DESCRIPTION
The Small Form-Factor Pluggable 10 Gigabit Ethernet XFP, 1310
nm, Temperature Hardened (XFP) optical transceiver is a fully
duplex serial electric, serial optic device with both transmit and
receive functions contained in a single module that provides a
high speed serial link at 10 Gbp/s. Installed into an appropriate
host module, the XFP provides a 10 Gigabit interface to the
supporting system.
The transmit side of the XFP converts serial NRZ electrical data at
the10 Gbp/s line rate to a standard compliant optical signal. The
receive side of the XFP converts the incoming DC balanced serial
NRZ optical data at the 10 Gbp/s line rate into serial electrical
data.
NOTE
To ensure compatibility, refer to the documentation provided
with the host module.
FEATURES
The following features are supported on the XFP:
■1310 nm optical signals for up to 10 km reach
■Case temperature hardened range from –40°C to 85°C
■Low power consumption (<2.5 W max)
■Bit error rate (<1x10-12)
■Excellent EMI performance
Small Form-Factor Pluggable
10 Gigabit Ethernet XFP, 1310 nm,
Temperature Hardened
INSTALLATION
Before installation, inspect the XFP. If damage has occurred
during shipping, file a claim with the carrier, and then contact
ADTRAN Customer Support. For more information, refer to
“Warranty”.
Installation Guidelines
The following are guidelines for this installation.
■The latch on the XFP is for removal only. When removing the
XFP, rotate the latch away from the XFP. The XFP should slide
easily out of the cage.
■It is recommended that the dust cover remain on whenever the
transceiver optical fiber connector is not inserted.
Installation Steps
To install the XFP, complete the following steps:
1. Insert the XFP into the XFP cage on the circuit board of the
host module with the latch handle facing outward. Slide the
XFP all the way into the cage.
2. Exert adequate pressure to ensure the XFP is completely
seated in the XFP cage.
3. Do not remove the dust cover until the optical fiber
connection is made.
4. Continue the installation and turn-up of the host module.
SPECIFICATIONS
■Optical Specifications:
♦Transmit Wavelength: 1310 nm
♦Receive Wavelength: 1260 to 1355 nm
♦Data rate: 9.95 Gbp/s to 10.30 Gbp/s
♦Optical transmit level: –8.2 to +0.5 dBm
♦Optical receive level: –12.6 to +0.5 dBm
♦Optical distance: 10 km maximum
♦Optical connectors: LC
■Extended Environmental Support:
♦Operational temperature range: –40°C to +65°C
●Case temperature hardened range: –40°C to +85°C
♦Storage temperature range: –40°C to +85°C
♦Relative humidity to 85%, noncondensing
CLEI: BVL3ADLD_ _
Product P/N: 1442910G1
Issue Date: October 2015
Document P/N: 61442910G1-22C
Documentation for ADTRAN Carrier Networks products is available for
viewing and download directly from the ADTRAN Support Community
website.
Go to: https://supportforums.adtran.com/welcome
Registration is required.
ADTRAN offers training courses on our products, including customized
training and courses taught at our facilities or at customer sites.
For inquiries, go to: http://adtran.com/training
The following documents provide additional information for this product:
SFP/XFP/SFP+ Compatibility Matrix (online tool, go to: http://www.adtran.com/sfp

CAUTION!
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY
HANDLING PRECAUTIONS REQUIRED
Warranty: ADTRAN will replace or repair this product within the warranty period if it does not
meet its published specifications or fails while in service. Warranty information can
be found online at www.adtran.com/warranty.
Trademarks: Brand names and product names included in this document are trademarks,
registered trademarks, or trade names of their respective holders.
©2015 ADTRAN, Inc. All Rights Reserved.
ADTRAN CUSTOMER CARE:
From within the U.S. 1.800.726.8663
From outside the U.S. +1 256.963.8716
PRICING AND AVAILABILITY 1.800.827.0807
*61442910G1-22C*
SAFETY AND REGULATORY COMPLIANCE
WARNING
!
Read all warnings and cautions before installing or servicing this
equipment
CAUTION
C
The product is a Class 1 Laser Product and complies with the
Laser Safety requirements of FDA 21CFR 1040.10 and 1040.11,
and EN60825-1 and -2. The XFP is NRTL listed and CB Certified
to all applicable American and European safety standards.
For continued compliance with the above laser safety standards,
only approved Class 1 modules from our approved vendor list,
located on the ADTRAN website, should be installed in ADTRAN
products.
CAUTION
!
■Electrostatic Discharge (ESD) can damage electronic modules.
When handling modules, wear an antistatic discharge wrist
strap to prevent damage to electronic components. Place
modules in antistatic packing material when transporting or
storing. When working on modules, always place them on an
approved antistatic mat that is electrically grounded.
■This product meets or exceeds all the applicable requirements
of NEBS, Telcordia GR-63-CORE, and GR-1089-CORE. This
product is intended for deployment in Central Office type
facilities, EEEs, EECs, and locations where the NEC applies
(for example, Customer Premises). This product is to be
installed in ADTRAN products in Restricted Access Locations
only, and installed by trained service personnel.
■Per GR-1089-CORE the ADTRAN system that this product is
being deployed in is designed and intended for installation as
part of a Common Bonding Network (CBN). The ADTRAN
system that this product is being deployed in is not designed
nor intended for installation as part of an Isolated Bonding
Network (IBN).
■Per GR-1089-CORE Section 9, this product does not have an
internal DC connection between battery return and frame
ground. This product can be installed in a DC-I (isolated) or
DC-C (common) installation. For installations where other
cards or the host system have internal connections between
battery return and frame ground, the system would be
intended for deployment only in a DC-C installation.
■The ADTRAN system chassis frame ground terminal must be
connected to a reliable earth ground to ensure that the metal
enclosure of this product is properly grounded via the
backplane connector.
NOTE
■The Gigabit Ethernet port(s) are optical and therefore are not
classified as any type of port as defined in Appendix B of GR-
1089-CORE.
■This product is designed to be deployed in GR-3108-CORE
environmental Class 1, 2, & 3.
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by ADTRAN
could void the user's authority to operate this equipment.
This product is designed to meet the following environmental
classes:
■ETSI EN 300 019-1-1 Classification of environmental conditions;
Storage, Class 1.2
■ETSI EN 300 019-1-2 Classification of environmental conditions;
Transportation, Class 2.3
■ETSI EN 300 019-1-3 Classification of environmental conditions;
Stationary use at weather-protected locations, Class 3.3
The equipment is designed to function without degradation
during exposure to all test severities per Class 3.3.
This product meets EU RoHS Directive 2002/95/EC and/or
applicable exemptions. Refer to www.adtran.com for further
information on RoHS/WEEE.
