Copernicus Tech Tub TEC600C User manual

Please Recycle
TEC600C - Version A - Released May 5, 2017 - Copernicus Educational Products Inc.
Assembly Guide
TEC600C_2017_A
TEC600C
Tech Tub
®
for Chromebooks

2
TEC600C - Version A - Released May 5, 2017 - Copernicus Educational Products Inc.
Assembly Guide
TEC600C_2017_A
TEC600C
Tech Tub
®
for Chromebooks
Life
Time
Tub and Lid
Warranty
1
Year
Component
Warranty

3
TEC600C - Version A - Released May 5, 2017 - Copernicus Educational Products Inc.
Power Strip
Read your power strip electrical specifications. Only plug in devices that are approved for use with this
power strip. Connect the supplied power strip directly to a wall outlet. Do not connect to another
power strip or use an extension cord. Unplug when not in use. Do not leave this product plugged in
for more than 72 consecutive hours. Turn off power strip before unplugging.
Please read the warnings below for important safety information regarding your product. Failure to
read these warnings or to follow the instructions below could result in personal injury or damage to
your product that could void your warranty.
Small
Parts
In its unassembled state, this product contains parts that can be hazardous to small children. This
product should be assembled by an adult.
Adult
Supervision
This product is to be used under the supervision of an adult.
This product is intended for indoor use only. To reduce the risk of fire or electric shock, do not expose
this product to rain or moisture. The internal components are not sealed from the environment.
Indoor Use
Only
Specifications
Electronic
Equipment
Read the electrical specifications of any electronic equipment you are using with your Copernicus
products. Failure to read these specifications and follow their instructions could result in damage to your
equipment or personal injury.
Cable Trip
Hazard
Ensure that any cables extending across the floor to your product are properly bundled and marked to
avoid tripping or falling which may lead to personal injury.
Do not install or use the electrical components of this unit during a lightning storm.
Electrical Shock
Climb Hazard
Do not climb on, hang from or suspend objects from any components of your product unless otherwise
specified.
Warning! Hazard Risks!

4
TEC600C - Version A - Released May 5, 2017 - Copernicus Educational Products Inc.
Power Strip (1)
Cable Management Channel (1)
Power Strip
Bracket (2)
Divider (6)
Locking Block (1)
Lid (1)
Tub (1)
Items not shown:
Bottom Foam Pad (1)
Padlock Keys (6)
Hook & Loop Straps (6)
Locking Pin (1)
Cable Hook (2)
Spacer (2)
Rail (2)
TEC600C
Tech Tub
®
for Chromebooks
Padlock (2)

5
TEC600C - Version A - Released May 5, 2017 - Copernicus Educational Products Inc.
Before beginning, you should have:
Hardware
Actual Size
M4 Wing Nut
x8
M4 Lock Washer
x8
M4 x 14mm
Carriage Screw
x4
M4 Flat Washer
x4
M6 Washer
x6
M6 Lock Nut
x2
M6 x 70mm
x2
Screw
TEC600C
Tech Tub
®
for Chromebooks - Parts
Contents - Box 1
Tech Tub
®
x1
Foam
x1
In Box 1
Hook & Loop
Straps
x6
Divider
x6
(23229)
Power Strip
x1
(25515)
Power Strip Bracket
x2
(232281)
Locking Pin
x1
(31079)
Locking Block
x1
(31078)
Padlock
x2
Cable Hook
x2
Key
x6
C
A
G
D
E
F
B
Additional tools required:
Adjustable wrench x2
OR
11mm Wrench x2
Allen Key 4mm
1x

6
TEC600C - Version A - Released May 5, 2017 - Copernicus Educational Products Inc.
Watch for These Helpful Symbols
This symbol denotes a 2- or 3- Person Task. For safety, please ensure that there are the
suggested number of people working on steps displaying this symbol.
Watch for this symbol throughout the Assembly Guide. Wherever you see it, pay close
attention. The symbol denotes a step needing extra attention to ensure it is done
correctly.
The star symbol highlights an advisory note.
Before You Begin
Lay out and identify all of the included parts.
The hardware has been packed according to step.
Read the assembly guide over once to familiarize yourself with them.
Please note that in its unassembled state, this product contains parts that can be
hazardous to small children. This product should be assembled by an adult.
As You Assemble the Unit
Follow the steps in sequence.
Before beginning each step, find the part(s) that you need for that step.
2- Person Task 3-Person Task
Pay attention to the labels on the parts; they are there to help direct
you at certain stages.
The title of each step states what you will be doing. Review the text
and the pictures as you build the unit.
Tips for Assembly

7
TEC600C - Version A - Released May 5, 2017 - Copernicus Educational Products Inc.
Install Cable Hooks
Note orientation
of cable hooks
Tighten fully
B B
A A
Interior of Tech Tub
You will need: (Not to Scale)
Power Strip Power Strip
Bracket x1
x2
D
M4 Flat Washer
x4
Install Carriage Bolts on Power Strip and Mount to Power Strip Brackets
Hold bracket in place
while tightening hardware.
Tighten fully.
Power strip
cord end
Keep your power strip upside
down as shown. This will make
the assembly easier!
Pay close attention to
orientation of power strip.
Actual Size:
1
A
M4 Wing Nut
x4
B
M4 Lock Washer
x4
You will need: (Not to Scale)
Tech Tub
®
x1
Cable Hook
x2
1
C
2
A
B
D
Actual Size:
2
A
M4 Wing Nut
x4
B
M4 Lock Washer
x4
C
M4 x 14mm Carriage Screw
x4

8
TEC600C - Version A - Released May 5, 2017 - Copernicus Educational Products Inc.
Assemble Power Strip on Divider
Install Power Strip
Use the 7th slot
when positioning
your power strip.
Make sure
divider tab
is pushed
down fully.
Run power strip cable
out of the bottom
back hole.
Pull power strip cable out of the
Tech Tub
®
completely. This will
make the installation of the power
strip easier!
3
You will need: (Not to Scale)
Divider
x1
1
Bracket hooks fit
into recess.
Do not hook brackets
below second rail.
2
Make sure snaps (x4)
are fully connected.
Actual Size:
4

9
TEC600C - Version A - Released May 5, 2017 - Copernicus Educational Products Inc.
Install Dividers
Wrap Power Strip Cable Lock Lid with Padlock
Note:
Padlock will not
lock without key
Plug cable directly into wall outlet.
DO NOT PLUG THIS POWER STRIP INTO ANOTHER POWER STRIP.
5
You will need: (Not to Scale)
Divider
x5
Use your devices to setup the spacing in between your
dividers. Using a smaller storage space for your device will
minimize your device’s movement during transport. Don’t
forget to leave extra room if you have a case!
Make sure divider tabs
are pushed down fully.
2 Grooves Between Dividers
for Chromebook Spacing
6
7
You will need: (Not to Scale)
Padlock
x1

10
TEC600C - Version A - Released May 5, 2017 - Copernicus Educational Products Inc.
OPTIONAL: Follow Steps 8 to 10 to install the Tech Tub® Locking Block
and Locking Pin System
8
You will need: (Not to Scale)
This system allows you to lock your Tech Tub
®
to a
table or countertop. This is a really good idea if you
leave your devices out in the open or your room
doesn’t lock. You can then lock the Tech Tub in place
and lock the Tech Tub itself.
Use Template and Drill Holes into Surface
Table or Countertop
Use positioning template
found at back of these
Assembly Instructions
Positioning Template (found at
back of this guide)
x1
Maximum thickness of
surface is 2-1/2” (63mm)
Use tape to secure
the positioning template
Use 1/4” or 6mm drill bit
Mount Locking Block
G
Label facing
upwards
Washer goes
INSIDE tube
Washer goes
UNDER tube
E E
F
Underside
Table or Countertop
E
Drilled holes from Step 6
F
E
G
Section
View
9
Actual Size:
E
M6 Washer
x6
F
M6 Lock Nut
x2
G
M6 x 70mm
x2
You will need: (Not to Scale)
Allen Key 4mm
x1
Locking Block
x1
E
E

11
TEC600C - Version A - Released May 5, 2017 - Copernicus Educational Products Inc.
x1
x3
OPTIONAL: Follow Steps 8 to 10 to install the Tech Tub® Locking
Block and Locking Pin System
Lock the Tech Tub
®
with Locking Pin
Push Tech Tub® onto Locking Block Push Tech Tub® all the way back until the
Locking Block is completely in channel.
Slide Locking Pin through hole on
Tech Tub®
Secure Locking Pin with Padlock
on other side.
10
You will need: (Not to Scale)
Padlock
x1
Key
Locking Pin
1
2
3
4

12
TEC600C - Version A - Released May 5, 2017 - Copernicus Educational Products Inc.
1
Start with the device at the front of the Tech Tub®. Plug cable into power strip and first device.
Push Cable down through top
slot on cable management
channel.
Insert cable into aligned slot.
Make sure it snaps into
place.
Make sure the power charging port
on the device is on the same side
as the cable management channel.
Cable Management
2
Feed excess cables down through the space between the tub and power strip.
To keep cables organized,
use hook & loop straps
secure cables around
power adapter.

13
TEC600C - Version A - Released May 5, 2017 - Copernicus Educational Products Inc.
Continue steps 1 & 2 for the remainder of the devices.
Cable Management
3

14
TEC600C - Version A - Released May 5, 2017 - Copernicus Educational Products Inc.
Device Management
Keeping track of your devices can be made even easier by creating
a sign-out program.
There are many automated software solutions available that make
setting up and running a device check-out program very easy.
Use a barcode and
scanner for identifying
your devices.
Does your school already use an automated system to keep track of books?
You could use this system to also keep track of your devices!
Carrying your Tech Tub
®
Use the Handles along the sides of the Tech Tub
®
for easy lifting and carrying.
Handle Handle
Handle Handle
Tips for Use

15
TEC600C - Version A - Released May 5, 2017 - Copernicus Educational Products Inc.
Hinge Side of Tech Tub
Tech Tub®
Mounting Template
Leave a minimum of 15-1/2” (395mm)
of space from Locking Block
Drill here
Snap Side of Tech Tub
®
Drill here
Leave a minimum of 15-1/2” (395mm)
of space from Locking Block
Hinge Side
Leave aminimum of 4” (102mm)
of space from Locking Block
Leave a minimum of 11” (280mm)
of space from Locking Block
Snap Side
