ADF Web HD67C56-IP-B2 User manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 1 of 3
User Manual
Revision 1.
English
EnOcean / BACnet Slave - Converter
(Order Code: HD67C56-IP-B2, HD67C56-MSTP-B2)
For Website information:
www.adfweb.com?Product=HD67C56-B2
For Price information:
www.adfweb.com?Price=HD67C56-IP-B2
www.adfweb.com?Price=HD67C56-MSTP-B2
Benefits and Main Features:
Very easy to configure
Power Supply 18…35V DC and 8…24 V AC
Temperature range: -4 °C/+85°C (-4 °F/+185°F)
For others EnOcean products, see also the following links:
Converter EnOcean to
www.adfweb.com?Product=HD67C5 (Serial)
www.adfweb.com?Product=HD67C52 (Modbus Slave)
www.adfweb.com?Product=HD67C54 (Modbus TCP Slave)
www.adfweb.com?Product=HD67C57 (CA )
www.adfweb.com?Product=HD67C58 (CA open)
www.adfweb.com?Product=HD67C61 (Device et Slave)
www.adfweb.com?Product=HD67C63 (Ether et/IP Slave)
www.adfweb.com?Product=HD67C65 (IEC61850 Server)
www.adfweb.com?Product=HD67C66 (J1939)
www.adfweb.com?Product=HD67C67 (K X)
www.adfweb.com?Product=HD67C7 (MQTT)
www.adfweb.com?Product=HD67C72 ( MEA 0183)
www.adfweb.com?Product=HD67C73 ( MEA 2000)
www.adfweb.com?Product=HD67C75 (PROFIBUS Slave)
www.adfweb.com?Product=HD67C77 (PROFI ET Slave)
www.adfweb.com?Product=HD67C79 (S MP Agent)
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 2 of 3
I DEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 7
CONFIGURATION 7
POWER SUPPLY 8
FUNCTION MODES 9
LEDS 1
ETHERNET 11
ENOCEAN 12
RS485 (FOR BACNET MS/TP) 13
USE OF COMPOSITOR SW67C56 14
NEW CONFIGURATION / OPEN CONFIGURATION 15
SOFTWARE OPTIONS 16
SET COMMUNICATION 18
ENOCEAN ACCESS 2
SET BACNET ACCESS 23
BACNET EDE FILE 24
UPDATE DEVICE 25
MECHANICAL DIMENSIONS 27
ORDERING INFORMATIONS 28
ACCESSORIES 28
DISCLAIMER 29
OTHER REGULATIONS AND STANDARDS 29
WARRANTIES AND TECHNICAL SUPPORT 3
RETURN POLICY 3
UPDATED DOCUME TATIO :
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISIO LIST:
WAR I G:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.
Revision Date Author Chapter Description
1. 5/12/2 19 Ff All First release version

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 3 of 3
SECURITY ALERT:
G E ERAL I FORMATIO
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I TE DED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED P ERSO EL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CO FORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 4 of 3
EXAMPLE OF CO ECTIO :

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 5 of 3
CO ECTIO SCHEME:
Figure 1a: Connection scheme for HD67C56- P-B2

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 6 of 3
Figure 1b: Connection scheme for HD67C56-MSTP-B2

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 7 of 3
CHARACTERISTICS:
The HD67C56-B2 is a EnOcean / BACnet Slave Converter.
It allows the following characteristics:
Electrical isolation between BACnet and Power Supply;
Mountable on 35mm Rail DIN;
Wide power supply input range: 18…35V DC and 8…24V AC;
Wide temperature range: -4 °C / 85°C [-4 °F / +185°F].
CO FIGURATIO :
You need Compositor SW67C56 software on your PC in order to perform the following:
Define the parameter of BACnet line;
Define the parameter of EnOcean line;
Define the list of BACnet objects accessible by the BACnet Master;
Update the device.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 8 of 3
POWER SUPPLY:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consumption [W/VA]
HD67C56-xxxx-B2 3.5
HD67C56-xxxx-B2
Caution: ot reverse the polarity power

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 9 of 3
FU CTIO MODES:
The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for upload the Project and/or Firmware.
For the operations to follow for the updating, see ‘UPDATE DEVICE’ section.
According to the functioning mode, the LEDs will have specifics functions, see ‘LEDS’ section.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 1 of 3
LEDS:
The device has got four LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED ormal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
2: EnOcean communication
(yellow) Blinks when EnOcean data is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: BACnet communication
(yellow) Blinks when a BACnet request is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: Error state (yellow) O : An error in the communication busses occurs
OFF: No errors are present
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 11 of 3
ETHER ET:
The Ethernet port is used for programming the device and for BACnet/IP communication.
The Ethernet connection must be made using Connector2 of HD67C77-B2 with at least a Category 5E cable. The maximum length of the
cable should not exceed 1 m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 1 Mbps. To connect the
device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC is recommended the use of a cross cable.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 12 of 3
E OCEA :
EnOcean is a protocol designed for energy harvesting devices communication. The main
fields of application are building automation and domotics, but it can also be potentially
used in the industrial field.
EnOcean products include solutions for environment monitoring, smart metering and
lighting. Each device uses a unique ID for identification and one of the standardized profiles
(EEPs) for data transmission. Communication process may be secure or unsecure and may
be unidirectional or bidirectional (for devices that support Smart Acknowledge operating
mode).
EnOcean is based on wireless communication on 868.3 MHz ASK.
It is possible to connect up to 1 EnOcean devices to a single converter, where up to 32
can be in Secure Mode and up to 19 with Smart Acknowledge.
The Antenna connector is a SMA Female (‘Female Outer Shell’ and ‘Female Receptacle’) so
the Antenna must have a SMA Male connector.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 13 of 3
RS485 (for BACnet MS/TP):
For terminating the RS485 line with a 12 Ω resistor it is necessary to put ON dip 1, like in figure.
The maximum length of the cable should be 12 m (4 feet).
Here some codes of cables:
Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;
Belden p/n 82842 - 2x 24AWG stranded twisted pairs conductor + foil shield + braid shield;
Tasker: p/n C521 - 1x 24AWG twisted pair conductor + foil shield + braid shield;
Tasker: p/n C522 - 2x 24AWG twisted pairs conductor + foil shield + braid shield.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 14 of 3
USE OF COMPOSITOR SW67C56:
To configure the Converter, use the available software that runs with Windows called SW67C56. It is downloadable on the site
www.adfweb.com and its operation is described in this document. The software works with MS Windows (XP, Vista, Seven, 8, 1 ; 32/64bit).
When launching the SW67C56, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
Figure 2: Main window for SW67C56

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 15 of 3
EW CO FIGURATIO / OPE CO FIGURATIO :
The “ ew Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a Programmable “EnOcean / BACnet Slave - Converter”
in order to configure another device in the same manner, it is necessary to maintain
the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 16 of 3
SOFTWARE OPTIO S:
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor.
In the section “Language” it is possible to change the language of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of Program”, the
SW67C56 check automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 17 of 3
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 18 of 3
SET COMMU ICATIO :
By Pressing the “Set Communication” button from the main window for SW67C56 (Fig. 2)
the window “Set Communication” appears (Fig. 3).
In the section “BACnet Slave” is possible to select the type of BACnet to use from:
BACnet/IP (uses Ethernet);
BACnet MS/TP (uses RS485).
If selected “BACnet/IP” the means of the fields for “BACnet” are:
In the fields “IP ADDRESS” the IP address of BACnet/IP side of the converter is
defined;
In the fields “SUB ET Mask” the SubNet Mask of BACnet/IP side of the converter is
defined;
In the fields “GATEWAY” the default gateway of the network is defined. This feature
can be enabled or disabled pressing the Check Box field. This feature is used for going
out of the net;
In the field “Port” the port used for BACnet communication is defined. The default
port used for BACnet communication is 478 8, but is possible to insert any value;
In the field "BACnet Device ame" the name of BACnet/IP side of the converter is
defined;
In the field “Device Identifier” the ID of BACnet/IP side of the converter is defined;
If the field “BACnet description up to 32 chars” is checked, the description of the
BACnet objects can be up to 32 chars.
Figure 3a: “Set Communication” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 19 of 3
If selected “BACnet MS/TP”, the means of the fields for “BACnet” are:
In the field “Baudrate” the data rate of the BACnet line is defined;
In the field “Parity” the parity of the line is defined;
In the field “BACnet Device ame” the name to give to the BACnet node is
defined;
In the field “MAC Address” the MAC of BACnet node (from to 254) is defined;
The field “Max Master” specifies the highest allowable address for master nodes.
The value shall be less than or equal to 127;
The field “Max Info Frames” specifies the maximum number of information frames
the node may send before it must pass the token;
In the field “Device Instance” the of the BACnet MS/TP side of the converter is
defined;
In the field “ etwork” the BACnet MS/TP network number is defined;
If the field “BACnet description up to 32 chars” is checked, the description of
the BACnet objects can be up to 32 chars.
The means of the fields for the “Ethernet Update” section are:
In the fields “IP ADDRESS” the IP address of the converter is defined;
In the fields “SUB ET Mask” the SubNet Mask of the converter is defined;
In the fields “GATEWAY” the default gateway of the network is defined. This
feature can be enabled or disabled pressing the Check Box field. This feature is
used for going out of the net.
Figure 3b: “Set Communication” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOc
ean / BACnet Slave
Document code: MN67C56_ENG Revision 1. Page 2 of 3
Figure 4: “EnOcean Access” window
E OCEA ACCESS:
By Pressing the “EnOcean Set Access” button from the main window for SW67C56 (Fig. 2) the window “EnOcean Set Access” appears (Fig.
4). This section is used to define the list of the EnOcean devices to read/write.
