Adam GBK 16a User manual

© Adam Equipment Company 2010
Adam Equipment
GBK and GFK Series
( P.N. 9679, Revision C, June 2010)
So tware Rev.
V1.17 GK-H scales or Europe
V2.25 EC Approved scale
V3.32 GK scale or USA
V4.07 GK-H scale or USA
V5.32 GK scales or Europe

© Adam Equipment Company 2010
Easy Reference:
Model name o the scale:
Serial number o the unit:
So tware revision number
(Displayed when power is irst turned on):
Date o Purchase:
Name o the supplier and place:

1 | page © Adam Equipment Company 2010
CONTENTS
1. INTRODUCTION......................................................................................3
2. SPECIFICATIONS ...................................................................................4
3. INSTALLATION .......................................................................................9
3.1. UNPACKING ........................................................................................................ 9
3.2. LOCATING ........................................................................................................... 9
3.3 SETTING UP THE SCALES............................................................................... 10
4. KEYPAD ................................................................................................11
5. DISPLAY................................................................................................13
5.1. SYMBOLS AND INDICATORS .......................................................................... 13
6. CALIBRATION COUNTER FOR APPROVED SCALES.......................14
7. BATTERY ..............................................................................................16
8. BACKLIGHT ..........................................................................................16
9. AUTO POWER OFF...............................................................................16
10. OPERATION.......................................................................................17
10.1. ZEROING ........................................................................................................ 17
10.2. TARING........................................................................................................... 17
10.2.1 MANUAL TARE........................................................................................... 17
10.2.2 PRESET TARE (NOT AVAILABLE ON APPROVED SCALES)................. 18
10.3. WEIGHING...................................................................................................... 19
10.4. PARTS COUNTING ........................................................................................ 19
10.5. CHECK-WEIGHING ........................................................................................ 22
10.5.1 SETTING UP WHILE WEIGHING ............................................................... 23
10.5.2 SETTING UP WHILE PARTS COUNTING OR % WEIGHING.................... 24
10.6. LIMITS STORING AND RECALLING............................................................. 24
10.7. PERCENT WEIGHING.................................................................................... 26
10.8. ANIMAL (DYNAMIC) WEIGHING................................................................... 29
10.8.1 ANIMAL WEIGHING PROCEDURE............................................................ 30
10.9. ACCUMULATED TOTAL................................................................................ 31
10.9.1 MANUAL ACCUMULATION ....................................................................... 31
10.9.2 AUTOMATIC ACCUMULATION ................................................................. 33
11. RS-232 SPECIFICATION....................................................................34
11.1. INPUT COMMANDS FORMAT....................................................................... 39
12. CALIBRATION....................................................................................40
13. PARAMETER SETTINGS...................................................................41
13.1. CHECK WEIGHING PARAMETERS .............................................................. 41
13.2. RS-232 PARAMETERS .................................................................................. 44
13.3. SCALE PARAMETERS .................................................................................. 46
13.4. PERCENT WEIGHING AND ANIMAL WEIGHING......................................... 48
14. ERROR MESSAGES ..........................................................................49
15. SERVICE PARAMETERS...................................................................51
15.1. ACCESS TO PARAMETERS ......................................................................... 51
15.2. USING “1000” TO ENTER THE SERVICE PARAMETERS........................... 52
16. REPLACEMENT PARTS AND ACCESSORIES.................................57
17. SERVICE INFORMATION ..................................................................58
18. WARRANTY INFORMATION .............................................................59
19. APPENDIX..........................................................................................60

2 | page © Adam Equipment Company 2010

3 | page © Adam Equipment Company 2010
1. NTRODUCT ON
•The GBK/GFK scales provides an accurate, ast and versatile general
purpose weighing scales with parts counting, percent weighing and
check-weighing unctions.
•The GBK/GFK has LEDs to indicate when a weight is below the low limit,
between the limits or above the high limit next to the display. These
can work in conjunction with an audible alarm or check weighing as
well as LCD showing LO, OK and HI.
•The GBK/GFK is supplied with a RS-232 bi-directional inter ace and real
time clock (RTC).
•The GBK/GFK has a sealed keypad with colour coded membrane
switches and a large easy to read liquid crystal type display (LCD)
supplied with a backlight.
•Includes automatic zero tracking, semi-automatic tare and
accumulation acility that allows the weight to be stored and recalled as
an accumulated total.
•O ML Approved models, GBK/GFK-M, do not allow pounds units, have
calibration controlled by jumpers or passcodes and other limitations as
noted in the manual.

4
| P a g e © Adam Equipment Company 2010
2. SPEC F CAT ONS GBK Models Model #
GBK 8 /
GBK 16a
GBK 16/
GBK 35a
GBK 32 /
GBK 70a
GBK 60 /
GBK 130a
GBK 120 /
GBK 260a
Maximum Capacity 8kg/16lb 16kg/35lb 32kg/70lb 60kg/130lb 120kg/260lb Readability 0.1g/0.0002lb 0.5g/0.001lb 1g/0.002lb 2g/0.005lb 5g/0.01lb Repeatability (Std Dev) 0.2g/0.0004lb 1g/0.002lb 2g/0.004lb 4g/0.01lb 10g/0.02lb Linearity + 0.3g/0.0006lb 1g/0.002lb 2g/0.004lb 4g/0.01lb
10g/0.02lb
Units o Measure Grams & Kilograms, XXXa also to have Pounds, Ounces, & Pound/Ounces Stabilization Time 2-3 Secs Operating Temperature -10°C to +40°C / +14°F to +104°F Power Supply 230VAC 50/60Hz. in Europe, Asia and South A rica.
12vDC 800mA UL/CSA adapter or USA
Calibration External Calibration Mass User Selectable Display Backlit Green display 25mm with capacity tracker Balance Housing Cast aluminum base, Pantone cool grey painted base, stainless steel grade 304 Top pan, ABS Cool grey indicator housing Pan Size 300mm x 400mm x 32mm / 12” x 15.5” x 1.25” Overal Dimensions (w x d x h) 300mmx 620mm x 860mm or small pillar version, 300 x 820 x 860mm or large pillar Net Weight 15kg / 33 Lb 15kg / 33 Lb 15kg / 33 Lb 15kg / 33 Lb 15kg / 33 Lb Features Weighing/Counting/Checkweighing with LED lights/Percentage/Hold unction/RS232

5
| P a g e © Adam Equipment Company 2010
GFK Models Model #
GFK 75 /
GFK 165a
GFK 150 /
GFK 330a
GFK 300 /
GFK 660a
GFK 600 /
GFK 1320a
GFK 75H /
GFK165aH
GFK 150H /
GFK330aH
Maximum Capacity 75kg / 165lb 150kg / 330lb 300kg / 660lb 600kg / 1320lb 75kg / 165lb 150kg / 330lb Readability 5g / 0.01lb 10g / 0.02lb 20g / 0.05lb 50g / 0.1lb 1g / 0.002lb 2g / 0.005lb Repeatability (Std Dev) 5g / 0.01lb 10g / 0.02lb 20g / 0.05lb 50g / 0.1lb 2g / 0.004lb 4g / 0.01lb Linearity + 10g / 0.02lb 20g / 0.04lb 40g / 0.1lb 100g / 0.2lb 3g / 0.006lb 6g / 0.015lb Units o Measure Grams & Kilograms, XXXa also to have Pounds, Ounces, & Pound/Ounces Stabilization Time 2-3 Secs Operating Temperature -10°C to +40°C / +14°F to +104°F Power Supply 230VAC 50/60Hz. in Europe, Asia and South A rica.
12vDC 800mA UL/CSA adapter or USA
Calibration External Calibration Mass User Selectable Display Backlit Green display 25mm with capacity tracker Balance Housing Cast aluminum base, Pantone cool grey painted base, stainless steel grade 304 Top pan, ABS Cool grey indicator housing Pan Size 400mm x 500mm
15.7” x 19.7”
400mm x 500mm
15.7” x 19.7”
400mm x 500mm
15.7” x 19.7”
600mm x 800mm
23.6” x 31.5”
400mm x 500mm
15.7” x 19.7”
400mm x 500mm
15.7” x 19.7”
Overal Dimensions (w x d x h)
400 mm x 675 mm x
950 mm
15.7” x 26.6” x 37.4”
400 mm x 675 mm x
950 mm
15.7” x 26.6” x 37.4”
400 mm x 675 mm x
950 mm
15.7” x 26.6” x 37.4”
600 mm x 925 mm x
970 mm
23.6” x 36.4” x 37.4”
400 mm x 675 mm x
950 mm
15.7” x 26.6” x 37.4”
400 mm x 675 mm x
950 mm
15.7” x 26.6” x 37.4”
Net Weight 15kg / 33 Lb 15kg / 33 Lb 15kg / 33 Lb 45 kg / 100 Lb 15kg / 33 Lb 15kg / 33 Lb Features Weighing/Counting/Checkweighing with LED lights/Percentage/Hold unction/RS232

6
| P a g e © Adam Equipment Company 2010
GBK-M Models
Model #
GBK 6M GBK 15M GBK 30M GBK 60M GBK 150M
Maximum Capacity 6kg 15kg 30kg 60kg 150kg Readability 0.002kg 0.005kg 0.01kg 0.02kg 0.05kg Units o Measure Kilograms only Stabilization Time 2-3 Secs Operating Temperature
-10°C to +40°C / +14°F to +104°F
Power Supply 230VAC 50/60Hz. Calibration External Calibration Mass User Selectable Display Backlit Green display 25mm with capacity tracker Balance Housing Cast Aluminum base, Pantone cool grey painted base, stainless steel grade 304 Top pan, ABS Cool grey indicator
housing
Pan Size 300mm x 400mm x 32mm / 12” x 15.5” x 1.25” Overal Dimensions (w x d x h)
300mmx 620mm x 860mm or small pillar version, 300 x 820 x 860mm or large pillar
Net Weight 15kg / 33 Lb Features Weighing/Counting/Checkweighing with LED lights/Percentage/Hold unction/RS232

7
| P a g e © Adam Equipment Company 2010
GFK-M Models
Model #
GFK 60M GFK 150M GFK 300M
Maximum Capacity 60kg 150kg 300kg Readability 0.02kg 0.05kg 0.1kg Units o Measure Kilograms only Stabilization Time 2-3 Secs 2-3 Secs 2-3 Secs Operating Temperature -10°C to +40°C / +14°F to +104°F Power Supply 230VAC 50/60Hz. Calibration External Calibration Mass User Selectable Display Backlit Green display 25mm with capacity tracker Balance Housing Cast Aluminum base, Pantone cool grey painted base, stainless steel grade 304
Top pan, ABS Cool grey indicator housing
Pan Size 400 mm x 675 mm x 950 mm
15.7” x 26.6” x 37.4”
Overal Dimensions (w x d x h)
400 mm x 675 mm x 950 mm 15.7” x 26.6” x 37.4”
Net Weight 15kg / 33 Lb Features Weighing/Counting/Checkweighing with LED lights/Percentage/Hold
unction/RS232

8 | P a g e © Adam Equipment Company 2010

9 | P a g e © Adam Equipment Company 2010
3. NSTALLAT ON
3.1. UNPACKING
The GBK/GFK scales have already been adjusted to work with a plat orm and have
been con igured or this application. The plat orm and indicator have been
calibrated as a pair and must be used together .
3.2. LOCATING
•The scales should not be placed in a location that will
reduce the accuracy.
•Avoid extremes o temperature. Do not place in direct
sunlight or near air conditioning vents.
•Avoid unsuitable tables. The table or loor must be rigid
and not vibrate.
•Avoid unstable power sources. Do not use near large
users o electricity such as welding equipment or large
motors.
•Do not place near vibrating machinery.
•Avoid high humidity that might cause condensation.
Avoid direct contact with water. Do not spray or
immerse the scales in water.
•Avoid air movement such as rom ans or opening doors.
Do not place near open windows or air-conditioning
vents.
• Keep the scales clean. Do not stack material on the
scales when they are not in use.

10 | P a g e © Adam Equipment Company 2010
3.3 SETT NG UP THE SCALES
•The pillar is attached to the base using a bracket that must be attached
to the base rame irst using the 4 bolts supplied. The pillar is secured
to the bracket using 2 sets o screws. The cable rom the base to the
indicator module is run through the tube and taken out through the
plastic support at the top. Excess cable can be stored within the tube.
•The GBK/GFK Series comes with a stainless steel plat orm packed
separately. Place the plat orm in the base.
•Level the scale by adjusting the our eet. I the scale rocks re-adjust the
eet.
•Attach the indicator module to the pillar by sliding it over the bracket
with the langes engaged in the groves on the base. Attach the cable
rom the base to the connector on the rear o the indicator.
•Attach the power to the indicator. Press the [On/Off] key. The so tware
revision number will be displayed ollowed by a sel -test showing all
digits be ore the zero is displayed along with the unit o weight that was
selected last.
•I the scale is an approved version, GBK/GFK..M, and the Calibration
Counter has been enabled (see section 6) the current values will be
displayed. These values should match the values marked on the scale
at the time o veri ication, i it has been veri ied.

11 | P a g e © Adam Equipment Company 2010
4. KEYPAD
KEYS PRIMARY FUNCTION SECONDARY FUNCTION
[Zero] Sets the zero point or all subsequent
weighing. The display shows zero.
Escape rom any setting menus
[Tare] It tares the scale and stores the current
weight in memory as a tare value, subtracts
the tare value rom the weight and shows
the results. This is the net weight.
Accept the set values
[Unit] This is used to select the weighing units
rom a preset list o available units.
Allows the weight, unit weight, and
count to be seen when parts
counting or to change rom weight
to % in percent weighing

12 | P a g e © Adam Equipment Company 2010
[Low
Limit]
&
[High
Limit]
It sets the limits or check weighing and
allows setting o either the low limit or the
high limit or both.
None
[

Lim] It stores and recalls any o 10 preset limits None
[Func] This is used to select percent weighing, RS-
232 parameters, Operation o the bar
graph, RTC settings, User ID and Scale ID.
None
[Count] Enter Parts Counting None.
[Print] It is used to print the results to a PC or
printer using the RS-232 inter ace. It also
adds the value to the accumulation memory
i the accumulation unction is not
automatic.
None
[1] to [0]
and [CE]
Allow entering numerical values where
required, setting o limits, tare value, time
and date or example.

13 | P a g e © Adam Equipment Company 2010
5. D SPLAY
5.1. SYMBOLS AND INDICATORS
The LCD has unique symbols to indicate the following:
0
The display is at Zero
The scale is Stable
Net
Net weight- The scale has been tared
kg /lb
Symbols shown or the units
Capacity Tracker- A bar graph indicating the proportion o the
scale capacity being used by the weight on the plat orm
bAt LO or
Low battery
%
The scale is in Percent weighing mode
pcs
The scale is in Parts counting mode
HI, OK, LO
The scale is in Check weighing mode
:
The colons “:” are used to separate pounds rom ounces and
or the real time clock.

14 | P a g e © Adam Equipment Company 2010
Next to the LCD are a number o LED’s that show when the weight is below, within
or over the limits during check weighing.
Weight LED LCD
below the low limit Amber LO
Within the limits Green OK
Above the high limit Red HI
NOTE: The LED’s can be set by the user to o , bar, spot or segment mode. See “F3
LED” in section 13.1
The LED can be set to display as a bar, increasing rom Low to OK to High, a single
spot increasing rom Low, OK to High, or as a single bar that changes colour as the
weight progresses rom Low to OK to High.
6. CAL BRAT ON COUNTER FOR APPROVED SCALES
The approved (GBK/GFK-M Model) scales have the ability to control access to the
calibration or metrology parameters using a passcode to limit access. The
requirements or doing this stipulate the code should be apparent and recorded in a
suitable location on the scale.
In this way i the record o the Calibration or Parameter counters do not agree with
recorded settings the responsible person inspecting the scale can take appropriate
action.

15 | P a g e © Adam Equipment Company 2010
The Counters are incremented any time the calibration section or the Factory
parameters section have been modi ied.
At power on, the display will show the current so tware revision number ollowed
by the message o the Calibration Count “[AL[nt” then a number i.e. “123”. The
number rom the counter memory. Then the Parameter Counter message o
“PAr[nt” and probably a di erent number, i.e. “234”. The counters cannot be
reset to 0, they will increment until the display can no longer hold the values. (1 to
999999). It is expected we will never have more than 1 million calibrations in the
li e o the machine.
Each display is held or 1-2 seconds.
The scale will then continue to do the display test and go to normal weighing.
I during the time the counting displays are shown, the user presses the [Tare] key,
the user will be given a message to enter the passcode necessary to calibrate the
scale, “P - - - - “ Enter the code “P0000” to Enter calibration or “P1000” to enter
the parameters, ollowed by pressing the [Tare] key.
The Calibration access will allow user calibration (See section 15.1) and the
parameter code will allow access to the ollowing parameters. (see section 15.2).
“F4 Int” Initial Zero Range
“F5 rEZ” Re-Zero range
“F6 SCS” Successive Tare Enable
“F7 Cnt” Display ADC counts
“F8 Zem” Zero Mode
“F9 Lvd” Low voltage detection

16 | P a g e © Adam Equipment Company 2010
7. BATTERY
•The scales can be operated rom the rechargeable battery, i desired.
The GBK/GFK scales have up to 70 hours battery li e be ore needing to
be recharged i the backlight is disabled and the battery is ully charged.
•When the battery needs charging a symbol on the display will turn on.
The battery should be charged when the symbol is on. The scale will still
operate or a period o time a ter which it will automatically switch o
to protect the battery.
•To charge the battery, simply plug into the mains power supply. The
scale does not need to be turned on.
•The battery should be charged or 12 hours or ull capacity.
•To the right o the display is a LED to indicate the status o battery
charging. When the scale is plugged into the mains power the internal
battery will be charged. I the LED is green the battery is being charged.
I it is red it is nearly discharged and yellow indicates the battery is
increasing the charge level. Continue to charge overnight or a
complete re-charge.
8. BACKL GHT
The backlight or the LCD can be set by the user to always o , always on or
automatic (on only when the scale is in use or a key is pressed). See setting o the
parameter “S2 bL” in section 13.3.
9. AUTO POWER OFF
The auto power o can be set by the user to disable the eature or to a pre-set time
interval. See setting o the parameter “S3 AoF “ in section 13.3.

17 | P a g e © Adam Equipment Company 2010
10. OPERAT ON
10.1. ZEROING
•You can press the [Zero] key at any time to set the zero point rom
which all other weighing and counting is measured. This will usually be
necessary when the plat orm is empty. When the zero point is obtained
the display will show the zero indicator.
•The scale has an automatic re-zeroing unction to account or minor
dri ting or accumulation o material on the plat orm. However you may
need to press [Zero] to re-zero the scale i small amount o weight is
still shown when the plat orm is empty.
10.2. TARING
10.2.1 MANUAL TARE
•Zero the scale by pressing [Zero]. The zero indicator will be on. Place a
container on the plat orm and its weight will be displayed.
•Press [Tare] when the reading is stable. The weight that was displayed
is stored as the tare value and it is subtracted rom the display, leaving
zero on the display. The stable and Net indicator will be on.
•As a product is added only the weight o the product will be shown. The
scale could be tared a second time i another type o product was to be

18 | P a g e © Adam Equipment Company 2010
added to the irst one. Again only the weight that is added a ter taring
will be displayed.
NOTE:
When the container is removed a negative value will be shown. I the scale was
tared just be ore removing the container, this value is the gross weight o the
container plus all products which were removed. The zero indicator will also be on
as the plat orm is back to the same condition it was when [Zero] was pressed last.
Press [Tare] or [Zero] to remove the tare value and display zero. The Net indicator
will disappear.
10.2.2 PRESET TARE (NOT AVA LABLE ON APPROVED SCALES)
When the scale is at zero with no weight on the plat orm it is possible to enter a
preset tare.
•Zero the scale by pressing [Zero]. The zero indicator will be on.
•Enter a value using the numeric keys.
•Press [Tare] to tare the scale. The value that was entered is stored as
the tare value and it is subtracted rom the display, leaving a negative
number on the display.
