC” port on MONSTER M4SK — it’s near the
reset button. You can optionally fashion a pop filter over the mic using a little fabric or foam, it’ll probably sound better.
Connect an audio cable from MONSTER M4SK headphone jack to the aux input on the powered speaker.
The voice changer is off by default! It saps a fair bit of compute cycles (anywhere from about 25 to 50 percent…with a
corresponding drop in eye animation frame rates) so you’ll have to turn this on only if you really want it. To do so, you'll
add a line to the config.eye JSON file on the root level of your MONSTER M4SK. Use:
"voice" : true
to enable the voice changer. See the link below (https://adafru.it/FSh) for an example config file that's been set up with
voice changer parameters. Add a trailing comma if it’s not the last line.
There are three buttons along the top edge of the monster’s left eye. Tapping the inner button (the one closest to the
nose) raises the pitch by 5%. Tapping the outer button (near the corner) lowers the pitch by 5%. Tapping the middle
button resets the pitch to its default.
The default pitch is set with the pitch keyword. This is a floating-point value, where 1.0 is normal (voice is passed
straight through, no change), 2.0 will double the frequency (raising the voice by one octave), 0.5 will halve the
frequency (lowering by one octave).
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 13 of 23

pitch can be from 0.4 to 4.0…but the actual usable range where you can still understand things is a bit narrower,
perhaps 0.6 to 2.0…you’ll want to experiment a bit to find a setting that achieves the desired effect with your own
voice.
Microphone gain (sensitivity) is set with the gain keyword. If installed in a mask and you need to adjust the
microphone to compensate for its placement relative to your mouth, use this with a floating-point value where 1.0 is
“normal” sensitivity, 0.5 is quieter by half, 2.0 is double the loudness and so forth. There are limits to what can be done
here, you may want to experiment a bit with this setting and the volume of an external amplified speaker.
Don’t shout! Speak in a normal to soft voice, let the speaker take care of amplification. This helps the “weird” voice be
heard over your own.
Similarly…speak at your normal voice pitch and let the voice changer do its thing. You don’t need to make a funny
voice.
Need a Dalek voice effect? With the voice changer enabled as described above, also add "waveform" : "sine" to
enable this effect, which applies a 30 Hz sine wave modulation to the pitch-adjusted voice — same as used for the
original Dr Who Daleks. You can try other waveforms ( "square" , "sine" , "tri" and "saw" are all supported) and other
modulation frequencies ( "modulate" : 100 for a 100 Hz modulation wave)…but, to be perfectly honest…this all turned
out a bit disappointing, the feature is only left in there because the 30 Hz Dalek modulation was spot-on. With some
experimentation with different pitch and modulation settings you might also get a passable “Chicken, fight like a
robot!” voice from Berzerk, if anyone even remembers that one.
Example Config.eye File
{
// Doom-spiral eyes with voice changer
"voice" : true, //Turns on voice changer
"waveform" : "sine" , //Modulates voice with sine wave
"modulate" : 55 , //Modulation wave freq. in Hz
"eyeRadius" : 125,
"eyelidIndex" : "0x00", // From table: learn.adafruit.com/assets/61921
"irisRadius" : 125, // Iris = whole eye!
"pupilMin" : 0, // Pupil is always 0 size
"pupilMax" : 0,
"pupilColor" : [ 255, 255, 169 ], // Shouldn't show, but just in case
"scleraColor" : [ 255, 0, 0 ],
"backColor" : [ 255, 0, 0 ],
"irisTexture" : "doom-spiral/spiral.bmp",
// The doom-red and doom-spiral eyelid bitmaps don't fully close.
// This is to give the IMPRESSION of a blink without actually blinking,
// so human eye behind is hidden better when doing Pepper's ghost trick.
"upperEyelid" : "doom-spiral/upper.bmp",
"lowerEyelid" : "doom-spiral/lower.bmp",
"left" : {
"irisSpin" : 80 // Rotate iris @ 80 RPM
},
"right" : {
"irisMirror" : true, // Flip spiral image
"irisSpin" : 70 // Slightly different speed for weirdness
}
}
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 14 of 23

Tips for using the Monoprice 5-Watt Guitar Amplifier
I have a love/hate thing with this speaker. On the plus side: it’s pretty inexpensive, is rechargeable, and is slim(ish) and
clips to one’s belt or a lanyard, making it handy for costume use.
It’s really designed for guitar use and MP3 playback (from microSD card) and there’s some hoops necessary to get it to
pass through audio undistorted…
Connect MONSTER M4SK to the AUX phono jack (center of three), not the MIC input.
After powering on, wait a moment and then press the “M” button to pass through audio.
You can see in the photo that I’ve labeled mine and highlighted the correct jack and button…I use it infrequently and
forget this ritual (also helps when others are borrowing it).
This is not an Adafruit product and we do not provide support. Please check with Monoprice if you encounter trouble.
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 15 of 23

Puppet Surgery
How you approach this will vary, depending on the particular puppet you use. The basic idea is to remove the existing
eyes, add in the MONSTER M4SK eyes, and incorporate the microphone, all while maintaining access to the on/off
switch, the three buttons used for voice pitch shifting, and the USB port for charging or changing your code/graphics.
Neck Incision
To begin, I needed to open up the puppet neck in order
to access the inside of the puppet -- it was clearly
designed for very tiny hands!
I decided to use my raptor as a display bust instead of a
hand puppet, so I don't necessarily need to re-join the
split later. If you choose to use yours as a puppet, you
can fasten the opening later with adhesive backed
Velcro.
Please be very careful with cutting implements and hole punching. Young makers should seek help to avoid
injury.

© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 16 of 23

Eye Openings
Next, I marked and cut holes for the M4SK lenses/eyes.
Use a hobby knife to remove the existing eyes.
Horrifying, I know.
Mounting M4SK Holes
You could decided to glue the lenses internally, but I
chose to mount them with screws from the outside,
going through the mask and then into the M4SK
mounting holes to sandwich it all in place.
I used the acrylic holders as a hole template, but
decided not to use the holders themselves in the final
build -- Note: In the end, and upside-down orientation
worked best for fitting the M4SK to this particular
puppet, so I should have marked the holes with the lens
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 17 of 23

holder in that orientation. It worked out in the end
because the rubber is very forgiving of poking new
holes where you need 'em!
Create the holes using an awl or thin screwdriver.
M4SK Placement
Here you can see how the upside down placement of
the M4SK works.
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 18 of 23

Push the three screws through from the outside, then
place the lens into the socket.
Fit the M4SK half in place, sliding the three screws
through the mounting holes, and then fasten them with
the nuts.
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 19 of 23

This upside down orientation give us plenty of clearance for plugging in the audio output cable as well as USB for
charging and coding!
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 20 of 23

Microphone Placement
With the PDM mic breakout board plugged into the
M4SK, mount the mic board using a screw and nut as
shown here.
© Adafruit Industries https://learn.adafruit.com/hand-puppet-voice-and-eye-upgrade-with-
monster-m4sk Page 21 of 23
