Adrenaline Rabbids & Ladders Installation and operating instructions

Rabbids & Ladders
RL-65-4001
Operation & Service Manual
Version 2.0
* Read this manual before use

Rabbids & Ladders Manual V2.0
2 | P a g e
General Remark
If you encounter any difficulties or if you need support on how to update and/ or install your
Hot Wheels King of the Road product, we invite you to contact your local distributor or reach us
at [email protected] or by calling our support line [phone]
Adrenaline Amusements Team
Adrenaline Amusements
2273 Antonio-Héroux street
Terrebonne, QC
Canada
J6X 4R3

Rabbids & Ladders Manual V2.0
3 | P a g e
Table of Contents
Contents
General Remark..................................................................................................2
Table of Contents................................................................................................3
Chapter 01 - Preface ...........................................................................................5
Precaution for Game Operation.................................................................................................. 5
Safety........................................................................................................................................... 6
Environmental Conditions........................................................................................................... 6
Operating & Voltage.................................................................................................................... 6
Chapter 02 - Game Features................................................................................7
How to Play ................................................................................................................................. 7
Chapter 03 –Unit Features .................................................................................8
Hardware Features...................................................................................................................... 8
Cabinet Facts............................................................................................................................... 8
Chapter 04 –Unit Installation .............................................................................9
How to assemble your Rabbids & Ladders unit .......................................................................... 9
Chapter 05 –Operator Menu............................................................................12
Operator Menu ......................................................................................................................... 12
Chapter 06 –Service & Repair...........................................................................14
Computer Connections ............................................................................................................. 14
Troubleshooting ........................................................................................................................ 15
Video Troubleshooting........................................................................................................................15
Audio Troubleshooting .......................................................................................................................15
RGB Led Troubleshooting.......................................................................................................... 16
Wireless Internet Configuration................................................................................................ 20
Operator Settings keeps resetting ............................................................................................ 21
Computer not powering at boot............................................................................................... 22

Rabbids & Ladders Manual V2.0
4 | P a g e
Chapter 07 - Parts .............................................................................................23
Major Structural Parts.................................................................. Error! Bookmark not defined.
Cabinet Parts ............................................................................................................................. 23
Monitor & Accessories ................................................................. Error! Bookmark not defined.
Other Cabinet Parts...................................................................... Error! Bookmark not defined.
Computer & Electronics ............................................................................................................ 26
Header & LEDs........................................................................................................................... 30
Cabling....................................................................................................................................... 33
Misc. Parts................................................................................................................................. 33
Wiring Harnesses....................................................................................................................... 33
Chapter 08 –Diagrams & Schematics................................................................35
I/O Board Connections.............................................................................................................. 36
Speakers Wiring Colors ............................................................................................................. 37
Power Distribution Schematics ................................................................................................. 38
Tray Assembly Schematics ........................................................................................................ 39
RGB LED Schematics................................................................................................................. 40
Chapter 09 –Software Recovery.......................................................................41
Chapter 10 –Card Reader .................................................................................42
Limited Warranty Policies ......................................................................43

Rabbids & Ladders Manual V2.0
Chapter 01 - Preface
5 | P a g e
Chapter 01 - Preface
Please read this page before preparing your Hot Wheels King of the Road
Arcade product for game play.
The following safety instructions apply to all game operators and service personnel. Specific
warnings and cautions will be included throughout this manual.
Use the following safety guidelines to help protect the system from potential damage and to
ensure your personal safety:
•Electronic components in the game cabinet run on 110V AC 60Hz (220V/ 50Hz in most of
Europe, the Middle East and the Far East delivered units).
•To help prevent electric shock, plug the system into a properly grounded power source.
These cables are equipped with 3-prong plugs to help ensure proper grounding. Do not
use adapter plugs or remove the grounding prong from a cable. If you must use an
extension cable, use a 3-wire cable with properly grounded plugs. We do recommend a
15A rated current or higher power cord.
•To help protect your system from sudden increases and decreases in electrical power,
use a surge suppressor, line conditioner or Uninterruptible Power Supply (UPS).
•Be sure nothing rests on the system’s cables and that the cables are not located where
they can be stepped on or tripped over.
•Keep your system far away from radiators and other heat sources.
•Do not block cooling vents.
Precaution for Game Operation
Adrenaline Amusements Inc. assumes no liability for injuries incurred while playing our games.
Operators should be aware that certain health and physical conditions may make people
susceptible to injury when playing video games.

Rabbids & Ladders Manual V2.0
Chapter 01 - Preface
6 | P a g e
Safety
To avoid electrical shock, unplug the cabinet before performing
installation or service procedures.
If a power cord is damaged, it must be replaced by the equivalent
power cord available from your distributor.
Adrenaline Amusement Inc. assumes no liability for any damages or
injuries incurred while setting up or servicing the cabinet. Only qualified
service personnel should perform installation or service procedures.
Environmental Conditions
Cabinet is intended for indoor use only. Be sure to keep the cabinet dry and maintain operating
temperatures of 59° - 86°F (15° - 30°C).
Operating & Voltage
Voltage
Operating
110V AC
4.0 AMP
220V AC
2.0 AMP

Rabbids & Ladders Manual V2.0
Chapter 02 –Game Features
7 | P a g e
Chapter 02 - Game Features
Rabbids & Ladders is a funny and addictive game where precision can earn you a lot of tickets
How to Play
•Spin your toilet paper roll to roll the dice
•Use ladders to advance quicker on the grid
•Avoid toilets that make you fall down the tube
•Reach the Bonus Wheel square for a chance to win the ultimate bonus

Rabbids & Ladders Manual V2.0
Chapter 03 –Unit Features
8 | P a g e
Chapter 03 – Unit Features
Hardware Features
•4 Players Game
•4 toilet rolls
•65 inches LCD Screen
•Bonus value screen
Cabinet Facts
Cabinet Dimensions
Height = 108.47” [2755.14mm]
Depth = 36.35” [923.29mm] Width = 77.32” [1963.93mm]
Shipping Dimensions
Width = 72”Depth = 45”Height = 88½”
Weight = 650 lbs

Rabbids & Ladders Manual V2.0
Chapter 04 –Unit Installation
9 | P a g e
Chapter 04 – Unit Installation
How to assemble your Rabbids & Ladders unit
1) Position the header assembly on top of the unit.
Secure the assembly and the Rabbid host with
2x hex head ¼-20 x ¾ screws
4x pan head 8-32 zinc screws
3x flat head #6 x 1¼ screws
2) Attach the top and the right header with 4 pan head 10-24 black machine screws

Rabbids & Ladders Manual V2.0
Chapter 04 –Unit Installation
10 | P a g e
3) Connect all wires and cables together
Connect the 3-pin connectors together (3x)
Connect the barrel connectors together (2x)
Connect the AC cable of the bonus spin monitor
Connect the DVI cable of the Bonus Spin monitor
3-pin connector
AC Cable
3-pin connector
3-pin connector
Barrel connector
DVI Cable

Rabbids & Ladders Manual V2.0
Chapter 04 –Unit Installation
11 | P a g e
4) Install the horizonal wire cover RL-01-0020 with the following hardware:
4x zinc pan head 8-32 screws
4 x pan head 10-24 black machine screws
5) Install the vertical wire cover RL-01-0018 with the following hardware:
3x zinc pan head 8-32 screws

Rabbids & Ladders Manual V2.0
Chapter 05 –Operator Menu
12 | P a g e
Chapter 05 – Operator Menu
Operator Menu
Access the Operator Menu by pressing the white operator menu button behind the center door of the
cabinet.
Navigate through the operator menu using the steering wheels and pedals or by using your keyboard’s
numerical pad keys “1”,”2” and “3”.
PREVIOUS
SELECT
NEXT

Rabbids & Ladders Manual V2.0
Chapter 05 –Operator Menu
13 | P a g e
SETTINGS
Operator Menu
Values
What It Does
Board Setting
1-12
Adjusts the game board’s configuration
Bonus Wheel Difficulty
1-3
Adjusts the difficulty to reach the bonus wheel
Game Audio Volume
0-20
Adjusts the in-game audio volume. “0” will mute the game.
Voice Attract Volume
0-20
Adjusts the in-game voice volume. “0” will mute the voice
Attract Audio Volume
0-20
Adjusts the volume of the voice attract loop. “0” will mute
the voice
Ticket Value
1-2
Adjusts the value of physical tickets. Physical tickets are
either worth “1” ticket or “2” tickets.
Minimum Tickets
0-20
Adjusts the minimum number of tickets dispensed per play.
Redemption Unit Name
Tickets/Coupon
Adjusts the in-game text accordingly
New Jersey Settings
On/Off
If set to On, a message will be displayed if more than 40
credits are inserted.
Bonus Value
100-2000
Maximum number of tickets that can be won when a player
reaches the bonus wheel
Language
English/Français
Switches the game and the menu’s language
PAYMENTS
Operator Menu
Values
What It Does
Credits Per Game
1-20
Adjusts the number of credits required to play. “0” sets the
unit in free play mode.
Spins per Game
1-3
Number of spins allowed for each player in a single game
Credit Sharing
On / Off
Adjusts the credit sharing option between each player. (Off:
Sharing Disabled // On: Sharing Enabled)
If you have Card Readers (2X) please use OFF.
Multicredit
On/Off
Payment Type
Credit / Card
Changes the credit type. “Credits” = Coins and
“Card” = Card Reader. This will change the in-game text
accordingly.
Clear Credits
Resets the Inserted credits to 0 if more than 40 credits are
entered.
Resume Game
Exits the Operator Menu and returns to the game.
Quit Game
Exits the game and returns to the Windows desktop.
Calibrate Pedals
Displays the previous errors
Activate Players
Exits the Operator Menu and returns to the game.

Rabbids & Ladders Manual V2.0
Chapter 06 –Service & repair
14 | P a g e
Chapter 06 – Service & Repair
Computer Connections
No.
Description
1
USB Port to I/O Board
2
USB Port to Quadrature Board
3
USB Port to USB Hub
4
Power Button
5
AC Inlet Power Supply
6
AC Power Switch
7
USB Port to 24V RGB Controller
8
USB Port to 12V RGB Controller
9
HDMI port for 65’’ Monitor
10
DVI Port for Bonus Spin Monitor
11
Green Audio Jack 3.5 mm for Speakers 1 & 2
11
4
5
9
6
10
7
8
3
1
2

Rabbids & Ladders Manual V2.0
Chapter 06 –Service & repair
15 | P a g e
Troubleshooting
* NOTE: When requesting a warranty replacement, you will be asked to
give the unit’s serial number from the back of the unit.
Video Troubleshooting
No Picture or Display
Problem
There might have loose or faulty connections between the monitor and the
computer. Make sure that both the DVI and HDMI cables are connected
properly in the computer’s video card and in the monitor connectors.
Verify that the Computer is powered on.
The fan on the side of the computer case should be spinning as a reference,
if it’s not spinning press the Power Button on the front of the computer.
Audio Troubleshooting
Low Volume / No
Sound
Increase the volume in the game by pressing the Operator Button and
adjusting the volume options in the Operator Menu. You might also Quit the
game to Windows desktop and increase the volume via the Speaker icon
on the bottom right of your screen.
Verify the wirings behind the speakers and the amplifiers.
Verify that the 1/8’’ audio jack is plugged in the computer’s sound input jack
and that the other end RCA’s are plugged in the sound amplifier.

Rabbids & Ladders Manual V2.0
Chapter 06 –Service & repair
16 | P a g e
RGB Led Troubleshooting
If the RGB LEDs are not working properly verify that the RGB LED Controller is connected on a valid COM
Port.
Press the Operator Button and Quit/Exit the game to Windows Desktop.
Connect a USB mouse.
Right-click on the windows flag on the bottom left corner and select Device Manager.

Rabbids & Ladders Manual V2.0
Chapter 06 –Service & repair
17 | P a g e
Expand the “Ports (COM & LPT)” line by clicking on the >.
Verify that the “USB Serial Device” is set between COM2 to COM9.

Rabbids & Ladders Manual V2.0
Chapter 06 –Service & repair
18 | P a g e
If it’s outside this range, double-click on it to open its properties.
Select the “Port Settings” Tab.
Click on “Advanced…”

Rabbids & Ladders Manual V2.0
Chapter 06 –Service & repair
19 | P a g e
Click on the COM Port Number scrolling menu and select COM9.
Click on OK.
Click on OK again.
Close the Device Manager window and restart Windows.

Rabbids & Ladders Manual V2.0
Chapter 06 –Service & repair
20 | P a g e
Wireless Internet Configuration
Your network can be configured via Ethernet cable or Wireless.
If you have an Ethernet cable available to be plugged in, insert it into the motherboard LAN
RJ45 connector.
If not, here’s how to configure your wireless network with your own existing Wi-Fi network.
-Start the unit.
-There will be Adrenaline Amusements wallpaper with a 150 seconds delay before the attract
mode shows up. It gives enough time for a wireless network to connect.
(This delay will be present on each reboot if you don’t connect your unit to the Internet)*.
-Open the service door and press the Operator button.
-Choose Exit/Quit to Windows.
-Connect the provided USB hub and into it the USB keyboard and mouse.
- Open Connect to a Network by clicking the network icon ( ) in the lower right corner of the
screen.
-In the list of networks, click the network you want to connect to and click connect.
-Enter your security key.
-Once connected, double-click the GameLauncher shortcut on the desktop.
Having your unit connected to the Internet includes free software live update!
*If you do not connect your unit to the Internet, you can double-click the Disable_Network
shortcut on the Windows desktop to bypass the 150seconds Internet lookup delay.
