Advantech DLoG DLT-V72 Series User manual

DLT-V72 Series
Industrial Computer
User Manual

IMPORTANT:
For safe and proper use, follow these instructions.
Keep them for future reference.
Manual version
Manual version: 2.70
Completed on: January 2, 2020
Revision history (starting from DLT-V72 Facelift 2019):
Version
Date
Manual modifications
V2.60 September 12,
2019
Description of new Facelift models DLT-V7210 KD and DLT-V7212 P+.
Description IGX Tool updated.
V2.70 January 2,
2020
Description of Sticky key feature for DLT-V7210 K and KD.
Description IGX Tool updated.
Manual layout modifications.
Copyright
This document and the software and hardware included with this product are copyrighted 2019
by Advantech Co., Ltd. All rights are reserved. This document is intended for reference
purposes only. All product specifications are subject to change without notice. Advantech Co.,
Ltd. reserves the right to make improvements in this document in the products described in
this document at any time without notice. No part of this document may be reproduced in any
form or by any means, electronic, photocopying, recording, translating, transmitting or
otherwise, without prior written permission of Advantech Co., Ltd. Information provided in this
document is intended to be accurate and reliable. However, Advantech Co., Ltd. assumes no
responsibility for its use, nor for any infringements of the rights of third parties, which may result
from its use.
Advantech Co., Ltd. assumes no liability for technical inaccuracies, typographic errors or faults
in this documentation. Advantech Co., Ltd. also assumes no liability for damages caused
directly or indirectly by the delivery, performance or usage of this material.
Note regarding all links and website content included in this document:
Advantech Co., Ltd. is not responsible for the accessibility of the websites and for the content
of external links contained in this document. The content and accessibility of the linked
websites are the sole responsibility of their operators.

Acknowledgements
The software and hardware designations as well as the brand names used in this
documentation are in most cases also registered trademarks and are subject to the
international law (trademark, brand and patent-protection laws). All product names or
trademarks are properties of their respective owners.
Windows® is a registered trademark of Microsoft Corporation in the United States (US) and
other countries.
Bluetooth® is a registered trademark of Bluetooth SIG, Inc. (Special Interest Group).
Android™ is a registered trademark of Google LLC.
Intel® and Pentium® are registered trademarks of Intel Corp.
RAM® and RAM Mount™ are both trademarks of National Products Inc., 1205 S. Orr Street,
Seattle, WA 98108.
DLT-V72 Industrial Computers can be delivered with or without preinstalled software. For
devices with preinstalled software observe the associated license agreements.
FreeRTOS™ is a registered trademark of Real Time Engineers Ltd (http://www.freertos.org).
This product uses FreeRTOS. FreeRTOS is licensed with a modified GNU GPL:
http://www.freertos.org/a00114.html
The FreeRTOS source text is available from:
http://sourceforge.net/projects/freertos/files/FreeRTOS/V7.4.0/ or from Advantech.
Manufacturer
Advantech Co., Ltd.
No. 1, Alley 20, Lane 26, Rueiguang Road, Neihu District, Taipei 11491, Taiwan, R.O.C.
Simplified EU declaration of conformity
The manufacturer:
Advantech Co., Ltd.
No.1, Alley 20, Lane 26, Rueiguang Road, Neihu District, Taipei 11491, Taiwan, R.O.C.
The importer:
Advantech Service-IoT GmbH
Industriestrasse 15, 82110 Germering, Germany
Hereby declare that the following products
Product name: Industrial Computer
Model name: DLT-V72XXXXXXXXXXXXXX
Comply with the provisions of the applicable EU directives, including their amendments
applicable at the time of the declaration. For getting the detailed declarations of conformity
please visit our websites and contact your regional person in charge: www.advantech.com /
www.advantech.eu / www.advantech-service-iot.eu

Technical customer support
Contact your distributor, sales representative, or an Advantech Service Center for technical
support.
Please have the following information ready:
Product name
Serial number
Description of your peripheral attachments
Description of your software (operating system, application software, etc.)
The exact wording of any error messages
A complete description of the problem
Find the contact data of our Global Advantech Service Centers on our website:
http://erma.advantech.com
Initial inspection
Before setting up the system, check that the items listed below are included and in good
condition. If any item does not accord with the table, please contact your dealer immediately:
•DLT-V72 Industrial Computer
•Cable cover and cable sealing set
•Product supplement
•Possibly “OS End User License Agreement” (depends on optional OS type)
If any of these items are missing or damaged, contact your distributor or sales representative
immediately. We have carefully inspected the device mechanically and electrically before
shipment. It should be free of marks and scratches and in perfect working order upon receipt.
1. As you unpack the device, check it for signs of shipping damage. For example: box
damage, scratches, dents, etc.
2. If it is damaged or it fails to meet the specifications, notify our service department or
your local sales representative immediately.
3. Also, please notify the carrier. Retain the shipping carton and packing material for
inspection by the carrier.
After inspection, we will make arrangements to repair or replace the unit.

A message to the customer
We want you to get the best performance possible from your products. If you run into technical
difficulties, we are here to help. For the most frequently asked questions, you can easily find
answers in your product documentation. These answers are normally a lot more detailed than
the ones we can give over the phone.
Please consult this manual first. If you still cannot find the answer, gather all the information or
questions that apply to your problem, and with the product close at hand, call your dealer. Our
dealers are well trained and ready to give you the support you need to get the most from your
Advantech products. In fact, most problems reported are minor and can be easily solved over
the phone.
In addition, free technical support is available from Advantech engineers every business day.
We are always ready to give advice about application requirements or specific information on
the installation and operation of any of our products.

Contents
1. Introduction................................................10
1.1. About the DLT-V72 manuals............................................................................................................... 11
1.1.1. Manuals for all DLT-V72 models ............................................................................................ 11
1.1.2. Further available manuals ...................................................................................................... 12
1.1.3. Abbreviations used ................................................................................................................. 12
1.1.4. Design elements used in the manuals.................................................................................... 13
1.1.5. Text formatting conventions.................................................................................................... 14
2. Safety Chapter ...........................................15
2.1. Please read and observe. ................................................................................................................... 16
2.2. Requirements for commissioning and operating personnel................................................................ 16
2.3. Battery pack safety.............................................................................................................................. 17
2.4. HF Radiation ....................................................................................................................................... 18
2.5. Information on safe mounting.............................................................................................................. 19
2.6. Information on safe electrical installation ............................................................................................ 20
2.7. Safety during ongoing work operations............................................................................................... 21
2.8. Regular maintenance work ................................................................................................................. 22
2.9. Repairs, modifications......................................................................................................................... 22
2.10. Recycling information.......................................................................................................................... 23
3. Functional Description ..............................24
3.1. Intended use ....................................................................................................................................... 25
3.2. Mount, operate and service the device correctly................................................................................. 26
3.3.Device identification / product label..................................................................................................... 26
4. Unpacking, Storing....................................27
4.1. Packing list .......................................................................................................................................... 28
4.2. Unpacking ........................................................................................................................................... 28
4.3. Transport............................................................................................................................................. 28
4.4. Storage................................................................................................................................................ 29
5. Technical Data – Device ............................30
5.1. General ............................................................................................................................................... 31
5.2. Environmental conditions .................................................................................................................... 34
5.3. Device dimensions .............................................................................................................................. 35
5.3.1. DLT-V7210 P, R, D................................................................................................................. 35
5.3.2. DLT-V7212 P, R, D................................................................................................................. 35
5.3.3. DLT-V7210 K, KD ................................................................................................................... 36
5.3.4. DLT-V7212 P+........................................................................................................................ 36
5.3.5. VESA drill holes ...................................................................................................................... 37
5.4. Integrated power supply, power supply cable ..................................................................................... 38
5.4.1. DC voltage supply connection ................................................................................................ 39
5.4.2. DC Power supply cable .......................................................................................................... 40

6. Technical Data – Radio..............................41
6.1. Identification of radio equipment variants............................................................................................ 42
6.2. Radio cards (optional) ......................................................................................................................... 43
6.2.1. Radio card for WLAN: SPARKLAN WPEQ-261ACN (BT) ...................................................... 43
6.2.2. Radio card for WWAN: QUECTEL EC25 A/E......................................................................... 44
6.3. Antennas (optional) ............................................................................................................................. 45
6.3.1. WLAN antenna IEEE 802.11 a/b/g/n/ac ................................................................................. 45
6.3.2. WLAN, WWAN, LTE 4G antenna (Multiband) ........................................................................ 46
6.3.3. External WLAN antenna IEEE 802.11 a/b/g/n........................................................................ 47
6.3.4. External WWAN antenna 2G, 3G, 4G .................................................................................... 48
6.3.5. Bluetooth integrated (optional)................................................................................................ 49
6.3.6. GPS receiver external (optional)............................................................................................. 49
7. Connectors.................................................50
7.1. Connectors under the cable cover ...................................................................................................... 51
7.1.1. Opening the cable cover......................................................................................................... 53
7.2. Connectors under the antenna............................................................................................................ 54
7.2.1. Devices with sealing plate ...................................................................................................... 54
7.2.2. Open/close the WLAN antenna IEEE 802.11 a/b/g/n/ac ........................................................ 56
7.2.3. Open/close the WLAN, WWAN, LTE 4G antenna .................................................................. 58
8. Operating the DLT-V72 ..............................61
8.1. Safety notes ........................................................................................................................................ 62
8.2. Switching the DLT-V72 on/off ............................................................................................................. 63
8.3. Operating the touchscreen.................................................................................................................. 64
8.3.1. Multi-touch capability .............................................................................................................. 64
8.3.2. Operating the PCT with gloves............................................................................................... 65
8.4. Operation elements............................................................................................................................. 66
8.4.1. DLT-V72 rear side .................................................................................................................. 66
8.4.2. Front side DLT-V7210 and DLT-V7212: P, R, D .................................................................... 67
8.4.3. Front side DLT-V7212 P+....................................................................................................... 68
8.4.4. Front side DLT-V7210 K, KD .................................................................................................. 69
8.5. Using the integrated keyboard ............................................................................................................ 70
8.5.1. Language variants .................................................................................................................. 70
8.5.2. Description of specific keys (in all languages)........................................................................ 70
8.5.3. Integrated keyboard German (QWERTZ) features................................................................. 71
8.5.4. Integrated keyboard French (AZERTY) features.................................................................... 72
8.6. Operating states.................................................................................................................................. 73
8.7. Software keyboard (optional) .............................................................................................................. 74
8.8. Operating the DLT-V72 with UPS ....................................................................................................... 75
8.9. Internal speaker, sound....................................................................................................................... 76
9. General Device Configuration ..................77
9.1. Operating systems (optional) .............................................................................................................. 78
9.2. MS Windows (optional) ....................................................................................................................... 78
9.2.1. General................................................................................................................................... 78
9.2.2. Configuring the front keys, automatic shutdown, etc.............................................................. 79
9.2.3. Energy options and battery pack durability............................................................................. 79
9.2.4. Suppress automatic Win10IoTEnt updates ............................................................................ 80
9.3. Linux (optional).................................................................................................................................... 81
9.4. ADLoG Android (optional) ................................................................................................................... 81
9.5. Automatic shut down........................................................................................................................... 82

10. WLAN Configuration..................................84
10.1. Safety notes ........................................................................................................................................ 85
10.2. Preparation work at the factory ........................................................................................................... 86
10.3. OS-specific configuration .................................................................................................................... 87
10.4. Customer-specific WLAN profiles ....................................................................................................... 88
10.5. Windows Zero Configuration (WZC) ................................................................................................... 88
10.6. Advantech WLAN Client Manager (IGX Tool)..................................................................................... 89
10.6.1. Area of application .................................................................................................................. 89
10.6.2. Program version 1.01 (new features) ..................................................................................... 89
10.6.3. Driver download...................................................................................................................... 89
10.6.4. After image reinstallation: Driver installation........................................................................... 90
10.6.5. “Standard” Driver installation WES7, Win7Pro, Win10IoTEnt ................................................ 90
10.6.6. “Silent” Driver installation Win7Pro, Win10IoTEnt .................................................................. 94
10.6.7. “Silent” Driver uninstaller Win7Pro, Win10IoTEnt................................................................... 94
10.6.8. Start WLAN Client Manager, Login......................................................................................... 95
10.6.9. WLAN Client Manager Functions ........................................................................................... 98
10.6.10. Browse nearby wireless networks.................................................................................... 99
10.6.11. Roam Management........................................................................................................ 106
10.6.12. Import / Export feature ................................................................................................... 113
11. WWAN Configuration ..............................118
11.1. Safety notes ...................................................................................................................................... 119
11.2. Preparation work at the factory (delivery status)............................................................................... 120
11.3. SIM card for WWAN (customer-specific)........................................................................................... 120
11.4. Configuration of Radio card QUECTEL EC25 .................................................................................. 121
11.4.1. Establish Internet connection................................................................................................ 121
11.4.2. Trouble Shooting .................................................................................................................. 124
12. Mechanical Installation............................126
12.1. Safety notes ...................................................................................................................................... 127
12.2. Overview: Recommended mounting sequence................................................................................. 127
12.2.1. Mounting the DLT-V72 at the deployment location............................................................... 128
12.2.2. Electrically isolated DLT-V72 mounting ................................................................................ 129
12.2.3. Attaching accessories to the DLT-V72 ................................................................................. 130
12.2.4. VESA mounting hole pattern ................................................................................................ 131
12.2.5. Attach the mounting bracket................................................................................................. 132
12.2.6. Attach accessories................................................................................................................ 133
13. Electrical Installation ...............................134
13.1. Safety notes ...................................................................................................................................... 135
13.1.1. Disconnecting device and emergency-off............................................................................. 135
13.1.2. Power cables and fuses........................................................................................................ 136
13.1.3. Observe the potential ratios.................................................................................................. 137
13.2. Preparations...................................................................................................................................... 138
13.2.1. Material required................................................................................................................... 138
13.3. Procedure.......................................................................................................................................... 140
13.3.1. Inserting the rubber seal in the cable compartment.............................................................. 140
13.3.2. Ensure a proper electrical connection .................................................................................. 141
13.3.3. Plugging in and screwing on the power supply cable ........................................................... 141
13.3.4. Secure the power supply cable to the strain relief rail .......................................................... 142
13.3.5. Connecting the USB, Ethernet and COM cables.................................................................. 143
13.3.6. Close off unused cable openings.......................................................................................... 144
13.3.7. Attach the cable cover .......................................................................................................... 144
13.4. Pressure compensation element....................................................................................................... 145

14. Optional Equipment.................................146
14.1. Integrated UPS (optional).................................................................................................................. 147
14.1.1. Battery pack specifications ................................................................................................... 147
14.1.2. Charging the battery pack..................................................................................................... 148
14.1.3. Replacing the battery pack ................................................................................................... 149
14.2. Screen defroster (optional)................................................................................................................ 150
14.3. Screen blanking (optional) ................................................................................................................ 151
14.4. USB recovery stick (optional)............................................................................................................ 151
14.5. Keyboards and keyboard mounts (optional) ..................................................................................... 152
14.6. Scanner and scanner bracket (optional) ........................................................................................... 153
14.7. Touch stylus (optional) ...................................................................................................................... 154
14.8. Protective film for touchscreen (optional).......................................................................................... 155
15. Repairs, Modifications.............................156
15.1. Authorized Advantech Service Centers ............................................................................................ 157
16. Maintenance .............................................158
16.1. Regular maintenance work ............................................................................................................... 159
16.1.1. General................................................................................................................................. 159
16.1.2. Cleaning the device .............................................................................................................. 159
16.1.3. Devices used in vehicles ...................................................................................................... 159
16.2. Replacing the integrated keyboard ................................................................................................... 160
16.2.1. Remove the integrated keyboard.......................................................................................... 160
16.2.2. Attach the integrated keyboard (example)............................................................................ 161
16.3. Replacing the battery pack................................................................................................................ 163
16.4. Replacing the touchscreen protective film ........................................................................................ 163
17. Troubleshooting ......................................164
18. Guidelines and Certificates.....................167
18.1. USA/CANADA: FCC Part 15 Statement ........................................................................................... 168
18.2. ICES Kanada .................................................................................................................................... 169
18.3. CNROHS........................................................................................................................................... 169
19. List of figures ...........................................170

Introduction
DLT-V72 Series User Manual V2.70
10 / 173
1. Introduction

Introduction
DLT-V72 Series User Manual V2.70
11 / 173
1.1. About the DLT-V72 manuals
NOTE Pay attention to the DLT-V72 manuals because they help avoid hazards,
reduce repair costs and downtimes, and increase the reliability and
service life of the DLT-V72.
Keep the manuals for future use.
Please contact Advantech if you require additional information or
clarification. You can find the contact address in section Technical
Customer Support.
The latest versions of our manuals are available at our websites:
www.advantech.com
www.advantech-service-iot.eu
1.1.1. Manuals for all DLT-V72 models
The following manuals are available for all DLT-V72 device models:
Manual type Contents For target group Availability
Startup Manual Safety instructions, First
commissioning:
mechanical mounting
and electrical installation
Skilled personnel
Printed, enclosed with
the device
User Manual Complete operating
instructions
Skilled personnel PDF file at our websites
Startup Manual and User Manual apply to all models of the DLT-V72 Series:
DLT-V7210 P (PCT)
DLT-V7210 R (Resistive Touch)
DLT-V7210 D (Defroster)
DLT-V7212 P (PCT)
DLT-V7212 R (Resistive Touch)
DLT-V7212 D (Defroster)
DLT-V7210 K (Integrated Keyboard)
DLT-V7210 KD (Integrated Keyboard and Defroster)
DLT-V7212 P+ (PCT)

Introduction
DLT-V72 Series User Manual V2.70
12 / 173
1.1.2. Further available manuals
Manual Contents OS For target
group
Availability
ADLoG Config Software
configuration
tool description
MS
Windows
Skilled
personnel PDF file at our
websites
ADLoG Linux OS and
configuration
Linux Skilled
personnel
Upon request, please
contact our Technical
Customer Support
Android
Nougat 1.xx
for DLT-V72
OS and
configuration
Android Skilled
personnel PDF file at our
websites
1.1.3. Abbreviations used
Term
Abbreviation
Lithium-ion battery pack Battery pack
MS Windows MS Win
MS Windows 10 IoT Enterprise Win10IoTEnt
MS Windows 7 Pro Win7Pro
MS Windows Embedded Standard 7 WES7
Operating System OS
Uninterrupted Power Supply UPS

Introduction
DLT-V72 Series User Manual V2.70
13 / 173
1.1.4. Design elements used in the manuals
Safety notes and other notices
<Signal word> Damage to persons
Signal word DANGER means that death or severe bodily injury
will occur if this information is not observed.
Signal word WARNING means that death or severe bodily injury
can occur if this information is not observed.
Signal word CAUTION means that slight bodily injury can occur if
this information is not observed.
NOTICE Prevent system malfunction and property damage
Information about possible property damage to avoid damaging
hardware or losing data
NOTE Notes provide optional additional information

Introduction
DLT-V72 Series User Manual V2.70
14 / 173
1.1.5. Text formatting conventions
Subject
Formatting
Example
Lists Bullet points 
Part 1
Part 2
Instructions Numbers 4. Copy file …
5. Rename file …
Product names Normal, not
highlighted
Software MDevice is a setup tool
for …
Buttons in software
dialogues
Bold With button Next…
Texts, parameters in
software dialogues
Bold
Parameter setting
ID-Test
should
be …
Placeholder for a variable <x> value in
angle brackets
Value <x> depends on …
Syntax, Strings
Courier New
Size 11
The
AT
prefix must be set.
Keyboard keys In capital letters,
sequence with +
CTRL + ALT + DEL
Cross reference to other
manual chapters
Text in italics,
underlined
Please refer to manual section 1.1
Examples
Program files
File names
Directories
In quotation
marks
File “quectel.exe“ …
In directory “C:/Program Files” ….
Links
Underlined, blue
Website https://advantech.eu

Safety Chapter
DLT-V72 Series User Manual V2.70
15 / 173
2. Safety Chapter

Safety Chapter
DLT-V72 Series User Manual V2.70
16 / 173
2.1. Please read and observe.
These safety instructions apply to all device models in the DLT-V72 Series: For DLT-
V7210 and DLT-V7212 in various equipment levels.
WARNING Non-observance of the safety instructions can result in injury to
persons and in physical damage, e.g. due to incorrect
commissioning procedures or due to maintenance work not
being completed. The manufacturer accepts no liability for
damage resulting from a failure to comply with this information.
1. Read and observe these safety instructions before
commissioning and using the DLT-V72. This protects you and
other persons and prevents damage to the equipment and to
technical equipment in the surrounding environment.
2.2. Requirements for commissioning and operating
personnel
Work such as commissioning and maintaining the DLT-V72 is only permitted to be
performed by skilled personnel who have specialist vocational training and who have up-
to-date knowledge and experience in the area of work in question.
Examples:
Mechanical mounting work must be performed by skilled mechanical personnel.
If the DLT-V72 is incorrectly mounted onto vehicles, for example, this can result
in serious accidents.
Electronic work on the DLT-V72 must be performed by skilled electronics
personnel; there is a risk of electric shock when connecting to the power supply,
for example.
For the DLT-V72 with integrated UPS, specialist knowledge on the handling of
battery packs is required.
Requirements for the operating personnel
Users of the DLT-V72 must be trained by skilled personnel and instructed in the
operation of the device. All users must be familiar with all functions of the product they
come into contact with.

Safety Chapter
DLT-V72 Series User Manual V2.70
17 / 173
2.3. Battery pack safety
The DLT-V72 is optionally available with an integrated UPS. The battery pack of the UPS
is located in the battery pocket of the device:
Fig. 2.1: Battery pocket with UPS DLT-V72
EXPLOSION HAZARD! BATTERY PACK SAFETY NOTICE
Battery packs may ignite if stored or handled incorrectly (fire risk, explosion risk), and
may cause chemical burns or release poisonous substances.
1. Handle the DLT-V72 and the integrated battery pack with care, and do not
allow it to become damaged, to fall or be dropped, or be short-circuited.
2. Do not tamper with, disassemble or repair the battery packs.
3. Observe the specified temperature range, both during storage and in the
work environment.
4. Do not utilize the device near sources of heat or fire, open flames or
heaters.
5. Do not allow water or other liquids to come into contact with the device
(exercise particular caution with corrosive liquids).
6. Suitable fire extinguishers must be provided in line with safety regulations.
7. If battery packs become damaged, caustic electrolyte liquid may leak out.
This liquid must not under any circumstances be permitted to come into
contact with eyes, skin or clothing. On contact with eyes or skin, rinse
immediately with clear, running water and consult a doctor.
THERE IS A RISK OF EXPLOSION IF THE BATTERY PACK IS SWAPPED OUT
AND REPLACED WITH AN INCORRECT/NON-APPROVED BATTERY PACK.
This also applies to the real time clock battery installed in the DLT-V72.
Do not open the DLT-V72, and do not replace the RTC battery.
No third-party battery packs permitted.
1. Use only original battery packs from Advantech. If battery packs from other
manufacturers are inserted in the DLT-V72, the warranty for this device will
be rendered void.
2. The battery packs must be certified for the DLT-V72.
3. Do not use battery packs from any other Advantech devices; they are not
compatible.

Safety Chapter
DLT-V72 Series User Manual V2.70
18 / 173
Prevent physical damage due to deep discharge.
Storing the battery packs incorrectly will cause them to discharge completely (deep
discharge) and thus damage them irreparably.
To prevent a deep discharge:
1. Remove the battery pack from the battery pocket, if the DLT-V72 is not
used for a longer period of time (more than one month).
2. Charge the battery pack in the DLT-V72 device every six months.
2.4. HF Radiation
Only applies to devices with radio equipment: Danger of radiation.
DLT-V72 devices with radio equipment emit high frequency energy (abbreviation: HF).
To protect persons and domestic animals against HF radiation:
1. Mount the DLT-V72 so that persons and domestic animals maintain a
minimum distance of 20 to 50 cm from the radio antennas.
2. Ensure that persons observe this minimum distance when operating the
DLT-V72.
3. High frequency energy can interfere with technical devices. For this reason,
do not use the DLT-V72 in the vicinity of pacemakers or other medical
devices.
4. Only operate the DLT-V72 with radio equipment that is approved by the
manufacturer for this device.
5. Make sure that the transmission power and the radio frequency of the DLT-
V72 comply with the regulations for the respective country where the
device is deployed.
6. Observe all applicable regulations for your deployment location/country
with regard to operating channels, radio frequencies and the maximum
permissible transmitting power. Responsibility for this lies with the company
operating the DLT-V72. The regulatory authorities in the relevant country
can provide information on this.
Any modifications to the DLT-V72 radio equipment which are not expressly approved by
the party responsible for the compliance can lead to the withdrawal of the operating
license for this device.

Safety Chapter
DLT-V72 Series User Manual V2.70
19 / 173
2.5. Information on safe mounting
During the mounting process
The DLT-V72 can fall down and cause injuries due to its weight.
1. Use the assistance of a second person for installation work.
2. Always hold the DLT-V72 by the housing with both hands.
3. Never use the antenna cap as a handle as it may break due to the weight
involved.
The strain relief rail of the DLT-V72 can have sharp edges and cause cutting injuries.
1. Do not hold the DLT-V72 by the strain relief rail.
Choosing the mounting position and installation environment
The installation height of the device shall not exceed 2 m.
1. The ergonomic operability of the DLT-V72 should be taken into account
when selecting the mounting position.
2. Mount the DLT-V72 in such a way that no persons can be injured if the
device mounting should break (e.g. as a result of a fatigue fracture).
3. Otherwise, it is essential to adopt corresponding safety measures.
4. Ensure that the installation environment is correct, as is not permitted to
result in an enclosed system because the cooling concept of the DLT-V72
requires fresh air. Without a supply of fresh cooling air, the DLT-V72 may
overheat and may be damaged beyond repair.
Specific information on vehicle mounting (forklifts, etc.)
1. Mount the DLT-V72 so that the driver's field of view remains clear and safe
driving operation is guaranteed.
2. During the mounting process, observe the requirements of the vehicle
manufacturer relating to attaching auxiliary devices and connecting
auxiliary consumers.
3. Observe all requirements relating to welding or drilling on support
components of the vehicle.

Safety Chapter
DLT-V72 Series User Manual V2.70
20 / 173
2.6. Information on safe electrical installation
Danger of electric shock
1. Do not put the DLT-V72 into operation if it is showing damage.
2. Do not open or modify the DLT-V72.
3. Only connect or disconnect electrical connections when the device is in a
de-energized state.
4. Use only original Advantech power supply cables; these meet the specific
requirements for low-temperature flexibility, UV resistance, oil resistance,
etc.
Installing the disconnecting device
The DLT-V72 is not equipped with disconnecting devices that are accessible from the
outside; it does not have switches.
1. To allow the device to be quickly disconnected from the power supply in
emergency situations, install an easily accessible disconnecting device
close to the device and ensure that the disconnecting device isolates all
supply lines.
Fuses
2. Only connect DLT-V72 devices to Safety Extra Low Voltage (SELV)
circuits.
3. The DC+ connecting cable must be protected by a fuse (30 AT max.).
4. The ignition connecting cable must be protected by a fuse of the following
type:
5x20 mm T 125 mA L / 250 V, for example, a Wickmann 195-125 mA / 250
V.
Power supply unit fuse blows repeatedly
If the fuse of the integrated power supply unit blows again immediately after replacement,
proceed as follows:
1. Check the electrical installation.
2. If it’s excluded that a faulty installation causes the problem: Send in the
DLT-V72 immediately for repair.
