Advantech UNO-1372GH User manual

User Manual
UNO-1372G/1372GH
Embedded Automation
Computer with Intel®Atom
Quad-Core Processor, 3 x GbE,
2 x mPCIe, 1 mSATA, 2xCOM,
8xDIO, 3xUSB, HDMI/VGA

UNO-1372G User Manual ii
限用物質含有情況標示聲明書
設備名稱：
Equipment name 電腦 型號 （型式）： Type designation (Type)
UNO-1372G 系列
( 系列型號參見說明書 )
單元 Unit
限用物質及其化學符號
Restricted substances and its chemical symbols
鉛Lead
(Pb)
汞
Mercury
(Hg)
鎘
Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr+6)
多溴聯苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl ethers
(PBDE)
電路板 － ○ ○ ○ ○ ○
機殼
( 外殼、支
架…等)
○○ ○ ○ ○ ○
其它固定
組件
(螺絲)
－○ ○ ○ ○ ○
配件
(線材) ○○ ○ ○ ○ ○
記憶卡 － ○ － ○ ○ ○
備考 1.“ 超出 0.1 wt %” 及 “ 超出 0.01 wt %” 係指限用物質之百分比含量超出百分比含
量基準值。
Note 1. “Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content
of the restricted substance exceeds the reference percentage value of presence condition.
備考 2.“ ○ ” 係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2. “○”indicates that the percentage content of the restricted substance does not exceed
the percentage of reference value of presence.
備考 3.“ － ” 係指該項限用物質為排除項目。
Note 3. The “-” indicates that the restricted substance corresponds to the exemption.

iii UNO-1372G User Manual
Copyright
The documentation and the software included with this product are copyrighted 2017
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Cor-
poration.
Intel and Core are trademarks of Intel Corporation
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Support
For more information on this and other Advantech products, please visit our websites
at: http://www.advantech.com
For technical support and service, please visit our support website at:
http://support.advantech.com/
This manual applies to the below model which is abbreviated as UNO-1372G series
products in this article.
*Model number:
UNO-1372G
*Part number:
UNO-1372G-E3AE
UNO1372GE3A1501E-T; UNO1372GE3A1502E-T
UNO1372GE3A1503E-T; UNO1372GE3A1701E-T
UNO1372GE3A1702E-T; UNO1372GE3A1703E-T
UNO1372GE3A1704E-Tl UNO1372GE3A1801E-T
UNO1372GE3A1802E-T; UNO1372GE3A1803E-T
UNO1372GE3A1804E-T; UNO1372GE3A1901E-T
UNO1372GE3A1902E-T; UNO1372GE3A1903E-T
UNO1372GE3A1904E-T; UNO1372GE3A2001E-T
UNO1372GE3A2002E-T; UNO1372GE3A2003E-T
UNO1372GE3A2004E-T
P/N: 2003W37202 Edition 3
Printed in Taiwan October 2017

UNO-1372G User Manual iv
UNO-1372GH-E3AE
UNO1372GHE3A1701-T; UNO1372GHE3A1702-T;
UNO1372GHE3A1703-T; UNO1372GHE3A1704-T;
UNO1372GHE3A1801-T; UNO1372GHE3A1802-T;
UNO1372GHE3A1803-T; UNO1372GHE3A1804-T;
UNO1372GHE3A1901-T; UNO1372GHE3A1902-T;
UNO1372GHE3A1903-T; UNO1372GHE3A1904-T;
UNO1372GHE3A2001-T; UNO1372GHE3A2002-T;
UNO1372GHE3A2003-T; UNO1372GHE3A2004-T;
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.

v UNO-1372G User Manual
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact your local supplier for
ordering information.
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
警告使用者：這是甲類資訊產品，在居住的環境中使用時， 可能會造成射頻干擾，在
這種情況下，使用者會被要求採取某些適當對策。
Technical Support and Assistance
1. Visit the Advantech web site at support.advantech.com/ where you can find the
latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.

UNO-1372G User Manual vi
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -10°C (-14° F) OR ABOVE 60°
C (140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
ATTENTION: Danger d'explosion si la batterie est mal REMPLACE. REM-
PLACER UNIQUEMENT PAR LE MEME TYPE OU EQUIVALENT RECOM-
MANDÉ PAR LE FABRICANT, jeter les piles usagées SELON LES
INSTRUCTIONS DU FABRICANT.
17. The sound pressure level at the operator's position according to IEC 704-1:1982
is no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

vii UNO-1372G User Manual
安全指示
1. 請仔細閱讀此安全操作說明。
2. 請妥善保存此用戶手冊供日後參考。
3. 用濕抹布清洗設備前，請從插座拔下電源線。請不要使用液體或去汙噴霧劑清洗
設備。
4. 對於使用電源線的設備，設備周圍必須有容易接觸到的電源插座。
5. 請不要在潮濕環境中使用設備。
6. 請在安裝前確保設備放置在可靠的平面上，意外跌落可能會導致設備損壞。
7. 設備外殼的開口是用於空氣對流，從而防止設備過熱。請勿覆蓋開孔。
8. 當您連接設備到電源插座上前，請確認電源插座的電壓是否符合要求。
9. 請將電源線佈置在人們不易絆到的位置，並不要在電源線上覆蓋任何雜物。
10. 請注意設備上的所有警告和注意標語。
11. 如果長時間不使用設備，請將其同電源插座斷開，避免設備被超標的電壓波動損
壞。
12. 請不要讓任何液體流入通風口，以免引起火災或者短路。
13. 請不要自行打開設備。為了確保您的安全，請由經過認證的工程師來打開設備。
14. 如遇下列情況，請由專業人員來維修：
 電源線或者插頭損壞；
 設備內部有液體流入；
 設備曾暴露在過於潮濕的環境中使用；
 設備無法正常工作，或您無法通過用戶手冊來使其正常工作；
 設備跌落或者損壞；
 設備有明顯的外觀破損。
15. 請不要把設備放置在超出我們建議的溫度範圍的環境，即不要低於 0°C
（32°F）或高於 40°C （104°F），否則可能會損壞設備。
16. 注意：若電池放置不正確，將有爆炸的危險。因此，只可以使用製造商推薦的同
一種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池。
17. 根據 IEC 704-1:1982 的規定，操作員所在位置的聲壓級不可高於 70dB(A)。
18. 限制區域：請勿將設備安裝於限制區域使用。
19. 免責聲明：該安全指示符合 IEC 704-1 的要求。研華公司對其內容的準確性不承
擔任何法律責任。

UNO-1372G User Manual viii

ix UNO-1372G User Manual
Contents
Chapter 1 Overview..............................................1
1.1 Introduction ............................................................................................... 2
1.2 Safety Precautions.................................................................................... 2
1.3 Accessories............................................................................................... 3
Chapter 2 Hardware Functionality ......................5
2.1 Introduction ............................................................................................... 6
Figure 2.1 Front of UNO-1372G/ 1372GH................................... 6
Figure 2.2 Top of UNO-1372G/ 1372GH..................................... 7
2.1.1 System Hardware ......................................................................... 7
2.2 Serial Interface (COM1~COM2) ............................................................... 8
2.2.1 RS-232 Interface (COM 1)............................................................ 8
2.2.2 Automatic Data Flow Control Function for RS-485....................... 8
2.3 LAN: Ethernet Connector.......................................................................... 8
2.4 Power Connector ...................................................................................... 8
2.5 USB Connector......................................................................................... 8
2.6 Display Connector..................................................................................... 8
2.7 RTC Battery .............................................................................................. 9
Figure 2.3 RTC Battery Location................................................. 9
2.8 Power Button/Power Management ........................................................... 9
2.9 Reset Button ............................................................................................. 9
2.10 PCI Express Mini Card Socket................................................................ 10
2.11 iDoor Expansion Slot ............................................................................. 10
2.12 Antenna Mounting................................................................................... 10
2.13 Dual Power Input .................................................................................... 10
2.14 Audio Jack .............................................................................................. 11
2.15 LED Indicators ........................................................................................ 11
2.16 Digital Input and Output .......................................................................... 11
Figure 2.4 Wet Contact Wiring .................................................. 12
Figure 2.5 Dry Contact Wiring ................................................... 12
Chapter 3 Initial Setup........................................13
3.1 Chassis Grounding ................................................................................. 14
Figure 3.1 Chassis Grounding Connection................................ 14
3.2 Inserting a mSATA.................................................................................. 14
3.3 Installing a Wireless LAN Card and Antenna (optional).......................... 15
3.4 Installing a Hard Disk.............................................................................. 17
3.5 BIOS Setup............................................................................................. 18
3.6 Din Rail Kit Assembly.............................................................................. 19
3.7 Connecting Power................................................................................... 20
Appendix A System Settings and Pin Assignments
21
A.1 System I/O Address and Interrupt Assignment....................................... 22
Table A.1: Interrupt Assignments .............................................. 22
A.2 Board Connectors and Jumpers ............................................................. 23
Figure A.1 Connector & Jumper Locations (front) ..................... 23
Table A.2: Connectors and Jumpers ......................................... 23
A.3 RS-232 Standard Serial Port (COM1)..................................................... 25

UNO-1372G User Manual x
Table A.3: RS-232 Serial Port Pin Assignments........................ 25
A.4 RS-422/485 Serial Port (COM2) ............................................................. 25
Table A.4: RS-422/485 Serial Port Pin Assignments................. 25
A.5 Power Connector (PWR) ........................................................................ 26
Table A.5: Power connector pin assignments ........................... 26
A.6 USB Connector ....................................................................................... 26
Table A.6: USB 2.0 Connector Pin Assignments....................... 26
A.7 HDMI Display Connector ........................................................................ 27
Table A.7: HDMI Adaptor Cable Pin Assignment ...................... 27

Chapter 1
1Overview
This chapter provides an overview
of the products specifications.
Sections include:
Introduction
Safety precautions
Accessories

UNO-1372G User Manual 2
1.1 Introduction
The UNO-1372G is an embedded Application Ready Platform (ARP) that can
shorten development time and offers multiple networking interfaces to fulfill the
extensive needs of different projects.
The UNO-1372G includes Intel's latest Intel Atom technology and provides multiple
interfaces including up to two serial ports, three GbE LAN and three USB ports.
The UNO-1372G supports two display types, HDMI and VGA for various high resolu-
tion requirements.
The UNO-1372G can operate in wide temperatures (from -20 to 60° C).
The UNO-1372G even adopts Intel Atom CPU with Quad-Core computing power and
up to 4GB DDR3 (supports a max of 8GB) built-in RAM for multi-tasking programs.
The UNO-1372G provides great expansion including two Mini PCIe and SIM card
support. With these expansions and iDoor technology the UNO-1372G has great
expandability from Wi-Fi, 3G, I/O expansion and fieldbus card with iDoor technology.
With a wide array of OS and driver support, such as Windows 7/8, WES7/WE8S, and
embedded Linux, users can integrate applications easily in an application ready plat-
form that can provide a versatile functions to fulfill diverse requirements.
1.2 Safety Precautions
The following sections tell how to make each connection. In most cases, you will sim-
ply need to connect a standard cable.
Note! Safety Certification Temperature 50° C(122° F)
Warning! Always disconnect the power cord from your chassis whenever you are
working on it. Do not connect while the power is on. A sudden rush of
power can damage sensitive electronic components. Only experienced
electronics personnel should open the chassis.
Warning! Toujours débrancher le cordon d'alimentation de votre boîtier lorsque
vous êtes travailler. Ne branchez pas lorsque l'appareil est allumé. Un
afflux soudain de puissance peut endommager les composants électro-
niques sensibles. Seulement connu personnel de l'électronique
devraient ouvrir le châssis.
Caution! Always ground yourself to remove any static electric charge before
touching the product. Modern electronic devices are very sensitive to
static electric charges. Use a grounding wrist strap at all times. Place all
electronic components on a static-dissipative surface or in a static-
shielded bag.
Caution! Toujours à la terre pour éliminer toute charge d'électricité statique avant
toucher UNO-1372G. Appareils électroniques modernes sont très sensi-
bles à charges d'électricité statique. Utilisez un bracelet antistatique à
tout moment. Placez tous composants électroniques sur une surface
antistatique ou dans un statique-sac blindé.

3 UNO-1372G User Manual
Chapter 1 Overview
1.3 Accessories
Please refer below for the accessory list:
4-pin connector for power wiring
10-pin connector for Digital I/O wiring
Din-Rail Mounting Bracket
Wall Mounting Bracket
4 x PCS screws for HDD
6 x PCS screws for mPCIe slot
4 x PCS screws for wall mounting bracket
3 x PCS screws for DIN-Rail Bracket
Driver DVD
Warranty card
Lockable I/O kit (only in UNO-1372GH-E3AE)
If anything is missing or damaged, contact your distributor or sales representative
immediately.

UNO-1372G User Manual 4

Chapter 2
2Hardware Functionality
This chapter shows how to setup the
product’s hardware functions, including
connecting peripherals, setting switches
and indicators.
Sections include:
Introduction
Serial Interface
LAN / Ethernet Connector
Power Connector
USB Connector
Display Connector
RTC Battery
Power Button/Power Management
Reset Button
mPCIe Socket
iDoor Expansion Slot
PCIe Slot
Antenna Mounting
Dual Power Input and Remote Power
Control
Audio Jack
LED Indicators

UNO-1372G User Manual 6
2.1 Introduction
The following figures show the connectors on the product. The following sections
give you information about each peripheral.
Figure 2.1 Front of UNO-1372G/ 1372GH

7 UNO-1372G User Manual
Chapter 2 Hardware Functionality
Figure 2.2 Top of UNO-1372G/ 1372GH
2.1.1 System Hardware
CPU: Intel Atom E3845 1.91GHz, 2MB L2 Cache
Memory:
–4G DDR3L SDRAM built-in,
–Transcend/AQD-SD3L4GN16-SG 4GB
Storage: One drive bay for SATA 2.5" HDD (Compatible with 9.5mm high
HDDs)
Display: 1 × VGA 1920 x 1200, 1 x HDMI 1920 x 1080, supports 2 independent
displays
Expansion Slots: 2 x Full-size mPCIe slot,1x mSATA (Full-size)

UNO-1372G User Manual 8
2.2 Serial Interface (COM1~COM2)
The UNO-1372G offers one standard RS-232 and RS-422/485 (with cable) serial
communication inter-face ports: COM1 ~ COM2.
The IRQ and I/O address range are listed below:
COM1: 3F8h, IRQ4
COM2: 2F8h, IRQ3
2.2.1 RS-232 Interface (COM 1)
The UNO-1372G offers one RS-232 serial communication interface ports: COM1.
Please refer to Appendix A.3 for their pin assignments.
2.2.2 Automatic Data Flow Control Function for RS-485
In RS-485 mode, the UNO-1372G automatically detects the direction of incoming
data and switches its transmission direction accordingly. So no handshaking signal
(e.g. RTS signal) is necessary. This lets you conveniently build an RS-485 network
with just two wires. More importantly, application software previously written for half
duplex RS-232 environments can be maintained without modification.
2.3 LAN: Ethernet Connector
The UNO-1372G is equipped with three Gigabit LAN controller. The controller chip
used is the Intel Ethernet controller with that is fully compliant with 802.1Qav,
IEEE1588/802.1AS, 802.3az standards. The Ethernet port provides standard RJ-45
jacks on the front I/O and LED indicators in front of the connector to show its status of
Link (100Mbps orange LED, 1000Mbps green LED) and Active (flashing green LED)
status.
2.4 Power Connector
The UNO-1372G comes with a Phoenix connector that carries 9~36 VDC external
power input, and features reversed wiring protection.Therefore, it will not cause any
damage to the system by reversed wiring of ground line and power line. Refer to
Appendix A
2.5 USB Connector
The USB interface supports Plug and Play, which enables you to connect or discon-
nect a device, without turning off the computer. This provides three USB connectors ,
which gives complete Plug & Play and hot swapping for up to 127 external devices.
One of the three connectors are compatible with USB3.0 devices. The USB interface
is USB EHCI, Rev. 2.0 compliant. The USB interface can be disabled in the system
BIOS setup. Refer to Appendix A for its pin assignment.
2.6 Display Connector
The UNO-1372G provides a HDMI and VGA controller for a high resolution interface.
It supports up to full HD resolution for two independent display.
1 x VGA, supports 1920 x 1200 @ 60Hz 24bpp
1 x HDMI 1.4a, supports 1920 x 1080 @ 60Hz 24bpp

9 UNO-1372G User Manual
Chapter 2 Hardware Functionality
2.7 RTC Battery
The RTC Battery to ensures the setting in BIOS and system clock can be kept, even
with power disconnected for a short time.
Type: BR2032 (Using CR2032 is NOT recommended)
Output Voltage: 3 VDC
Location: Top side removable cover named RTC BTR
Figure 2.3 RTC Battery Location
2.8 Power Button/Power Management
Press the “PWR” button to power on or power off (ATX type). This product supports
the ACPI (Advanced Configuration and Power Interface). As well as power on/off, it
supports multiple suspend modes, such as Power on Suspend (S1), Suspend to
RAM (S3), Suspend to Disk (S4).
2.9 Reset Button
Press the “Reset” button to activate the hardware reset function.

UNO-1372G User Manual 10
2.10 PCI Express Mini Card Socket
There are three sockets for full size PCI Express mini cards. The first interface
(CN16) on bottom board is for mSATA and the second (CN8) interface is mainly tar-
get to support iDoor technology/module for diversified application such as isolated
COM port, Profibus, WLAN GPRS, 3G, MRAM and soon. Users can install the card
easily by using the optional kit, refer to Chapter 3 for details. An additional SIM card
slot is used for 3G applications with CN7. Note, you still require a 3G Mini-PCIe mod-
ule installed to be able to use 3G functions.The third one (CN7) is a full-size mini
PCIe card which can be installed with Wi-Fi, Bluetooth, GPS modules for example.
2.11 iDoor Expansion Slot
At the front side, there's a iDoor Expansion slot that provide user to install mPCIe
modules to extend extra I/O port for specific application, like Isolation COM, Digital
I/O, CANOpen modules.
2.12 Antenna Mounting
This product offers two antenna mounting holes covered by pre-cut holes for users to
install with antenna kit once users need 3G, WiFi or other wireless functions.
2.13 Dual Power Input
In the power connector, there is a secondary power input that helps users plug-in a
second power source to prevent main power source failure.
