Advantech ITA-5231 Series User manual

User Manual
ITA-5231 Series
Fanless Embedded Industrial
Computer with 6th Gen Intel®
Core™ i Processor for Railway
Applications

ITA-5231 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2019
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. The information provided in this manual is intended to be accurate and reliable.
However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any
infringements of the rights of third parties that may result from its use.
Acknowledgements
The ITA-5231 is trademark of Advantech Co., Ltd.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants the original purchaser that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products that have been repaired or altered by
persons other than repair personnel authorized by Advantech, or products that have
been subject to misuse, abuse, accident, or improper installation. Advantech
assumes no liability under the terms of this warranty as a consequence of such
events.
Because of Advantech’s high quality-control standards and rigorous testing, most
customers never need to use our repair service. If an Advantech product is defective,
it will be repaired or replaced free of charge during the warranty period. For out-of-
warranty repairs, customers are billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you believe your product is defective, follow the steps outlined below.
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any messages displayed onscreen when the prob-
lem occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain a return merchandize authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a completed Repair and Replacement
Order Card, and a proof of purchase date (such as a photograph of your sales
receipt) into a shippable container. Products returned without a proof of pur-
chase date are not eligible for warranty service.
5. Write the RMA number clearly on the outside of the package and ship the pack-
age prepaid to your dealer.
Part No. 2001523131 Edition 2
Printed in Taiwan September 2019

iii ITA-5231 User Manual
Technical Support and Assistance
1. Visit the Advantech website at http://support.advantech.com to obtain the latest
product information.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before calling:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
A Message to the Customer
Advantech Customer Services
Each and every Advantech product is built to the most exacting specifications to
ensure reliable performance in the harsh and demanding conditions typical of indus-
trial environments. Whether your new Advantech equipment is destined for a labora-
tory or factory floor, you can be assured that your product will provide the reliability
and ease of operation for which the name Advantech has come to be known. Your
satisfaction is our primary concern. Below is a guide to Advantech's customer ser-
vices. To ensure you get the full benefit of our services, please follow the instructions
carefully.
Technical Support
We want you to get the best performance possible from your products. If you encoun-
ter technical difficulties, we are here to help. You can find answers to the most fre-
quently asked questions in your product documentation. These answers are typically
a lot more detailed than the ones provided over the phone.Therefore, please consult
this manual first. If you still cannot find the answer, gather all the information or ques-
tions that apply to your problem, and with the product close at hand, call your dealer.
Our dealers are well trained and ready to give you the support you need to get the
most from your Advantech products. In fact, most problems reported are minor and
can be easily solved over the phone.
In addition, free technical support is available from Advantech engineers every
business day. We are always ready to give advice about application requirements or
specific information regarding the installation and operation of any of our products.

ITA-5231 User Manual iv
Initial Inspection
Before setting up the system, check that the items listed below are included and in
good condition. If any item does not accord with the list, contact your dealer immedi-
ately.
1 x ITA-5231 series industrial computer
1 x ITA-5231 accessory box
1 x Warranty card
If any of these items are missing or damaged, contact your distributor or sales
representative immediately. We have carefully inspected the ITA-5231 mechanically
and electrically before shipment. It should be free of marks and scratches and in per-
fect working order upon receipt. As you unpack the ITA-5231, check it for signs of
shipping damage (for example, box damage, scratches, dents). If it is damaged or
fails to meet the specifications, notify our service department or your local sales rep-
resentative immediately. Also, please notify the carrier. Retain the shipping carton
and packing material for inspection by the carrier. After inspection, we will make
arrangements to repair or replace the unit.
Safety Instructions
1. Read these safety instructions carefully.
2. Retain this user manual for future reference.
3. Disconnect the equipment from any power outlet before cleaning. Use only a
damp cloth for cleaning. Do not use liquid or spray detergents.
4. For pluggable equipment, the power outlet socket must be located near the
equipment and easily accessible.
5. Protect the equipment from humidity.
6. Place the equipment on a reliable surface during installation. Dropping or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. Do not cover the openings.
8. Ensure that the voltage of the power source is correct before connecting the
equipment to a power outlet.
9. Position the power cord away from high-traffic areas. Do not place anything over
the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage from transient overvoltage.
12. Never pour liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following occurs, have the equipment checked by service person-
nel:
The power cord or plug is damaged.
Liquid has penetrated the equipment.
The equipment has been exposed to moisture.
The equipment is malfunctioning, or does not operate according to the user
manual.
The equipment has been dropped and damaged.
The equipment shows obvious signs of breakage.

v ITA-5231 User Manual
15. Do not leave the equipment in an environment with a storage temperature of
below -40 °C (-104 °F) or above 55 °C (131 °F) as this may cause damage. The
equipment should be kept in a controlled environment.
16. CAUTION: The battery is at risk of exploding if incorrectly installed. Do not
attempt to recharge, force open, or heat the battery. Replace only with the same
or equivalent type recommended by the manufacturer. Discard used batteries
according to the manufacturer’s instructions.
In accordance with IEC 704-1:1982 specifications, the sound pressure level at the
operator's position does not exceed 70 dB (A).
DISCLAIMER: These instructions are provided according to the IEC 704-1 specifica-
tions. Advantech disclaims all responsibility for the accuracy of any statements con-
tained herein.
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from the PC chassis
before manual handling. Do not touch any components on the CPU card or
other cards while the PC is powered on.
Disconnect the power before making any configuration changes. A sudden rush
of power after connecting a jumper or installing a card may damage sensitive
electronic components.
Battery Information
Batteries, battery packs, and accumulators must not be disposed of as unsorted
household waste. Please use the public collection system to return, recycle, or treat
such items in compliance with local regulations.

ITA-5231 User Manual vi
Warnings, Cautions, and Notes
Warning! Warnings indicate conditions that if not observed may cause personal
injury!
Caution! Cautions are included to help prevent hardware damage and data
losses.
For example,
“The battery is at risk of exploding if incorrectly installed. Do not attempt
to recharge, force open, or heat the battery. Replace the battery only
with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer's instructions.”
Note! Notes provide additional optional information.

vii ITA-5231 User Manual
Contents
Chapter 1 Overview...............................................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications ............................................................................................ 2
1.3 Power Information ..................................................................................... 3
Table 1.1: Power Input ................................................................ 3
1.4 Environmental Specifications .................................................................... 3
Table 1.2: Environmental Specifications ..................................... 3
1.5 Dimensions ............................................................................................... 4
Figure 1.1 ITA-5231 System Diagram ......................................... 4
Figure 1.2 ITA-5231 Exploded Diagram ...................................... 5
Table 1.3: Parts List..................................................................... 5
Chapter 2 H/W Installation....................................7
2.1 Introduction ............................................................................................... 8
2.2 Jumpers and Connectors .......................................................................... 8
2.2.1 Jumper Description ....................................................................... 8
2.2.2 Jumper and Connector Locations ................................................. 9
Figure 2.1 Jumper and Connector Locations on Main Board ...... 9
Table 2.1: Jumpers and Switches ............................................... 9
Table 2.2: BAT1 (RTC Battery Pin Header) .............................. 10
Table 2.3: JCMOS1 (Clear CMOS Settings) ............................. 10
Table 2.4: PMOD1 (AT, ATX Switch) ........................................ 10
2.3 I/O Connectors ........................................................................................ 11
Figure 2.2 ITA-5231 I/O View .................................................... 11
2.3.1 COM Connector .......................................................................... 11
Table 2.5: COM Connector Pin Definitions................................ 11
2.3.2 Audio Connector ......................................................................... 12
Table 2.6: Audio Connector Pin Definitions............................... 12
2.3.3 Digital I/O Connector................................................................... 12
Table 2.7: Digital I/O Connector Pin Definitions ........................ 12
2.3.4 USB Connector ........................................................................... 13
Table 2.8: USB 3.0 Connector Pin Definitions........................... 13
Table 2.9: USB 2.0 Connector Pin Definitions........................... 13
2.3.5 Ethernet ...................................................................................... 13
Table 2.10: Ethernet Connector Pin Definitions .......................... 13
2.3.6 Power Input................................................................................. 14
Table 2.11: Power Connector Pin Definitions.............................. 14
2.3.7 DVI-I............................................................................................ 14
Table 2.12:DVI-I ......................................................................... 14
2.3.8 LED Indicators ............................................................................ 15
Chapter 3 System Setup.....................................17
3.1 Introduction ............................................................................................. 18
3.2 mSATA Installation.................................................................................. 18
Figure 3.1 Mini-PCIe and mSATA Locations on Main Board..... 18
Figure 3.2 mSATA Installation ................................................... 18
Figure 3.3 Mini-PCIe Installation................................................ 19
3.3 SSD Installation....................................................................................... 19
Figure 3.4 SSD Bracket ............................................................. 19
Figure 3.5 SSD Module Installation ........................................... 20
3.4 ITA-EM Easy-Swap Module Installation.................................................. 20

ITA-5231 User Manual viii
Figure 3.6 ITA-5231 Front View ................................................ 20
Figure 3.7 Easy-Swap Module Installation ................................ 21
Figure 3.8 COM Module (ITA-EM-SR51-001AE) ...................... 21
Figure 3.9 PoE Module (ITA-EM-PE51-001AE) ........................ 22
Figure 3.10CAN Module (ITA-EM-CN51-001AE) ....................... 22
Figure 3.11Battery Module (ITA-EM-BA51-00A1E).................... 23
3.5 RTC Battery Installation .......................................................................... 23
Figure 3.12RTC Battery Installation ........................................... 23
3.6 Antenna Installation ................................................................................ 24
Figure 3.13Antenna Installation.................................................. 24
Chapter 4 BIOS Settings .................................... 25
4.1 Introduction ............................................................................................. 26
4.2 Entering BIOS Setup............................................................................... 26
4.3 Main Setup.............................................................................................. 27
4.3.1 Advanced BIOS Setup................................................................ 28
4.3.2 Chipset Configuration ................................................................. 41
4.3.3 Security Configuration ................................................................ 48
4.3.4 Boot Configuration ...................................................................... 49
4.3.5 Save & Exit ................................................................................. 50
Chapter 5 Driver Installation.............................. 53
5.1 Introduction ............................................................................................. 54
5.2 Driver Installation .................................................................................... 54
5.2.1 Chipset Windows Driver Setup ................................................... 55
5.2.2 VGA Windows Driver Setup........................................................ 58
5.2.3 ME Windows Driver Setup.......................................................... 58
5.2.4 LAN Windows Driver Setup ........................................................ 59
5.2.5 USB 3.0 Windows Driver Setup.................................................. 59
5.2.6 Audio Windows Driver Setup ...................................................... 59
Chapter 6 GPIO Programming Guide ............... 63
6.1 Digital DI/O Definition.............................................................................. 64
6.2 Configuration Sequence ......................................................................... 64
Table 6.1: ICH SMBUS I/O Space ............................................ 64
Table 6.2: Pin Definitions .......................................................... 64
6.2.1 Command Byte ........................................................................... 65
Table 6.3: Command Byte......................................................... 65
6.2.2 PCA9554 Register 0 ................................................................... 65
Table 6.4: Register 0 – Input Port Register Bit Description....... 65
6.2.3 PCA9554 Register 1 – Output Port Register .............................. 65
Table 6.5: Register 1 – Output Port Register Bit Description .... 65
6.2.4 PCA9554 Register 2 – Polarity Inversion Register ..................... 66
Table 6.6: Register 2 – Polarity Inversion Register Bit Description
..................................................................................66
6.2.5 PCA9554 Register 3 – Configuration Register ........................... 66
Table 6.7: Register 2 – Polarity Inversion Register Bit Description
..................................................................................66
6.3 Example .................................................................................................. 66
Appendix A Programming the Watchdog Timer .73
A.1 Introduction ............................................................................................. 74
A.1.1 Watchdog Timer Overview ......................................................... 74

ix ITA-5231 User Manual
A.1.2 Programming the Watchdog Timer ............................................. 74
Appendix B Declaration of the Presence Condition
of the Restricted Substances Marking
.............................................................79
Appendix C Chinese Language Safety Instructions
and Battery Information....................81
C.1 安全指示.......................................................82
C.2 電池信息.......................................................82

ITA-5231 User Manual x

Chapter 1
1Overview
Introduction
Specifications
Power Information
Environment Specifications
Dimension Diagram

ITA-5231 User Manual 2
1.1 Introduction
ITA-5231 is a compact and fanless embedded industrial computer equipped with a
6th generation Intel® CoreTM i processor and wide voltage input range. Specifically
designed for intelligent transportation and road surveillance applications, this power-
ful computing platform can withstand 24/7 operation.
1.2 Specifications
Processer and Chipset: Intel® CoreTM i7/i5/Celeron® processor + Intel®
QM170 chipset
BIOS: AMI SPI 128 MB Flash
Memory: On-board 8 GB DDR4 2133 MHz
Display: Intel® HD Graphics 530 (Core i)
–VGA: 1920x1200 @ 60 Hz
–DVI: 1920x1200 @ 60 Hz
DP Extension:
–HDMI: 4096x2160 @ 24 Hz, 24 bpp
–DVI: 1920x1200 @ 60 Hz
–VGA: 1920x1200 @ 60 Hz
EDP Extension: LVDS
Storage: Supports 2 x 2.5" SSD (default 1 x ITA-EM-ST51-00A1E)
–Up to 4 x 2.5" SSD
–1 x Full-size mSATA (on main board)
Expansion: 3 x Full-size mini PCIe socket (2 with SIM slot)
Ethernet: 3 x 10/100/1000Mbps with M12 X-coded (female) controller: Intel®
I210-IT
USB: 2 x USB 3.0 (Type A), 1 x USB 2.0 with M12, A-coded (F) 4-pin
DVI: 1 x DVI-I
Series I/O: 2 x RS-232/422/485 with 2 KV isolation; supports auto-flow control,
DB9 type
Digital I/O: 1 x DI/DO (4 bit) with 2KV isolation, DB9 type
Audio: 1 x Speaker-Out with 2 x 4W 4Ωspeakers, 1 x Mic-In
Optional I/O Modules:
–1 x ITA-EM-SR51: 4 x RS232/422/484 with 2KV isolation
–1 x ITA-EM-CN51: 2 x CAN ports
–1 x ITA-EM-NC51: 2 x M12 copper LAN ports
–1 x ITA-EM-PE51: 2 x M12 PoE ports
–1 x ITA-EM-BA51: Battery module
Dimensions (W x H x D):
427 x 88 x 195.8 mm (16.8 x 3.46 x 7.7 in)
482.6 x 88 x 221.3 mm (19 x 3.46 x 8.71 in) with mounting kit
Net Weight: 7.5 kg (16.53 lb)

3 ITA-5231 User Manual
Chapter 1 Overview
1.3 Power Information
The ITA-5231’s power design is compliant with the EN 50155 S2/C1 standard.
1.4 Environmental Specifications
The shock and vibration test were conducted according to the EN 61373, Category 1
- Body mounted, Class B specifications with acceptable results..
Table 1.1: Power Input
DC-In Voltage 24V 48V 72V 110V
Voltage Range (0.7~1.25) 16.8 ~ 30V 33.6 ~ 60V 50.4 ~ 90V 77 ~ 137.5V
Transient (0.6~1.4/0.1s) 14.4 ~ 33.6V 28.8 ~ 67.2V 43.2 ~ 100.8V 66 ~ 154V
Power Connector 1 x M12 S-coded (M) 4-pin
Table 1.2: Environmental Specifications
Operating Temperature EN50155 Tx level: -40 ~ 70 °C (-40 ~ 158 °F) with industrial
storage
Safety Certificate
Temperature Range -10 ~ 50 °C (14 ~ 122 °F) with industry level accessory
Storage Temperature -40 ~ 85 °C (-40 ~ 185 °F)
Humidity 95% @ 40 ºC, non-condensing
Vibration 2 Grms @ 5 ~ 500 Hz, random, 1 hr/axis (SSD/mSATA)
Shock 10G, IEC-68-2-27, half-sine wave, 11 ms duration
Bump 10G, IEC60068-2-27:1987, half-sine wave, 16 ms duration
Safety UL, CCC, BSMI, CE, FCC

ITA-5231 User Manual 4
1.5 Dimensions
Figure 1.1 ITA-5231 System Diagram

5 ITA-5231 User Manual
Chapter 1 Overview
Figure 1.2 ITA-5231 Exploded Diagram
Table 1.3: Parts List
1 Top cover 10 Rear board
2 Carrier board 11 Rail bracket
3 LAN extension board 12 Front panel
4 Carrier board bracket 13 Right panel
5 Main board 14 Empty bracket with screws
6 Bottom heatsink 15 Ear bracket
7 Side heatsink 16 Handle
8 Chassis 17 Power module
9 Rear panel

ITA-5231 User Manual 6

Chapter 2
2H/W Installation
Introduction
Jumpers and Connectors
I/O Connectors

ITA-5231 User Manual 8
2.1 Introduction
The following sections show the internal jumper settings and external connector pin
assignments for system configuration according to applications.
2.2 Jumpers and Connectors
2.2.1 Jumper Description
ITA-5231 can be configured for specific applications by setting jumpers. A jumper is a
metal bridge used to close an electric circuit. It consists of two metal pins and a small
metal clip (often protected by a plastic cover) that slides over the pins to connect
them. To close a jumper, remove the clip. Some jumpers may have three pins,
labelled 1, 2, and 3. For these jumpers, connect either Pins 1 and 2, or Pins 2 and 3.
Open Closed 2-3 Closed
The jumper settings are schematically depicted in this manual as shown below.
Open Closed 2-3 Closed
A pair of needle-nose pliers may be helpful when working with jumpers. If you have
concerns about the best hardware configuration for your application, contact your
local distributor or sales representative before making any changes. For most con-
nection, only a standard cable is required.
12
12
123

9 ITA-5231 User Manual
Chapter 2 H/W Installation
2.2.2 Jumper and Connector Locations
The main board features a number of connectors and jumpers for system configura-
tion. The location of each jumper and connector on the main board is shown in Figure
2.1. The function of each of the connectors and jumpers is listed in Table 2.1 below.
Figure 2.1 Jumper and Connector Locations on Main Board
Table 2.1: Jumpers and Switches
Name Function
PSIN1 Power button pin header
BAT1 RTC battery pin header
JCOMS1 Clear CMOS settings
PMOD1 ATX, AT mode switch

ITA-5231 User Manual 10
Table 2.2: BAT1 (RTC Battery Pin Header)
Pin Setting
1 Power (3.3V)
2 GND
Table 2.3: JCMOS1 (Clear CMOS Settings)
Pin Setting
1-2 Default*
2-3 Clear CMOS
*Default
Table 2.4: PMOD1 (AT, ATX Switch)
Pin Setting
On AT
Off ATX*
*Default
