TOTAL ACCESS®MX2800 POWER SUPPLY UNIT
JOBAID
PSU
CLEI: L1 M3PQ0A4B_ _
L2 M3PQ0A5B_ _
DESCRIPTION
The MX2800 Power Supply Unit (PSU) is a plug-in unit for the MX2800 chassis that
provides the necessary voltages required to operate the MX2800 and accessories such as
the fan faceplate. The DC version is P/N 1202289L2 and the AC version is P/N
1202289L1. With two cards installed, the MX2800 can recover from power supply unit or
power source failure, depending on configuration. There are three possible
configurations and modes of operation.
Non-Redundant Power Mode
This mode offers no backup protection, but only requires one source of power and one
PSU.
Power Supply Recovery Mode
This mode offers backup protection in the event of power supply card failure. This
configuration uses a primary and a backup PSU, but only utilizes one source of power.
In this mode, the MX2800 can continue operation in the event of a power supply unit
failure, without interrupting service.
Power Supply and Source Recovery Mode
This mode offers a backup system for both card and source failure. In this mode, two
power supply units are installed and are connected to two individual power sources.
This allows the MX2800 to handle any combination of power source or power supply
failure. The MX2800 is able to internally re-route the power source if a power supply
card and the opposite power source fail.
Features of this unit include:
■Receives unregulated power input
■Faceplate status LEDs
■Provision free plug-and-play
■Hot-swappable
■Meets the requirements for NEBS Level 3
■
Accessory plug for fan faceplate
TURNUP STEPS
Unpack the MX2800 Power Supply Unit and inspect for damage. If damage is
apparent, refer to your carrier or supplier for remedy.
Note: To prevent ESD events when handling this equipment, all personnel should utilize
ESD shoes or wrist straps, or an ESD flooring must be present.
Remove faceplate and insert MX2800 PSU into one of the PSU slots. To insert,
hold the unit by the front edge while supporting the sides. Align the card edges
to the guide grooves in the designated PSU slot. Insert into chassis until the
edge connector seats firmly into the backplane. Lock the unit in place by
pushing in on the locking lever.
Verify that PWR (power) LED is active.
LED DESCRIPTIONS
The MX2800 PSU has LED status indicators. The LEDs provided are PWR (power)
and CHK (check). The power LED is active when the unit is on and receiving full
power. The check LED is active when the power supply is failing or is providing
low power and needs to be checked.
COMPLIANCE CODES
This product is intended for installation in equipment providing a Type “B” or “E”
enclosure, and in a restricted access location.
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Changes or modifications not expressly approved by ADTRAN could void the
user’s authority to operate this equipment.
WARRANTY
Warranty for Carrier Networks products manufactured by ADTRAN and supplied
under Buyer’s order for use in the U.S. is ten (10) years. For a complete faxback
copy of ADTRAN’s U.S. and Canada Carrier Networks Equipment Warranty:
[phone], Document #414.
C A U T I O NC A U T I O N !
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY.
HANDLING PRECAUTIONS REQUIRED.
Code Input Output
Power Code (PC) F C
Telecommunication Code (TC) – –
Installation Code (IC) A –
1
2
3
PRICING AND AVAILABILITY 800.827.0807
TECHNICAL SUPPORT 800.726.8663
RETURN FOR REPAIR 256.963.8722
61202289L2-22A 0112
