ADTRAN ESU LT User manual

ESU LT
User Manual
Part Number 1200410L1
61200410L1-1B
February 2003

Trademarks
Any brand names and product names included in this manual are trademarks, registered
trademarks, or trade names of their respective holders.
T-Watch PRO®is a registered trademark of ADTRAN, Inc.
To the Holder of the Manual
The contents of this manual are current as of the date of publication. ADTRAN reserves
the right to change the contents without prior notice.
In no event will ADTRAN be liable for any special, incidental, or consequential
damages or for commercial losses even if ADTRAN has been advised thereof as a result
of issue of this publication.
901 Explorer Boulevard
P.O. Box 140000
Huntsville, AL 35814-4000
[phone]
Copyright © 2003 ADTRAN, Inc.
All Rights Reserved.
Printed in U.S.A.

61200410L1-1B ESU LT User Manual 3
The following conventions are used in this manual.
Safety Instructions
When using your telephone equipment, please follow these basic safety precautions to
reduce the risk of fire, electrical shock, or personal injury:
1. Do not use this product near water, such as a bathtub, wash bowl, kitchen sink,
laundry tub, in a wet basement, or near a swimming pool.
2. Avoid using a telephone (other than a cordless-type) during an electrical storm.
There is a remote risk of shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord, power supply, and/or batteries indicated in the
manual. Do not dispose of batteries in a fire. They may explode. Check with
local codes for special disposal instructions.
Save These Important Safety Instructions
Cautions signify information that could prevent service interruption.
Notes provide additional useful information.
Warnings provide information that could prevent damage to the
equipment or endangerment to human life.

4 ESU LT User Manual 61200410L1-1B
Federal Communications Commission Radio Frequency Interference
Statement
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio frequencies. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Canadian Emissions Requirements
The Class B digital apparatus meets all requirements of the Canadian Interference
Equipment Regulations.
Cet appareil numérique dela Class B respecte les exigences du Regulement sur le materiel
brouilleur du Canada.
Shielded cables must be used with this unit to ensure compliance with
Class A FCC limits.
Changes or modifications to this unit not expressly approved by
the party responsible for compliance could void the user’s
authority to operate the equipment.

61200410L1-1B ESU LT User Manual 5
International Cordset Selection
The following list is a selection of recommended cordset configurations to ensure
protective earthing continuity when utilizing this product internationally. This list gives
the proper rating, cordage type, and plug/connector configuration for the specific
country where the product is to be utilized.
Country Minimum
Rating
Cordage Type Plug Type Connector
Type
Austria
Belgium
Czech Republic
Finland
France
Germany
Greece
Hungary
Iceland
Luxembourg
Netherlands
Norway
Poland
Portugal
Slovenia
Spain
Sweden
Yugoslavia
250 VAC, 10A HAR CEE 7/7 IEC 60320 C13
Australia, China 250 VAC, 10A V76419 AS 3112 IEC 60320 C13
Denmark 250 VAC, 10A HAR Afsnit 107-2-D1 IEC 60320 C13
India/South Africa 250 VAC, 10A HAR BS 546 IEC 60320 C13
Israel 250 VAC, 10A HAR SI-32 IEC 60320 C13
Italy 250 VAC, 10A HAR CEI-23-16/VII IEC 60320 C13
Japan 125 VAC, 7 A 12-1367
Yukita 300 V
JIS 8303 IEC 60320 C13
Russian
Federation
250 VAC, 10A HAR GOST 7396 IEC 60320 C13
Switzerland 250 VAC, 10A HAR SEV 1011 IEC 60320 C13
Ireland;
United Kingdom
250 VAC, 10A HAR BS 1363 IEC 60320 C13
Korea 125 VAC, 10A HAR KSC 8305 IEC 60320 C13
North America 125 VAC, 10A AWG NEMA 5-15 IEC 60320 C13

6 ESU LT User Manual 61200410L1-1B
Warranty and Customer Service
ADTRAN will replace or repair this product within the warranty period if it does not meet
its published specifications or fails while in service. Warranty information can be found at
www.adtran.com/warranty.

61200410L1-1B ESU LT User Manual 7
Customer Service, Product Support Information, and Training
ADTRAN will repair and return this product if within the warranty period from the date
of shipment the product does not meet its published specification or the product fails
while in service.
A return material authorization (RMA) is required prior to returning equipment to
ADTRAN. For service, RMA requests, training, or more information, use the contact
information given below.
Repair and Return
If you determine that a repair is needed, please contact our Customer and Product
Service (CAPS) department to have an RMA number issued. CAPS should also be
contacted to obtain information regarding equipment currently in house or possible fees
associated with repair.
Identify the RMA number clearly on the package (below address), and return to the
following address:
Pre-Sales Inquiries and Applications Support
Your reseller should serve as the first point of contact for support. If additional pre-sales
support is needed, the ADTRAN Support web site provides a variety of support services
such as a searchable knowledge base, latest product documentation, application briefs,
case studies, and a link to submit a question to an Applications Engineer. All of this, and
more, is available at:
When needed, further pre-sales assistance is available by calling our Applications
Engineering Department.
CAPS Department [phone]
ADTRAN Customer and Product Service
901 Explorer Blvd. (East Tower)
Huntsville, Alabama 35806
RMA # _____________
http://support.adtran.com
Applications Engineering [phone]

8 ESU LT User Manual 61200410L1-1B
Post-Sale Support
Your reseller should serve as the first point of contact for support. If additional support is
needed, the ADTRAN Support web site provides a variety of support services such as a
searchable knowledge base, updated firmware releases, latest product documentation,
service request ticket generation and trouble-shooting tools. All of this, and more, is
available at:
When needed, further post-sales assistance is available by calling our Technical Support
Center. Please have your unit serial number available when you call.
Installation and Maintenance Support
The ADTRAN Custom Extended Services (ACES) program offers multiple types and
levels of installation and maintenance services which allow you to choose the kind of
assistance you need. This support is available at:
For questions, call the ACES Help Desk.
Training
The Enterprise Network (EN) Technical Training Department offers training on our most
popular products. These courses include overviews on product features and functions
while covering applications of ADTRAN's product lines. ADTRAN provides a variety of
training options, including customized training and courses taught at our facilities or at
your site. For more information about training, please contact your Territory Manager or
the Enterprise Training Coordinator.
http://support.adtran.com
Technical Support (888) 4ADTRAN
http://www.adtran.com/aces
ACES Help Desk (888) 874-ACES (2237)
Training Phone [phone], ext. 7500
Training Fax [phone]
Training Email [email protected]

61200410L1-1B ESU LT User Manual 9
Table of Contents
List of Figures .............................................................................................................13
List of Tables ..............................................................................................................15
Chapter 1. Introduction ............................................................................................17
ESU LT Overview .......................................................................................................17
Functional Description ........................................................................................17
ESU LT Features ...................................................................................................18
ESU LT Configuration Application .........................................................................19
Bridge/Router Application ................................................................................19
Chapter 2. Installation ..............................................................................................21
Unpack, Inspect, Power Up ......................................................................................21
Receipt Inspection ................................................................................................21
ADTRAN Shipments Include.............................................................................21
Customer Provides...............................................................................................21
Power Connection ......................................................................................................22
Grounding Instructions.......................................................................................22
Identification of Rear Panel Layout .........................................................................24
ESU LT Rear Panel ...............................................................................................24
ESU LT Interfaces.................................................................................................25
Network Interface (NI) ................................................................................25
Network Test Interface ................................................................................25
Nx56/64 Serial Interface .............................................................................25
Control Port Input ........................................................................................26
Chain Port Output .......................................................................................26
Power Up Testing And Initialization ......................................................................26
Self-Test .................................................................................................................26
Chapter 3. Operation.................................................................................................29
Front Panel Overview ................................................................................................29
Front Panel Menu Structure and Operation ...........................................................30
Menu Structure.....................................................................................................30
Status ..............................................................................................................30
Config (Configuration) ................................................................................31

Table of Contents
10 ESU LT User Manual 61200410L1-1B
Util (Utilities) ............................................................................................... 31
Test ................................................................................................................ 31
Menu Operation .................................................................................................. 31
Editing Data Fields ...................................................................................... 32
Exiting Menu Field Operation Or Display .............................................. 33
Alternate Methods of Control............................................................................ 33
T-Watch PRO Management Software Program ...................................... 33
Chapter 4. Status Menu ........................................................................................... 35
STATUS ....................................................................................................................... 35
NI PERF RPTS...................................................................................................... 36
CURR ERR/ALM ................................................................................................ 37
Alarms and Errors ....................................................................................... 38
ERR/ALM Hist.................................................................................................... 39
Chapter 5. Configuration Menu............................................................................. 41
CONFIG ...................................................................................................................... 41
Network (NI)........................................................................................................ 42
Interface ........................................................................................................ 42
Framing ......................................................................................................... 42
Line Code .................................................................................................... 44
CRC-4 ............................................................................................................ 44
NFAS Word .................................................................................................. 44
RFA Gen ....................................................................................................... 44
Timing Mode ............................................................................................... 44
Unit........................................................................................................................ 46
CNTRL Port ................................................................................................. 47
Alarms ........................................................................................................... 47
Management ................................................................................................ 48
Port (Port Configuration) ................................................................................... 49
Interface ........................................................................................................ 49
TS0 Rate ........................................................................................................ 50
Mapping ....................................................................................................... 50
DTE TX Clock .............................................................................................. 50
Start TS0 ........................................................................................................ 50
Number of TS0s ........................................................................................... 51
Data ............................................................................................................... 51
CTS ................................................................................................................ 51
DCD ............................................................................................................... 51
DSR ................................................................................................................ 51
Inband ........................................................................................................... 52

Table of Contents
61200410L1-1B ESU LT User Manual 11
Chapter 6. Utility Menu ...........................................................................................53
UTIL ..............................................................................................................................53
Time/Date.............................................................................................................54
Software Rev ........................................................................................................55
Reinit Unit .............................................................................................................55
Address..................................................................................................................55
Set Passcode ..........................................................................................................55
Keypad...................................................................................................................56
Fact Restore ...........................................................................................................56
Chapter 7. Test Menu................................................................................................57
TEST .............................................................................................................................57
Network Tests.......................................................................................................58
Loopback Tests .............................................................................................58
Network Interface Loopbacks ....................................................................58
DTE Interface Loopbacks ............................................................................59
Local Loopbk ................................................................................................60
Remote Loopbk ............................................................................................60
Test Pattern ...................................................................................................60
CLR Errors ....................................................................................................61
Insert QRSS or 511 Errors ...........................................................................62
Run Self-test ..........................................................................................................62
Port Tests ...............................................................................................................63
Cancel Tests...........................................................................................................63
Chapter 8. Example Operations ..............................................................................65
Testing Examples ........................................................................................................65
Far End Looped Back Test ..................................................................................65
Appendix A. DTE Data Rate Chart....................................................................... 67
Appendix B. Pinouts ................................................................................................ 69
Index ............................................................................................................................77

Table of Contents
12 ESU LT User Manual 61200410L1-1B

61200410L1-1B ESU LT User Manual 13
List of Figures
Figure 1-1. ESU LT Unit.............................................................................................17
Figure 1-2. Simple Bridge Application on an E1 or FE1 Circuit ..........................19
Figure 2-1. ESU LT Rear Panel..................................................................................24
Figure 2-2. ESU LT Interfaces....................................................................................25
Figure 3-1. Front Panel Layout .................................................................................29
Figure 3-2. Cursor on Menu Item.............................................................................32
Figure 3-3. Submenu Fields.......................................................................................32
Figure 4-1. Status Menu.............................................................................................35
Figure 4-2. Severely Errored Seconds Screen..........................................................36
Figure 4-3. Loss of Signal (Current Errors/Alarms) Screens ...............................37
Figure 4-4. Clear History Screen...............................................................................39
Figure 5-1. Configuration Menu...............................................................................41
Figure 5-2. Network Submenu .................................................................................42
Figure 5-3. Network Timed Clock Source...............................................................45
Figure 5-4. Internal Timing Clock Source ...............................................................45
Figure 5-5. DTE Clock Source ...................................................................................46
Figure 5-6. Unit Submenu .........................................................................................46
Figure 6-1. Utility Menu ............................................................................................53
Figure 6-2. Time/Date Screen...................................................................................54
Figure 6-3. Address Screen........................................................................................55
Figure 7-1. Test Menu.................................................................................................57
Figure 7-2. Local Loopback Screen...........................................................................58
Figure 7-3. Network Loopback Tests .......................................................................59
Figure 7-4. DTE Interface Loopback ........................................................................59
Figure 7-5. Clear Errors Screen .................................................................................61
Figure 7-6. Self Test Results Screen ..........................................................................63
Figure 7-7. Loopback Setting Screen........................................................................63

List of Figures
14 ESU LT User Manual 61200410L1-1B

61200410L1-1B ESU LT User Manual 15
List of Tables
Table 2-1. Self-Test Results.......................................................................................27
Table 3-1. Front Panel Descriptions ........................................................................29
Table 3-2. Activating the Network Menus from the Config Menu.....................31
Table 3-3. Editing a Data Field .................................................................................32
Table 5-1. Normal Mode Operation for Port Control Signals..............................51
Table 6-1. Editing the Time/Date ............................................................................54
Table 8-1. Initiating a Remote Loopback.................................................................66
Table A-1. DTE Data Rate vs. TS0s ..........................................................................67
Table B-1. Network Pinouts......................................................................................69
Table B-2. Control-In/Chain-In Pin Assignments.................................................70
Table B-3. Chain-Out Pin Assignments...................................................................71
Table B-4. Nx56/64 Pin Assignments for EIA-530 and V.36................................72
Table B-5. Nx56/64 Pin Assignments for V.35 Mode ...........................................73
Table B-6. DB-25 to V.35, 34-Pin Winchester Cable...............................................74
Table B-7. Nx56/64 Pin Assignments for V.11/X.21 Mode .................................75
Table B-8. Adapter Cable DB-25 to X.21, DB-15 Connector .................................76

List of Tables
16 ESU LT User Manual 61200410L1-1B

61200410L1-1B ESU LT User Manual 17
Chapter 1 Introduction
ESU LT OVERVIEW
This section provides a functional description of the ESU LT,
describes its features, and illustrates its four interfaces.
Functional Description
The ADTRAN ESU LT(Figure 1-1) is one of several E1
CSU/DSUs that offer complete flexibility for connection of
various data sources to E1 or FE1 facilities. This family of
ESU products includes the following:
•ESU LT - E1 CSU/DSUs with a single Nx56K/64K serial
port.
•ESU 120e - Same as the ESU LT with the added feature of
a G.703 drop port and a slot in the rear panel to house an
option module. Each module offers up to four additional
data ports.
Figure 1-1. ESU LT Unit
PWRTEST
ALM
ERR
TD CS
RS
RD
CANCEL
ENTER
ESU LT

Chapter 1. Introduction
18 ESU LT User Manual 61200410L1-1B
The ESU LT serves as the link between user data sources such
as local area network (LAN) bridges and routers, computers,
CAD systems, and teleconferencing equipment. The amount
of bandwidth allocated to the port is user-programmable.
The data terminal equipment (DTE) data can occupy
contiguous or alternate channels in the E1 stream, and the
channels may start at any position.
ESU LT Features
• An E1 interface and an Nx56/64 DTE serial interface port.
• Easy configuration capabilities using simplistic menus
displayed in a liquid crystal display (LCD) window oper-
ated by a front panel keypad.
• Data port supports V.35, EIA-530, V.36 and X.21 electrical
interfaces.
• Selectable timing from the network, the Nx56/64 DTE
port, or internally.
• All ones, all zeros, 511, QRSS, and 1:8 test patterns.
• Extensive self-testing and monitoring ensures proper op-
eration.
• Flexible channel allocation (any starting channel and al-
ternate or contiguous).
• Remote management via 8K inband channel or 64K
dedicated TS0 (using T-Watch as the network manager).

Chapter 1. Introduction
61200410L1-1B ESU LT User Manual 19
ESU LT CONFIGURATION APPLICATION
The following example illustrates a possible ESU LT
application.
Bridge/Router Application
A bridge or router can be interfaced to the network by
using the DTE interface. The bandwidth used is
programmable at Nx56 or Nx64 data rates for E1 or FE1
service. The bandwidth can be selected as contiguous or
alternate. Figure 1-2 shows a simple bridge application.
Figure 1-2. Simple Bridge Application on an E1 or FE1 Circuit
High-speed
serial interface
ESU LT ESU LT
Bridge Router Nx56/64
E1
Nx56/64 Bridge Router
High-speed
serial interface

Chapter 1. Introduction
20 ESU LT User Manual 61200410L1-1B
