ADE M403020 User manual

Operating Manual
Class III Approved Scales
Electronic Chair Scales
M403020
M403020-210322-Rev006-UM-e

2 M403020-210322-Rev00 -UM-e
Contents
Introduction .............................................................................................................................................. 3
Assembly and set up ............................................................................................................................... 3
Power supply ........................................................................................................................ 3
Replacing the rechargeable batteries ................................................................................ 4
Tips for handling the batteries ............................................................................................ 4
Quality features .................................................................................................................... 4
Using the scales for legal metrological applications ....................................................... 4
Display ..................................................................................................................................................... 5
Description ............................................................................................................................ 5
Safety .......................................................................................................................................................
Safety instructions ...............................................................................................................
Connecting additional devices ...........................................................................................
Housing and connections ................................................................................................... 7
odes of operation .............................................................................................................. 7
Settings ................................................................................................................................. 7
Setting date and time ........................................................................................................... 8
Operation ................................................................................................................................................. 8
Positioning of patient ........................................................................................................... 8
Weighing ............................................................................................................................... 8
Resetting the scales back to zero ...................................................................................... 8
Tare function ......................................................................................................................... 8
Hold function ........................................................................................................................ 9
Determining the Body ass Index (B I) ........................................................................... 9
Evaluating Body ass Index ............................................................................................. 10
Print out a record ............................................................................................................... 10
Care, servicing and recalibration ........................................................................................................... 10
Cleaning .............................................................................................................................. 10
Waste disposal ................................................................................................................... 11
Storage and transport conditions .................................................................................... 11
Warranty .............................................................................................................................. 11
Recalibration ....................................................................................................................... 11
Technical specifications ......................................................................................................................... 12
Conformity declaration ........................................................................................................................... 13

M403020-210322-Rev00 -UM-e 3
Introduction
This symbol means: "Consult operating instructions". To achieve accurate results, read the
instructions for use carefully before use and follow all instructions provided therein. Keep the
instructions for use for future reference.
Your ADE electronic chair-scale is a quality, sturdy and durable product manufactured under the high stand-
ards and regulations for calibrated class III scales in accordance with national regulation in Germany. The
scale is designed and manufactured for the daily practice in hospitals, doctors’ surgeries and in-patient nursing
facilities.
ADE instruction manuals have been prepared to provide the user with all the necessary knowledge about the
safe use of ADE scales and their related accessory equipment.
For further questions about how to use the products or about this or other service manuals, feel free to contact
your local ADE representative or visit our web page at www.ade-hamburg.de
In order to achieve the best possible results kindly read and follow the operation manual in all respects.
Assembly and set up
The ADE chair scale is already been delivered in a fully assembled condition. Please insure that your scale is
being placed vibration free at a dry place.
Alignment of the scale
1) Place the chair scale on a plain, dry and level surface before the weighing of patients.
3) The air bubble in the spirit level should be right in the centre of the circle
4) Please ensure that the scale has no other contact to the floor than by the four wheels after the patient has
been seated onto the chair scale.
Power supply
Power is supplied either by the rechargeable battery in the display unit or by the mains power via the supplied
power unit. The imprinted voltage value at the mains adapter must match the local mains voltage.
After checking same connect the mains cable to the indicator and to a socket.
Note: The wall socket must be located near to the unit and be easily accessible. Please use only the mains
adapter supplied by ADE. The mains adapter is charging the battery pack at the same time.
When the battery is being charged for the first time a sufficient charging period of approx. 24 hours is neces-
sary to achieve a full battery load.
In case the scale is being used with batteries only and the display indicates – Lo, the battery should be re-
charged with the ADE mains adapter. After the first charging period the battery need 12-1 hours. The battery
should be charged while the scale is switched off. Upon completion of the charging period switch the scale on
again to check the battery status. In case Lo- still appears on the display inform your service partner.

4 M403020-210322-Rev00 -UM-e
Replacing the rechargeable batteries
The battery compartment is located at the front of the unit.
1) Open the battery compartment.
2) Remove the battery cable and the corresponding connector carefully from the housing. Disconnect the
battery pack. Connect the wires/plug (red to red, black to black) with the new battery pack and insert
same into the housing.
3) Close the battery compartment.
Only use original rechargeable batteries and charger units from ADE. The warranty does not
cover any damage caused by using other types of batteries or charger units.
Tips for handling the batteries
The life of a battery depends essentially on the load, frequency of use, temperatures, settings and the acces-
sories used.
– New batteries or batteries that have been stored for long periods require a longer charging period.
– Charge the batteries at room temperature.
– Store the batteries empty (uncharged) in a cool, dark and dry place.
– Never expose the batteries to temperatures below -10°C (14°F) or above 45°C (113°F).
– Over the course of time, batteries lose their charging capacity and require a recharging period. If the bat-
tery performance drops considerably, then it is time to replace the battery.
– New batteries are supplied only in partial charged condition. Some batteries only achieve their full capaci-
ty after several complete charge and discharge cycles.
– When disposing of disused batteries, observe the valid legal and municipal regulations.
Never dispose of batteries in fire as they can leak or explode!
Quality features
ADE products correspond to the applicable EC Directives and European standards to manufacture
and distribute world-wide medical devices as per the latest technical standards ensuring a long life
time and continuous reliability.
This symbol stands for compliance of the European Directive covering medical
devices and declares the conformity as per the Medical Device Law..
Approved scales classes III respecting the standards of the European guideline
covering approved scales are carrying this sign.
This symbol means: "Consult operating instructions". To achieve accurate results,
read the instructions for use carefully before use and follow all instructions provid-
ed therein. Keep the instructions for use for future reference.
Products carrying this symbol meet the requirements as per:
 The valid EC Directive for non automatic scales
in the latest version.
Using the scales for legal metrological applications
The scales are used in medical facilities for diagnostic and medicinal purposes as long as they are calibrated.
The scales must be recalibrated according to legal conditions and regulations.

M403020-210322-Rev00 -UM-e 5
Display
Description
The ADE-display (MAK) is a digital precision display unit for medical use in hospitals by doctors and special-
ists of all medical fields.
Fig. 1-1 Indicator and operating controls
No. Name Description
1 Display LCD display for weight, mode, settings and configuration information.
2 Battery charge level Status indicator for the current battery charge level.
3 Switching points 1 & 2 In program mode: Status indicator for switching points 1 & 2.
4 BMI status indicator
(HI, OK, LO) Status indicator of the automatic BMI (Body Mass Index) evaluation.
5 Net status indicator LCD on - net weight is being displayed.
LCD off – gross weight is being displayed.
Status indicator LCD on - the weight is within ¼ of a calibrated value from the zero point.
LCD off - the weight is outside ¼ of a calibrated value from the zero point.
7 Hold – button Activates the hold function.
8 On/off, zero – button Switch the scale on and off or re-sets the display.
9 Tare- button Activate/ deactivate the tare function.
10 Preset tare – button Press briefly to access the tare function.
Press for a long period to enter and save the tare value.
11 BMI – Button Enter to proceed with BMI mode and to enter as next step the height.
Press again to return to weight mode.
12 Units – Button Switch button between primary and secondary units. Not available for CE
approved class III scales
13 Number pad
Figures 0-9, Clear, Enter. - Navigation functions:
Key menu direction to the RIGHT
Key 4 menu direction to the LEFT
Key 8 menu direction DOWN
Key 2 menu direction UP
The blue symbols under the keys (up, down, left, and right) describe the
key functions in configuration and setting modes. These keys are used
to navigate through the menus, to select numerical values and to in-
crease or lower the values.
Special function:
"0" key
In weight mode, you can change between gross and net weight using
figure "0" (if any weight have been tared off).
"Enter" key Function in weight mode: "Print" if printer has been connected.
14 Standstill status indica-
tor (14) :
The scale is at a standstill, meaning the weight is stable and no
movement is on the platform. This is a mandatory precondition for func-
tions such as resetting, printing and taring).
If the LCD is not displayed: The scale is not in a the standstill mode
15 “Hold” If displayed is the hold function is activated
18
17
1
15
14
1
2
3
4
5
7
8
9
10
11
12
13

M403020-210322-Rev00 -UM-e
1 “Ib” If displayed is the weight is displayed in pounds
17 “oz” If displayed is the weight is displayed in ounces
18 “kg” If displayed is the weight is displayed in kilograms
Safety
Safety instructions
The ADE-display unit (MAK) corresponds to the latest state of the art technology and complies with standard
regulations and directives. Kindly follow the safety instructions in this operating manual, the country-specific
installation standards as well as the applicable safety conditions and accident prevention regulations in all
aspects. Portable and mobile HF-communication systems may influence electronic medical devices.
Electronic medical devices are restricted to special safety regulations in respect of their electromagnetic com-
patibility. For positioning and operation follow the instructions of this Operating Manual.
– Before commissioning, ascertain whether the mains voltage and power type stated on the type plate
match the mains voltage and power type at the place of use.
– Make sure that the mains cable does not pose any potential trip hazard.
– Only use approved accessories and peripheral equipment.
– Only operate the unit under permitted ambient conditions.
– Remove the mains plug before cleaning the unit.
– Do not operate the unit in hazardous or unstable conditions.
– Do not submerge the unit in water or other liquids.
– All actions/operations described in this operating manual may only be carried out by trained and by ADE
authorised professional personnel.
– Using accessories that do not meet the safety requirements of this unit can lead to a reduction in the
safety level of the entire system.
– Set up the unit as far away as possible from equipment that generates electromagnetic or other interfer-
ence.
– Only ADE power adapters are allowed to use to avoid any risk of fire and electric shock.
– Clean with a dry cloth; do not use any sharp cleaning materials.
Hazard-free operation is no longer guaranteed:
- If the power unit exhibits visible damage.
- If the power unit is no longer working.
- After longer periods of storage in damp rooms.
Inform your service partner in such cases for your own safety.
Connecting additional devices
Connection of printer, PC or remote-display will be done with the RS-232 interface. For connection of addi-
tional devices kindly ask your local representative or authorized ADE dealer for further instructions.

M403020-210322-Rev00 -UM-e 7
Housing and connections
The mains adapter connection, serial port connection and connection to the weighing cell are located on the
back of the ADE indicator housing. The set-up switch to start configuration mode is recessed underneath the
housing. It is protected by a cover plate and secured by a screw (not shown in Fig. 2-1).
Do not use the set-up button as otherwise calibration will be lost. This procedure is only al-
lowed to be done by authorized service personnel appointed by ADE (GmbH & Co.). Any unau-
thorized manipulations made to the configuration mode will affect the warranty agreement.
odes of operation
 Weighing mode
The "weighing mode" is of course the standard mode of your scale. After initial configuration and sealing (by
attaching a calibration sticker to the back of the unit), the ADE-scale can only be operated in this mode.
 Setting mode
Date, time and consecutive numbers for print commands are being set in this mode. To start setting mode,
hold the GROSS/NET key pressed until TIME appears on the display.
 Configuration mode (set-up mode)
The values for different parameters including the calibration could be set in the configuration mode. This func-
tion is reserved for authorized service personnel only.
 Test mode
There are different diagnostic functions for the ADE-MAK in test mode. This is reserved for service personnel
only.
anipulations to test and configuration modes can revoke the calibration status and will result
in loss of warranty!
Settings
The following functions are available in setting mode:
– Select the serial interface,
– Set date, time and consecutive printout numbers.
– Set print format.
– Set switching points.
– Test functions
The setting mode is not designed for the input of metrological parameters. Access the function menu by press-
ing the CLEAR (13) key until TIME appears on the display. Use the key pad (13) to navigate within the menus,
to select numerical values and to increase or lower the values. Press the ENTER key to save the values en-
tered and to return to the super ordinate menu level.

8 M403020-210322-Rev00 -UM-e
enus structure of setting mode:
FILTER SERIAL PROGR PFORMT SETPTS TEST TIME DATE VERS
Setting date and time
– Enter the CLEAR key for approx. 4 sec; FILTER appears on the display.
– Press key " " six times and TI E appears on the display.
– Press ENTER key and SHOW appears on the display.
– Press key " " one time and HOUR appears on the display.
– Press ENTER key and set the hours using the arrow keys "2", "4", " " and "8".
– Press the ENTER key and set the minutes and seconds.
– Go back by pressing key "2"; TI E appears on the display.
– Press key " " one time and DATE appears on the display like the time entry.
– Press key "2" two times and EXIT Y appears on the display.
– Confirm with ENTER and date & time are set.
Operation
Positioning of patient
Please ensure for security reasons that all brakes at the wheels are being locked. Move the armrest and foot-
rest in an upright position before the patient is being moved onto the scale. Fold down the armrest and foot-
rest and place the feet of the patient upon the footrest.
After finishing the weighing procedure please make sure, that arm- and foodrest are being moved
again into the upright position before patient stand up again.
Armrest and footrest are not to be used as helping device for getting up from the chair!
They are to be understood as supporting device for arms and legs only in order to allow an ac-
curate weighing procedure!
Weighing
Press the ON key for at least 3 seconds to turn the scales on. An automatic function test is carried out after
being switched on. This test is completed when the display shows zero. The scale is now ready for the weigh-
ing procedure.
Resetting the scales back to zero
Wait until the standstill status indicator  (14) appears. By pressing the ZERO key (8), measuring inaccura-
cies after switching on the scale are being compensated. The zero key restarts the scale. The status indicator
( ) appears when the scale is being resetted.
Tare function
The TARE key (9) is used when the patient is being weighed with other items (e.g. clothing, shoes or other
items) which should be ignored by the scale. To do this, weigh these items first. After the weight is displayed,
press the TARE key (9) to reset the display back to zero. The display changes to net mode (NET status indica-
tor (5) is on). The weight of the previously weighed and saved items is ignored when the patients’ weight is
displayed. Enter the tare button again to get back to the normal weighing mode and remove any load from the
platform.

M403020-210322-Rev00 -UM-e 9
Entering manually tare - values:
Enter the appropriate tare value just by using the key pad under normal weighing mode. If the tare value has
been entered correctly, the value will be stored. Press the ENTER key (or TARE). The ADE-display is now
ready for weighing and changes to net mode [NET status indicator (5) is on]. Enter the tare button again to
leave this mode.
The manual tare value must be >0, the maximum value is limited by the weighing range.
Preset tare
Press and hold the PRESET TARE key (10) [approx. 3 sec.], PRO PT X appears on the display. Select the
memory location 1-10. Now enter the TARE VALUE which you would like to be ignored by the scale and con-
firm same with ENTER. Enter the tare button again to leave this mode.
Restore the preset tare value
Press the PRESET TARE key (10). "Pt x" appears on the display. Enter a number from 0-9 (memory location
for the tare value). If no number is entered within five seconds, the unit will turn back to weighing mode.
After entering the number, the ADE-MAK accesses the preset tare value, shows it for five seconds on the dis-
play and then changes to net mode. The accessed tare value is accepted at the same time. Enter the tare
button again to leave this mode.
Displaying the gross weight, net weight and tare value
Press the "0" key to change between displays for tare, gross weight (NET status indicator (5) off) and net
weight (NET status indicator (5) on). If a tare value is saved, the net weight shown corresponds to the gross
weight minus the tare value. If there is no tare value saved, the display remains in gross mode.
The tare value flashes briefly, then after a second the display changes to gross mode.
Hold function
Use the HOLD key to hold the display if there are weight fluctuations which e.g. are caused by patient move-
ments on the scales. You could also use this function if you like to hold the results at the display after the
weight/load has been removed from the scale.
To do this, the scales must be at standstill, e.g. the standstill status indicator  (14) is on (depending on the
setting it is not always necessary for the scales to be at standstill). The Hold status indicator (15) is on.
Deactivate the HOLD function by pressing the key again.
Determining the Body ass Index (B I)
The BMI figure is a index which displays the ratio between height and weight.
BMI=
body weight
(height)²
To determine this value you need the height of the person. Best way to get the height is of course to use an
ADE height measuring rod; model MZ10023.
Start the scale and weigh the person. Then press the BMI key (11) to start BMI mode. The last value entered
appears on the display. Use the numerical key pad to enter a new value for the height (in cm) or retain the
value which is already displayed.
Confirm the value entered with the ENTER key or delete same by using the CLEAR key. After the entry has
been confirmed by the ENTER key, the BMI value will be calculated using the weight on the scales. The dis-
play changes between weight value and BMI value "b xx.x" (every two seconds) for a period of 3 minutes.
Press the BMI key (11) to cancel befoe this time has expired.

10 M403020-210322-Rev00 -UM-e
Evaluating Body ass Index
Print out a record
The scales must be at standstill, e.g. standstill status display  (14) appears at the screen.
Press the ENTER key (13) to send the data to the serial interface.
Note: Printing is not possible if the net weight is 0. The print function only produces one print-out. A reset is
required to print out another copy.
Care, servicing and recalibration
Cleaning
Please disconnect the unit from the operating voltage before cleaning. Do not use any aggressive cleaning
materials for cleaning; only use a damp cloth or conventional disinfectant.
ake sure that no liquids penetrate the unit!
Error messages
Error mes-
sage
Description Problem solution
Overload display Weight exceeds max. capacity of the
scales.
Overflow indicator (negative) Negative weight indicated – weight too
low to be displayed (<=99999).
Overflow indicator (positive) Positive weight indicated – weight too
high to be displayed (>=999999).
AD LOW A/D above negative range Check if the scales are correctly as-
sembled or if they are damaged.
AD HI A/D above positive range Check if the scales are correctly as-
sembled or if they are damaged.
EE SUM Parameter or calibration error Recalibrate – please contact your sup-
plier or service partner:
EE WR EEPROM indicates an error Please contact your supplier or service
partner.
PM SUM Internal program indicates a check error Please contact your supplier or service
partner.
HOFSET Switch on – above zero Please remove the weight from the
scales and restart.
BMI evaluation according to WHO
BMI < 1 Severely underweight
1 - 17 Moderately underweight
17 - 18.5 Slightly underweight
BMI 18.5 - 25 Normal weight
BMI 25 - 30 Overweight
30 - 35 Obese Class I
35 - 40 Obese Class II
> 40 Obese Class III

M403020-210322-Rev00 -UM-e 11
LOFSET Switch on – below zero Check scales for damage and inform
your service partner:
UOFSET Irregular Do not touch the scales afte
r they have
been switched on.
Waste disposal
Used electrical equipment and batteries do not belong in the domestic waste.
Please dispose of defective or used equipment and batteries according to legal regulations of
your specific country!
Please make sure that only discharged batteries or batteries with insulated "poles" are dis-
posed of as otherwise they may short-circuit!
Storage and transport conditions
Keep all packaging in case you need to return the item, in order to avoid any potential transport damage.
Disconnect all connected cables before dispatch. This is how you can avoid unnecessary damage.
Warranty
A two-year warranty from date of delivery applies to defects attributable to poor materials or workmanship.
All movable parts, e.g. batteries, cables, power units, etc. are excluded. This warranty does not cover any
normal, external appearance of use and wear or any damage occurring as a result of an accident or misuse.
Any warranty or damage compensation claims presuppose the use of original ADE accessories and replace-
ment parts. The warranty does not cover units that have been opened by unauthorised persons.
The legally regulated rights of the customer are in no way affected by this agreement.
The supplier who sold the scales is in charge of complaints, customer service and replacement parts.
Recalibration
Have the calibration carried out by an authorised company or authorised person according to national legisla-
tive regulations. The CE symbol shows the authorised site (0122) and the year of initial calibration. Recalibra-
tion must be carried out
- if the calibration mark has been damaged
- after calibrated scales have been successfully repaired
- or after expiry of a period for recalibration as stipulated by national, legal regulations.

12 M403020-210322-Rev00 -UM-e
Technical specifications
Power supply
Mains Adapter:
Mains voltage 115 or 230VAC
Frequency 50 or 0HZ
Power Consumption 11W in-charger, 2W off-charger
Main power circuit
Input Voltage 5.0VDC
Max. Current (in-charger) 1000mA
Battery Requirement: Rechargeable Lithium Ion Cylindrical (18 50x2) Cell 3.7V 4000mAH
Battery Operation:
Charger 7~10 Hours
Saving (350ohm, Backlight-ON 30Sec,
Shutdown 5Min) 200Hours
Serial Communications
EDP Port Full duplex RS-232
38400,19200,9 00, 4800, 2400, 1200 bps
Printer Port Output-only RS-232 or active 20 mA current loop,
9 00, 4800, 2400, 1200 bps
Both Ports 7 or 8 data bits; even, odd, or no parity
Operator Interface
Display -digit LCD display. 7-segment, 0.815 in (21.2 mm) digits
LCD annunciator net, center of zero, standstill, kg/lb/g/oz/ units,
Battery, Set points, Hold, HI/OK/LO
Keyboard 24-key flat membrane panel
Environmental
Operating Temperature –10 to +40°C (legal);
Storage Temperature –25 to +70°C
Humidity 0–95% relative humidity
Altitude 2000 m ( 500 ft) maximum
Housing
Dimensions 18. cm x 9.5 cm x 10 cm
Weight 0.4 kg (without battery)
Material ABS plastic, white

M403020-210322-Rev00 -UM-e 13
Conformity declaration
anufacturer
:
ADE Germany GmbH
Neuer Hoeltigbaum 15
22143 Hamburg / Germany
℡ [phone]
 [phone]

info@ade
-
germany.de
Notified body:
TÜV NORD CERT GmbH
NB 0044 (93/42/EEC)
Langemarckstraße 20
D - 45141 Essen
℡ [phone]
 [phone]

info.tncert@tuev
-
nord.de
Declaration of conformity by the manufacturer
This product has been manufactured in accordance with the harmonised European standards. They con-
form to the regulations of the EC-directives listed below:
 NAWI Directive 2014/31/EC
 Medical Devices Directive 93/42/EEC
 EMC Directive 2014/30/EC
 Low Voltage Directive 2014/35/EC
 RoHS Directive 2011/ 5/EC
in the currently valid versions.
This declaration loses its validity if modifications are made to the scale without our approval.
Hamburg, March 2021
ADE Germany GmbH
Neuer Hoeltigbaum 15
22143 Hamburg / Germany

14 M403020-210322-Rev00 -UM-e

M403020-210322-Rev00 -UM-e 15

1 M403020-210322-Rev00 -UM-e
Dealer:
