ADC®SatinTM Laryngoscope
Blades and Handles:
Standard and Fiberoptic
Instructions
for Use
LIMITED WARRANTY
American Diagnostic Corporation (ADC®) warrants its products against defects in materials and
workmanship under normal use and service as follows:
1. Warranty service extends to the original retail purchaser only and commences with the date
of delivery.
2. Your laryngoscope is warranted for one year from date of purchase (all parts).
What Is Covered: Replacement of parts, and labor.
What Is Not Covered: Transportation charges to and from ADC. Damages caused by abuse,
misuse, accident, or negligence. Incidental, special, or consequential damages. Some states do not
allow the exclusion or limitation of incidental, special, or consequential damages, so this limitation
may not apply to you.
To Obtain Warranty Service: Send item(s) postage paid to ADC, Attn: Repair Dept.,
55 Commerce Dr., Hauppauge, NY 11788. Please include your name and address, phone no.,
proof of purchase, and a brief note explaining the problem.
Implied Warranty: Any implied warranty shall be limited in duration to the terms of this warranty
and in no case beyond the original selling price (except where prohibited by law). This warranty gives
you specific legal rights and you may have other rights which vary from state to state.
For Australian Consumers: Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for a major failure and com-
pensation for any other reasonable foreseeable loss or damage. You are also entitled to have the
goods repaired or replaced if the goods fail to be acceptable quality and the failure does not amount
to a major failure.
IB p/n 9358-00 rev 18 (02/14/2023) Printed in the U.S.A.
FOR QUESTIONS, COMMENTS, OR SUGGESTIONS CALL TOLL FREE: 1-800-ADC-2670
This manual is available in a variety of languages, follow the links for language options.
www.adctoday.com/care
To register your product, visit us at
www.adctoday.com/support/warranty-registration
®
REPLACEMENT PARTS CHART
STANDARD MODELS
DESCRIPTIONS
FIBEROPTIC MODELS
DESCRIPTIONS
CAUTION: Be sure lamp’s glass surface is clean and free from fingerprints after assembly. If necessary,
the glass may be cleaned with a soft cloth or cotton ball moistened in alcohol.
Fiberoptic Light Guide Replacement:
1) Loosen the locking screw with a screwdriver.
NOTE: This screw is NOT designed to be completely removed. This prevents the screw from falling
out while the laryngoscope is in use. DO NOT attempt to remove this screw from the laryngoscope blade.
2) Pull out the green base of the fiberoptic bundle and slide out the light guide (Figure 5).
NOTE: The fiberoptic bundle is tightly fitted and may be difficult to remove.
3) Insert new fiberoptic bundle by reversing the above steps.
4) Tighten the locking screw, ensuring that the fiberoptic bundle is securely
attached to the laryngoscope blade.
Test Procedures
Laryngoscope blades and handles should always be tested after cleaning/disinfecting/sterilization, and
prior to use. To test, connect the laryngoscope blade to handle and push blade to ON position. If the
unit fails to light or flickers, check the lamp for a secure connection, check batteries, and check
electrical contacts. Be sure to have adequate supplies of replacement bulbs and batteries.
Caps on battery handles should be secure before use. If they are not, it could cause the blade to move
out of position. Laryngoscopes should be visually inspected for wear or aging prior to use and after
long storage periods. It is strongly recommended that back-up laryngoscopes are kept on hand for
emergency situations.
Any serious incident that has occurred in relation to laryngoscope medical devices should be reported
to ADC and the competent authority of the Member State in which the user and/or patient is established.
For our European Customers
On request, send to ADC by e-mail ([email protected]), we can send to you this manual on paper
form within 7 calendar days at no additional cost to the user.
Our website, https://www.adctoday.com, where you downloaded these instruction for use fulfill require-
ments of personal data protection, according to Directive 95/46/EC and GDPR on the protection of indi-
viduals with regard to the processing of personal data and on the free movement of such data.
Laryngoscope Fiberoptic Fiberoptic Fiberoptic
Item Blade Replacement Lamp Light Guide
Mac 0 4070F NA 4070FLP-00
Mac 1 4071F NA 4071FLP-00
Mac 2 4072F NA 4072FLP-00
Mac 3 4073F NA 4073FLP-00
Mac 4 4074F NA 4074FLP-00
Miller 00 NA NA NA
Miller 0 4080F NA 4080FLP-00
Miller 1 4081F NA 4081FLP-00
Miller 2 4082F NA 4082FLP-00
Miller 3 4083F NA 4083FLP-00
Miller 4 4084F NA 4084FLP-00
Wisconsin 0 NA NA NA
Wisconsin 1 NA NA NA
Wisconsin 1.5 NA NA NA
Wisconsin 2 NA NA NA
Wisconsin 3 NA NA NA
Wisconsin 4 NA NA NA
“C” Cell Handle 4065F 4532-1 (old) / 5111N-4 (new) NA
“AA” Cell Handle 4066F 4532-1 (old) / 5111N-4 (new) NA
Stubby Handle 4067F 4532-1 (old) / 5111N-4 (new) NA
Laryngoscope Standard Standard
Item Blade Replacement Lamp
Mac 0 4070 4500
Mac 1 4071 4500
Mac 2 4072 4500
Mac 3 4073 4501
Mac 4 4074 4501
Miller 00 4080-0 4500
Miller 0 4080 4500
Miller 1 4081 4500
Miller 2 4082 4501
Miller 3 4083 4501
Miller 4 4084 4501
Wisconsin 0 4090 4500
Wisconsin 1 4091 4500
Wisconsin 1.5 40915 4500
Wisconsin 2 4092 4501
Wisconsin 3 4093 4501
Wisconsin 4 4094 4501
“C” Cell Handle 4065 NA
“AA” Cell Handle 4066 NA
Stubby Handle 4067 NA
Figure 5
9358-00 rev 18.qxp_Layout 1 2/23/23 2:32 PM Page 1

Thank you for choosing an ADC®Satin™ Laryngoscope.
Device Description and Intended Use
A laryngoscope is a two-part, hand-held device consisting of a handle that contains batteries and a
detachable blade. Laryngoscopes are designed to provide illumination within the larynx during the
process of performing intubations. This instruction book covers standard and fiberoptic laryngoscope
models. Fiberoptic laryngoscopes are indicated by an “F” following the item number.
Contraindications
The following are only relative contraindication to tracheal intubation:
1. Severe airway trauma or obstruction that does not permit safe passage of an endotracheal tube.
Emergency cricothyrotomy is indicated in such cases.
2. Cervical spine injury, which requires complete immobilization of the cervical spine, makes
endotracheal intubation difficult.
Symbol Definitions
The following symbols are associated with your ADC laryngoscope blades and handles:
General Warnings
A warning statement in this manual identifies a condition or practice which, if not corrected
or discontinued immediately, could lead to patient injury, illness, or death.
WARNING: Federal law restricts this device to sale by or on the order of a physician or licensed healthcare
practitioner.
WARNING: Only trained personnel should use a laryngoscope for intubation.
WARNING: ADC recommends that spare lamps, batteries, and replacement parts always be available for
emergency use.
WARNING: The sterilization guidelines included in this instruction booklet are intended as procedures com-
patible with specific materials. Sterilization must be performed to approved hospital protocol. ADC cannot
guarantee that any of the recommended methods will guarantee sterility. This must be validated by the hos-
pital and/or sterilization equipment manufacturer.
WARNING: Fiberoptic handles may be used with ALL fiberoptic blades (reusable) that conform to the ISO
7376 standards. Standard handles may be used with any standard blades that conform to the ISO 7376
standards. Standard and fiberoptic blades and handles are NOT interchangeable.
Operation of all Laryngoscope Models
To activate, attach selected blade onto handle by hooking blade onto
handle rod as shown in Figure 1. Pull blade upward to open position to
automatically activate light.
To turn off, push blade downward into off position and disconnect
from handle. (See Figure 1).
Compatibility/Standards
Standard ADC Satin Laryngoscopes conform to current ISO 7376 standards. They are compatible with
virtually all major brands of standard illumination hook-on blades and handles.
Fiberoptic ADC Satin Laryngoscopes conform to current ISO 7376 standards. They are compatible with
virtually all major brands of fiberoptic illumination hook-on blades and handles. For easy visual
identification, ALL fiberoptic models are clearly delineated by a green indicator on both handle and blade.
Cleaning, Disinfecting, and Sterilization Procedures
ADC Satin Laryngoscope blades are crafted from rugged stainless steel. Handles are machined from
chrome-plated brass or anodized aluminum. To ensure maximum life and optimum performance, the
following instructions should be strictly adhered to.
See the sections on the reverse panel for specific cleaning, disinfection, and sterilization
procedures for your laryngoscope type.
Cleaning Procedure for Standard and Fiberoptic Blades:
Almost immediately after use, laryngoscope blades should be cleaned to prevent blood, saliva, and
other residues from drying. On standard blades, the lamp socket and wires are an integral part of the
blade for cleaning and replacement.
WARNING: Ultrasonic cleaning is not recommended.
Disinfection/Sterilization Warnings for Standard and Fiberoptic Blades:
CAUTION: ADC laryngoscope blades do not come sterilized. The Sterrad®process is NOT to be used
with fiberoptic blades.
WARNING: Flash autoclaving and hot air sterilization are not recommended, as these processes will
damage the instrument. The repeated high temperature and changes in temperature caused by autoclaving
will shorten the life of all laryngoscope products.
WARNING: Do not immerse blades in bleach, betadine, or peroxide solutions. Doing so will severely
damage the instrument. Also, avoid metal-to-metal contact on blades.
Disinfection/Sterilization Warnings for Standard and Fiberoptic Handles:
CAUTION: Do not allow excess fluid to seep into electrical contact. Be sure that the top and bottom of
the battery handle are secure before use. Poor maintenance of this device or failure to follow the warnings
in this instruction booklet could result in device failure and/or patient injury.
NOTE: Remove lamp cartridge, bulb, and batteries before disinfecting/sterilizing.
Basic Cleaning Procedure for Standard and Fiberoptic Blades:
Prepare a Klenzyme®, Manu-klenz™, or equivalent cleaning solution as per manufacturer’s instructions
and soak for ten minutes. Rinse devices with lukewarm running tap water for one minute to remove any
residual detergent after cleaning. Dry with a clean, lint-free cloth.
Basic Cleaning Procedures for Standard and Fiberoptic Handles:
Prepare a Klenzyme, Manu-klenz, or equivalent cleaning solution as per manufacturer’s instructions. Remove
both end caps, lamp cartridge and bulb, and batteries from device, and rinse with lukewarm tap water until all
visible contamination has been removed. Soak handle and end caps in the prepared solution for a minimum
of ten minutes, ensuring that all components are fully submerged. After the soak, the components should be
scrubbed with a soft-bristled brush paying particular attention to hard-to-reach areas. Rinse with cool running
tap water to remove all residual detergent. Dry with a clean, lint-free cloth.
NOTE: Always allow handles to completely dry before disinfection or use. Lamp cartridge and bulb can be
wiped with a cloth dampened with 70% isopropyl alcohol. Do not allow solution to enter into the cartridge.
The lamp cartridge and bulb CANNOT be SOAKED OR AUTOCLAVED.
High-Level Disinfection for Standard and Fiberoptic Blades:
To achieve high-level disinfection, a 2.4% glutaraldehyde solution (Cidex®or equivalent) must be pre-
pared at 77°F (25°C) to the manufacturer’s instructions. The blades should be fully immersed in the disin-
fectant for a minimum of 45 minutes. No air bubbles should be visible on the immersed blades during this
soak time. The blades should then be removed from the disinfectant and immersed in purified water to
rinse off all disinfectant. Immersion should be for a minimum of one minute and the process should be
repeated two additional times using fresh purified water each time. Once rinsing is complete, the blades
should be thoroughly dried using a sterile, lint-free cloth. Note: Always allow blades to completely dry
before use.
High-Level Disinfection for Standard and Fiberoptic Handles:
To achieve high-level disinfection, a 2.4% glutaraldehyde solution (Cidex or equivalent) must be prepared
at 77°F (25°C) to the manufacturer’s instructions. The end caps of the handles, lamp cartridge and bulb,
and batteries must be removed. Both the end caps and handles should be fully immersed in the disinfec-
tant for a minimum of 45 minutes. No air bubbles should be visible on the immersed components during
this soak time. The components should then be removed from the disinfectant and immersed in purified
water to rinse off all disinfectant. Immersion should be for a minimum of one minute and the process
should be repeated two additional times using fresh purified water each time. Once rinsing is complete, the
components should be thoroughly dried using a sterile, lint-free cloth.
NOTE: Always allow components to completely dry before reassembling the handles, inserting batteries, or
using the devices. Lamp cartridge and bulb can be wiped with a cloth dampened with 70% isopropyl alco-
hol. Do not allow solution to enter into the cartridge. The lamp cartridge and bulb CANNOT be SOAKED
OR AUTOCLAVED.
Steris Sterilization Processes for Fiberoptic Laryngoscopes:
This product has been validated with the V-PRO 1 Standard Cycle; V-PRO 1 Plus Lumen and Non Lumen
Cycles; V-PRO maX Lumen, Non Lumen, and Flexible Cycles; V-PRO 60 Lumen and Non Lumen Cycles
using the V-PRO 60 Low Temperature Sterilization System with VAPPROX®HC Sterilant and V-PRO maX
Low Temperature Sterilization System.
Steam Sterilization for Standard and Fiberoptic Blades and Handles:
Sterilizer Type: Prevacuum Sterilizer Type: Gravity
Preconditioning Pulses: 3Minimum Temperature: 249.8°F (121°C)
Minimum Temperature: 269.6°F (132°C) Full Cycle Time: 30 minutes
Full Cycle Time: 4 minutes Minimum Dry Time: 15 minutes
Minimum Dry Time: 20 minutes
Repair/Maintenance
Battery Replacement:
1) Unscrew bottom cap of handle and remove batteries.
2) Replace with appropriate size battery, taking care to insert positive ends
first. Screw bottom cap on and tighten. (Figure 2).
NOTE: Alkaline batteries should be used with your handle for maximum
performance and are recommended for replacement. Ordinary carbon zinc
batteries may also be used.
Battery Replacement: (4067F Stubby Handle)
1) Unscrew bottom cap of handle and remove battery insert.
2) Replace with appropriate size batteries. Insert one battery positive end first
and the other negative end first into battery insert, paying attention to the
polarity markings. Slide battery insert back into handle following the direction
of the “Insert This Way Only” arrows. Screw bottom cap on and tighten. (Figure 3)
NOTE: Alkaline batteries should be used with your handle for maximum
performance and are recommended for replacement. Ordinary carbon zinc
batteries may also be used.
Lamp Replacement: (Standard Models)
For correct illumination, alignment, and assurance of watertight seal during
immersion/autoclave, we recommend using only ADC #4500-1 and #4501-1
replacement lamps for standard blades.
1) To remove lamp on standard blades, grip lamp collar and rotate lamp counter
clockwise until free.
2) Replace the lamp with a new ADC lamp.
3) Verify that lamp is sufficiently tightened before use.
CAUTION: Be sure lamp’s glass surface is clean and free from fingerprints after assembly. If necessary,
the glass may be cleaned with a soft cloth or cotton ball moistened in alcohol.
Lamp Replacement: (Fiberoptic Models)
For correct illumination and alignment we recommend using only ADC replacement
lamp model #5111N-4 (Figure 4).
1) Prior to removal, allow lamp time to cool.
2) Unscrew the laryngoscope head from the barrel of the handle in a
counterclockwise direction.
3) Pull lamp out of the laryngoscope head. The lamp is friction fit and does not
need to be twisted.
4) Insert replacement lamp by firmly pressing into head until it is completely seated.
5) Screw the laryngoscope head onto the barrel of the handle. Tighten by hand only.
Figure 4
Figure 1
Figure 3
Figure 2
Symbol Definition
Attention. Read operating manual
for cautions and instructions for use.
Meets general safety and performance
requirements of Regulation (EU)
2017/745 of the European Union
Authorized European
Representative’s Information
Medical device
Not made with natural rubber latex
Type BF applied part
Keep away from sunlight
Product code
Symbol Definition
Phthalate free
Manufacturer’s Information
Lot/Batch code
Do not dispose of this product
as unsorted municipal waste
Follow instructions for use
Date of manufacture
Keep in a cool, dry place
Unique Device Identifier
Consult instructions for use
Non-sterile
Do not use if the package is damaged
9358-00 rev 18.qxp_Layout 1 2/23/23 2:32 PM Page 2
