ADTRAN TRACER QUAD E1 User manual

TRACER QUAD E1 MODULE P/N 1280044L2
For more detailed documentation, visit us online at www.adtran.com
Quick Start Guide
Quick Start Guide, 61280044L2-13A, February 2005 Technical Support 1-888-4ADTRAN (1-888-423-8726) Copyright ©2005 ADTRAN, All Rights Reserved
SPECIFICATIONS
Capacity: 4xE1 (CCITT G.703) – 8.192 Mbps
Interface Type: G.703, G.704, and G.823 Compliant (BNC interfaces only)
Connectors: DB-25 with optional breakout panel providing 75ΩBNCs
Line Code: HDB3 (default), AMI
Alarms: LOS, LCV, AIS, RMT, OOF, CRC
Loopbacks: Local and remote line, local and remote link
DB-25 CONNECTION PINOUT
Pin Name Description
1 E1D RX TIP Receive signal for E1 D interface
2 E1D TX TIP Output signal for E1 D interface
3 GND Ground
4 E1C RX TIP Receive signal for E1 C interface
5 E1C TX TIP Output signal for E1 C interface
6 GND Ground
7 E1B RX TIP Receive signal for E1 B interface
8 E1B TX TIP Output signal for E1 B interface
9 GND Ground
10 E1A RX TIP Receive signal for E1 A interface
11 E1A TX TIP Output signal for E1 A interface
12-25 GND Ground
INSTALLATION INSTRUCTIONS
1. Remove the cover plate from the appropriate option slot in the TRACER
rear panel.
2. Slide the TRACER Quad E1 Module into the option slot until the module
is firmly positioned in the chassis.
3. Secure the thumbscrews at both edges of the module. Tighten with a
screwdriver.
4. Connect the cables to the associated device(s).
5. Complete installation of remaining modules and system as specified in
the TRACER 6000 Series System Manual.
The TRACER Quad E1 Module is not
hot-swappable. Removepower from the TRACER
system before installing or removing the module.

TRACER QUAD E1 MODULE P/N 1280044L2
Quick Start Guide
Quick Start Guide, 61280044L2-13A, February 2005 Technical Support 1-888-4ADTRAN (1-888-423-8726) Copyright ©2005 ADTRAN, All Rights Reserved
CONNECTING THE QUAD E1 MODULE INTERFACES
The physical E1 interfaces are provided using a single DB-25
interface, an adapter cable, and a BNC breakout panel.
Connect the end of the adapter cable (labeled TO RADIO) to
the module’s DB-25 connector, and then attach the other end
of the cable (labeled TO PANEL) to the BNC breakout panel.
The 75Ωunbalanced interfaces provided by the breakout
panel are available for connection to standard E1 DTE
devices (see Figure 1).
FIGURE 1. E1 CONNECTION WITH BREAKOUT PANEL
DB-25 TO 75ΩUNBALANCED CABLE PINOUT
E1 Cable Interface DB-25 Male (TRACER Side) DB-25 Male (Breakout Panel)
Channel 1 Input 10 14
Channel 1 Output 11 3
Channel 2 Input 7 17
Channel 2 Output 8 6
Channel 3 Input 4 20
Channel 3 Output 5 9
Channel 4 Input 1 23
Channel 4 Output 2 12
Ground All other pins All other pins
