User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 1 of 5
User Manual
Revision 2. 00
English
Modbus TCP Slave / Modbus Master - Converter
(Order Code: HD67507-A1, HD67507-A1- 22, HD67507-B2,
HD67507-Slim-232, HD67507-Slim- 85, HD67507-WiFi-B2-
232, HD67507-WiFi-B2- 85)
for Website information:
www.adfweb.com?Product=HD67507
for Price information:
www.adfweb.com?Price=HD67507-A1
www.adfweb.com?Price=HD67507-A1- 22
www.adfweb.com?Price=HD67507-B2
www.adfweb.com?Price=HD67507-Slim-232
www.adfweb.com?Price=HD67507-Slim- 85
www.adfweb.com?Price=HD67507-WiFi-B2-232
www.adfweb.com?Price=HD67507-WiFi-B2- 85
Benefits and Main Features:
Wide supply input range
Galvanic Isolation
Temperature range: - 0°C/+85°C (- 0°F/+185°F)
For others products, see also the following links:
RS232 / RS485 / SB / Ethernet
www.adfweb.com?Product=HD67118 (RS232 / RS 85 - Converter)
www.adfweb.com?Product=HD67119 (USB / RS 85 - Converter)
www.adfweb.com?Product=HD67038 (RS 85 / RS232 / Ethernet - Converter)
CAN / CANopen / Modbus / Modbus TCP
www.adfweb.com?Product=HD67001 (CANopen / Modbus Master - Converter)
www.adfweb.com?Product=HD67502 (CANopen / Modbus Slave - Converter)
www.adfweb.com?Product=HD67011 (CAN / Modbus Master - Converter)
www.adfweb.com?Product=HD67012 (CAN / Modbus Slave - Converter)
www.adfweb.com?Product=HD6751 (CAN / Modbus TCP Master – Converter)
www.adfweb.com?Product=HD67515 (CAN / Modbus TCP Slave – Converter)
Modbus RT Slave / Modbus TCP Master - Converter
www.adfweb.com?Product=HD67510
Do you have your customer protocol? Then go to:
www.adfweb.com?Product=HD67003
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 2 of 5
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLES OF CONNECTION
CONNECTION SCHEME 6
CHARACTERISTICS 13
CONFIGURATION 13
POWER SUPPLY 1
FUNCTION MODES 15
LEDS (for HD67507-A1 and HD67507-B2) 16
LEDS (for HD67507-Slim-xxx) 17
LEDS (for HD67507-WiFi-B2) 18
ETHERNET 19
WI-FI 19
RS232 20
RS 85 21
RS 22 22
USE OF COMPOSITOR SW67507 23
NEW PROJECT / OPEN PROJECT 2
SOFTWARE OPTIONS 25
SET COMMUNICATION 26
OPERATION MODE 33
TRANSLATE TABLE 3
UPDATE VIA UDP 36
MECHANICAL DIMENSIONS 38
ORDERING INFORMATIONS 2
ACCESSORIES 3
DISCLAIMER
OTHER REGULATIONS AND STANDARDS
WARRANTIES AND TECHNICAL SUPPORT 5
RETURN POLICY 5
PDATED DOC MENTATION:
Dear customer, we thank you for your attention and we remind you that you
need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code” that
appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/ and
search for the corresponding code on the page. Click on the proper “Document
Code” and download the updates.
REVISION LIST:
Revision Date Author Chapter Description
2.100 1 /07/201 Ff All Added chapters
2.200 27/12/2017 Ff All New Hardware for Wi-Fi
2.300 0 /01/2023 Ff All Added Slim version
2. 00 26/01/2023 Ff All New Hardware for Wi-Fi
WARNING:
ADFweb.com reserves the right to change information in this manual about our
product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective owners.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 3 of 5
SEC RITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for
each individual application, legal and safety regulation. The same applies also when using accessories.
I NTENDED SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e. independent limit
switches, mechanical interlocks, etc.).
Q ALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and who
have appropriate qualifications for their job.
R ESID AL R ISKS
The device is state of the art and is safe. The instrument can represent a potential hazard if they are inappropriately installed and operated
by personnel untrained. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is danger for people to serious injury or death and / or the
possibility of damage.
CE CONFORMITY
The declaration is made by us. You can send an email to [e-mail] or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page of 5
EXAMPLES OF CONNECTION:

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 5 of 5

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 6 of 5
CONNECTION SCHEME:
Figure 1a: Connection scheme for HD67507 A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 7 of 5
Figure
1b
: Connection
s
cheme for HD67507
A1
422

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 8 of 5
Figure 1c: Connection scheme for HD67507 B2

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 9 of 5
Figure 1d: Connection scheme for HD67507 Slim 232

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 10 of 5
Figure
1e
: Connection
s
c
heme for HD67507
Slim
485

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 11 of 5
Figure 1f: Connection scheme for HD67507 WiFi B2 232

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 12 of 5
Figure 1g: Connection scheme for HD67507 WiFi B2 485

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 13 of 5
CHARACTERISTICS:
The HD67507 is a Modbus TCP Slave / Modbus Master – Converter.
It allows for the following characteristics:
Triple isolation between Serial - Power Supply, Serial - Ethernet, Power Supply - Ethernet.
Ethernet 10Base-T / 100Base-T, autosensing for Modbus TCP;
For Wi-Fi version, Access Point or Client mode ;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…2 V AC or 12…35V DC;
Wide temperature range: - 0°C / 85°C [- 0°F / +185°F].
This HD67507-A1/B2 is able to manage a maximum of ten simultaneous connections from Ethernet side.
It can be used in two operative ways:
In the “Routing Mode” the command Modbus is forwarded on the serial line using the same requested addresses.
In the “NAT Mode” the device addresses and data are altered through a translation table of the addresses.
CONFIG RATION:
You need Compositor SW67507 software on your PC in order to perform the following:
Define the parameters of Modbus TCP line;
Define the parameters of Modbus Serial line;
Update the device.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 1 of 5
POWER S PPLY:
The devices can be powered at 8…2 V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 2 V DC:
Device Consumption [W/VA]
HD67507-A1 3.5
HD67507-A1- 22 3.5
HD67507-B2 3.5
HD67507-Slim-xxx 3.5
HD67507-WiFi-B2-xxx 3.5
Caution: Not reverse the polarity power
HD67507
-
A1
HD67507-A1- 22
HD67507
-
B2
HD67507-Slim-xxx
HD67507-WiFi-B2

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 15 of 5
F NCTION MODES:
The device has got two function modes depending on the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for uploading the Project and/or Firmware.
For the operations to follow for the updating, see ‘UPDATE DEVICE’ section.
According to the functioning mode, the LEDs will have specific functions, see ‘LEDS’ section.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 16 of 5
LEDS (for HD67507-A1 and HD67507-B2):
The devices has got four (five for HD67507-B2) LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: Serial Communication Blinks when Modbus frame
(RS232/RS 85/RS 22) are received
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
2: Ethernet Link ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected
3: Device state Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
: Ethernet comm Blinks when a Modbus TCP request is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Not used (yellow) (Present
only on HD67507-B2) OFF Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 17 of 5
LEDS (for HD67507-Slim-xxx):
The devices has got five LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: Device state Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
2: Modbus comm. Blinks when Modbus frame (RS232/RS 85) are
received
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: Modbus TCP comm. Blinks when a Modbus TCP request is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
: Not used OFF Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Ethernet Link ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 18 of 5
LEDS (for HD67507-WiFi-B2):
The devices has got five LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: Device state Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
2: Modbus comm. Blinks when Modbus frame (RS232/RS 85) are
received
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: Modbus TCP comm. Blinks when a Modbus TCP request is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
: Not used OFF Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Ethernet Link ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 19 of 5
ETHERNET:
The Ethernet connection must be made using Connector2/3/5 of HD67507 with at least a Category 5E cable. The maximum length of the
cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the
device to a Hub/Switch the use of a straight cable is recommended. To connect the device to a PC/PLC/other the use of a cross cable is
recommended.
Wi-Fi (for HD67507-WiFi-B2):
The HD67507-WiFi-B2 can be configured as Wi-Fi Access Point or Wi-Fi Client. It supports DHCP functions.
The type of Wi-Fi used is the 802.11b/g/n and it supports different type of security protocol: WEP, WPA, WPA2 and none.
The antenna is integrated in the hardware, so any external antenna is ned.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Modbus TCP Slave
/
Modbus Master
Document code: MN67507_ENG Revision 2. 00 Page 20 of 5
RS232:
The connection from RS232 socket to a serial port (example one from a personal computer) must be made with a Null Modem cable (a serial
cable where the pins 2 and 3 are crossed).
It is recommended that the RS232 cable not exceed 15 meters.
The HD67507-A1/B2 is provided with a D-sub connector type DE-9 Male (also called DB-9). The cable must use a DE-9 Female connector.
The serial port is used for programming the device and for Modbus communication.
The HD67507-Slim-232 and HD67507-WiFi-B2-232 is provided with a 3way 5mm removable screw terminal.
The serial port is used for Modbus communication.
