Adrenaline Tomb Raider 65" Installation and operating instructions

Tomb Raider 65”
TR-65-1001
Operation & Service Manual
Version 2.0
* Read this manual before use

Tomb Raider 65” Manual V2.0
Page 2of 58
General Remark
If you encounter any difficulties or if you need support on how to update and/ or install your
Tomb Raider product, we invite you to contact your local distributor or reach us at
[email protected] or by calling our support line [phone]
Adrenaline Amusements Team
Adrenaline Amusements
1150 Levis, Suite 302
Terrebonne, Qc
Canada
J6W 5S6

Tomb Raider 65” Manual V2.0
Page 3of 58
Table of Contents
Contents
General Remark..................................................................................................2
Table of Contents................................................................................................3
Chapter 01 - Preface ...........................................................................................5
Precaution for Game Operation.................................................................................................. 5
Safety........................................................................................................................................... 6
Environmental Conditions........................................................................................................... 6
Operating & Voltage.................................................................................................................... 6
Chapter 02 –Unit Features .................................................................................7
Hardware Features...................................................................................................................... 7
Cabinet Facts............................................................................................................................... 7
Chapter 03 –Unit Installation .............................................................................8
Assembling your Tomb Raider 65” Unit...................................................................................... 8
How to slide out the Screen Module: ......................................................................................... 8
Header Assembly....................................................................................................................... 10
How to open the Dash Board:................................................................................................... 16
Chapter 04 –Operator Menu............................................................................17
Operator Menu ......................................................................................................................... 17
Chapter 05 –Service & Repair...........................................................................19
Computer Connections ............................................................................................................. 19
Gun tracking Hardware Troubleshooting Guide....................................................................... 20
Gun Controller ID Remapping ................................................................................................... 21
Troubleshooting ........................................................................................................................ 23
Video Troubleshooting........................................................................................................................23
Audio Troubleshooting .......................................................................................................................23
RGB Led Troubleshooting.......................................................................................................... 24

Tomb Raider 65” Manual V2.0
Page 4of 58
Replacing RGB LED PCBs............................................................................................................ 28
Wireless Internet Configuration................................................................................................ 29
Operator Settings keeps resetting trouble ............................................................................... 30
Computer not powering at boot............................................................................................... 31
Chapter 06 - Parts .............................................................................................34
Cabinet Parts ............................................................................................................................. 34
Computer & Electronics ............................................................................................................ 36
Header & LEDs........................................................................................................................... 40
Cabling....................................................................................................................................... 41
Wiring Harness .......................................................................................................................... 42
Misc. Parts................................................................................................................................. 42
Chapter 07 –Diagrams & Schematics................................................................43
I/0 Board ADR-04-1003 ............................................................................................................. 43
I/O Board –Detailed Wiring...................................................................................................... 45
Power Distribution Schematics ................................................................................................. 50
RGB LED Schematics................................................................................................................. 53
Channel 1................................................................................................................................... 54
Channel 2................................................................................................................................... 55
Chapter 08 –Software Recovery.......................................................................56
Chapter 09 –Card Reader .................................................................................57
Limited Warranty Policies ......................................................................58

Tomb Raider 65” Manual V2.0
Chapter 01 - Preface
Page 5of 58
Chapter 01 - Preface
Please read this page before preparing your Tomb Raider Arcade product for
game play.
The following safety instructions apply to all game operators and service personnel. Specific
warnings and cautions will be included throughout this manual.
Use the following safety guidelines to help protect the system from potential damage and to
ensure your personal safety:
Electronic components in the game cabinet run on 110V AC 60Hz (220V/ 50Hz in most of
Europe, the Middle East and the Far East delivered units).
To help prevent electric shock, plug the system into a properly grounded power source.
These cables are equipped with 3-prong plugs to help ensure proper grounding. Do not
use adapter plugs or remove the grounding prong from a cable. If you must use an
extension cable, use a 3-wire cable with properly grounded plugs. We do recommend a
15A rated current or higher power cord.
To help protect your system from sudden increases and decreases in electrical power,
use a surge suppressor, line conditioner or Uninterruptible Power Supply (UPS).
Be sure nothing rests on the system’s cables and that the cables are not located where
they can be stepped on or tripped over.
Keep your system far away from radiators and other heat sources.
Do not block cooling vents.
Precaution for Game Operation
Adrenaline Amusements Inc. assumes no liability for injuries incurred while playing our games.
Operators should be aware that certain health and physical conditions may make people
susceptible to injury when playing video games.

Tomb Raider 65” Manual V2.0
Chapter 01 - Preface
Page 6of 58
Safety
To avoid electrical shock, unplug the cabinet before performing
installation or service procedures.
If a power cord is damaged, it must be replaced by the equivalent
power cord available from your distributor.
Adrenaline Amusement Inc. assumes no liability for any damages or
injuries incurred while setting up or servicing the cabinet. Only qualified
service personnel should perform installation or service procedures.
Environmental Conditions
Cabinet is intended for indoor use only. Be sure to keep the cabinet dry and maintain operating
temperatures of 59° - 86°F (15° - 30°C).
Operating & Voltage
Voltage
Operating
110V AC
4.0 AMP
220V AC
2.0 AMP

Tomb Raider 65” Manual V2.0
Chapter 02 –Unit Features
Page 7of 58
Chapter 02 – Unit Features
Hardware Features
4 Players Game
65 inches LCD Screen
Unique Sensor Tracker “Gun” Technology!
Cabinet Facts
Cabinet Dimensions
Height = 100.25” [2546.33mm]
Depth = 54.24” [1377.62mm] Width = 65.90” [1673.77mm]
Shipping Dimensions
Width = 45”Depth = 68”Height = 84”
Weight = 650 lbs

Tomb Raider 65” Manual V2.0
Chapter 03 –Unit Installation
Page 8of 58
Chapter 03 – Unit Installation
Assembling your Tomb Raider 65” Unit
**You need to be 2 persons to assemble the unit**
1. Carefully remove the cabinet from the shipping skid, giving you enough space.
2. Move the cabinet to the desired location.
How to slide out the Screen Module:
3. Remove the 4x bolts #10-24 x 1-¼” (2x per side) holding the monitor cabinet assembly to the front
cabinet assembly.
4. Slide out the 2 cabinets and align the bracket holes with the center part holes.
5. Re-insert the 4x bolts and tighten them.

Tomb Raider 65” Manual V2.0
Chapter 03 –Unit Installation
Page 9of 58
6. Lower the Level adjustors until the Pivot Wheels are slightly above the floor.

Tomb Raider 65” Manual V2.0
Chapter 03 –Unit Installation
Page 10 of 58
Header Assembly
**You need to be 2 persons to install the header on the monitor**
1. Tool needed: Phillips #2 screwdriver (Do not use a drill)
-Lay down the “Tomb Raider” acrylic header on a flat surface.
-Remove the protective tape.
-Install 1x 2½” x 2½” angle bracket with 2x Phillips #6 x 3/8”screws on the back of the header, in the
predrilled holes as seen below.

Tomb Raider 65” Manual V2.0
Chapter 03 –Unit Installation
Page 11 of 58
2. Tool needed: 2 Ladders
-Insert the “Tomb Raider” header on the wooden plate front slot.
-Using 2x Phillips #6 x 3/8” screws affix the angle bracket to the wooden plate as seen below.

Tomb Raider 65” Manual V2.0
Chapter 03 –Unit Installation
Page 12 of 58
3. Install 1x 2½” x 2½” metal angle bracket behind the “Lara” header using 2x Phillips #6 x 3/8” screws
in the predrilled holes as seen below.

Tomb Raider 65” Manual V2.0
Chapter 03 –Unit Installation
Page 13 of 58
4. Insert the “Lara” Header on the middle wooden plate slot.
Using 2x Phillips #6 x 3/8” screws affix the angle bracket to the wooden plate as seen below.
5. Connect the header12V Barrel connector with the connector coming out from the top of the
monitor. (ref.: I/O board J4 Pins 1&2 as seen on page 43 & 47)

Tomb Raider 65” Manual V2.0
Chapter 03 –Unit Installation
Page 14 of 58
6. Insert the 2x plastic push rivets from the front through the predrilled holes of the mountains header
to affix 2x ¾” x ¾” metal angle brackets in the back as seen below.

Tomb Raider 65” Manual V2.0
Chapter 03 –Unit Installation
Page 15 of 58
7. Insert the “mountains” header in the last slot of the wooden support.
There is a small notch on the bottom right of the mountain header that will go above the metal
bracket that holds the “Lara” part.
Using 2x Phillips #6 x 3/8” screws affix the mountain header to the wooden support.

Tomb Raider 65” Manual V2.0
Chapter 03 –Unit Installation
Page 16 of 58
How to open the Dash Board:
-To open the dash and access the electronics, open the cash box doors to get access to the 2 Draw
Latches inside the cabinet.

Tomb Raider 65” Manual V2.0
Chapter 04 –Operator Menu
Page 17 of 58
Chapter 04 – Operator Menu
Operator Menu
Access the Operator Menu by pressing the Operator button located inside the drawer on the I/O board
directly.
Oper: Open the Operator Menu
Up: Scroll Up & Increase Value
Down: Scroll Down & Decrease Value
Select Button: Select/Deselect

Tomb Raider 65” Manual V2.0
Chapter 04 –Operator Menu
Page 18 of 58
Operator Menu
Values
What It Does
Credits Per Game
1-20
Adjusts the number of credits required to play. “0” sets
the unit in free play mode
Game Audio Volume
0-20
Adjusts the in-game audio volume. “0” will mute the
game
Attract Audio Volume
0-20
Adjusts the audio volume of the attract loop. “0” will
mute the attract loop
Payment Type
Credit / Card
Changes the credit type. “Credits” = Coins and
“Card” = Card Reader. This will change the in-game text
accordingly
Credit Sharing
1_2 / 3_4
On / Off
Adjusts the credit sharing option between each
player.(Off: Sharing Disabled // On: Sharing Enabled)
If you have Card Reader (4X) please use OFF
Difficulty
1-5
Adjusts the Difficulty Level (1 is Easiest, 5 is Hardest)
Gun Frequency
1-4
If you have 2 units* close to each other select a different
frequency. (Default: 2)
Gun P1
On / Off
Gun Operating Mode (On: Working Off: Not Working)
Gun P2
On / Off
Gun Operating Mode (On: Working Off: Not Working)
Gun P3
On / Off
Gun Operating Mode (On: Working Off: Not Working)
Gun P4
On / Off
Gun Operating Mode (On: Working Off: Not Working)
Clear Credits
Resets the Inserted credits to 0 if more than 40 credits
are entered
Game Stats
Shows the Stats Screen
Gun Tool
Gun Diagnostic Tool
Resume Game
Exits the Operator Menu and returns to the game
Quit Game
Exits the game and returns to the Windows desktop
*Units can be another Adrenaline Amusements Tomb Raider (65” / 120”) or
Rabbids Hollywood (65” / 120”) arcades.

Tomb Raider 65” Manual V2.0
Chapter 05 –Service & repair
Page 19 of 58
Chapter 05 – Service & Repair
Computer Connections
No.
Description
1.
PCI-e Video Adapter DVI to Monitor DVI
2.
Audio Jack to Amplifier #1
3.
USB to Gun Controller 1
4.
USB to Gun Controller 2
5.
USB to Gun Controller 3
6.
USB to Gun Controller 4
7.
USB to STEM Base
8.
USB to USB Hub Inlet
9.
AC Inlet Power Supply
10.
AC Power Switch
11.
Power Button

Tomb Raider 65” Manual V2.0
Chapter 05 –Service & repair
Page 20 of 58
Gun tracking Hardware Troubleshooting Guide
The gun tracking system consists of 3 main components.
1. Gun base board, under center plastic console
2. Tracking coil, which is connected to the base board
3. Gun stem stick, inside the gun
Issue: Aims moves left or right when you approach the gun closer to the screen.
Problem: There is a big metal structure behind the cabinet that makes electromagnetic interference.
Solution: Move the cabinet about 45cm (18’') in front away from the interference.
Issue: Aim is not accurate on gun 1 or gun 4. It is even worse when the gun is closer to the side panel.
Problem: There is a metal structure on the side of the cabinet that makes electromagnetic interference.
Solution: Move the cabinet about 45cm (18'') away from the interference.
Issue: Aim on one gun locks randomly in place during game play.
Problem: USB communication between gun and computer is erratic.
Solution: Change the USB extension from gun harness to the USB hub, if that does not work you can
change the gun hose harness or the complete gun assembly.
Issue: Aim is completely erratic or even not present on one of the guns.
Problem: Tracking hardware in gun defective.
Solution: Change the gun.
Issue: Aim is completely erratic on all 4 guns.
Problem: Coil is disconnected from base board or base board is defective.
Solution: Check if coil connection is ok, change the base board.
