ADF Web HD67806-KNX-B2 User manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 1 of 25
User Manual
Revision 1.000
English
EtherNet/IP Master / KNX- Converter
(Order Code: HD67806-KNX-B2)
For Website information:
www.adfweb.com? roduct=HD67806-B2
For rice information:
www.adfweb.com? rice=HD67806-KNX-B2
Benefits and Main Features:
Very easy to configure
ower Supply 18…35V DC and 8…24 V AC
Temperature range: -40°C/+85°C (-40°F/+185°F)
For others KNX products, see also the following links:
Converter KNX to
www.adfweb.com? roduct=HD67746 (IEC 618 0 Server)
www.adfweb.com? roduct=HD67773 (IEC 618 0 Client)
www.adfweb.com? roduct=HD67801 (BACnet Master)
www.adfweb.com? roduct=HD67802 (BACnet Slave)
www.adfweb.com? roduct=HD67803 (CAN)
www.adfweb.com? roduct=HD67804 (CANopen)
www.adfweb.com? roduct=HD67807 (EtherNet/IP Slave)
www.adfweb.com? roduct=HD67808 (DeviceNet Master)
www.adfweb.com? roduct=HD67809 (DeviceNet Slave)
www.adfweb.com? roduct=HD67810 (J1939)
www.adfweb.com? roduct=HD67811 (M-Bus Master/wM-Bus)
www.adfweb.com? roduct=HD67812 (Modbus Master)
www.adfweb.com? roduct=HD67813 (Modbus Slave)
www.adfweb.com? roduct=HD67814 (Modbus TCP Master)
www.adfweb.com? roduct=HD67815 (Modbus TCP Slave)
www.adfweb.com? roduct=HD67818 (PROFINET slave)
www.adfweb.com? roduct=HD67820 (SNMP)
www.adfweb.com? roduct=HD67821 (DMX)
www.adfweb.com? roduct=HD67822 (DALI)
www.adfweb.com? roduct=HD67825 (Ethernet)
www.adfweb.com? roduct=HD67830 (NMEA 2000)
www.adfweb.com? roduct=HD67947 (MQTT)
www.adfweb.com? roduct=HD67B18 (OPC UA Client)
www.adfweb.com? roduct=HD67B41 (OPC UA Server)
www.adfweb.com? roduct=HD67B79 (PROFINET Master)
Do you have an your customer protocol?
www.adfweb.com? roduct=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 2 of 25
INDEX:
age
INDEX 2
U DATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAM LE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
OWER SU LY 7
FUNCTION MODES 8
LEDS 9
KNX 10
ETHERNET 11
USE OF COM OSITOR SW67806 12
NEW CONFIGURATION / O EN CONFIGURATION 13
SOFTWARE O TIONS 14
SET COMMUNICATION 16
ETHERNET/I ACCESS 17
KNX ACCESS 18
U DATE DEVICE 20
MECHANICAL DIMENSIONS 22
ORDERING INFORMATIONS 23
ACCESSORIES 23
DISCLAIMER 24
OTHER REGULATIONS AND STANDARDS 24
WARRANTIES AND TECHNICAL SU ORT 25
RETURN OLICY 25
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION LIST:
WARNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.
Revision Date Author Chapter Description
1.000 05/06/2019 Ff All First release version

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 3 of 25
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 4 of 25
EXAMPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 5 of 25
CONNECTION SCHEME:
Figure 1: Connection scheme for HD67806- NX-B2

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 6 of 25
CHARACTERISTICS:
The HD67806-KNX is a EtherNet/I Master / KNX Converter.
It allows the following characteristics:
Electrical isolation between Ethernet and KNX;
Mountable on 35mm Rail DIN;
Wide power supply input range: 18…35V DC and 8…24V AC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67806 software on your C in order to perform the following:
Define the parameter of EtherNet/I ;
Define the parameter of KNX line;
Define the list of EtherNet/I slaves connected to the converter;
Define the list of KNX data points to read/write;
Update the device.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 7 of 25
POWER SUPPLY:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 3 V
Consumption at 24V DC:
Device Consumption [W/VA]
HD67806-KNX-B2 3.5
HD67806-KNX-B2
Caution: Not reverse the polarity power

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 8 of 25
FUNCTION MODES:
The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for upload the roject and/or Firmware.
For the operations to follow for the updating, see ‘U DATE DEVICE’ section.
According to the functioning mode, the LEDs will have specifics functions, see ‘LEDS’ section.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 9 of 25
LEDS:
The device has got five LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0. Hz): update in progress
2: EtherNet/I
communication (yellow) Blinks when EtherNet/I communication is running Blinks quickly: Boot state
Blinks very slowly (~0. Hz): update in progress
3: KNX communication
(yellow) Blinks when KNX communication is running Blinks quickly: Boot state
Blinks very slowly (~0. Hz): update in progress
4: Not used (yellow) OFF Blinks quickly: Boot state
Blinks very slowly (~0. Hz): update in progress
5: KNX prog. (red) ON: KNX program mode activated
OFF: KNX program mode not activated
OFF

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 10 of 25
KNX:
KNX is the standard that allows the automated and decentralized management of the technologic plans of
a big typology of structures: commercial buildings, factories, houses, public locals, schools and so on.
KNX can be used in all the applications and functions for the building automations: from lighting to control
dampers, to the security, to the heating monitoring, to the conditioning, to the hydric control and alarms,
to energy management and so on.
Characteristics Description TP1-2 6
Medium Shielded Twisted air
Topology Linear, Star, Tree or mixed
Baudrate 9600 bps
Device supplying Normal: bus powered devices
Optional: remote powered devices
Device power consumption 3 mA- 12 mA
ower Supply Unit ( SU) DC 30 V
Number of SU’s per physical
Segment Max. 2
Number of connectable devices
per physical Segment Max. 256
Number of addressable devices
per physical Segment Max. 255
Total cable length per physical
Segment Max. 1000 m
Distance between two devices Max. 700 m
(*) Taken from NX specifications

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 11 of 25
ETHERNET:
The Ethernet port is used for programming the device and for EtherNet/I communication.
The Ethernet connection must be made using Connector2 of HD67806-KNX-B2 with at least a Category 5E cable. The maximum length of the
cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the
device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a C is recommended the use of a cross cable.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 12 of 25
USE OF COMPOSITOR SW67806:
To configure the Converter, use the available software that runs with Windows called SW67806. It is downloadable on the site
www.adfweb.com and its operation is described in this document. The software works with MS Windows (X , Vista, Seven, 8, 10; 32/64bit).
When launching the SW67806, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
Figure 2: Main wind
ow for SW67806

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 13 of 25
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a rogrammable “EtherNet/I Master / KNX - Converter”
in order to configure another device in the same manner, it is necessary to maintain
the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 14 of 25
SOFTWARE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor.
In the section “Language” it is possible to change the language of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of Program”, the
SW67806 check automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 15 of 25
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 16 of 25
SET COMMUNICATION:
This section define the fundamental communication parameters of two buses, KNX
and EtherNet/I .
By ressing the “Set Communication” button from the main window for SW67806
(Fig. 2) the window “Set Communication” appears (Fig. 3).
The means of the fields for “KNX” are:
In the field “Type” the type of KNX is defined (fixed to ‘KNX T ’);
In the field “ID Device” the ID of the KNX side of the converter is defined.
The means of the fields for “EtherNet/I Master” are:
In the fields “IP ADDRESS” the I address for EtherNet/I side of the
converter is defined;
In the fields “SUBNET Mask” the SubNet Mask for EtherNet/I side of the
converter is defined;
In the fields “GATEWAY” the default gateway of the net is defined. This
feature can be enabled or disabled pressing the Check Box field. This feature
is used for going out of the net;
In the field “Port” the port used for EtherNet/I communication is defined.
The port has a fixed value of 44818.
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 17 of 25
Figure 4: “Set EtherNet/IP Slaves Access” window
ETHERNET/IP ACCESS:
By ressing the “EtherNet/IP Access” button from the main window for SW67806 (Fig. 2) the window “Set EtherNet/I Slaves Access”
appears (Fig. 4).
This section is used to define the list of the EtherNet/I slaves to read/write from KNX side.
The means of the fields are:
If the field “Enable” is checked, the polling to the EtherNet/I slave is enabled;
In the field “IP Address” the I Address of the EtherNet/I slave is defined;
In the field “Start Input” the starting Input byte of the EtherNet/I slave to map on internal memory array is defined;
In the field “Num Input” the number of consecutive Input byte to map on internal memory array is defined;
In the field “Start Output” the starting Output byte of the EtherNet/I slave to write from internal memory array is defined;
In the field “Num Output” the number of consecutive Output byte to write from internal memory array is defined;
In the field “Time Poll” the polling time in ms is defined;
In the field “Instance T > O” the instance of the assembly for the Target to Originator data direction is defined;
In the field “Conn. Point T > O” the connection point of the assembly for the Target to Originator data direction is defined;
In the field “Instance O > T” the instance of the assembly for the Originator to Target data direction is defined;
In the field “Conn. Point O > T” the connection point of the assembly for the Originator to Target data direction is defined;
In the field “Mnemonic” a brief description is defined.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 18 of 25
Figure 5: “ NX Set Access” window
KNX ACCESS:
By pressing the “KNX Access” button
from the main window for SW67806
(Fig. 2) the “KNX Access” window
appears (Fig. 5).
The means of the fields are:
If the field “Enable” is checked,
the KNX message is enabled;
In the field “Source Address”
the Source Address to assign to
the KNX message is defined;
In the field “Dest/Group the Group address (2 level structure, 3 level structure or free address structure) or the device address is
defined. In case of Group address, the levels must be separated by ‘/’, in case of Device address, the parts of the address must be
separated by ‘.’;
In the field “APCI” the A CI of the KNX message is defined. You can choose between the following:
oRead: it is used to send a reading request to a KNX device;
oWrite: it is used to send a writing request to a KNX device;
oSpecific value (edited manually).
In the field “Priority” the riority of the KNX message is defined. You can choose between the following:
oSystem (Highest);
oUrgent;
oNormal;
oLow (Lowest).
In the field “Format” the data format of the KNX message is defined;
If the field “Extended” is checked, the extended format of the KNX message is used;
If the field “ReTest” is checked, the KNX message is re-sent in case of not correct response;
If the field “OnCMD” is checked, the KNX request is sent when a EtherNet/I message is received;
If the field “On Change” is checked, the gateway sends the KNX command when the data on EtherNet/I change the value;
If the field “On Timer” is checked, the gateway sends the KNX command cyclically;
In the field “Poll Time” the delay in ms between two KNX commands is defined (if “On Timer” is checked);

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 19 of 25
In the field “Position” insert the address of the internal array where placing the information;
In the field “Bit Mode” insert the start bit of the first byte of the field “ osition” where start to insert the data read;
In the field “Lenght” the dimension of the KNX message is defined;
In the field “Mnemonic” the description for the request is defined.
Note:
If the field “On change” is checked and the “ oll Time” is different from 0, the converter sends the KNX command cyclically and also
when the data is changed.
Note:
If the field “OnCMD”, “OnChange” and “OnTimer” are not checked, the converter only sniffs the bus in order to monitor the status of
the KNX message.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP Master / KNX
-
Converter
Document code: MN67806_ENG Revision 1.000 age 20 of 25
UPDATE DEVICE:
By pressing the “Update Device” button, it is possible to load the created
Configuration into the device; and also the Firmware, if necessary. This by using the
Ethernet port.
If you don’t know the actual I address of the device you have to use this procedure:
Turn OFF the Device;
ut Dip1 of ‘Dip-Switch A’ in ON position;
Turn ON the device
Connect the Ethernet cable;
Insert the I “192.168.2.20 ”;
Select which operations you want to do;
ress the “Execute update firmware” button to start the upload;
When all the operations are “OK” turn OFF the Device;
ut Dip1 of ‘Dip-Switch A’ in OFF position;
Turn ON the device.
If you know the actual I address of the device, you have to use this procedure:
Turn ON the Device with the Ethernet cable inserted;
Insert the actual I of the Converter;
Select which operations you want to do;
ress the “Execute update firmware” button to start the upload;
When all the operations are “OK” the device automatically goes at Normal Mode.
At this point the configuration/firmware on the device is correctly updated.
Figure 6: “Update device” windows
