Advantech UNO-2483 User manual

Quick Start Guide
UNO-2483
UNO-2473G
嵌入式工業電腦
Intel® Core™ i7/i3/Celeron/Atom
Regular-Size Automation
Computer w/ 4/2 x GbE 3/1 x
mPCIe, HDMI/VGA

UNO-2483G/2473G Quick Start Guide ii
限用物質含有情況標示聲明書
Declaration of the Presence Condition of the Restricted Substances Marking
申請商 : 研華股份有限公司
地址 : 台北市內湖區瑞光路 26 巷 20 弄 1 號
電話 : [phone]
設備名稱 : 嵌入式工業電腦 型號 ( 型式 )：UNO-2483( 系列型號請參見次頁說明書 )
Equipment name Type designation (Type)
單元 Unit
限用物質及其化學符號
Restricted substances and its chemical symbols
鉛
Lead
(Pb)
汞
Mercury
(Hg)
鎘
Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr+6)
多溴聯苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated-
diphenyl ethers
(PBDE)
電路板 － ○ ○ ○ ○ ○
其它固定組件
( 螺絲 )
－○ ○ ○ ○ ○
機殼 ( 外殼、
支架 …)
○ ○ ○ ○ ○ ○
記憶體 － ○ ○ ○ ○ ○
配件 ( 線材 ) ○ ○ ○ ○ ○ ○
備考 1. 〝超出 0.1 wt % 〞及〝超出 0.01 wt % 〞係指限用物質之百分比含量超出百分比含
量基準值
Note 1: “Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage con-
tent of the restricted substance exceeds the reference percentage value of presence condi-
tion.
備考 2. 〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2: “○” indicates that the percentage content of the restricted substance does not exceed
the percentage of reference value of presence.
備考 3. 〝－〞係指該項限用物質為排除項目。
Note 3: The “−” indicates that the restricted substance corresponds to the exemption.

iii UNO-2483G/2473G Quick Start Guide
限用物質含有情況標示聲明書
Declaration of the Presence Condition of the Restricted Substances Marking
設備名稱 : 嵌入式工業電腦 型號 ( 型式 )：UNO-2473G( 系列型號請參見次頁說明書 )
Equipment name Type designation (Type)
單元 Unit
限用物質及其化學符號
Restricted substances and its chemical symbols
鉛
Lead
(Pb)
汞
Mercury
(Hg)
鎘
Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr+6)
多溴聯苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated-
diphenyl ethers
(PBDE)
電路板 － ○ ○ ○ ○ ○
內外殼
( 外殼、內部
框架 … 等 )
○ ○ ○ ○ ○ ○
其它固定組件
( 螺絲、夾
具、卡筍 )
－○ ○ ○ ○ ○
配件 ( 線材 ) － ○ ○ ○ ○ ○
記憶卡 － ○ ○ ○ ○ ○
備考 1. 〝超出 0.1 wt % 〞及〝超出 0.01 wt % 〞係指限用物質之百分比含量超出百分比含
量基準值
Note 1: “Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage con-
tent of the restricted substance exceeds the reference percentage value of presence condi-
tion.
備考 2. 〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2: “○” indicates that the percentage content of the restricted substance does not exceed
the percentage of reference value of presence.
備考 3. 〝－〞係指該項限用物質為排除項目。
Note 3: The “−” indicates that the restricted substance corresponds to the exemption.

UNO-2483G/2473G Quick Start Guide iv
Copyright
The documentation and the software included with this product are copyrighted 2020
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Cor-
poration.
Intel®, Core™ and Atom™ are the trademarks of Intel Corporation
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Support
For more information on this and other Advantech products, please visit our websites
at: http:/www.advantech.com
For technical support and service, please visit our support website at:
http:/support.advantech.com/
Part No. 2003Y47322 Edition 3
Printed in Taiwan June 2020

v UNO-2483G/2473G Quick Start Guide
*UNO-2483G
UNO-2483G-474AE, UNO-2483G-434AE, UNO-2483G-4C3AE,
UNO2483G4741503E-T, UNO2483G4741603E-T, UNO2483G4341701E-T,
UNO2483G4341801E-T, UNO2483G4C31801E-T, UNO2483G4742001E-T,
UNO2483G4742002E-T, UNO2483G4742003E-T, UNO2483G4742004E-T,
UNO2483G4742005E-T, UNO2483G4342001E-T, UNO2483G4342002E-T,
UNO2483G4342003E-T, UNO2483G4342004E-T, UNO2483G4342005E-T,
UNO2483G4C32001E-T, UNO2483G4C32002E-T, UNO2483G4C32003E-T,
UNO2483G4C32004E-T, UNO2483G4C32005E-T, UNO2483G4742101E-T,
UNO2483G4742102E-T, UNO2483G4742103E-T, UNO2483G4742104E-T,
UNO2483G4742105E-T, UNO2483G4342101E-T, UNO2483G4342102E-T,
UNO2483G4342103E-T, UNO2483G4342104E-T, UNO2483G4342105E-T,
UNO2483G4C32101E-T, UNO2483G4C32102E-T, UNO2483G4C32103E-T,
UNO2483G4C32104E-T, UNO2483G4C32105E-T, UNO2483G4742201E-T,
UNO2483G4742202E-T, UNO2483G4742203E-T, UNO2483G4742204E-T,
UNO2483G4742205E-T, UNO2483G4342201E-T, UNO2483G4342202E-T,
UNO2483G4342203E-T, UNO2483G4342204E-T, UNO2483G4342205E-T,
UNO2483G4C32201E-T, UNO2483G4C32202E-T, UNO2483G4C32203E-T,
UNO2483G4C32204E-T, UNO2483G4C32205E-T, UNO2483G4742301E-T,
UNO2483G4742302E-T, UNO2483G4742303E-T, UNO2483G4742304E-T,
UNO2483G4742305E-T, UNO2483G4342301E-T, UNO2483G4342302E-T,
UNO2483G4342303E-T, UNO2483G4342304E-T, UNO2483G4342305E-T,
UNO2483G4C32301E-T, UNO2483G4C32302E-T, UNO2483G4C32303E-T,
UNO2483G4C32304E-T, UNO2483G4C32305E-T, UNO2483G4742401E-T,
UNO2483G4742402E-T, UNO2483G4742403E-T, UNO2483G4742404E-T,
UNO2483G4742405E-T, UNO2483G4342401E-T, UNO2483G4342402E-T,
UNO2483G4342403E-T, UNO2483G4342404E-T, UNO2483G4342405E-T,
UNO2483G4C32401E-T, UNO2483G4C32402E-T, UNO2483G4C32403E-T,
UNO2483G4C32404E-T, UNO2483G4C32405E-T, UNO2483G4742501E-T,
UNO2483G4742502E-T, UNO2483G4742503E-T, UNO2483G4742504E-T,
UNO2483G4742505E-T, UNO2483G4342501E-T, UNO2483G4342502E-T,
UNO2483G4342503E-T, UNO2483G4342504E-T, UNO2483G4342505E-T,
UNO2483G4C32501E-T, UNO2483G4C32502E-T, UNO2483G4C32503E-T,
UNO2483G4C32504E-T, UNO2483G4C32505E-T
*UNO-2473G
UNO-2473G-E3AE
UNO-2473G-J3AE
UNO2473GE3A1401E-T, UNO2473GE3A1402E-T, UNO2473GE3A1403E-T,
UNO2473GE3A1404E-T, UNO2473GE3A1405E-T, UNO2473GE3A1406E-T,
UNO2473GE3A1407E-T, UNO2473GE3A1408E-T, UNO2473GE3A1409E-T,
UNO2473GE3A1501E-T, UNO2473GE3A1502E-T, UNO2473GE3A1503E-T,
UNO2473GE3A1504E-T, UNO2473GE3A1505E-T, UNO2473GE3A1506E-T,
UNO2473GE3A1507E-T, UNO2473GE3A1508E-T, UNO2473GE3A1509E-T,
UNO2473GE3A1601E-T, UNO2473GE3A1602E-T, UNO2473GE3A1603E-T,
UNO2473GE3A1604E-T, UNO2473GE3A1605E-T, UNO2473GJ3A1601E-T,
UNO2473GJ3A1602E-T, UNO2473GJ3A1603E-T, UNO2473GJ3A1604E-T,
UNO2473GJ3A1605E-T, UNO2473GE3A1701E-T, UNO2473GE3A1702E-T,
UNO2473GE3A1703E-T, UNO2473GE3A1704E-T, UNO2473GE3A17015E-T,
UNO2473GJ3A1701E-T, UNO2473GJ3A1702E-T, UNO2473GJ3A1703E-T,

UNO-2483G/2473G Quick Start Guide vi
UNO2473GJ3A1704E-T, UNO2473GJ3A1705E-T, UNO2473GE3A1801E-T,
UNO2473GE3A1802E-T, UNO2473GE3A1803E-T, UNO2473GE3A1804E-T,
UNO2473GE3A1805E-T, UNO2473GJ3A1801E-T, UNO2473GJ3A1802E-T,
UNO2473GJ3A1803E-T, UNO2473GJ3A1804E-T, UNO2473GJ3A1805E-T,
UNO2473GE3A1901E-T, UNO2473GE3A1902E-T, UNO2473GE3A1903E-T,
UNO2473GE3A1904E-T, UNO2473GE3A1905E-T, UNO2473GJ3A1901E-T,
UNO2473GJ3A1902E-T, UNO2473GJ3A1903E-T, UNO2473GJ3A1904E-T,
UNO2473GJ3A1905E-T, UNO2473GE3A2001E-T, UNO2473GE3A2002E-T
UNO2473GE3A2003E-T,UNO2473GE3A2004E-T, UNO2473GE3A2005E-T,
UNO2473GJ3A2001E-T, UNO2473GJ3A2002E-T, UNO2473GJ3A2003E-T,
UNO2473GJ3A2004E-T, UNO2473GJ3A2005E-T, UNO2473GE3A2101E-T,
UNO2473GE3A2102E-T, UNO2473GE3A2103E-T, UNO2473GE3A2104E-T,
UNO2473GE3A2105E-T, UNO2473GJ3A2101E-T, UNO2473GJ3A2102E-T,
UNO2473GJ3A2103E-T, UNO2473GJ3A2104E-T, UNO2473GJ3A2105E-T,
UNO2473GE3A2201E-T, UNO2473GE3A2202E-T, UNO2473GE3A2203E-T,
UNO2473GE3A2204E-T, UNO2473GE3A2205E-T, UNO2473GJ3A2201E-T,
UNO2473GJ3A2202E-T, UNO2473GJ3A2203E-T, UNO2473GJ3A2204E-T,
UNO2473GJ3A2205E-T, UNO2473GE3A2301E-T, UNO2473GE3A2302E-T,
UNO2473GE3A2303E-T, UNO2473GE3A2304E-T, UNO2473GE3A2305E-T,
UNO2473GJ3A2301E-T, UNO2473GJ3A2302E-T, UNO2473GJ3A2303E-T,
UNO2473GJ3A2304E-T, UNO2473GJ3A2305E-T, UNO2473GE3A2401E-T,
UNO2473GE3A2402E-T, UNO2473GE3A2403E-T, UNO2473GE3A2404E-T,
UNO2473GE3A2405E-T, UNO2473GJ3A2401E-T, UNO2473GJ3A2402E-T,
UNO2473GJ3A2403E-T, UNO2473GJ3A2404E-T, UNO2473GJ3A2405E-T,
UNO2473GE3A2501E-T, UNO2473GE3A2502E-T, UNO2473GE3A2503E-T,
UNO2473GE3A2504E-T, UNO2473GE3A2505E-T, UNO2473GJ3A2501E-T,
UNO2473GJ3A2502E-T, UNO2473GJ3A2503E-T, UNO2473GJ3A2504E-T,
UNO2473GJ3A2505E-T

vii UNO-2483G/2473G Quick Start Guide
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact your local supplier for
ordering information.
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.

UNO-2483G/2473G Quick Start Guide viii
警告使用者
這是甲類測試產品，在居住的環境中使用時，可能會造成射頻干擾，在這種情況下，
使用者會被要求採取某些適當的對策
Technical Support and Assistance
1. Visit the Advantech web site at www.advantech.com/support where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.

ix UNO-2483G/2473G Quick Start Guide
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
–The power cord or plug is damaged.
–Liquid has penetrated into the equipment.
–The equipment has been exposed to moisture.
–The equipment does not work well, or you cannot get it to work according to
the user manual.
–The equipment has been dropped and damaged.
–The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
17. ATTENTION: Danger d'explosion si la batterie est mal REMPLACE. REM-
PLACER UNIQUEMENT PAR LE MEME TYPE OU EQUIVALENT RECOM-
MANDÉ PAR LE FABRICANT, jeter les piles usagées SELON LES
INSTRUCTIONS DU FABRICANT.
18. The sound pressure level at the operator's position according to IEC 704-1:1982
is no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

UNO-2483G/2473G Quick Start Guide x
安全指示
1. 請仔細閱讀此安全操作說明。
2. 請妥善保存此用戶手冊供日後參考。
3. 用濕抹布清洗設備前，請從插座拔下電源線。請不要使用液體或去汙噴霧劑清洗
設備。
4. 對於使用電源線的設備，設備周圍必須有容易接觸到的電源插座。
5. 請不要在潮濕環境中使用設備。
6. 請在安裝前確保設備放置在可靠的平面上，意外跌落可能會導致設備損壞。
7. 設備外殼的開口是用於空氣對流，從而防止設備過熱。請不要覆蓋這些開口。
8. 當您連接設備到電源插座上前，請確認電源插座的電壓是否符合要求。
9. 將電源線佈置在人們不易絆到的位置，並不要在電源線上覆蓋任何雜物。
10. 請注意設備上的所有警告和注意標語。
11. 如果長時間不使用設備，請將其同電源插座斷開，避免設備被超標的電壓波動損
壞。
12. 請不要讓任何液體流入通風口，以免引起火災或者短路。
13. 請不要自行打開設備。為了確保您的安全，請由經過認證的工程師來打開設備。
14. 如遇下列情況，請由專業人員來維修：
電源線或者插頭損壞；
設備內部有液體流入；
設備曾暴露在過於潮濕的環境中使用；
設備無法正常工作，或您無法通過用戶手冊來使其正常工作；
設備跌落或者損壞；
設備有明顯的外觀破損。
15. 請不要把設備放置在超出我們建議的溫度範圍的環境，即不要低於 -20°C （-
4°F）或高於 60°C （140°F），否則可能會損壞設備。
16. 注意：若電池更換不正確，將有爆炸危險。因此，只可以使用製造商推薦的同一
種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池。
17. 根據 IEC 704‐1:1982 規定，操作員所在位置音量不可高於 70 分貝。
18. 限制區域：請勿將設備安裝於限制區域使用。
19. 免責聲明：請安全訓示符合 IEC 704‐1 要求。研華公司對其內容之準確性不承
擔任何法律責任。

xi UNO-2483G/2473G Quick Start Guide
Contents
Chapter 1 Overview...............................................1
1.1 Introduction ............................................................................................... 2
1.2 Safety Precautions.................................................................................... 2
1.3 Accessories............................................................................................... 3
1.4 Optional Accessories ................................................................................ 3
1.5 Hardware Specifications ........................................................................... 3
Chapter 2 Hardware Functionality.......................5
2.1 Introduction ............................................................................................... 6
Figure 2.1 Front Panel of UNO-2483G/ UNO-2473G-E3AE........ 6
Figure 2.2 Rear Panel of UNO-2483G/UNO-2473G-E3AE ........ 6
Figure 2.3 Front Panel of UNO-2473G-J3AE .............................. 6
Figure 2.4 Rear Panel of UNO-2473G-J3AE............................... 6
2.2 UNO-2483G/UNO-2473G Interface (COM1~COM4)................................ 7
2.2.1 RS-232 Interface (COM 1 ~ 2)...................................................... 7
2.2.2 RS-422/485 detection ................................................................... 7
2.2.3 Automatic Data Flow Control Function for RS-485....................... 7
2.3 LAN: Ethernet Connector.......................................................................... 8
2.4 Power Connector ...................................................................................... 8
2.5 USB Connector ......................................................................................... 8
2.6 HDMI Display Connector........................................................................... 8
2.7 RTC Battery Specification......................................................................... 9
Figure 2.5 RTC Battery Location ................................................. 9
2.8 Power Button/Power Management ........................................................... 9
2.9 Reset Button ............................................................................................. 9
2.10 HD Audio................................................................................................. 10
2.11 PCI Express Mini Card Socket................................................................ 10
Figure 2.6 UNO-2483G mPCIe Location................................... 10
Figure 2.7 UNO-2473G-E3AE mPCIe Location......................... 11
Figure 2.8 UNO-2473G-J3AE mPCIe Location ......................... 11
Chapter 3 Initial Setup ........................................13
3.1 Inserting an mSATA SSD........................................................................ 14
3.2 Chassis Grounding.................................................................................. 14
Figure 3.1 Chassis Grounding Connection................................ 14
3.3 Connecting Power................................................................................... 14
3.4 Installing a Hard Disk .............................................................................. 15
3.5 Installing a Wireless LAN Card and Antenna .......................................... 16
Figure 3.2 UNO-2483G.............................................................. 17
Figure 3.3 UNO-2473G.............................................................. 17
3.6 BIOS Setup ............................................................................................. 18
3.7 AMT Configuration .................................................................................. 18
3.8 Teaming Configuration............................................................................ 20
3.9 Enabling RAID in BIOS ........................................................................... 22
Appendix A Sys Settings & Pin Assignments .....23
A.1 System I/O Address and Interrupt Assignment....................................... 24
Table A.1: Interrupt Assignments............................................... 24
A.2 Board Connectors and Jumpers ............................................................. 25

UNO-2483G/2473G Quick Start Guide xii
Figure A.1 UNO-2483G Connector & Jumper Locations (front) 25
Table A.2: Connectors and Jumpers ......................................... 25
Figure A.2 UNO-2473G Connector & Jumper Locations (front) 26
A.3 Connectors and Jumpers........................................................................ 26
Table A.3: Connectors and Jumpers ......................................... 26
A.4 RS-232 Standard Serial Port .................................................................. 27
Table A.4: RS-232 Serial Port Pin Assignments........................ 27
A.5 RS-422/485 Serial Port ........................................................................... 27
Table A.5: RS-422/485 Serial Port Pin Assignments................. 27
A.6 Power Connector (PWR) ........................................................................ 28
Table A.6: Power connector pin assignments ........................... 28
A.7 USB Connector ....................................................................................... 29
Table A.7: USB 2.0 Connector Pin Assignments....................... 29
Table A.8: USB 3.0 Connector Pin Assignments....................... 29
A.8 HDMI Display Connector ........................................................................ 30
Table A.9: HDMI Display Connector.......................................... 30
A.9 Turn On/Off Termination Resistors (120 ohm) for COM3/COM4 (SW1) 31

Chapter 1
1Overview
This chapter provides an overview
of UNO-2483G/UNO-2473G speci-
fications.
Sections include:
Introduction
Safety Precautions
Accessories
Optional Accessories
Hardware Specifications

UNO-2483G/2473G Quick Start Guide 2
1.1 Introduction
The UNO-2483G/UNO-2473G is an embedded Application Ready Platform (ARP)
that can shorten your development time and offers a wide array of networking inter-
faces to fulfill the extensive needs of different projects. UNO-2483G/UNO-2473G
includes Intel’s latest Core i7/i3/Celeron/Atom technology and provide rich interfaces
including up to 4 serial ports, 4 x GbE LAN, 4 x USB ports and Audio. UNO-2483G/
UNO-2473G supports two display types, VGA and HDMI for various high resolution
requirements and also Advantech latest iDoor technology.
The UNO-2483G/UNO-2473G can operate in wide temperatures (from -20 to 60°C
for UNO-2483G/UNO-2473G). The UNO-2483G/UNO-2473G also uses Intel Core i7/
i3/Celeron/Atom CPUs with great computing power and built-in up to 8G DDR3 RAM
for heavy programs.
The UNO-2483G/UNO-2473G provides great expansion including up to 3 x Mini-
PCIe. With these expansions UNO-2483G/UNO-2473G has great expandability from
Wi-Fi, 3G, I/O expansion and industrial protocols with iDoor technology.
With multiple OS and driver support, such as Windows 7/8, Windows Embedded
Standard 7, application ready drivers, and embedded Linux, users can integrate
applications easily in an application ready platform that can provide versatile func-
tions to fulfill diverse requirements.
1.2 Safety Precautions
The following sections tell how to make each connection. In most cases, you will sim-
ply need to connect a standard cable.
Warning! Always disconnect the power cord from your chassis whenever you are
working on it. Do not connect while the power is on. A sudden rush of
power can damage sensitive electronic components. Only experienced
electronics personnel should open the chassis.
Warning! Toujours à la terre pour éliminer toute charge d'électricité statique avant
toucher UNO-2483G/UNO-2473G. Appareils électroniques modernes
sont très sensibles à charges d'électricité statique. Utilisez un bracelet
antistatique à tout moment. Placez tous composants électroniques sur
une surface antistatique ou dans un statique-sac blindé.
Caution! Always ground yourself to remove any static electric charge before
touching UNO-2483G/UNO-2473G. Modern electronic devices are very
sensitive to static electric charges. Use a grounding wrist strap at all
times. Place all electronic components on a static-dissipative surface or
in a static-shielded bag.
Caution! Toujours débrancher le cordon d'alimentation de votre boîtier lorsque
vous êtes travailler. Ne branchez pas lorsque l'appareil est allumé. Un
afflux soudain de puissance peut endommager les composants électro-
niques sensibles. Seulement connu personnel de l'électronique
devraient ouvrir le châssis.

3 UNO-2483G/2473G Quick Start Guide
Chapter 1 Overview
1.3 Accessories
Please refer below for the accessory list:
3-pin connector for power wiring (Advantech P/N: 1652003206)
HDD screws (Advantech P/N: 1930000687)
mPCIe screws (Advantech P/N: 1935020300)
2 PCS jumper (Advantech P/N: 1653302122)
Mounting Screws (Advantech P/N:1935040620)
Driver DVD
Warranty card
If anything is missing or damaged, contact your distributor or sales representative
immediately.
1.4 Optional Accessories
Din-rail Mounting Kit (Advantech P/N:UNO-2000G-DMKAE)
VESA Mounting Kit (Advantech P/N:UNO-2000G-VMKAE)
1.5 Hardware Specifications
Operating Temperature:
–UNO-2483G: -20~60oC (-4~140oF) @ 5~85% RH with 0.7m/s airflow
–UNO-2473G-E3AE: -20~60oC (-4~140oF) @ 5~85% RH with 0.7m/s airflow
–UNO-2473G-J3AE: -10~60oC (14~140oF) @ 5~85% RH with 0.7m/s airflow
Power Input:
–UNO-2483G and UNO-2473G-E3AE: 24VDC+20%
–UNO-2473G-J3AE: 12VDC+/-20% and 24VDC+/-20%
Power Consumption:UNO-2483G: 28W (Typical), 72W (Max)
–UNO-2473G-E3AE: 28W (Typical), 48W (Max)
–UNO-2473G-J3AE: 10W (Typical), 14W(Max)
CPU:
–UNO-2483G-474AE: 4th Gen Intel® Core™ i7-4650U ULT 1.7 GHz Dual
Core, 4MB L2
–UNO-2483G-434AE: 4th Gen Intel® Core™ i3-4010U ULT 1.7 GHz Dual
Core, 3MB L2
–UNO-2483G-4C4AE: 4th Gen Intel® Celeron® 2980U ULT 1.6 GHz Dual
Core, 2MB L2
–UNO-2473G-E3AE: Intel® Atom® E3845 1.91 GHz Quad Core, 2MB L2
–UNO-2473G-J3AE: Intel® Celeron® J1900 2.42 GHz Quad Core, 2MB L2
 Memory:
–UNO-2483G-474AE/434AE: Built in 8G DDR3L 1600MHz RAM
–UNO-2483G-4C3AE: Built in 4G DDR3L 1600MHz RAM
–UNO-2473G-E3AE: Built in 4G DDR3L 1600MHz RAM
–UNO-2473G-J3AE: Built in 4G DDR3L 1333MHz RAM
Graphic Engine:
–UNO-2483G: Intel® HD Graphics 5000/4400
–UNO-2473G: Intel® HD Graphics Gen7 with 4EU

UNO-2483G/2473G Quick Start Guide 4
Ethernet:
–UNO-2483G:Intel® i210-IT GbE, 802.1Qac, IEEE1588/802.1AS, 802.3az
Intel® i218-LM GbE, Intel® AMT, IEEE1588/802.1AS, 802.3az
–UNO-2473G:Intel® i210-IT GbE, 802.1Qac, IEEE1588/802.1AS, 802.3az
Storage: CFast drive by iDoor Technology (Optional)
–UNO-2483G:One mSATA, Two drive bays for SATA 2.5" HDD/SSD
–UNO-2473G:One mSATA, One drive bays for SATA 2.5" HDD/SSD
Expansion:
–UNO-2483G: 2 x Full-size mPCIe slot, mPCIe 2.0
–UNO-2473G-E3AE: 3 x Full-size mPCIe slot, mPCIe 2.0
–UNO-2473G-J3AE: 1 x Full-size mPCIe slot, mPCIe 2.0
Display: 1 x VGA, supports 1920 x 1200 at 60Hz, 1 x HDMI, supports 1920 x
1080 at 60Hz. eDP is supported on a project basis
Applicable Models:
–UNO-2483G-4C3AEIntel® Celeron® 2980U ULT 1.6GHz, 4GB, 4 x LANs, 2
x mPCIe
–UNO-2483G-434AEIntel® Core™ i3-4010U ULT 1.7GHz, 8GB, 4 x LANs, 2 x
mPCIe
–UNO-2483G-474AEIntel® Core™ i7-4650U ULT 1.7GHz, 8GB, 4 x LANs, 2 x
mPCIe
–UNO-2473G-E3AEIntel® Atom™ E3845 1.91GHz, 4GB, 4 x LANs, 3 x
mPCIe
–UNO-2473G-J3AEIntel® Celeron® J1900 2.42GHz, 4GB, 2 x LANs, 1 x
mPCIe
–

Chapter 2
2Hardware
Functionality
This chapter shows how to setup
the UNO-2483G/UNO-2473G’s
hardware functions, including
connecting peripherals, setting
switches and indicators.
Sections include:
Introduction
RS-232 Interface
RS-422/485 Interface
LAN / Ethernet Connector
Power Connector
Audio Connector
USB Connector
HDMI Display Connector
Reset Button
mPCIe Expansion Slot

UNO-2483G/2473G Quick Start Guide 6
2.1 Introduction
The following figures show the connectors on UNO-2483G/UNO-2473G. The follow-
ing sections give you information about each peripheral.
Figure 2.1 Front Panel of UNO-2483G/ UNO-2473G-E3AE
Figure 2.2 Rear Panel of UNO-2483G/UNO-2473G-E3AE
Figure 2.3 Front Panel of UNO-2473G-J3AE
Figure 2.4 Rear Panel of UNO-2473G-J3AE

7 UNO-2483G/2473G Quick Start Guide
Chapter 2 Hardware Functionality
2.2 UNO-2483G/UNO-2473G Interface
(COM1~COM4)
UNO-2483G/UNO-2473G offers two standard RS-232 and two RS-422/485 (with
cable) serial communication inter-face ports: COM1 ~ COM4.
The IRQ and I/O address range of COM1 to COM4 are listed below:
COM1: 3F8h, IRQ4
COM2: 2F8h, IRQ3
COM3: 3E8h, IRQ10
COM4: 2E8h, IRQ5
The setting can be adjusted in the BIOS page, the driver will be installed automati-
cally during OS installation
2.2.1 RS-232 Interface (COM 1 ~ 2)
The UNO-2483G/UNO-2473G offers two RS-232 serial communication interface
ports: COM1 and COM2. Please refer to Appendix A.3 for their pin assignments.
2.2.2 RS-422/485 detection
In RS-422/485 mode, UNO-2483G/UNO-2473G automatically detects signals to
match RS-422 or RS-485 networks. (No jumper change required)
2.2.3 Automatic Data Flow Control Function for RS-485
In RS-485 mode, UNO-2483G/UNO-2473G automatically detects the direction of
incoming data and switches its transmission direction accordingly. So no handshak-
ing signal (e.g. RTS signal) is necessary. This lets you conveniently build an RS-485
network with just two wires. More importantly, application software previously written
for half duplex RS-232 environments can be maintained without modification.
Note! Refer to Appendix A.4 for their pin assignments.

UNO-2483G/2473G Quick Start Guide 8
2.3 LAN: Ethernet Connector
UNO-2483G/2473G are equipped with four/two Gigabit LAN controllers.
For the UNO-2483G and UNO-2473G-E3AE:
The controller chip used is an Intel® i210-IT GbE Ethernet controller that is fully
compliant with 802.1Qac, IEEE1588/802.1AS, 802.3az
The controller chip used is an Intel® i218-LM GbE Ethernet controller that is
fully compliant with Intel® AMT, IEEE1588/802.1AS, 802.3az
For the UNO-2473G-J3AE
The controller chip used is an Intel® i210-IT GbE Ethernet controller that is fully
compliant with 802.1Qac, IEEE1588/802.1AS, 802.3az
The Ethernet port is a standard RJ-45 jack, and LED indicators are on the front
to show its Link (Green LED) and Active (Yellow LED) status.
2.4 Power Connector
The UNO-2483G/UNO-2473G comes with a Phoenix connector that carries external
power input as below, and features reversed wiring protection so it will not cause any
damage to the system due to reversed wiring of ground line and power line. Please
refer to Appendix A.5.
UNO-2483G and UNO-2473G-E3AE: 24VDC+/-20%
UNO-2473G-J3AE: 12VDC+/-20% and 24VDC+/-20%(e.g +12V @1.16A)
2.5 USB Connector
The USB interface supports Plug and Play, which enables you to connect or discon-
nect a device whenever you want, without turning off the computer. UNO-2483G/
UNO-2473G provides four connector USB interface, which gives complete Plug &
Play and hot swapping for up to 127 external devices. Two of the four connectors on
UNO-2483G and one of the four connector on UNO-2473G are USB 3.0 standard.
The USB interface complies with USB EHCI, Rev. 2.0 compliant. The USB interface
can be disabled in the system BIOS setup. Please refer to Appendix A.6 for its pin
assignments.
2.6 HDMI Display Connector
The UNO-2483G/UNO-2473G provides a HDMI controller for a high resolution inter-
face. UNO-2483G/UNO-2473G supports up to full HD resolution for two independent
displays. DisplayPort is also available on a per-project basis.
Note! UNO-2483G with i218 LAN chip can support AMT9.0.
