STARTUP MANUAL
MIC-3327 Startup Manual 1
MIC-3327DC01-A43E
3U CompactPCI® Intel® Atom™ N2600 Controller
Packing List
Before you begin installing your module, please make
sure that the following materials have been shipped:
MIC-3327 Series CPU Board
Driver CD
Startup Manual
If any of these items are missing/damaged, contact
your distributor or sales representative immediately.
Overview
The MIC-3327 is a 3U CompactPCI®system
control board, with an Intel® Atom™ N2600
1.6GHz processor and highly integrated Intel®
NM10 Express chipset. It supports on board DDR3
SDRAM up to 2 GMB and dual Gigabit Ethernet.
The MIC-3327 is a powerful 3U CompactPCI
controller which can fulll your need in any mission
critical applicaitons, such as transportaiton, trafc
control, and military defense applicaitons.
User Manualtion
For detailed information on this product, refer to:
CD:MIC-3327\Manual\MIC-3327_User_Manual.pdf
Notes
For more information on this and other Advantech
products, please visit our websites at:
http://www.advantech.com
http://www.advantech.com/eAutomation
For technical support and service:
http://www.advantech.com.tw/eservice
This manual is for MIC-3327.
Part No: 2003332700 1st Edition
February 2014
Declaration of Conformity
FCC Class A
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant
to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference when the equipment is operated
in a commercial environment. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications. Operation
of this equipment in a residential area is likely to
cause interference in which case the user is required
to correct interference at his own expense.
CE
This product has passed the CE test for environmental
specifications when shielded cables are used
for external wiring. We recommend the use of
shielded cables. This kind of cable is available from
Advantech. Please contact your local representative.

2 MIC-3327 Startup Manual
Specifications
Certication: CE, FCC, Class A
CPU: Intel®Atom N2600 1.6 GHZ
BIOS: AMI UEFI 16Mbit SPI BIOS
System Chipset: Intel NM10
Memory:
–SDRAM: DDR3 800 MHz Support 2G
Graphics:
–Chipset: Intel Gfx integrated in Atom Processor
–Resolution: 1600 x 1200
Ethernet:
–Interface: 1000/100/10M Base-T Giga Ethernet
–Controller: Intel @ 82574L Ethernet Controller
–Connector: RJ-45*2 (Pins reserved on PCB
next to LAN2 for customer lead wire)
Bus:
–PCI Bus: 7 x 32 bit / 33 MHz Compact PCI
Bus Master Interface( PCIe-PCI Bridge
PERICOM
–PI7C9X110)
Serial:
–Interface: RS-232/422/485 Selectable
(COM1~COM4)
–UART: 954 compatible
–Data bits: 5, 6, 7, 8
–Stop Bits: 1, 1.5, 2
–Parity: None, Even, Odd
–Speed: 50 ~ 115.2 Kbps
–Connector: COM1 (9 PIN, DB9 Front Panel)
COM2~COM4 (5 PIN, J2)
Audio:
–Line-in (DB9: 7, 8 PIN)
–Line-out (DB9: 2, 3 PIN) (Pins reserved on
PCB next to DB9 for customer lead wire)
–MIC-in: 3.5’’ Audio Connector
SATA: 1 x SATA interface, data transfer rate up
to 300 MB/S
USB: 3 x USB 2.0 channels up to 480Mbps, 2 as
front I/O
P-IDE: 1 x CompactFlash Slot Type II
Watchdog Timer: 256 levels timer interval, from
1 to 255 sec or min setup by software
Front Panel Function(8HP):
–COM1: 1 x DB9, RS-232/422/485
–Audio: 1 x DB9, 1 x 3.5’’ Audio Connector
–Ethernet: 2 x RJ-45 Connector with LED
–VGA: 1 x 15pin D-SUB Connector
–USB: 2 x USB2.0, 4pin Connector
–Button: Reset Button
–LED: Power, HDD
Environment:
–Humidity: 5~95%(non-condensing)
–Operation Temp: -20 ~ 60°C
–Storage Temp: -40 ~ 80°C
Physical:
–Dimensions (L x H): 160 x 100 mm (3U)
–Weight: 0.8 Kg

MIC-3327 Startup Manual 3
Jumpers and Connections
Connector Description
Figure 1 -MIC-3327CB Board Connector Locations (1F)
Figure 2 -MIC-3327DAU Board Connector Locations (2F)

MIC-3327 Startup Manual 4
Connector Function Description
1F-SW1 Reset Reset Button
1F-CN1 SOM SOM Connector
1F-CN2 VGA D-Sub 15-pin (Female) on Front side panel
1F-CN4 LAN1 10/100/1000Base-T Ethernet on Front side panel
1F-CN6 USB1 USB1 Type-A Female on Front side panel.
1F-CN8 B to B Connector B to B Connector
1F-CN9 CF CF Connector
1F-CN10 USB2 USB2 Type-A Female on Front side panel
1F-J1 CPCI Connector CPCI Connector
1F-J2 CPCI Connector CPCI Connector
2F-CN2 SATA connector Serial ATA 22P connector
2F-CN3 Audio(Line in/ Line out) Audio connector
2F-CN4 MIC MIC connector
2F-CN5 COM1 DB9 connector
2F-CN6 COM1 Type Select RS-232/422/485 Selection
2F-CN8 Audio Jumper Audio(Line in/ Line out/ MIC)
2F-CN9 LAN2 Jumper 10/100/1000Base-T Ethernet
2F-CN10 LAN2 10/100/1000Base-T Ethernet on Front side panel.
2F-XYM1 B to B Connector B to B Connector
2F-SW1 COM2~COM4 COM2/COM3/COM4 Type Selection
2F-SW2 COM1~COM4 RS-422 Master/ Slave
Select
COM1/COM2/COM3/COM4 RS-422 Master/ Slave
Selection
Table 1 -MIC-3327 Connector Description

MIC-3327 Startup Manual 5
Card Installation
The CompactPCI connectors are rm and rigid, but require careful handling while plugging and unplugging.
Improper installation of a card can easily damage the backplane of the chassis.
The inject/eject handle of MIC-3327 helps you install and remove the card easily and safely. Follow the
procedure below to install the MIC-3327 into a chassis:
To install a card:
1. Hold the card vertically. Be sure that the card is pointing in the correct direction. The components of the
card should be pointing to the right.
2. Holding the lower handle, pull out the red portion in the middle of the handle to unlock it.
Caution! Keep your ngers away from the hinge to prevent them from getting pinched.
3. Insert the card into the chassis by sliding the upper and lower edges of the card into the card guide.
4. Push the card into the slot gently by sliding the card along the card guide until the handles meet the
rectangular holes of the cross rails.
Note: If the card is correctly positioned and has been slid all the way into the chassis, the handle should
match the rectangular holes. If not, remove the card from the card guide and repeat step 3 again. Do not try to
install a card by forcing it into the chassis.
5. Lift the lower handle up to push the card into place.
To remove a card:
1. Unscrew the four screws on the front panel.
2. Press the lower handle down to release the card from the backplane.
3. Slide the card out.
Figure 3 -Chassis Installation/ Removal

6 MIC-3327 Startup Manual
J1 & J2 Connectors
Pin A B C D E F
1 5V -12V TRST# +12V 5V GND
2 TCK 5V TMS TDO TDI GND
3 INTA# INTB# INTC# 5V INTD# GND
4 RSV1 GND V(I/O) INTP INTS(SERIRQ) GND
5 RSV2 RSV3 RST# GND GNT0# GND
6 REQ0# GND 3.3V CLK0 AD[31] GND
7 AD[30] AD[29] AD[28] GND AD[27] GND
8 AD[26] GND V(I/O) AD[25] AD[24] GND
9 C/BE[3] IDSEL AD[23] GND AD[22] GND
10 AD[21] GND 3.3V AD[20] AD[19] GND
11 AD[18] AD[17] AD[16] GND C/BE[2]# GND
12
13
14
15 3.3V FRAME# IRDY# GND TRDY# GND
16 DEVSEL# GND V(I/O) STOP# LOCK# GND
17 3.3V REQA# GNTA# GND PERR# GND
18 SERR# GND 3.3V PAR C/BE[1]# GND
19 3.3V AD[15] AD[14] GND AD[13] GND
20 AD[12] GND V(I/O) AD[11] AD[10] GND
21 3.3V AD[9] AD[8] M66EN C/BE[0]# GND
22 AD[7] GND 3.3V AD[6] AD[5] GND
23 3.3V AD[4] AD[3] 5V AD[2] GND
24 AD[1] 5V V(I/O) AD[0] ACK64# GND
25 5V REQ64# ENUM# 3.3V 5V GND
Table 2 -MIC-3327 J1 Connectors

MIC-3327 Startup Manual 7
Pin A B C D E F
1/26 CLK1 GND REQ1# GNT1# REQ2# GND
2/27 CLK2 CLK3 GNT2# REQ3# GND
3/28 CLK4 GND GNT3# REQ4# GNT4# GND
4/29 V(I/O) GND GND
5/30 COM2_TX+ V(I/O) GND
6/31 COM2_TX- COM2_TX COM2_RX GND COM2_CTS GND
7/32 COM2_RX+ GND V(I/O) COM2_RTS GND
8/33 COM2_RX- COM3_TX COM3_RX GND COM3_CTS GND
9/34 COM3_TX+ GND V(I/O) COM3_RTS GND
10/35 COM3_TX- COM3_RX+ COM3_RX- GND GND
11/36 COM4_TX+ GND V(I/O) GND
12/37 COM4_TX- COM4_TX COM4_RX GND COM4_CTS GND
13/38 COM4_RX+ GND V(I/O) COM4_RTS GND
14/39 COM4_RX- USB+ USB- GND GND
15/40 GND REQ5# GNT5# GND
16/41 GND GND
17/42 GND REQ6# GNT6# GND
18/43 GND GND
19/44 GND GND
20/45 CLK5 GND GND
21/46 CLK6 GND GND
22/47 GND
Table 3 -MIC-3327 J2 Connectors
