ADTRAN NetVantaE1/FE1 User manual

NetVanta E1/FE1 + G.703 Drop Network Interface Module (NIM) P/N 1200878L1
For more detailed documentation, visit us online at www.adtran.com.
Quick Start Guide
®
Quick Start Guide, 61200878L1-13C, March 2005 ADTRAN Technical Support [phone] Copyright © 2005 ADTRAN, All Rights Reserved
SPECIFICATIONS
Operating Modes E1/FE1 Frame Relay, E1/FE1 PPP
E1/FE1 Interface Line Rate: 2.048 Mbps ±50 PPM
Line Code: AMI or HDB3
Framing: FAS with optional CRC-4
FE1 Line Rate: Timeslot, channelized (in multiples of
56/64 kbps)
Receiver Sensitivity: -30 dB
Connector: RJ-48C
G.703 Interface Line Interface: Per ITU-T G.703
Receiver Sensitivity: -30 dB
Line Rate: 2.048 Mbps, ±50 PPM
Capacity: 1 to 31 timeslots
If timeslot 16 signaling is used on the drop port, a maximum
of 15 timeslots can be mapped to router (1 to 15 or 17 to 31).
Line Code: AMI or HDB3
Framing: FAS with Optional CRC-4
Connector: RJ-48C
Clock Source Network, Internal, and Through
Diagnostics Test Pattern Generation and Detection: QRSS, 511
Network loopbacks
Alarm generation and detection
Network performance data (15 minutes and 24 hours)
Standards FCC Part 15 Class A, EN 55022 Class A, EN 55024,
EN 61000-3-2, EN 61000-3-3
ACIF S016, ETSI TBR 12/TBR 13
EN60950, AS/NZS 60950, IEC 60950
ITU G.703, ITU-T G.704 (CRC-4), ITU-T G.823,
ITU-T G.797
Physical Dimensions: 2.75 inch W x 4.25 inch D
Operating Temperature: 0°C to 50°C
Storage Temperature: -40°C to 85°C
Relative Humidity: Up to 95 percent, noncondensing
WAN-E1 G.703 DBU
INSTALLATION INSTRUCTIONS
1. Remove power from the unit.
2. Slide the Network Interface Module (NIM) into the option slot
until the NIM is firmly seated against the front of the chassis.
3. Secure the pins at both edges of the NIM.
4. Connect the cables to the associated device(s).
5. Complete the installation of the base unit.
6. Restore power to the unit.
WAN-E1 NETWORK (RJ-48C) CONNECTION PINOUT
Pin Name Description
1 R1 Receive data from the network
2 T1 Receive data from the network
3 — Unused
4 R Transmit data toward the network
5 T Transmit data toward the network
6-8 — Unused
G.703 (RJ-48C) CONNECTION PINOUT
Pin Name Description
1 R Transmit data toward the DTE
2 T Transmit data toward the DTE
3 — Unused
4 R1 Receive data from the DTE
5 T1 Receive data from the DTE
6-8 — Unused
NetVanta modules should be installed only in
NetVanta Series products.

NetVanta E1/FE1 + G.703 Drop Network Interface Module (NIM) P/N 1200878L1
For more detailed documentation, visit us online at www.adtran.com.
Quick Start Guide
®
Quick Start Guide, 61200878L1-13C, March 2005 ADTRAN Technical Support [phone] Copyright © 2005 ADTRAN, All Rights Reserved
loopback remote v54
Initiates an E1 remote loopback test (with a V54 loopback pattern). Deactivate using
the no loopback remote v54 command.
remote-alarm [rai* | ais]
Selects the alarm signaling type to be sent when a loss of frame is detected on the
E1 receive signal.
rai* Specifies Remote Alarm Indication.
ais Specifies Alarm Indication Signal.
remote-loopback
Enables acceptance of remote loopback requests on this E1 interface. Deny
acceptance using the no remote-loopback command. This setting is enabled by
default.
sa4tx-bit [0 | 1*]
Assigns a value to the Tx spare bit in position 4.
show test-pattern
Shows current test pattern error count.
shutdown
Turns off the interface. The no version of this command turns the interface on and
allows it to pass data.
snmp trap link-status
Enables the unit interface to send SNMP traps when there is an interface status
change and controls the SNMP variable, ifLinkUpDownTrapEnable.
tdm-group <group#> timeslots <DS0 range> speed [56 | 64*]
Creates a group of contiguous DS0s on this interface to be used during the cross-
connect process.
<group#> Identifies this TDM group using a number label.
<DS0 range> Identifies DS0s in this group in the form: <starting DS0 -
ending DS0>. Valid range is 1 through 31.
56 | 64* Optional. Specifies a channel rate of 56 kbps or 64 kbps.
test pattern [clear | insert | ones | p511 | qrss | zeros]
Initiates sending the specified test pattern.
clear Clears the test pattern error count.
insert Inserts an error into currently active test pattern.
ones Generates a pattern of continuous ones.
p511 Generates a repeating pattern of ones and zeros.
qrss Generates a random test pattern.
zeros Generates a pattern of continuous zeros.
ts16
Enables timeslot 16 multiframe to be checked on the receive signal.
* Indicates default values.
DBU CONNECTION PINOUT
Pin Name Description
1-2 — Unused
3 R1 Network-Ring1
4 R Network-Ring
5TNetwork-Tip
6 T1 Network-Tip1
7-8 — Unused
An optional Dial Backup Interface Module (DIM) is
required for dial backup applications.
E1/FE1 + G.703 NIM COMMANDS
clock source [line* | internal | through]
Configures the source timing used for the interface.
line* Recovers clock from the E1 circuit.
internal Provides clocking using the internal oscillator.
through Recovers clock from the circuit connected
to the G.703 interface.
coding [ami | hdb3*]
Configures the line coding for the E1 or G.703 physical interface. This setting must
match the line coding supplied on the circuit by the service provider.
ami Specifies Alternate Mark Inversion.
hdb3* Specifies High-Density Bipolar 3.
framing [crc4]
Configures the framing format of the E1 interface.
crc4 Enables CRC-4 framing.
loop-alarm-detect
Enables detection of loop alarms on the E1 interface. Use the no form of this
command to disable loop alarm detection. This setting is enabled by default.
loopback network [line | payload]
Initiates a loopback on the interface toward the network. Deactivate using the no
loopback network command.
line Initiates a metallic loopback of the physical E1 network
interface.
payload Initiates a loopback of the E1 framer (CSU portion) of the
E1 network interface.
