Advantech TREK-674 User manual

User Manual
TREK-674
Computer

Copyright
The documentation and the software included with this product are copyrighted
2010 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd.
reserves the right to make improvements in the products described in this
manual at any time without notice. No part of this manual may be reproduced,
copied, translated or transmitted in any form or by any means without the prior
written permission of Advantech Co., Ltd. Information provided in this manual is
intended to be accurate and reliable. How- ever, Advantech Co., Ltd. assumes
no responsibility for its use, nor for any infringements of the rights of third
parties, which may result from its use.
Acknowledgements
Intel and Atom are trademarks of Intel Corporation. Microsoft Windows and
MS-DOS are registered trademarks of Microsoft Corp. All other product
names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will
be free from defects in materials and workmanship for two years from the date
of purchase.
This warranty does not apply to any products which have been repaired or
altered by persons other than repair personnel authorized by Advantech, or
which have been subject to misuse, abuse, accident or improper installation.
Advantech assumes no liability under the terms of this warranty as a
consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing,
most of our customers never need to use our repair service. If an Advantech
product is defective, it will be repaired or replaced at no charge during the
warranty period. For out- of-warranty repairs, you will be billed according to the
cost of replacement materials, service time and freight. Please consult your
dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example,
CPU speed, Advantech products used, other hardware and software used,
etc.) Note anything abnormal and list any onscreen messages you get
when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual,
product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return
merchandise authorization) number from your dealer. This allows us to
process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and
Replacement Order Card and a photocopy proof of purchase date (such as
your sales receipt) in a shippable container. A product returned without
proof of the purchase date is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it
prepaid to your dealer.

Declaration of Conformity
This product has passed the WES8 test for environmental specifications.
Test conditions for passing included the equipment being operated within
an industrial enclosure. In order to protect the product from being
damaged by ESD (Electrostatic Discharge) and EMI leakage, we
strongly recommend the use of CE-compliant industrial enclosure
products.
FCC Class B
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
! Reorient or relocate the receiving antenna.
! Increase the separation between the equipment and receiver.
! Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
! Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that
may cause undesired operation. “Complies with CANADA RSS-210
FCC Part 15.21 information for user
You are cautioned that changes or modifications not expressly approved by the
party responsible for compliance could void your authority to operate the
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that
may cause undesired operation
Notes and Warnings to the User and Installer:
Caution:
This Installation Guide is intended for use by the professional wireless LAN
system installer.
The device cannot be sold retail, to the general public or by mail order. It must be
sold to dealers or have strict marketing control.

Warning: It is the responsibility of the professional installer to ensure that the
system is used exclusively for fixed, point-to-point operations.
Warning: When using the device in the United States (or where FCC rules apply),
it is the responsibility of the professional installer
to ensure to control the output power not greater then the application.
Who Should Use this Guide:
Installation of this device should be accomplished only by a qualified wireless LAN
system installer who is: -Knowledgeable of the use, installation and configuration
procedures and associated networking components. -Knowledgeable of each
system component’s equipment User and Installation Guide. -Knowledgeable of
the installation and configuration procedures for the site’s network infrastructure
system and wiring.
-Knowledgeable of the installation procedures, safety, and code requirements for
the site’s antenna, antenna mast, antenna cabling, and installation. We highly
recommend that the antenna installation be performed by a qualified antenna
installation Professional.
Users should not attempt to make such connections themselves, but should
contact the appropriate electrical inspection authority, or
electrician, as appropriate.
1. This Transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a
minimum distance of 20 centimeters between the radiator and your body.
In the users manual of the end product, the end user has to be informed to keep at least
20cm separation with the antenna while this end product is installed and operated. The
end user has to be informed that the FCC radio-frequency exposure guidelines for an
uncontrolled environment can be satisfied. The end user has to also be informed that any
changes or modifications not expressly approved by the manufacturer could void the
user's authority to operate this equipment.
FCC SAR : 0.0946

Technical Support and Assistance
1. Visit the Advantech web site at www.advantech.com/support for the
latest information about the product.
2. Contact the distributor, sales representative, or Advantech's customer
service center for technical support if you need additional assistance.
Please have the following information ready before you call:
– Product name and serial number
– Description of your peripheral attachments
– Description of your software (operating system, version, application
software, etc.)
– A complete description of the problem
– The exact wording of any error messages

Warnings, Cautions and Notes
Warning! Warnings indicate conditions, which if not observed, can cause
personal
Injury!
Caution! Cautions are included to help you avoid damaging hardware or
losing data. e.g.
There is a danger of a new battery exploding if it is incorrectly
installed. Do not attempt to recharge, force open, or heat the battery.
Replace the battery only with the same or equivalent type
recommended by the manufacturer. Discard used batteries according
to the manufacturer's instructions.
Note! Notes provide optional additional information.
Document Feedback
To assist us in making improvements to this manual, we would welcome
comments and constructive criticism. Send all such in writing to:
[email protected]
Packing List
Before setting up, check that the items listed below are included, in good
condition. If any item does not accord with the table, please contact your dealer
immediately.
! TREK-674 series ComputingBox
! WIFI+BT 2.4+5G Antenna
!VIO Cable
! GIO Cable
!Video Cable
!2 in 1 Antenna
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a
damp cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or
letting it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place
anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power
source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical
shock.
13. Never open the equipment. For safety reasons, the equipment
should be opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by
service personnel:
15. The power cord or plug is damaged.
16. Liquid has penetrated into the equipment.
17. The equipment has been exposed to moisture.
18. The equipment does not work well, or you cannot get it to work according
to the user's manual.
19. The equipment has been dropped and damaged.
20. Theequipmenthasobvioussignsofbreakage.
21. DONOTLEAVETHISEQUIPMENTINANENVIRONMENTWHERETHE
STORAGETEMPERATUREMAYGOBELOW-30°C(-22°F)ORABOVE70°C
(158°F).THISCOULDDAMAGETHEEQUIPMENT.THEEQUIPMENT
SHOULDBEINACONTROLLEDENVIRONMENT.
Operatingtemperature:50°C
22. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT
TYPE RECOMMENDED BY THE MANUFACTURER, DISCARD USED
BATTERIES ACCORDING TO THE MANUFACTURER'S
INSTRUCTIONS.
23. The sound pressure level at the operator's position according to IEC
704-1:1982 is no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1.
Advantech disclaims all responsibility for the accuracy of any statements
contained herein.
Wichtige Sicherheishinweise
1. Bitte lesen sie Sich diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden
Sie Keine Flüssig-oder Aerosolreiniger. Am besten dient ein
angefeuchtetes Tuch zur Reinigung.
4. Die NetzanschluBsteckdose soll nahe dem Gerät angebracht und
leicht zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein
Kippen oder Fallen könnte Verletzungen hervorrufen.
7. Die Belüftungsöffnungen dienen zur Luftzirkulation die das Gerät vor
überhit- zung schützt. Sorgen Sie dafür, daB diese Ö ffnungen nicht
abgedeckt werden.
8. Beachten Sie beim. AnschluB an das Stromnetz die AnschluBwerte.
9. Verlegen Sie die NetzanschluBleitung so, daB niemand darüber fallen
kann. Es sollte auch nichts auf der Leitung abgestellt werden.
10. Alle Hinweise und Warnungen die sich am Geräten befinden sind zu
beachten.
11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten Sie es
vom Stromnetz trennen. Somit wird im Falle einer Ü berspannung eine
Beschädigung vermieden.
12. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder
Flüssigkeiten in das Gerät gelangen. Dies könnte einen Brand bzw.
elektrischen Schlag aus- lösen.
13. Ö ffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen
Sicherheit nur von authorisiertem Servicepersonal geöffnet werden.
14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu
trennen und von einer qualifizierten Servicestelle zu überprüfen:
15. Netzkabel oder Netzstecker sind beschädigt.
16. Flüssigkeit ist in das Gerät eingedrungen.

17. Das Gerät war Feuchtigkeit ausgesetzt.
18. Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert
oder
Sie mit Hilfe dieser Anleitung keine Verbesserung erzielen.
19. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
20. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
21. VOSICHT: Explisionsgefahr bei unsachgemaben Austausch der
Batterie.Ersatz nur durch densellben order einem vom Hersteller
empfohlene-mahnlichen Typ. Entsorgung gebrauchter Batterien navh
Angaben des Herstellers.
22. ACHTUNG: Es besteht die Explosionsgefahr, falls die Batterie auf nicht
fach- männische Weise gewechselt wird. Verfangen Sie die Batterie nur
gleicher oder entsprechender Type, wie vom Hersteller empfohlen.
Entsorgen Sie Batterien nach Anweisung des Herstellers.
23. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000
beträgt
70dB(A) oder weiger.
Haft ungsausschluss: Die Bedienungsanleitungen wurden entsprechend
der IEC-
704-1 erstellt. Advantech lehnt jegliche Verantwortung für die
Richtigkeit der in diesem Zusammenhang getätigten Aussagen ab.

Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products
from damage.
! To avoid electrical shock, always disconnect the power from your PC
chassis before you work on it. Don't touch any components on the CPU
card or other cards while the PC is on.
! Disconnect power before making any configuration changes. The sudden
rush of power as you connect a jumper or install a card may damage
sensitive electronic components.
Warning! 1. Input voltage rated: 9-32 Vdc.
2. Transport: carry the unit with both hands and handle with care.
3. Maintenance: to properly maintain and clean the surfaces, use
only approved products or clean with a dry applicator.
4. CompactFlash: Turn off the power before inserting or removing
CompactFlash storage cards.
European Contact information:
Advantech Europe GmbH
Kolberger Straße 7
D-40599 Düsseldorf, Germany
Tel: [phone]
Fax: [phone]

Chapter 1
General Information This
chapter gives background
information on the TREK-674
Computing Box.
Sections include:
! Introduction
! General Specifications
! Dimensions

1.1 Introduction
The TREK-674 is a dedicated box computer for industrial, transport trucks,
buses and taxis. TREK-674 combined with variety of I/O connectors can be
connected to devices like OBD-II (see Ch3.3) or TPMS (Tire Pressure
Monitoring System) external modules via COM port. Dual display/dual audio
interfaces supporting different resolutions can deliver different applications to
different displays; eg: one application to a driver and another to a digital
signage application.
Built-in wireless communications (WWAN, WLAN, BT) enable TREK-674 to
send important driver/ location/cargo information back to the control center.
TREK-674 can also operate in extreme environments with features like a
wide working temperature range (-30 to 70 degrees). TREK-674 also uses a
special design to handle the critical issue of in power. Special power
protection (ISO7637-2/SAE J1455 Class A/ SAE J1113) and power
management software (Ignition on/off, delay on/off, low battery monitor)
prevent electrical noise and surges from impacting the system, guarding
against damage from transient power.
Rear-Side Connectors
1.2 General Specifications
Key features
Supports WES8/WES7 and Linux
Automotive grade working temperature range (-30°C to 70°C)
Rich I/O including RS-232, WLAN1,WLAN2,WWAN1,WWAN2,GPS,Power in,
Smart Display, VGA, A/V in, Vehicle I/O, Generic I/O,USB*2, LAN1, LAN2
Built-in communication modules, including GSM/GPRS/HSDPA/CDMA,
WLAN & Bluetooth
GPS with AGPS and dead reckoning technology (speed line)
Certifications: CE/FCC/e-mark, MIL-SD810F, ISO 7637-2, SAE J1455, SAE
J1113 regulations
Ignition on/off delay; SW detectable/controllable for power management
1.2.1 General
! Dimensions : (W x H x D): 294X73X184mm.
! Weight : 3.5 KG
! Power supply :
– Input voltage : 9 ~ 32Vdc, support ignition cold crank
– Ignition on/off
Note! For more detail of function please refer to Chapter 4, Section
4.3.2 of this manual.
! Power consumption : The maximum current consumption is about 32.4
watts. The power consumption is 12 watts in normal mode (with only XPE
running; no I/O device and modules connected to the TREK-674).
! Front panel and back cover : IP65 Sealed; NEMA4 compliant
(Not including the I/O ports).
! Enclosure : Ruggedized aluminum without ventilation holes.

1.2.2 Standard PC Functions
CPU : intel Antom Baytrail-I, E3827 (Dual Core, 1.75GHz)
System memory : So-Dimm DDR3L-1066/1333 2G or 4G
Graphic: Integrated 2D/3D Graphic Engine
Storage: CFast 16GB (OS), SSD 64GBUMLC
Serial ports : RS-232, WLAN1,WLAN2,WWAN1,WWAN2,GPS,Power in,
Smart Display, VGA, A/V in, Vehicle I/O, Generic I/O,USB*2, LAN1, LAN2
Universal serial bus (USB) port : Supports up to three USB2.0*1 & USB3.0*1
Bluetooth: One Class2 Bluetooth V2.1 + EDR module/ BT 3.0
Watchdog timer : 63-level timer intervals automatically generate system reset
when the system stops due to a program error. Jumper selection
and software enabled/disabled.
RTC Battery : 3.0 V @ 200 mA lithium battery.
Power management : Supports power saving modes including Normal
Standby/Suspend modes.
CAN bus: CAN, J1939, OBDII/ISO-15765
Video/Audio input: 8-ch Video input
Optional modules : 12 channels GPS, quad-band GSM/GPRS, WLAN card
1.2.3 Touchscreen
Type : Analog Resistive
Light transmission : 80%
Controller : RS-232 interface
Power consumption : <5.5 V@ 20 mA
Durability : > 10 million depressions
Software driver : Supports Windows WES7/WES8, Linux
1.2.4 Environment
High/low temperature: -30 ~ 70°C
Relative humidity : 10 ~ 95% @ 40°C (non-condensing)
Shock : 30 G peak acceleration (11 msec duration)
Certifications : CE, FCC, CCC, Emark, CB.
Vibration : 5 ~ 500 Hz SAE J1455 4.9.4.2, MIL-STD-810F 514.5

1.4 Dimensions
igure 1.1 TREK-674 di

Chapter 2
System Setup
This chapter details system setup
on TREK-674
Sections include:
!AQuick Tour of the computer box
!Installation Procedures
!Running the BIOS Setup
Program

2.1 A Quick Tour of the TREK-674 Computingbox.
Before starting to set up the ComputingBox, take a moment to become familiar with the
locations and purposes of the controls, drives, connectors and ports, which are illustrated
in the figures below. When the Computer box is placed inside truck glove cabinet or under
the passenger’s seat next to the driver, its front appears as shown in Figure 2.1.
Figure 2.1. front view of TREK-674
Figure 2.2Rear view of
Figure 2.2. Rear view of TREK-674
2.3 Installing System Software
Recent releases of operating systems from major vendors include setup
programs which load automatically and guide users through the entire
process of operating system installation. The guidelines below help to

determine the steps necessary to install your operating system on the
computer hard drive.
Note! Some distributors and system integrators may have already
pre- installed system software prior to shipment of your
Mounted
Computer.
The BIOS of the computer supports system boots-up directly from the drive
whenever it is connected using a USB interface.
Power on the computer, or reset the system by pressing the “Ctrl” + “Alt” + “Del”
keys simultaneously. The computer will automatically load the operating
system from the diskette .
When presented with the opening screen of a setup / installation program,
simply fol- low the onscreen instructions. The setup program guides users
through preparations of the hard drive, and installation of the operating system.
When presented with an operating system command prompt, like, A:\>, then it
is nec- essary to partition and format the hard drive, and manually copy the
operating sys- tem files to it. Refer to the operating system user instructions
about partitioning and formatting the hard drive.
Note! The drivers and utilities used for the TREK-674 are subject to change without
notice. If in doubt, check Advantech's website or contact our
application engineers for the latest information regarding
drivers and utilities.
2.4 Programming Function Keys and GPIO/CAN BUS
The Mount Computer provides five function keys, GPIO and CAN bus as
shown in section 2.1. These functions must be activated with the correct
software, that’s why we provide an AP library for customers to design their own
software. Refer to Appendix C for more detail.

Chapter 3
Pin Assignments
This appendix explains pin
assignments on the TREK-674

3.1 Front Side Connectors
3.2 Rear Side Connectors
IO Ports
I/O
Vehicle I/O Port
Dual CANBus (Raw CAN, J1939,OBD-II/ ISO-15765)
J1587/J1708
Generic I/O Port
RS485 with auto flow control (x1)
4-wire RS-232 (x1)
Isolated DI(x4)/ DO(x2)
CVBS in (x0)
Line-Out x1
Mic-in x1
Standard I/O Port
USB 3.0 Type A x1; (Front side)
USB 2.0 Type A x2; (Rear side)
Full RS232C x1 (DB-9)
Giga LAN x2
VGA Port x1
A/V-IN
Video x8 / Audio x4
Smart Display Port
For TREK-303,306
Indicators
LEDx5 (PWR, Sotrage, WLAN,WWAN,GPS)
Sensors
G-Sensor

3.3 VIO
A(DSUB15)
Define
B(Housing)
1
CAN_L
1
2
CAN_H
2
3
GND
3
4
J1708_DN
4
5
J1708_DP
5
6
NC
6
7
DGND
7
8
ODB_CAN_L
8
9
ODB_CAN_H
9
10
DGND
10
11
DR_SPEED#_R
11
12
DR_SPEED_R
12
13
DR_DIRECTION#_R
13
14
DR_DIRECTION_R
14
15
NC
15
3.4 Smart Display Connector
SmartDisplayConnector
Pin
Signal
Pin
Signal
1
Backlight Enable output
2
Panel Power Enable output
3
LVDS Ground
4
Reset Button Input
5
LVDS Clock +
6
LVDS Clock -
7
LVDS Ground
8
LVDS Ground
9
LVDS Data2 +
10
LVDS Data2 -
11
RS232 TXD1
12
RS232 RXD1
13
LVDS Data1 +
14
LVDS Data1 -
15
LVDS Ground
16
LVDS Ground
17
LVDS Data0 +
18
LVDS Data0 -
19
USB D-
20
USB D+
21
USB Ground
22
USB Ground
23
+12VDC output
24
+12VDC output
25
+12VDC output
26
+12VDC output
27
Power Ground
28
Power Ground
29
Power Ground
30
Power Ground
31
RS232 TXD2
32
RS232 RXD2
33
RS232 RTS2
34
Power Button Input
35
Audio Ground
36
Mono. Line-out

3.5 RS-232 Connector
RS-232 Connector
Pin
Signal
Pin
Signal
1
RS-232 DCD
2
RS-232 RXD
3
RS-232 TXD
4
RS-232 DTR
5
RS-232 Ground
6
RS-232 DSR
7
RS-232 RTS
8
RS-232 CTS
9
RS-232 RI / +5V / +V12
