Advantech UNO-2050 User manual

UNO-2050
GX1-300UniversalNetworkController
with 2 x LAN, 2 x RS-232, 2 x isolated
RS-232/422/485,16 xisolated DI/O
User’s Manual

Copyright notice
This document is copyrighted, 2002, by Advantech Co., Ltd. All rights
are reserved. The original manufacturer reserves the right to make
improvements to the products described in this manual at any time
without notice.
No part of this manual may be reproduced, copied, translated or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, nor for any
infringements upon the rights of third parties which may result from
such use.
Acknowledgements
IBM, PC/AT, PS/2 and VGA are trademarks of International Business
Machines Corporation.
Intel®and Pentium®are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of
Microsoft Corp.
C&T is a trademark of Chips and Technologies, Inc.
All other product names or trademarks are properties of their respec-
tive owners.
PartNo.2003205000
1st Edition Printed in Taiwan Sep. 2002

Product warranty
Advantech warrants to you, the original purchaser, that each of its
products will be free from defects in materials and workmanship for
one year from the date of purchase.
This warranty does not apply to any products that have been repaired
or altered by persons other than repair personnel authorized by
Advantech, or which have been subject to misuse, abuse, accident or
improper installation. Advantech assumes no liability under the terms
of this warranty as a consequence of such events.
Because of Advantech high quality-control standards and rigorous
testing, most of our customers never need to use our repair service. If
an Advantech product is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you
will be billed according to the cost of replacement materials, service
time and freight. Please consult your dealer for more details. If you
think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For
example, CPU speed, Advantech products used, other hardware and
software used, etc.) Note anything abnormal and list any on-screen
messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual,
product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return
merchandize authorization) number from your dealer. This allows us
to process your return more quickly.
4. Carefully pack the defective product, a fully completed Repair and
Replacement Order Card and a photocopy proof of purchase date
(such as your sales receipt) in a shippable container. A product
returned without proof of the purchase date is not eligible for
warranty service.
5. Write the RMA number visibly on the outside of the package and
ship it prepaid to your dealer.

Technical support and sales assistance
If you have any technical questions about the UNO-2050 or any other
Advantech products, please visit our support website at:
http://www.advantech.com/support
For more information about Advantech’s products and sales informa-
tion, please visit:
http://www.advantech.com

Contents
Chaper 1 Overview ..................................................... 1
1.1 Introduction....................................................................... 2
1.2 Hardware Specifications.................................................. 3
1.3 Safety Precautions ............................................................ 6
1.4 UNO-2050 Series............................................................. 7
1.5 Chassis Dimensions......................................................... 8
Chaper 2 Hardware Functionality ............................. 9
2.1 UNO-2050 Peripherals.................................................. 10
2.2 COM1 ~ COM2: RS-232 Interfaces........................... 10
2.3 COM3 ~ COM4:
Isolated 5-wire RS-232/422/485 Interfaces ............... 11
2.4 On-board Isolated Digital Input................................... 12
2.5 On-board Isolated Digital Output................................ 16
2.6 On-board Isolated Counter/Timer .............................. 18
2.7 LAN: Ethernet Connector............................................ 24
2.8 Power Connector............................................................ 24
2.9 LED Indicators ............................................................... 24
2.10 PS/2 Keyboard and Mouse Connector ....................... 24
2.11 VGA: VGA Display Connector..................................... 25
2.12 Programmable LED and Buzzer for
System Diagnosis ........................................................... 25
2.13 RESET: Reset Button ................................................... 26
Chaper 3 Initial Setup ............................................... 27
3.1 Insert CompactFlash Card ........................................... 28
3.2 Chassis Grounding......................................................... 28
3.3 Connect the Power......................................................... 29

3.4 Plug-in Screw Terminal Block Field
Wiring Considerations................................................... 29
3.5 BIOS Setup and System Assignments........................ 30
3.6 HDD Extension Flexibility .......................................... 30
Appendix A Pin Assignments ................................... 31
A.1 Board Connector and Jumpers.................................... 32
A.2 Standard RS-232 Serial Port (COM1 ~ C0M2)......... 34
A.3 Isolated 5-wire RS-232/422/485 Serial Port
(COM3 ~ COM4) .......................................................... 35
A.4 Ethernet RJ-45 Connector (LAN1~LAN2) ............... 38
A.5 Phoenix Power Connector (CN3) ................................ 39
A.6 PS/2 Keyboard and Mouse Connector (KM1).......... 39
A.7 VGA Display Connector (VGA1) ................................. 40
A.8 CompactFlashTM Master/Slave Jumper Setting
(JP2) ................................................................................. 41
A.9 Enhanced IDE connctor (CN2) .................................... 42
A.10 LCD connector (CN7, Reserved) ............................... 43
A.11 UNO-2050 Control Register........................................ 45

Figures
Figure 1-1: Chassis dimensions................................................................8
Figure 2-1: UNO-2050 front panel ............................................................10
Figure 2-2: UNO-2050 rear panel .............................................................10
Figure 2-3: Digital input connector pin assignments ...............................12
Figure 2-4: Isolated digital input connection.............................................13
Figure 2-5: Digital output connector pin assignments .............................16
Figure 2-6: Isolated digital output connection ..........................................17
Figure 2-7: Counter 0 function block.........................................................19
Figure 2-8: Counter 1 function block.........................................................20
Figure 2-9: 32-bit Counter function block..................................................20
Figure 3-1: Chassis Grounding connection .............................................28
Figure A-1: UNO-2050 connector and jumper locations (Top View) ........32
Figure A-2: UNO-2050 connector and jumper locations (Bottom View) ..32
Figure A-3: RS-485 Wiring topology..........................................................38

Tables
Table 2-1: Serial ports default setting...................................................... 11
Table 2-2: Digital input connector signal description..............................12
Table 2-3: Interrupt control register bit map ............................................14
Table 2-4: Interrupt disable/enable control bit values .............................15
Table 2-5: Interrupt triggering edge control bit values.............................15
Table 2-6: Interrupt flag bit values............................................................15
Table 2-7: Digital output connector signal description ...........................16
Table 2-8: JP12 Digital output power on configuration ...........................17
Table 2-9: Counter/Timer control register bit map ..................................18
Table 2-10 Counter clock source control bit.............................................21
Table 2-11 Counter internal clock control bit ............................................21
Table 2-12 Counter gate source control bit ..............................................22
Table 2-13 Counter output destination .....................................................22
Table 2-14: Counter interrupt flag control bit .............................................23
Table 2-15: 32-bit counter control bit .........................................................23
Table 2-16: LED and Buzzer control register bit map................................25
Table 2-17: Programmable LED control bit...............................................26
Table 2-18: Programmable Buzzer control bit ...........................................26
Table A-1: UNO-2050 connectors and jumpers......................................33
Table A-2: RS-232 serial port pin assignments......................................34
Table A-3 Isolated 5-wire RS-232/422/485 serial port
pin assignments.....................................................................35
Table A-4: Jumpers to select 5-wire RS-232/422/485 ............................35
Table A-5: RS-485 auto flow control mode and RS-422 master/slave
mode selection .......................................................................36
Table A-6: JP7 RS-422/485 terminal resistor setting..............................37
Table A-7: Ethernet RJ-45 connector pin assignments ..........................38
Table A-8: Phoenix power connector pin assignments ..........................39
Table A-9: Keyboard and Mouse connector pin assignments................39
Table A-10: VGA adaptor cable pin assignments .....................................40
Table A-11: IDE hard drive connector ........................................................42
Table A-12: LCD connector ........................................................................43
Table A-13: UNO-2050 control register .....................................................45

UNO-2050
Overview
This chapter gives background informa-
tion on the UNO-2050. It shows you the
UNO-2050overview and specifications.
Sections include:
•Introduction
•Hardware Specifications
•Safety Precautions
•UNO-2050Series
•Chassis Dimension
1
CHAPTER

2UNO-2050 User's Manual
1.1 Introduction
Are you looking forward to a suitable embedded Application Ready
Platform (ARP) that could shorten your development time and offer
rich networking interfaces to fulfill your extensive needs in different
kind of projects? Advantech Universal Network Controller (UNO-2000
series) is your ANSWER concentrating the services on Network-
enabled Application Ready Platform total solution.
Leveraging field-approved and worldwide-awareness real-time OS
technology, Advantech UNO-2000 series provides Windows CE .NET
ready solution and support several standard networking interfaces,
such as Ethernet, Wireless LAN, RS-232/422/485 and so on. Because
of its openness, great expansion capability and reliable design –
fanless and diskless, Advantech UNO-2000 series becomes an ideal
embedded platform to implement custom applications in diversified
applications.

Chapter 1 UNO-2050 Overview 3
1.2 Hardware Specifications
CPU:NSGeodeGX1-300MHz
Chipset:NSCS5530A
BIOS:AWARD256 KB FLASHBIOS
RAM:64/128 MBSDRAM onboard
VGA:Supports VGAand VESA
- Displaymemory: 1 ~ 4MB share memory, set inBIOS
- CRT display mode: Non-interlaced CRT monitors resolutions up to
1280x 1024 @256 colorsor 1024x768 @16 bpp
- DB-15VGA connector
Serial Port: Two standard RS-232 ports
- Data bits: 5, 6, 7, 8
- Stop bits: 1, 1.5, 2
- Parity: none, even, odd
- Speed:50 ~ 115.2 Kbps
- Datasignals:TxD,RxD, RTS,CTS, DTR,DSR,DCD,RI,GND
- Max data distance: 50 feet (15.2 meters)
Serialport:2x5-wire RS-232/422/485
- Automatic RS-485 data flow control
- 2000 VDC surge protection and 1500 VDC isolation
- Stop bits: 1, 1.5, 2
- Parity: non, even, odd
-RS-232 Speed:50 ~230.4 Kbps
-RS-422/485 speed:50 ~921.6 Kbps
-5-wireRS-232 data signals:TxD,RxD, RTS, CTS,GND
-RS-422datasignals:TxD+,TxD-,RxD+,RxD-, GND

4UNO-2050 User's Manual
- RS-485data signals: DATA+, DATA-, GND
- RS-232max datadistance: 50 feet(15.2 meters)
- RS-422/485max datadistance: 4000feet (1200 meters)
- Plug-inscrew-terminal block: Accepts 0.5mm2to 2.5mm2, 1 - #12 or
2 - #14 to #22 AWG
EthernetPort:Dual 10/100Base-TEthernet
- LAN chip: Realtek 8139C chipset supports
- LED on the front side
8-chisolateddigitalinput:(DI0~DI7)
- 2,000 VDC isolation, 2000 VDC ESDprotection and 70 VDC over-voltage
protection
- 0 ~ 50 VDC input range and 10 KHz speed
- Input Voltage
- Logic0: 0~ 3VDC
- Logic1: 10 ~50 VDC
- Input Current
- 10VDC:1.7 mA(typical)
- 12VDC:2.1 mA(typical)
- 24VDC:4.4 mA(typical)
- 48VDC:9.0 mA(typical)
- 50VDC:9.4 mA(typical)
- Interrupt handling capability
- Plug-inscrew-terminal block: Accepts 0.5mm2to 2.5mm2, 1 - #12 or
2 - #14 to #22 AWG
8-chisolateddigital output:(DO0 ~DO7)
- 2,000 VDC isolation and 200 mA max / channel sink current
- Keep output status after system hot reset
- 5 ~ 40 VDC output range and 10 KHz speed
- Plug-inscrew-terminal block: Accepts 0.5mm2to 2.5mm2, 1 - #12 or
2 - #14 to #22 AWG

Chapter 1 UNO-2050 Overview 5
Two16-bitcounters/timers:
- Counter source: DI6 & DI7, Pulse output: DO6 & DO7
- Can be cascaded as one 32-bit counter/timer
- Down counting, Preset counting value
- Interrupt handling, speed: 40 KHz
- Timertimebase:100 KHz, 10KHz,1KHz, 100 Hz
SSD: One Type I / Type II CompactFlashTM card slot inside the chassis
HDD:Offer HDD extension kit for installation of one standard 2.5"
HDD.
LED:One powerLED, oneIDE LED,one programmable LED and one
programmablebuzzer
Keyboard/Mouseconnector: Mini-DIN connector supportsPS/2
keyboard and a PS/2 mouse
Powersupply voltage: 9 ~ 36 VDC ,reversed wiring protection
PowerConsumption: 0.6A maxunder +24V powerinputor 1.2A max.
under +12 V power input
PowerRequirement: 1A typical under +24V power input or1.5 A
typical under +12 V power input
Operatingtemperature:-10~ 55°C (14~131°F)
Chassissize:164.8 mm(W)x106.5 mm(L)x35.5 mm (H)(6.5"x4.2" x
1.4")
Weight:0.8 kg

6UNO-2050 User's Manual
1.3 Safety Precautions
The following sections tell how to make each connection. In most
cases, you will simply need to connect a standard cable. All of the
connector pin assignments are shown in Appendix A.
Warning! Alwaysdisconnect the power cord from your chassis
wheneveryou areworkingon it.Do not connectwhile
thepower is on. Asudden rush of powercandamage
sensitiveelectronic components.Only experienced
electronics personnel should open the chassis.
Caution! Alwaysground yourself toremoveany static electric
chargebefore touchingUNO-2050. Modernelectronic
devices are very sensitive to static electric charges.
Use a grounding wrist strap at all times. Place all
electronic components on a static-dissipative surface
or in a static-shielded bag..

Chapter 1 UNO-2050 Overview 7
1.4 UNO-2050 Series
There are two products in UNO-2050 series listed as below:
•UNO-2050:UNO-2050 hardwareplatform
•UNO-2050CE:UNO-2050 hardwareplatform with Windows CEOS
(built in 32MB CompactFlashTM card)
Packing list
Before installing your board, make sure that the following materials
have been received:
Commonparts:
•Warranty certificate
•SoftwareSupporting CD-ROM
•6P-6P-6P20cm KB andPS/2 MouseY cable(P/N:1700060202)
•Plug-inBlock2PFemale (P/N1652002205)
•DIN-railmountingaccessory(1997001110,1997001120, 1997001130,
1997001140)
ForUNO-2050CEonly:
•Built in 32 MB CompactFlashTM card with Microsoft Windows CE OS
•End User License Agreement for Windows CE
If any of these items are missing or damaged, contact your distributor
or sales representative immediately.

8UNO-2050 User's Manual
1.5 Chassis Dimensions
Figure 1-1: Chassis dimensions

Hardware
Functionality
This chapter shows how to set up the
UNO-2050’s hardware functions, including
connecting peripherals, switches and
indicators.
Sections include:
•UNO-2050Peripherals
•COM1 ~COM 2:RS-232 Interfaces
•COM3 ~COM 4:Isolated 5-wireRS-232/
422/485Interfaces
•On-board Isolated Digital Input
•On-board Isolated Digital Output
•On-board Isolated Counter/Timer
•LAN: Ethernet Connector
•Power Connector
•LEDIndicators
•PS/2 Keyboard and Mouse Connector
•VGA:VGA DisplayConnector
•ProgrammableLEDand Buzzerfor
System Diagnosis
•RESET: ResetButton
2
CHAPTER

10 UNO-2050 User's Manual
2.1 UNO-2050 Peripherals
The following two figures show the connectors on UNO-2050. The
following sections give you detail information about function of each
peripheral.
Figure 2-1: UNO-2050 front panel
Figure 2-2: UNO-2050 rear panel
2.2 COM1 ~ COM2: RS-232 Interfaces
TheUNO-2050 offers two standard RS-232 serial communication
interface ports, and they are COM1 and COM2. Please refer to A.2 for
its pin assignments.

Chapter 2 Hardware Functionality 11
2.3 COM3 ~ COM4: Isolated 5-wire RS-232/
422/485 Interfaces
TheUNO-2050 offerstwo isolated5-wire RS-232/422/485serial
communication interface ports, and they are COM3 and COM4. The
connector type of COM3 and COM4 is screw-terminal block that it’s
easy for wiring without additional daughter board. Each port can be
configuredindividually to either RS-232,RS-422 or RS-485by using
on-board jumpers (see Appendix A.3), and Table 2-1 lists the default
setting of each port.
Table 2-1: Serial ports default setting
16C954 UARTs with 128-byte standard
AdvantechUNO-2050 comes standard with OxfordOX16PCI964
UARTs containing 128 bytes FIFOs. These upgraded FIFOs greatly
reduce CPU overhead and are an ideal choice for heavy multitasking
environments.
Automatic Data Flow Control Function for RS-485
In RS-485 mode, UNO-2050 automatically senses the direction of
incoming data and switches its transmission direction accordingly.
Therefore no handshaking signal (e.g. RTS signal) is necessary. This
feature lets you simply and quickly build an RS-485 network with just
two wires. More importantly, application software previously written
for half duplex RS-232 environments can be maintained without need
formodification.
IRQ and Address Setting
The IRQ and I/O address range are both assigned by BIOS. COM3,
COM4 serial ports and on-board digital I/O use the same IRQ.
COM Port Default Setting
COM3 RS-485
COM4 RS-485

12 UNO-2050 User's Manual
2.4 On-board Isolated Digital Input
The UNO-2050 has 8 isolated digital input channels designated
DI0~DI7.
Pin Assignment
The connector type of UNO-2050 is plug-in screw terminal block that
enables you to connect to field I/O devices directly without additional
accessories. Figure 2-3 and Table 2-2 shows its pin assignment as well
as signal description.
Figure 2-3: Digital input connector pin assignments
Table 2-2: Digital input connector signal description
Isolated Inputs
Each of isolated digital input channels accepts 10 ~ 50 VDC voltage
inputs, and accepts bi-directional input. It means that you can apply
positive or negative voltage to an isolated input pin (Vin). All eight
channels share one common pin (COM). Figure 2-4 shows how to
connect an external input source to one of the UNO-2050’s isolated
input channels.
Signal Name Reference Direction Description
DI <0...7> COM Input Isolated digital input signals
COM - Input External common input of DI
DI0
DI1
DI2
DI3
COM
DI4
DI5
DI6
DI7
Isoated DI
