Adrenaline RAM-65-1001 Installation and operating instructions

RAMPAGE
RAM-65-1001
Operation & Service Manual
Version 1.0
* Read this manual before use

Rampage Manual V1.0
Page 2of 44
General Remark
If you encounter any difficulties or if you need support on how to update and/ or install your
Rampage product, we invite you to contact your local distributor or reach us at
[email protected] or by calling our support line [phone]
Adrenaline Amusements Team
Adrenaline Amusements
1150 Levis, Suite 302
Terrebonne, Qc
Canada
J6W 5S6

Rampage Manual V1.0
Page 3of 44
Table of Contents
Contents
General Remark..................................................................................................2
Table of Contents................................................................................................3
Chapter 01 - Preface ...........................................................................................5
Precaution for Game Operation.................................................................................................. 5
Safety........................................................................................................................................... 6
Environmental Conditions........................................................................................................... 6
Operating & Voltage.................................................................................................................... 6
Chapter 02 –Unit Features .................................................................................7
Hardware Features...................................................................................................................... 7
Cabinet Facts ............................................................................................................................... 7
Chapter 03 –Unit Installation .............................................................................8
Assembling your Rampage Unit .................................................................................................. 8
How to slide out the Screen Module: ......................................................................................... 8
Header Assembly....................................................................................................................... 10
How to open the Dash Board:................................................................................................... 12
Chapter 04 –Operator Menu ............................................................................13
Operator Menu ......................................................................................................................... 13
Chapter 05 –Service & Repair...........................................................................15
Computer Connections ............................................................................................................. 15
Troubleshooting ........................................................................................................................ 16
Video Troubleshooting........................................................................................................................16
Audio Troubleshooting .......................................................................................................................16
RGB Led Troubleshooting.......................................................................................................... 17
Replacing RGB LED PCBs............................................................................................................ 21
Wireless Internet Configuration................................................................................................ 22

Rampage Manual V1.0
Page 4of 44
Chapter 06 - Parts .............................................................................................23
Cabinet Parts ............................................................................................................................. 23
Computer & Electronics ............................................................................................................ 25
Header & LEDs........................................................................................................................... 26
Cabling....................................................................................................................................... 27
Wiring Harness .......................................................................................................................... 27
Chapter 07 –Diagrams & Schematics................................................................28
I/0 Board ADR-04-1003 ............................................................................................................. 28
I/O Board - Schematics Wiring .................................................................................................. 31
Player 1...................................................................................................................................... 31
Player 2...................................................................................................................................... 32
Player 3...................................................................................................................................... 33
Tickets Wiring............................................................................................................................ 34
Meters - Operator Button - Header LED Power........................................................................ 35
Power Distribution Schematics ................................................................................................. 37
RGB LED Schematics................................................................................................................. 38
RGB LED Controller Channel 1................................................................................................... 39
RGB LED Controller Channel 2................................................................................................... 40
RGB LED Controller Channel 3................................................................................................... 41
Chapter 08 –Software Recovery.......................................................................42
Chapter 09 –Card Reader .................................................................................43
Limited Warranty Policies ......................................................................44

Rampage Manual V1.0
Chapter 01 - Preface
Page 5of 44
Chapter 01 - Preface
Please read this page before preparing your Rampage Arcade product for game
play.
The following safety instructions apply to all game operators and service personnel. Specific
warnings and cautions will be included throughout this manual.
Use the following safety guidelines to help protect the system from potential damage and to
ensure your personal safety:
Electronic components in the game cabinet run on 110V AC 60Hz (220V/ 50Hz in most of
Europe, the Middle East and the Far East delivered units).
To help prevent electric shock, plug the system into a properly grounded power source.
These cables are equipped with 3-prong plugs to help ensure proper grounding. Do not
use adapter plugs or remove the grounding prong from a cable. If you must use an
extension cable, use a 3-wire cable with properly grounded plugs. We do recommend a
15A rated current or higher power cord.
To help protect your system from sudden increases and decreases in electrical power,
use a surge suppressor, line conditioner or Uninterruptible Power Supply (UPS).
Be sure nothing rests on the system’s cables and that the cables are not located where
they can be stepped on or tripped over.
Keep your system far away from radiators and other heat sources.
Do not block cooling vents.
Precaution for Game Operation
Adrenaline Amusements Inc. assumes no liability for injuries incurred while playing our games.
Operators should be aware that certain health and physical conditions may make people
susceptible to injury when playing video games.

Rampage Manual V1.0
Chapter 01 - Preface
Page 6of 44
Safety
To avoid electrical shock, unplug the cabinet before performing
installation or service procedures.
If a power cord is damaged, it must be replaced by the equivalent
power cord available from your distributor.
Adrenaline Amusement Inc. assumes no liability for any damages or
injuries incurred while setting up or servicing the cabinet. Only qualified
service personnel should perform installation or service procedures.
Environmental Conditions
Cabinet is intended for indoor use only. Be sure to keep the cabinet dry and maintain operating
temperatures of 59° - 86°F (15° - 30°C).
Operating & Voltage
Voltage
Operating
110V AC
4.0 AMP
220V AC
2.0 AMP

Rampage Manual V1.0
Chapter 02 –Unit Features
Page 7of 44
Chapter 02 – Unit Features
Hardware Features
3 Players Game
65 inches Screen
Cabinet Facts
Cabinet Dimensions
Height = 112.4” [2854.0 mm]
Full Depth = 54.14” [1375.1 mm] Width = 64.20” [1630.7 mm]
Shipping Dimensions
Width = 45.00”Depth = 68.00”Height = 84.00”
Weight = 650 lbs

Rampage Manual V1.0
Chapter 02 –Unit Features
Page 8of 44
Chapter 03 – Unit Installation
Assembling your Rampage Unit
**You need to be 2 persons to assemble the unit**
1. Carefully remove the cabinet from the shipping skid, giving you enough space.
2. Move the cabinet to the desired location.
How to slide out the Screen Module:
3. Remove the 4x bolts #10-24 1-1/4” (2x per side) holding the monitor cabinet assembly to the
front cabinet assembly.
4. Slide out the 2 cabinets and align the bracket holes with the center part holes.
5. Re-insert the 4x bolts and tighten them.

Rampage Manual V1.0
Chapter 03 –Unit Installation
Page 9of 44
6. Lower the level adjustors until the Pivot Wheels are slightly above the floor.

Rampage Manual V1.0
Chapter 03 –Unit Installation
Page 10 of 44
Header Assembly
**You need to be 2 persons to install the header**
Using a ladder, fix the header to the monitor using the 8x bolts # 10-24 1/2”.

Rampage Manual V1.0
Chapter 03 –Unit Installation
Page 11 of 44
-Connect the +12V Barrel connector coming out from the monitor bezel to the header LED
connector.

Rampage Manual V1.0
Chapter 03 –Unit Installation
Page 12 of 44
How to open the Dash Board:
-To open the dash and access the electronics, open the Player-1 & Player-3 ticket doors to get
access to the 2 Draw Latches inside the cabinet.

Rampage Manual V1.0
Chapter 04 –Operator Menu
Page 13 of 44
Chapter 04 – Operator Menu
Operator Menu
Access the Operator Menu by pressing the Operator button located inside the drawer on the I/O board
directly.
Oper: Open the Operator Menu
Up: Scroll Up & Increase Value
Down: Scroll Down & Decrease Value
Select Button: Select/Deselect

Rampage Manual V1.0
Chapter 04 –Operator Menu
Page 14 of 44
Operator Menu
Values
What It Does
Credits Per Game
1 - 20
Adjusts the number of credits required to play. “0”
sets the unit in free play mode.
Game Audio Volume
0 - 20
Adjusts the in-game audio volume. “0” will mute the
game.
Attract Audio Volume
0 - 20
Adjusts the audio volume of the attract loop. “0” will
mute the attract loop.
Redemption Mode
On / Off
Adjusts the Redemption availability.
Minimum Tickets
0 - 20
Adjusts the minimum number of tickets per game.
Ticket Value
1 - 2
Adjusts the value of physical tickets. Physical tickets
are either worth “1” ticket or “2” tickets.
Point Per Tickets
10K - 1000K
Adjusts the amount of tickets given per Points
(Increment per 10K).
Redemption Unit Name
Tickets /
Coupons
Adjusts the in-game text accordingly
Jackpot Tickets
0 - 5000
Adjusts the number of tickets given when the
Jackpot is reached.
Average Game
To Win Bonus
100 - 1000
Sets how frequently the Bonus could be awarded.
New Jersey Settings
On / Off
If set to On, a message will be displayed if more than
40 credits are inserted.
Fixed Tickets
0 - 10
Adjusts the fixed number of tickets given per game.
Set it to 0 to disable this option.
Clear Credits
Resets the Inserted credits to 0 if more than 40
credits are entered.
Game Stats
Shows the Stats Screen.
Resume Game
Exits the Operator Menu and returns to the game.
Quit Game
Exits the game and returns to the Windows desktop.

Rampage Manual V1.0
Chapter 05 –Service & repair
Page 15 of 44
Chapter 05 – Service & Repair
Computer Connections
No.
Description
1.
HDMI Cable to Projector HDMI-1 Connector
2.
Audio Jack to Amplifier #1
3.
USB Port to I/O Board
4.
USB Wi-Fi Adapter
5.
USB Restore Flash Drive
6.
Power Button
7.
AC Power Switch
8.
AC Inlet Power Supply
9.
USB RGB LED Controller
10.
USB License Dongle

Rampage Manual V1.0
Chapter 05 –Service & repair
Page 16 of 44
Troubleshooting
* NOTE: When requesting a warranty replacement you will be asked to
give the unit’s serial number from the back of the unit.
Video Troubleshooting
No Picture or
Display Problem
There might have loose or faulty connections between the monitor and the
computer. Make sure the DVI cable is connected properly in the computer
connector and in the monitor connector.
Verify that the Computer is powered on.
The fan on the side of the computer case should be spinning as a reference,
if it’s not spinning press the Power Button on the front of the computer.
Audio Troubleshooting
Low Volume / No
Sound
Increase the volume in the game by pressing the Operator Button and
adjusting the volume options in the Operator Menu. You might also Quit the
game to Windows desktop and increase the volume via the Speaker icon
on the bottom right of your screen.
If the sound comes from the projector integrated speaker it needs to be
changed in Windows. Quit the game to the Windows desktop.
Right click on the speaker icon and select Playback Devices.
Select the Speakers and choose “Set default”, then click OK.
Verify the wirings behind the speakers and the amplifier.
Verify that the 1/8’’ audio jack is plugged in the computer’s sound input jack
and that the other end RCA’s is plugged in the sound amplifier.

Rampage Manual V1.0
Chapter 05 –Service & repair
Page 17 of 44
RGB Led Troubleshooting
If the RGB LEDs in the building and the Dash are not working properly verify that the RGB LED Controller
is connected on a valid COM Port.
Press the Operator Button and Quit/Exit the game to Windows Desktop.
Connect a USB mouse.
Right-click on the windows flag on the bottom left corner and select Device Manager.

Rampage Manual V1.0
Chapter 05 –Service & repair
Page 18 of 44
Expand the “Ports (COM & LPT)” line by clicking on the >.
Verify that the “USB Serial Device” is set between COM2 to COM9.

Rampage Manual V1.0
Chapter 05 –Service & repair
Page 19 of 44
If it’s outside this range, double-click on it to open its properties.
Select the “Port Settings” Tab.
Click on “Advanced…”

Rampage Manual V1.0
Chapter 05 –Service & repair
Page 20 of 44
Click on the COM Port Number scrolling menu and select COM9.
Click on OK.
Click on OK again.
Close the Device Manager window and restart Windows.
