Advantech DLoG DLT-V72 Series Installation and operation manual

DLT-V72 Series
Industrial Computer
Safety Instructions / Quick Start and Installation (EN)
Sicherheitshinweise / Quick Start und Installation (DE)
安全 / 快速入门和安装 (CN)
Startup Manual

II
DLT-V72 EN: Startup Manual – Content Overview
DE: Erste Schritte – Inhaltsübersicht
CN:
入门指导
–
内容概述
IMPORTANT:
For safe and proper use, follow these instructions.
Keep them for future reference.
WICHTIG:
Für einen sicheren Gebrauch des Produkts,
diese Anleitung lesen und befolgen.
Aufbewahren für späteres Nachschlagen.
重要事项：
为确保安全和正确使用，请遵照这些说明。
请妥善保存，以供日后查阅。
English (EN)
Important Information
Page 1 - 2
Copyright / Technical support and assistance
Safety Instructions
Page 3 - 12
Introduction / Intended use / Requirement for commissioning and operating
personell / Battery pack safety / HF Radiation / Information on safe mounting
/ Information on safe electrical installation / Safety during ongoing work
operations / Regular maintenance work / Repairs and modifications /
Recycling / Regulatory information
Quick Start and Installation
Page 13 - 30
Packing list / Overview of important operating elements / External
connectors / Configuration (Front keys, radio) / Notes on the mechanical
mounting / Notes on the electrical installation / Connect cables, seal cable
passages, attach the cable cover / Integrated UPS and battery pack (optional)

III
Deutsch (DE)
Wichtige Informationen
Seite 31 - 32
Copyright / Technische Kundenunterstützung
Sicherheitshinweise
Seite 33 - 42
Einführung / Bestimmungsgemäße Verwendung / Anforderungen an das
Inbetriebnahme- und Bedienpersonal / Akkupack-
Sicherheit / Strahlenemission /
Hinweise zur sicheren Montage / Hinweise zur sicheren elektrischen Installation /
Sicherheit im laufenden Betrieb / Regelmäßige Wartung / Reparatur und Modifikationen
/ Recycling / Regulatorische Informationen
Quick Start und Installation
Seite 43 - 60
Lieferumfang / Wichtige Bedienungselemente / Externe Anschlüsse / Konfiguration
(Front-Tasten, Funk) / Hinweise zur mechanischen Montage / Hinweise zur elektrischen
Installation / Kabel anschliessen, Kabeldurchgänge adbichten, Kabelabdeckung
anbringen / Integrierte USV und Akkupack (optional)
中文（
CN
）
重要信息
页61 - 62
版权 / 技术支持
安全
页63 - 72
概述
/
按规定使用
/
调试和操作人员的资质要求
/
电池组安全
/
辐射发射 / 安全安装的相关信息 / 安全电气安装的相关信息 /
操作期间的安全事项
/
定期维护工作
/
修理和修改
/
回收
/
监管信息
快速入门和安装
页73 - 90
供货范围 /重要操作元件概览 /外部接口 /
配置（正面按钮，无线电等）/ 机械安装注意事项 /
电气安装注意事项 / 连接电缆，密封电缆通道，装上电缆盖罩 /
集成式 UPS 和电池组（可选）
Regulatory EN / DE
RED Sheet

Regional Service & Customization Centers
China: Kunshan 86-512-5777-5666 Taiwan: Taipei 886-2-2792-7818
Netherlands: Eindhoven 31-40-267-7000 Poland: Warsaw 00800-2426-8080
USA: Milpitas, CA 1-408-519-3898
Worldwide Offices
IV
Greater China
China
Toll Free 800-810-0345
Beijing 86-10-6298-4346
Shanghai 86-21-3632-1616
Shenzhen 86-755-8212-4222
Chengdu 86-28-8545-0198
Hong Kong 852-2720-5118
Taiwan
Toll Free 0800-777-111
Taipei & IoT
Campus 886-2-2792-7818
Taichung 886-4-2329-0371
Kaohsiung 886-7-229-3600
Middle East and Africa
Israel 072-2410527
Asia
Japan
Toll Free 0800-500-1055
Tokyo 81-3-6802-1021
Osaka 81-6-6267-1887
Nagoya 81-0800-500-1055
Korea
Toll Free 080-363-9494
Seoul 82-2-3663-9494
Singapore
Singapore 65-6442-1000
Malaysia
Kuala Lumpur 60-3-7725-4188
Penang 60-4-537-9188
Thailand
Bangkok 66-02-2488306-9
Vietnam
Hanoi 84-24-3399-1155
India
Bangalore 91-80-2545-0206
Pune 91-94-2260-2349
Indonesia
Jakarta 62-21-751-1939
Australia
Toll Free 1300-308-531
Melbourne 61-3-9797-0100
Europe
Germany
Toll Free 00800-2426-8080/81
Munich 49-89-12599-0
Düsseldorf 49-2103-97-855-0
France
Paris 33-1-4119-4666
Italy
Milano 39-02-9544-961
Benelux & Nordics
Breda 31-76-523-3100
UK
Newcastle 44-0-191-262-4844
London 44-0-870-493-1433
Poland
Warsaw 48-22-31-51-100
Russia
Moscow 8-800-555-01-50
St. Petersburg 8-800-555-81-20
Czech Republic
Ústí nad Orlicí
420-465-521-020
Ireland
Oranmore 353-91-792444
Americas
North America
Toll Free 1-888-576-9668
Cincinnati 1-513-742-8895
Milpitas 1-408-519-3898
Irvine 1-949-420-2500
Ottawa 1-815-434-8731
Brazil
Toll Free 0800-770-5355
São Paulo 55-11-5592-5367
Mexico
Toll Free 1-800-467-2415
Mexico City 52-55-6275-2727

1
DLT-V72 Startup Manual
P/N 20080V7241
English (EN): Important information
Copyright
This document and the software and hardware included with this product are
copyrighted 2019 by Advantech Co., Ltd. All rights are reserved.
This document is intended for reference purposes only. All product specifications
are subject to change without notice.
Advantech Co., Ltd. reserves the right to make improvements in this document in
the products described in this document at any time without notice
No part of this document may be reproduced in any form or by any means,
electronic, photocopying, recording, translating, transmitting or otherwise, without
prior written permission of Advantech Co., Ltd.
Information provided in this document is intended to be accurate and reliable.
However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any
infringements of the rights of third parties, which may result from its use.
Advantech Co., Ltd. assumes no liability for technical inaccuracies, typographic
errors or faults in this documentation. Advantech Co., Ltd. also assumes no liability
for damages caused directly or indirectly by the delivery, performance or usage of
this material.
Note regarding all links and website content included in this document:
Advantech Co., Ltd. is not responsible for the accessibility of the websites and for
the content of external links contained in this document. The content and
accessibility of the linked websites are the sole responsibility of their operators.
Acknowledgements
The software and hardware designations as well as the brand names used in this
documentation are in most cases also registered trademarks and are subject to the
international law (trademark, brand and patent-protection laws). All product names
or trademarks are properties of their respective owners.

2
Manufacturer address
Advantech Co., Ltd.
No. 1, Alley 20, Lane 26, Rueiguang Road,
Neihu District, Taipei 11491, Taiwan, R.O.C.
Technical support and assistance
Contact your distributor, sales representative, or an Advantech Service Center for
technical support.
Please have the following information ready:
−Product name
−Serial number
−Description of your peripheral attachments
−Description of your software (operating system, application software, etc.)
−A complete description of the problem
−The exact wording of any error messages
Find the contact data of our Global Advantech Service Centers on our website:
http://erma.advantech.com

3
DLT-V72 Industrial Computer
Safety Instructions (EN)
IMPORTANT:
For safe and proper use, follow these safety instructions.
Keep them for future reference.
1INTRODUCTION
WARNING
Important for your safety.
These safety instructions apply to all models in the DLT-V72 Series: For DLT-V7210 and DLT-
V7212 in various equipment levels.
Non-observance of the safety instructions can result in injury to persons and in physical damage,
e.g. due to incorrect commissioning procedures or due to maintenance work not being completed.
The manufacturer accepts no liability for damage resulting from a failure to comply with this
information.
−Read and observe these safety instructions before commissioning and using the DLT-V72.
This protects you and other persons and prevents damage to the equipment and to technical
equipment in the surrounding environment.
−Observe all other documents included with the device.
−Retain all documents and pass them on to any future owners of the equipment.
−Read and observe the “DLT-V72 Operating Instructions” available online and provided for
download from our websites:
www.advantech.com
www.advantech-service-iot.eu
On our websites you will also find the latest versions of all DLT-V72 documentation.

4
2INTENDED USE
DLT-V72 Industrial Computers are data communication terminals for use in commercial industries
such as logistics, warehousing and manufacturing. Any other or additional use beyond this is
regarded as improper use.
DLT-V72 Industrial Computers are only permitted to be operated:
−In accordance with the defined intended use.
−Within the usage limits and in accordance with the technical data.
−Observing the information in the documentation and in particular the safety and warning
notices.
DLT-V72 Industrial Computers:
−Are not approved for use in explosion-hazard areas.
−Are not approved for use on ships.
−Are not approved for use on rail vehicles.
−Are not approved for use in life-support systems or critical safety systems where system
malfunction can lead to the direct or indirect hazard of human life.
DLT-V72 Industrial Computers were designed and built according to modern technology and
accepted safety regulations. Improper use can result in injury to persons and in property damage,
however, necessitating the following:
−Correct transport, storage, commissioning and maintenance as specified
−Operation by trained personnel
The owner/operator commitments with regards to safety (accident prevention regulations,
occupational safety) must be observed.

5
3REQUIREMENT FOR COMMISSIONING AND OPERATING
PERSONNEL
Requirements for commissioning and maintenance
Work such as commissioning and maintaining the DLT-V72 is only permitted to be performed by
skilled personnel who have specialist vocational training and who have up-to-date knowledge and
experience in the area of work in question.
Examples:
−Mechanical mounting work must be performed by skilled mechanical personnel.
If the DLT-V72 is incorrectly mounted onto vehicles, for example, this can result in serious
accidents.
−Electronic work on the DLT-V72 must be performed by skilled electronics personnel; there is a
risk of electric shock when connecting to the power supply, for example.
−For the DLT-V72 with integrated uninterrupted power supply (UPS), specialist knowledge on
the handling of lithium-ion battery packs is required.
The “DLT-V72 Operating Instructions” (available online) offer comprehensive information on
commissioning the device, in particular also for use on vehicles.
Requirements for the operating personnel
Users of the DLT-V72 must be trained by skilled personnel and instructed in the operation of the
device. All users must be familiar with all functions of the product they come into contact with.

6
4BATTERY PACK SAFETY
EXPLOSION HAZARD! BATTERY PACK SAFETY NOTICE
DLT-V72 devices with integrated uninterrupted power supply (UPS) contain lithium-ion battery
packs:
Battery packs may ignite if stored or handled incorrectly (fire risk, explosion risk), and may cause
chemical burns or release poisonous substances.
−Handle the DLT-V72 and the integrated battery pack with care, and do not allow it to become
damaged, to fall or be dropped, or be short-circuited.
−Do not tamper with, disassemble or repair the battery packs.
−Observe the specified temperature range, both during storage and in the work environment.
−Do not utilize the device near sources of heat or fire, open flames or heaters.
−Do not allow water or other liquids to come into contact with the device (exercise particular
caution with corrosive liquids).
−Suitable fire extinguishers must be provided in line with safety regulations.
−If battery packs become damaged, caustic electrolyte liquid may leak out. This liquid must not
under any circumstances be permitted to come into contact with eyes, skin or clothing. On
contact with eyes or skin, rinse immediately with clear, running water and consult a doctor.
THERE IS A RISK OF EXPLOSION IF THE BATTERY PACK IS SWAPPED OUT AND
REPLACED WITH AN INCORRECT/NON-APPROVED BATTERY PACK.
This also applies to the real time clock battery installed in the DLT-V72.
Do not open the DLT-V72, and do not replace the RTC battery. EXPLOSION HAZARD.
No third-party battery packs permitted.
−Use only original battery packs from Advantech.
−If battery packs from other manufacturers are inserted in the DLT-V72, the warranty for this
device will be rendered void.
−The battery packs must be certified for the DLT-V72.
−Do not use battery packs from any other Advantech devices; they are not compatible.

7
Prevent physical damage due to deep discharge.
Storing the battery packs incorrectly will cause them to discharge completely (deep discharge)
and thus damage them irreparably.
To prevent a deep discharge:
−Remove the battery pack from the battery pocket, if the DLT-V72 is not used for a longer period
of time (more than one month).
−Charge the battery pack in the DLT-V72 device every six months.
5HF RADIATION
Only applies to devices with radio equipment: Danger of radiation.
DLT-V72 devices with radio equipment emit high frequency energy (abbreviation: HF).
To protect persons and domestic animals against HF radiation:
−Mount the DLT-V72 so that persons and domestic animals maintain a minimum distance of
20 to 50 cm from the radio antennas.
−Ensure that persons observe this minimum distance when operating the DLT-V72.
−High frequency energy can interfere with technical devices. For this reason, do not use the
DLT-V72 in the vicinity of pacemakers or other medical devices.
−Only operate the DLT-V72 with radio equipment that is approved by the manufacturer for this
device.
−Make sure that the transmission power and the radio frequency of the DLT-V72 comply with
the regulations for the respective country where the device is deployed.
−Observe all applicable regulations for your deployment location/country with regard to
operating channels, radio frequencies and the maximum permissible transmitting power.
Responsibility for this lies with the company operating the DLT-V72. The regulatory authorities
in the relevant country can provide information on this.
Any modifications to the DLT-V72 radio equipment which are not expressly approved by the party
responsible for the compliance can lead to the withdrawal of the operating license for this device.

8
6INFORMATION ON SAFE MOUNTING
During the mounting process
The DLT-V72 can fall down and cause injuries due to its weight.
−Use the assistance of a second person for installation work.
−Always hold the DLT-V72 by the housing with both hands.
−Never use the antenna cap as a handle as it may break due to the weight involved.
The strain relief rail of the DLT-V72 can have sharp edges and cause cutting injuries.
−Do not hold the DLT-V72 by the strain relief plate.
Choosing the mounting position and installation environment
−The installation height of the device shall not exceed 2 m.
−The ergonomic operability of the DLT-V72 should be taken into account when selecting the
mounting position.
−Mount the DLT-V72 in such a way that no persons can be injured if the device mounting
should break (e.g. as a result of a fatigue fracture).
−Otherwise, it is essential to adopt corresponding safety measures.
−Ensure that the installation environment is correct, as is not permitted to result in an enclosed
system because the cooling concept of the DLT-V72 requires fresh air. Without a supply of
fresh cooling air, the DLT-V72 may overheat and may be damaged beyond repair.
Specific information on vehicle mounting (forklifts, etc.)
−Mount the DLT-V72 so that the driver's field of view remains clear and safe driving operation is
guaranteed.
−During the mounting process, observe the requirements of the vehicle manufacturer relating to
attaching auxiliary devices and connecting auxiliary consumers.
−Observe all requirements relating to welding or drilling on support components of the vehicle.
−Observe the more detailed information on the mounting process given in the “DLT-V72
Operating Instructions” available online, for example on the potential conditions on vehicles,
requirements for electrically isolated mounting, etc.

9
7INFORMATION ON SAFE ELECTRICAL INSTALLATION
Danger of electric shock
−Do not put the DLT-V72 into operation if it is showing damage.
−Do not open or modify the DLT-V72.
−Only connect or disconnect electrical connections when the device is in a de-energized state.
−Use only original Advantech power supply cables; these meet the specific requirements for
low-temperature flexibility, UV resistance, oil resistance, etc.
Installing the disconnecting device
The DLT-V72 is not equipped with disconnecting devices that are accessible from the outside; it
does not have switches.
−To allow the device to be quickly disconnected from the power supply in emergency situations,
install an easily accessible disconnecting device close to the device and ensure that the
disconnecting device isolates all supply lines.
Fuses
−Only connect DLT-V72 devices to Safety Extra Low Voltage (SELV) circuits.
−The DC+ connecting cable must be protected by a fuse (30 AT max.).
−The ignition connecting cable must be protected by a fuse of the following type:
5x20 mm T 125 mA L / 250 V, for example, a Wickmann 195-125 mA / 250 V.
Power supply unit fuse blows repeatedly
If the fuse of the integrated power supply unit blows again immediately after replacement, proceed
as follows:
−Check the electrical installation.
Observe the information regarding to the potential ratios on vehicles, the requirements for an
electrically isolated mounting etc. in the „DLT-V72 Operating Instructions“ available online.
If it’s excluded that a faulty installation causes the problem:
−Send in the DLT-V72 immediately for repair.

10
8SAFETY DURING ONGOING WORK OPERATIONS
Requirements for the operating personnel
Users of the DLT-V72 must be trained by skilled personnel and instructed in the operation of the
device. All users must be familiar with all functions of the product they come into contact with.
General
−Do not use the DLT-V72 in explosion hazard areas.
−Switch off the DLT-V72 if located in the vicinity of petrol stations, fuel depots,
chemical plants, etc.
−Switch off the DLT-V72 before using the interfaces underneath the antenna.
−Switch off the DLT-V72 before replacing the battery pack.
The following applies when using the DLT-V72 on vehicles:
−The vehicle driver is not permitted to operate the DLT-V72 while driving. Operating the device
can represent a distraction from driving operations and there is an increased risk of accident.
−The DLT-V72 must be disconnected from the vehicle battery while the vehicle battery is being
charged. Or it must be ensured that the maximum permitted input voltage of the DLT-V72 is
not exceeded.

11
9REGULAR MAINTENANCE WORK
General
To avoid damage to the DLT-V72 and to ensure safe functioning:
−Depending on the load and environmental conditions, check at least once per month, and
more often if necessary, that all connected cables are secured and that the cable cover is
tightly sealed (important for IP protection against dust, etc.).
Cleaning the device
There is a danger of electric shock if live parts of the DLT-V72 are touched during cleaning.
−Switch off the DLT-V72 before cleaning.
−Disconnect from the power supply.
−Disconnect connected accessories.
−Clean the touchscreen and housing with a damp cloth and a neutral glass cleaning agent.
−Do not use any chemicals such as benzene, thinner or acidic/alkaline solutions for cleaning.
−Do not use any compressed air or high-pressure cleaning equipment.
Devices used in vehicles
DLT-V72 devices used in vehicles are subject to high loads due to vibration and shocks.
To ensure the secure fastening of the device to the vehicle, the following points must be checked
at least once a month, and where necessary more often, depending on the load and
environmental conditions:
−Check that the DLT-V72 is securely positioned in the corresponding mount (e.g. in the RAM
mount or in the mounting bracket).
−Check that all fastening elements are correctly secured (e.g. screws, etc.).
−Check that the mounting with the DLT-V72 is securely fastened to the vehicle.

12
10 REPAIRS AND MODIFICATIONS
Only authorized Advantech Service Centers may perform the following:
−Open the device (front unit and base unit)
−Repairs
−Modifications
−Replace integrated modules, e.g. radio cards
The device operator may perform the following (only qualified skilled personnel):
−Open and close the antenna cap (e.g. for replacing CFast card and SIM card)
−Open and close the cable cover
−Opening/closing the battery pocket to replace the battery pack
−Replacing the integrated keyboard of the DLT-V7210 K/KD versions
The legal warranty shall apply. It expires if the customer performs measures on the device that
are only permitted to be performed by Advantech Service Centers.
Accessories and peripherals
Accessories and peripherals may only be installed or integrated if expressly approved by
Advantech for the respective DLT-V72. If other parts are attached or installed and connected,
claims for warranty and / or product liability will be lost.
THERE IS A RISK OF EXPLOSION IF THE BATTERY PACK IS SWAPPED OUT AND
REPLACED WITH AN INCORRECT/NON-APPROVED BATTERY PACK.
11 RECYCLING
Waste electrical equipment and battery packs that are no longer being used may not be disposed
of in the regular residential or domestic waste; they must be taken to an official public collection
point and handled by a disposal provider.
Please contact the responsible authorities in your country/region to find out about the applicable
regulations for proper disposal, if necessary.
12 REGULATORY INFORMATION
You can find regulatory information in the “DLT-V72 Operating Instructions”. Please observe the
device labels on the rear side of the DLT-V72 (FCC-ID information, etc.).

13
DLT-V72 Industrial Computer
Quick Start and Installation (EN)
These Quick Start and Installation Instructions apply to all DLT-V72 series models in
various equipment levels.
IMPORTANT:
−Read and observe these instructions before commissioning
and using the DLT-V72.
−Read and observe the “DLT-V72 Safety Instructions”.
−Observe all other documents included with the device.
−Retain all documents and pass them on to any future owners of the
equipment.
−Read and observe the “DLT-V72 Operating Instructions” available
online and provided for download from our websites:
www.advantech.com
www.advantech-service-iot.eu
On these websites you will also find the latest versions of all
DLT-V72 documentation.
1PACKING LIST
Before setting up the system, check that the items listed below are included and in good
condition. If any item does not accord with the table, please contact your dealer
immediately:
−DLT-V72 Industrial Computer
−Cable cover and cable sealing set
−Product supplement like these instructions and possibly “OS End User License
Agreement” (depends on optional OS type)

14
2OVERVIEW OF IMPORTANT OPERATING ELEMENTS
NOTICE: Property damage
Users of the DLT-V72 must be trained by skilled personnel and instructed about the
operation of the device.
2.1 Rear side DLT-V72
Antenna:
−Do not cover
−Must have a distance of
> 20 to 50 cm to persons
4 VESA drill holes
−75 x 75 mm spacing
−Cooling fins in between
Pressure compensation element:
−Do not modify or remove
Cable cover
Drilled holes M6 for mounting brackets and accessory holders
(2 on the left side and 2 on the right side of the device)
Battery pocket
Speaker (underneath the device)

15
2.2 Front side DLT-V72
A) DLT-V7210 and 12: P, R, D
Note for the Touch key:
This key has two functions if the device is equipped with a screen defroster (optional)
(Din the device name):
−Function 1: Activate/deactivate touchscreen
−Function 2: Combined with FN – Activate/deactivate screen defroster
LEDs:
Front keys:
−Device on/off
−Display brighter
−Display darker
−Backlighting on/off
−Touchscreen or
screen defroster
on/off
(LED is on = active)
−FN: Shift-key
(LED is on = active)
Operate the
touchscreen with:
−Dry fingers
−Dry, soft gloves
−Suitable touch
stylus
Antenna:
−Do not cover
−Must have a distance of
> 20 to 50 cm to persons
Front keys:
−S1 to S6
−S7 to S12
−Temperature: Red blinking = overtemperature or
undertemperature in the device
Red permanently = screen defroster is active
Off: Screen defroster not active
−Flash access
−Power supply
Battery pocket

16
B) DLT-V7212 P+
Operate the PCT
touchscreen with:
−Dry fingers
−Dry gloves
−Suitable touch
stylus
(capacitive
peak)
Antenna:
−Do not cover
−Must have a distance
of > 20 to 50 cm
to persons
Front keys:
−Display darker
−Device on/off
−Display brighter
Battery pocket
LEDs:
−Temperature: Red blinking = over- or
undertemperature in the device
−Flash access
