Advantech MIC-7 Series Installation and operation manual

MIC-75M10 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
1. MIC-75M10 i-Module x1 P/N: MIC-75M10-00A1/
MIC-75M10-00A2
2. MIC-75M10 Startup Manual x1 P/N: 20415M1000
3. Mounting bracket (I-type) x1 P/N: 1960070543T00A
4. Mounting bracket (C-Type) x1 P/N: 1960070545N006
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF le.
Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
MIC-75M10
PCIE Expansion Module for MIC-7 Series Embedded
System
Startup Manual
PCIe Slots
• One PCIe x16 socket
Note 1: PCIe x16 power consumes 75W.
Environment
• Operating Temperature: -20 ~ 60° C with 0.7 m/sec air ow
• Storage Temperature: - 40 ~ 85° C (-40 ~185° F)
• Relative Humidity: 95% @ 40° C (non-condensing)
Mechanical
• i-Module Dimensions (H x W x D): 24 x 192 x 230 mm
• With MIC-7 series (H x W x D): 97 x 192 x 230 mm
Note: Width will be increased by 4mm with MIC-77xx.
The table below lists the functions of each of the connectors.
PCIE x16 Socket FAN Conn
12V Extra Power
Connectors
No. Item Function
1 PPCIE1 PCIEx16 Socket
2 DC12VOUT1 4 Pin Power Connector (12V)
3 SYSFAN1 4 Pin FAN connector
SpecicationsPacking List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/
default.aspx
This manual is for the MIC-75M10 Rev. A1.
Part No. 20415M1000
Printed in China
1st Edition
April 2022
Jumpers and Connectors

2 MIC-75M10 Startup Manual
4. Align MIC-75M10 and MIC-7 and secure 4 x screws.
5. Reassmble the cover and secure with screws.
Note: The chassis cover has a special notch which
must mate with the hook on the chassis.
Chassis Cover
Chassis hook
Chengyang.Hsu
3/22/2022
James.Chen
3/22/2022
James Chen
3/22/2022
Chengyang.Hsu
3/22/2022
Zone Mark Description
Date
Sign
A
B
D
E
F
G
H
I
J
K
L
M
N
123456 7 8 9 10 11 12 13 14 15 16 17 18 19 20
A
B
C
D
E
F
G
H
I
J
K
L
M
N
123456 7 8 9 10 11 12 13 14 15 16 17 18 19 20
C
0.20
D
0.20
P1
0.05
SIZE UNITS
mm
SHEET
2 Of 2
A0
APPROVED
DESIGNER
CHECKED
DRAWER
SCALE
D
THIRD ANGLE
PROJECTION
0.25
0.30
0.40
0.60
D=3L/1000
0.50
0.20
(Max)
1:1
S2S1
M2
0.10
0.40
L
0.70
0.40
0.15
0.25
0.20
0.30
0.25
0.50
0.80
1.0
0.50 0.35 0.60
1.10
0.25
0.30
0.45
0.20
0.10 0.15
M1
DIMENSIONAL
TOLERANCES
0.10
0.15
0.15
0.30
0.20
ANGLE
6~29.99
30~79.99
80~179.99
180~314.99
315~800
0.05 0~5.99
90
Other 1.5
0.60
1.00
P2
0.15
0.10
0.40
0.50
TOLERANCES
DESCRIPTION/PART NAME
MATERIAL
FINISHING
PART NO.
DRAWER
CHECKED
DESIGNER
APPROVED
REV.
MIC-75M10
MODEL NAME
P/N ADDED CODE
00-SYSTEM_ASSY_MIC-75M10
FILE NAME
INTERIOR
PART
APPEARANCE
PART
System Installation
MIC-7 series i-module can be assembled with all MIC-7
series IPC systems.
1. Undo MIC-7 series system screws and remove the
bottom cover.
1
1
1
1
2
2. Undo the 6 x screws of MIC-75M10.
3. Remove i-door cover on system bottom and assemble
and secure cover into i-module’s bottom cover.
3
3
Chengyang.Hsu
3/22/2022
James.Chen
3/22/2022
James Chen
3/22/2022
Chengyang.Hsu
3/22/2022
Zone Mark Description
Date
Sign
A
B
D
E
F
G
H
I
J
K
L
M
N
123456 7 8 9 10 11 12 13 14 15 16 17 18 19 20
A
B
C
D
E
F
G
H
I
J
K
L
M
N
123456 7 8 9 10 11 12 13 14 15 16 17 18 19 20
C
0.20
D
0.20
P1
0.05
SIZE UNITS
mm
SHEET
2 Of 2
A0
APPROVED
DESIGNER
CHECKED
DRAWER
SCALE
D
THIRD ANGLE
PROJECTION
0.25
0.30
0.40
0.60
D=3L/1000
0.50
0.20
(Max)
1:1
S2S1
M2
0.10
0.40
L
0.70
0.40
0.15
0.25
0.20
0.30
0.25
0.50
0.80
1.0
0.50 0.35 0.60
1.10
0.25
0.30
0.45
0.20
0.10 0.15
M1
DIMENSIONAL
TOLERANCES
0.10
0.15
0.15
0.30
0.20
ANGLE
6~29.99
30~79.99
80~179.99
180~314.99
315~800
0.05 0~5.99
90
Other 1.5
0.60
1.00
P2
0.15
0.10
0.40
0.50
TOLERANCES
DESCRIPTION/PART NAME
MATERIAL
FINISHING
PART NO.
DRAWER
CHECKED
DESIGNER
APPROVED
REV.
MIC-75M10
MODEL NAME
P/N ADDED CODE
00-SYSTEM_ASSY_MIC-75M10
FILE NAME
INTERIOR
PART
APPEARANCE
PART
Simple Maintenace Process (Cont.) Simple Maintenace Process

MIC-75M10 Startup Manual 3
Chengyang.Hsu
3/22/2022
James.Chen
3/22/2022
James Chen
3/22/2022
Chengyang.Hsu
3/22/2022
101
192
197.20
235.20
230
Zone Mark Description
Date
Sign
A
B
D
E
F
G
H
I
J
K
L
M
N
123456 7 8 9 10 11 12 13 14 15 16 17 18 19 20
A
B
C
D
E
F
G
H
I
J
K
L
M
N
123456 7 8 9 10 11 12 13 14 15 16 17 18 19 20
C
0.20
D
0.20
P1
0.05
SIZE UNITS
mm
SHEET
1 Of 1
A0
APPROVED
DESIGNER
CHECKED
DRAWER
SCALE
D
THIRD ANGLE
PROJECTION
0.25
0.30
0.40
0.60
D=3L/1000
0.50
0.20
(Max)
1:1
S2S1
M2
0.10
0.40
L
0.70
0.40
0.15
0.25
0.20
0.30
0.25
0.50
0.80
1.0
0.50 0.35 0.60
1.10
0.25
0.30
0.45
0.20
0.10 0.15
M1
DIMENSIONAL
TOLERANCES
0.10
0.15
0.15
0.30
0.20
ANGLE
6~29.99
30~79.99
80~179.99
180~314.99
315~800
0.05 0~5.99
90
Other 1.5
0.60
1.00
P2
0.15
0.10
0.40
0.50
TOLERANCES
DESCRIPTION/PART NAME
MATERIAL
FINISHING
PART NO.
DRAWER
CHECKED
DESIGNER
APPROVED
REV.
MIC-75M10
MODEL NAME
P/N ADDED CODE
00-SYSTEM_ASSY_MIC-75M10
FILE NAME
INTERIOR
PART
APPEARANCE
PART
PCIE x16 Socket FAN Conn
12V Extra Power
IO Connectors
System Dimensions

MIC-75M10 快速入门手册 1
安装系统之前，用户需确认包装中含有下面所列各项：
1. MIC-75M10 i-Module x 1 P/N：MIC-75M10-00A1/
MIC-75M10-00A2
2. MIC-75M10 快速入门手册 x 1 P/N：P/N:20415M1000
3. 安装支架（I-type）x1 P/N: 1960070543T00A
4. 安装支架（C-type）x1 P/N: 1960070545N006
如果其中任何一项缺失或损坏，请立即与经销商或销售代
表联系。
注: 阅读PDF文件需要使用Acrobat Reader。用户可从
以下路径下载Acrobat Reader：get. adobe.com/
reader (Acrobat is a trademark of Adobe)
MIC-75M10
适用于 MIC-7 系列嵌入式系统的 PCIE 扩展模块
快速入门手册
PCIe插槽
• 1 个 PCIex16 插槽
注 1：PCIEx16 功耗为 75 W。
环境规格
• 工作温度： -20 ~ 60°C，0.7 m/sec 气流
• 储存温度：- 40 ~ 85°C (-40 ~ 185°F)
• 相对湿度：95% @ 40°C（非凝结）
物理规格
• 模块尺寸 (H x W x D): 24 x 192 x 230 mm
• 加上 MIC-7 系列后的尺寸(H x W x D): 97 x 192 x 230 mm
注：MIC-77xx 的宽度增大 4mm 。
下表为每个跳线和接口的功能列表。
接口
编号 标签 功能
1PPCIE1 PCIEx16 插槽
2 DC12VOUT1 4 针电源接口 (12V)
3SYSFAN1 4 针 FAN 接口
PCIE x16 Socket FAN Conn
12V Extra Power
产品规格 包装清单
如需了解有关本产品及研华其它产品的详细信息，请访
问研华网站：
http://www.advantech.com.cn
http://www.advantech.com.cn/eplatform
如需技术支持与服务，请访问研华网站：
http://support.advantech.com.cn/support/default.
aspx
本手册适用于 MIC-75M10 系列 Rev. A1。
料号：20415M1000
中国印刷
第一版
2022年4月
跳线和接口

2 MIC-75M10 快速入门手册
4. 将 MIC-75M10 安装至 MIC-7 系统，并用 4 颗螺丝固
定。
5. 放回底盖并用螺丝固定。
注： 机箱盖上设计了一个凹口，安装时必须扣住机箱
上的挂钩。
Chassis Cover
Chassis hook
