DESCRIPTION
The OC-48 DWDM, 1558.98 nm, 80 km SFP (DWDM SFP) is a full
duplex serial electric, serial optic device with both transmit and
receive functions contained in a single module that provides a
high speed serial link at SONET OC-3, OC-12, OC-48, and GigE
rates. The DWDM SFP operates on Optical Channel 23
(1558.98 nm). When installed in the appropriate host module, the
DWDM SFP provides a SONET OC-3, OC-12, OC-48, or GigE
interface to the supporting system.
The transmit side of the DWDM SFP converts serial NRZ
electrical data at the line rate to a standard compliant optical
signal. The receive side converts the incoming DC balanced serial
NRZ optical data at the line rate into serial electrical data.
NOTE
To ensure compatibility, refer to the documentation provided
with the host module.
The DWDM SFP supports the following features:
•1558.98 nm optical signals for up to 80 km reach
•Low power consumption (<1.5 W max)
•Bit error rate 10^–12
CAUTION
!
Due to compliance certification requirements, use only SFPs/
XFPs supplied by ADTRAN with the host module. ADTRAN
cannot certify system integrity with other SFP/XFPs.
Small Form-Factor Pluggable
OC-48 DWDM, 1558.98 nm, 80 km SFP
OPERATIONAL SPECIFICATIONS
•Channel Spacing: 100 GHz
•Data Rate: SONET OC-3/OC-12/OC-48 or GigE
•Optical distance: 80 km nominal
•Transmit Wavelength: 1558.98 nm (Channel 23)
•Receive Wavelength: 1525 to 1565 nm
•Optical transmit levels: 0.0 to +5.0 dBm
•Spectral Width: 0.4 nm (20 dB spectral width)
•Extinction Ratio: 8.2 dB
•Optical receive level: –29.0 to –8.0 dBm
•Receiver Damage Threshold: –5.0 dBm
•Optical Path Penalty: 2.0 dB max
•Minimum Span Attenuation: 13 dB
•Optical Budget: –27 dB
•Dispersion Tolerance: 1600 ps/nm
•Optical connectors: LC
•Environmental Support:
oOperational temperature range: –40°C to +65°C
oStorage temperature range: –40°C to +85°C
oRelative humidity: up to 85%, noncondensing
INSTALLATION
To install the DWDM SFP into an appropriate module, complete
the following steps:
1. Inspect the DWDM SFP. If damaged, file a claim with the
carrier and then contact ADTRAN Customer Support.
CAUTION
!
Do not remove the protective end cap from the SFP until the fiber
optic cable is ready to be connected.
2. Insert the DWDM SFP into the SFP cage on the module.
Ensure that the manufacturer label on the SFP is facing
upward for correct installation.
3. Slide the DWDM SFP all the way into the receptacle until
there is an audible “click”.
NOTE
Use the latch on the DWDM SFP to remove the SFP from the SFP
cage mounted on the printed circuit board.
CLEI: SOOTALXJ__
Product P/N: 1442707G3
Issue Date: August 2011
Document P/N: 61442707G3-22A

Warranty: ADTRAN will replace or repair this product
within the warranty period if it does not meet its
published specifications or fails while in
service. Warranty information can be found
online at www.adtran.com/warranty.
©2011 ADTRAN, Inc. All Rights Reserved.
ADTRAN CUSTOMER CARE:
From within the U.S. 1.800.726.8663
From outside the U.S. +1 256.963.8716
PRICING AND AVAILABILITY 1.800.827.0807
*61442707G3-22A*
SAFETY AND REGULATORY COMPLIANCE
CAUTION
C
The OC-48 DWDM, 1558.98 nm, 80 km SFP is a Class 1 Laser
Product and complies with the Laser Safety requirements of FDA
21 CFR 1040.11, EN60825-1, and EN60825-2. The DWDM SFP is
NRTL Listed and CB Certified to all applicable American and
European safety standards.
CAUTION
!
• Electrostatic Discharge (ESD) can damage electronic modules.
When handling modules, wear an antistatic discharge wrist
strap to prevent damage to electronic components. Place
modules in antistatic packing material when transporting or
storing. When working on modules, always place them on an
approved antistatic mat that is electrically grounded.
• Per GR-1089-CORE the ADTRAN system that the DWDM SFP
is being deployed in is designed and intended for installation
as part of a Common Bonding Network (CBN). The ADTRAN
system that the DWDM SFP is being deployed in is not
designed nor intended for installation as part of an Isolated
Bonding Network (IBN).
• Per GR-1089-CORE Section 9, the DWDM SFP does not have an
internal DC connection between battery return and frame
ground. The DWDM SFP can be installed in a DC-I (isolated)
or DC-C (common) installation. For installations where other
cards or the host system have internal connections between
battery return and frame ground, the system would be
intended for deployment only in a DC-C installation.
• The ADTRAN system chassis frame ground terminal must be
connected to a reliable earth ground to ensure that the metal
enclosure of the DWDM SFP is properly grounded through
the backplane connector.
NOTE
• The Gigabit Ethernet port(s) are optical and therefore are not
classified as any type of port as defined in Appendix B of GR-
1089-CORE Issue 5.
• This DWDM SFP is compliant with SFF-8472 “Digital
Diagnostics Monitoring Interface for Optical Transceivers,”
Revision 9.3.
• This DWDM SFP is compliant with the XFP Multi-Source
Agreement (MSA).
• This DWDM SFP is designed to be deployed in GR-3108-CORE
environmental class 1 or 2 as defined in GR-3108-CORE Issue
2.
The DWDM SFP meets or exceeds all the applicable requirements
of NEBS, Telcordia GR-63-CORE, GR-1089-CORE, and ETSI EN
300368. The DWDM SFP is intended for deployment in Central
Office type facilities, EEEs, EECs, and locations where the NEC
applies (for example, Customer Premises).
The DWDM SFP is to be installed in ADTRAN products in
Restricted Access Locations only, and installed by trained service
personnel.
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by ADTRAN
could void the user's authority to operate this equipment.
The DWDM SFP is designed to meet the following environmental
classes:
•ETSI EN 300 019-1-1 “Classification of environmental
conditions; Storage,” Class 1.2
•ETSI EN 300 019-1-2 “Classification of environmental
conditions; Transportation,” Class 2.3
•ETSI EN 300 019-1-3 “Classification of environmental
conditions; Stationary use at weather-protected locations,”
Class 3.3
The equipment is designed to function without degradation
during exposure to all test severities per Class 3.3.
The OC-48 DWDM, 1558.98 nm, 80 km SFP meets EU RoHS
Directive 2002/95/EC and/or applicable exemptions. Refer to
www.adtran.com for further information on RoHS/WEEE.
C A U T I O N
C A U T I O N
!
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY.
HANDLING PRECAUTIONS REQUIRED.
