Operation & Service Manual
Version 5.0
* Read this manual before use

Tomb Raider Manual V5.0
2 | P a g e
General Remark
If you encounter any difficulties or if you need support on how to update and/ or install your
Tomb Raider product, we invite you to contact your local distributor or reach us at
[email protected] or by calling our support line [phone]
Adrenaline Amusements Team
Adrenaline Amusements
2273 Antonio-Héroux street
Terrebonne, QC
Canada
J6X 4R3

Tomb Raider Manual V5.0
3 | P a g e
Table of Contents
Contents
General Remark..................................................................................................2
Table of Contents................................................................................................3
Chapter 01 - Preface ...........................................................................................5
Precaution for Game Operation.................................................................................................. 5
Safety........................................................................................................................................... 6
Environmental Conditions........................................................................................................... 6
Operating & Voltage.................................................................................................................... 6
Maintenance Warning................................................................................................................. 7
Chapter 02 –Unit Features .................................................................................8
Hardware Features...................................................................................................................... 8
Cabinet Facts............................................................................................................................... 8
Chapter 03 –Unit Installation .............................................................................9
Parts included.............................................................................................................................. 9
Assembling your Tomb Raider Unit .......................................................................................... 10
Cabinet & Side Panels Assembly ............................................................................................... 11
Screen Assembly ....................................................................................................................... 16
Header Assembly....................................................................................................................... 19
Chapter 04 –Operator Menu............................................................................29
Operator Menu ......................................................................................................................... 29
Chapter 05 –Service & Repair...........................................................................31
Computer Connections ............................................................................................................. 31
Projector Connections............................................................................................................... 32
Projector Settings...................................................................................................................... 33
Gun Controller ID Remapping ................................................................................................... 35
Troubleshooting ........................................................................................................................ 37

Tomb Raider Manual V5.0
4 | P a g e
Video Troubleshooting........................................................................................................................37
Audio Troubleshooting .......................................................................................................................37
Wireless Internet Configuration................................................................................................ 38
Operator Settings keeps resetting trouble ............................................................................... 39
Computer not powering at boot............................................................................................... 40
Chapter 06 - Parts .............................................................................................41
Cabinet Parts ............................................................................................................................. 41
Computer & Electronics ............................................................................................................ 43
Header & LEDs........................................................................................................................... 47
Cabling....................................................................................................................................... 48
Wiring Harness .......................................................................................................................... 49
Chapter 07 –Diagrams & Schematics................................................................50
I/0 Board ADR-04-1003 ............................................................................................................. 50
I/O Board - Wiring ..................................................................................................................... 52
Power Distribution Schematics ................................................................................................. 58
Chapter 08 –Software Recovery.......................................................................60
Chapter 09 –Card Reader .................................................................................61
Limited Warranty Policies ......................................................................62

Tomb Raider Manual V5.0
Chapter 01 - Preface
5 | P a g e
Chapter 01 - Preface
Please read this page before preparing your Tomb Raider Arcade product for
game play.
The following safety instructions apply to all game operators and service personnel. Specific
warnings and cautions will be included throughout this manual.
Use the following safety guidelines to help protect the system from potential damage and to
ensure your personal safety:
•Electronic components in the game cabinet run on 110V AC 60Hz (220V/ 50Hz in most of
Europe, the Middle East and the Far East delivered units).
•To help prevent electric shock, plug the system into a properly grounded power source.
These cables are equipped with 3-prong plugs to help ensure proper grounding. Do not
use adapter plugs or remove the grounding prong from a cable. If you must use an
extension cable, use a 3-wire cable with properly grounded plugs. We do recommend a
15A rated current or higher power cord.
•To help protect your system from sudden increases and decreases in electrical power,
use a surge suppressor, line conditioner or Uninterruptible Power Supply (UPS).
•Be sure nothing rests on the system’s cables and that the cables are not located where
they can be stepped on or tripped over.
•Keep your system far away from radiators and other heat sources.
•Do not block cooling vents.
Precaution for Game Operation
Adrenaline Amusements Inc. assumes no liability for injuries incurred while playing our games.
Operators should be aware that certain health and physical conditions may make people
susceptible to injury when playing video games.

Tomb Raider Manual V5.0
Chapter 01 - Preface
6 | P a g e
Safety
To avoid electrical shock, unplug the cabinet before performing
installation or service procedures.
If a power cord is damaged, it must be replaced by the equivalent
power cord available from your distributor.
Adrenaline Amusement Inc. assumes no liability for any damages or
injuries incurred while setting up or servicing the cabinet. Only qualified
service personnel should perform installation or service procedures.
Environmental Conditions
Cabinet is intended for indoor use only. Be sure to keep the cabinet dry and maintain operating
temperatures of 59° - 86°F (15° - 30°C).
Operating & Voltage
Voltage
Operating
110V AC
4.0 AMP
220V AC
2.0 AMP

Tomb Raider Manual V5.0
Chapter 01 - Preface
7 | P a g e
Maintenance Warning
You should be very careful when touching the screen material as it is relatively
easy to scratch.
If the screen is dusty, use a feather duster. If this is not enough use a damp
cloth and wipe carefully sideways following the direction of the lens structure.
If rubbing too hard, you risk damaging the screen material and making a
noticeable mark.

Tomb Raider Manual V5.0
Chapter 02 –Unit Features
8 | P a g e
Chapter 02 – Unit Features
Hardware Features
•4 Players Game
•120 inches Screen
•Unique Sensor Tracker “Gun” Technology!
Cabinet Facts
Cabinet Dimensions
Height = 114.9” [2918.46mm]
Depth = 40.35” [1024.89mm] Width = 109.00” [2768.60mm]
Shipping Dimensions
Width = 44”Depth = 90”Height = 93”
Weight = 650 lbs
Width = 6”Depth = 113”Height = 63”
Weight = 150 lbs

Tomb Raider Manual V5.0
Chapter 03 –Unit Installation
9 | P a g e
Chapter 03 – Unit Installation
Parts included
1x Large bag bolts & washers (For Cabinet Assembly)
- 34x Allen Button Head Black Bolts #10-24 x 1½”
- 34x Black Washers #10
- 2x Allen Button Head Black Bolts ¼-20 x ¾”
- 2x Black Washers ¼”
- 15x Phillips Black Screws #8 x ¾”
- 4x Carriage Black Bolts #10-24 x 1½”
- 4x K-Lock Nuts #10-24 zinc
1x Small bag bolts & washers & Flat Bars (For Header Assembly)
- 2x metal square 2½” x 2½” x 5/8”
- 19x Phillips Black Screws #8 x ¾”
- 2x Metal Flat Bar zinc 5/8” x 2”
- 8x Screws zinc #6 x 3/8”
- 2x Metal Angle
1x Left Cabinet
1x Center Cabinet
1x Right Cabinet
1x Left Side Panel
1x Right Side Panel
1x “Lara” Header part
1x “Tomb Raider” Header part
1x “Mountain” Header part
1x Left tablet with splitter power cable
1x Right tablet
1x Large Metal Angle Plate
1x Small Metal Plate with Fold
1x Box with Screen

Tomb Raider Manual V5.0
Chapter 03 –Unit Installation
10 | P a g e
Assembling your Tomb Raider Unit
**You need to be 3 persons to assemble the unit**
1. Carefully remove the cabinets from the shipping skids, giving you enough space.
2. Move the 3 cabinets and the side panels to the desired location.

Tomb Raider Manual V5.0
Chapter 03 –Unit Installation
11 | P a g e
Cabinet & Side Panels Assembly
3. Assemble the cabinet together using the provided 10X Bolts Allen button head #10-24 x 1-½” &
washers. 5x Bolts per sides.
The bolts need to be inserted from the center cabinet towards the exterior ones.
You will need to remove the back cabinet service doors to get the access.
You will also need to open the upper coin door from the center cabinet to install bolts there too.

Tomb Raider Manual V5.0
Chapter 03 –Unit Installation
12 | P a g e
4. Under the cabinets, locate and install the provided 2x Allen button Head Bolts ¼-20 x ¾”with the
washers ¼” to hold and secure the cabinets together.
5. Lower the Level adjustors until the Pivot Wheels are slightly above the floor.

Tomb Raider Manual V5.0
Chapter 03 –Unit Installation
13 | P a g e
6. The illuminated “Lara Croft”is the exterior side of the unit.
-Take the power cable from the side panel and guide it through the hole on the side cabinet.
-Slowly get the side panel closer to the cabinet while watching to avoid squeezing the cable.
-When it’s close enough, align the side panel with the cabinet.

Tomb Raider Manual V5.0
Chapter 03 –Unit Installation
14 | P a g e
7. Install the side panel to the cabinet by using the Black Allen Button Head Bolts #10-24 x 1½” and
Black Washers #10. Each side panels needs 6 bolts.
8. Install the metal angle on each panel with Black Phillips Screws #8 x ¾”.

Tomb Raider Manual V5.0
Chapter 03 –Unit Installation
15 | P a g e
9. Connect the 5 harnesses between the edge cabinets to the center cabinet together.

Tomb Raider Manual V5.0
Chapter 03 –Unit Installation
16 | P a g e
You should be very careful when touching the screen material as it is relatively
easy to scratch.
If the screen is dusty, use a feather duster. If this is not enough use a damp
cloth and wipe carefully sideways following the direction of the lens structure.
If rubbing too hard, you risk damaging the screen material and making a
noticeable mark.
Screen Assembly
10. *3 persons minimum required*
Align the bottom of the screen to the upper back edge of the cabinet.
Flip it between the side panels.

Tomb Raider Manual V5.0
Chapter 03 –Unit Installation
17 | P a g e
11. Using the #10-24 x 1½” Allen Head Buttons Bolts & Washers #10 (3 on each sides), affix the screen
to the side panels of the cabinet.

Tomb Raider Manual V5.0
Chapter 03 –Unit Installation
18 | P a g e
12. Secure the metal bottom plate of the screen to the cabinet by using the 7x black Philips screws #8 x
¾”.
13. The +12V Barrel Power Cable behind the cabinet will be for the header LEDs power. Leave it
attached for now we will use it later.

Tomb Raider Manual V5.0
Chapter 03 –Unit Installation
19 | P a g e
Header Assembly

Tomb Raider Manual V5.0
Chapter 03 –Unit Installation
20 | P a g e
14. Parts Needed: “Right Side” piece of wood, the large metal square, the small metal square,
2x Carriage Bolts #10-24 x 1½” and 2x K-Lock Nuts #10-24.
- Install the longer side of the larger metal square bracket on a flat surface, the smaller side will
be vertical and near you.
- Take the piece of wood that has the larger “groove” on top and install it on the left side of the
square bracket ass seen below.
- Take the smaller metal square bracket and align the holes with those on the piece of wood.
- Align & insert the carriage bolts towards you and secure it with the K-Nut.
